[DC SF 2022] Hitchhiking through Jetpack Compose

Transcript

1. Hitchhiking through
   Jetpack Compose
   Amanda Hinchman-Dominguez
   Kotlin GDE, Android Engineer @ Groupon
   Jossi Wolf
   Software Engineer @ Google
   #hg2compose


   View Slide

2. @mvndy_hd @jossiwolf #hg2compose


   View Slide

3. Why Compose?
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

4. @Composable
   fun MyApp() {
   var counter by remember { mutableStateOf(0) }
   HelloWorld(“Clicked $counter times”)
   Button(onClick = { counter.+ }) { … }
   }
   @Composable
   fun HelloWorld(greeting: String) {
   Text(“Hello World, $greeting”)
   }
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

5. "A Snapshot is a lot like a save point in a video
   game: it represents the state of your entire
   program at a single point in history."
   - "Introduction to the Compose Snapshot System" by Zach Klippenstein
   Snapshots 📸
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

6. 1
   Snapshots 📸
   data class Dog(
   val name: MutableState
   )
   Dog(name = "Spot")
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

7. Snapshot.takeMutableSnapshot()
   1
   2
   Snapshots 📸
   Snapshot.takeSnapshot()
   📸
   Dog(name = "Spot")
   “Spot”
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

8. 1
   2
   Snapshots 📸
   📸
   Dog(name = "Spot")
   “Spot”
   dog.name.value = "Fido"
   Dog(name = "Fido")
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

9. 1
   2
   Snapshots 📸
   📸
   Dog(name = "Spot")
   “Spot”
   dog.name.value = "Fido"
   Dog(name = "Fido")
   snapshot.enter {
   dog.name.value = "Taco"
   }
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

10. 1
    2
    Snapshots 📸
    📸
    Dog(name = "Spot")
    “Spot”
    dog.name.value = "Fido"
    Dog(name = "Fido")
    snapshot.enter {
    dog.name.value = "Taco"
    }
    Dog(name = "Taco")
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

11. 1
    2
    Snapshots 📸
    📸
    Dog(name = "Spot")
    “Spot”
    dog.name.value = "Fido"
    Dog(name = "Fido")
    snapshot.enter {
    dog.name.value = "Taco"
    }
    Dog(name = "Taco")
    snapshot.apply()
    “Taco”
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

12. - State changes cause recomposition
    - Compose has a Snapshot system
    Recap!
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

13. @mvndy_hd @jossiwolf #hg2compose


    View Slide

14. https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn
    fun main() {
    val dog = Dog()
    dog.name.value = "Spot"
    val snapshot = Snapshot.takeSnapshot(
    readObserver = { readObject .>
    }
    )
    snapshot.enter {
    println(dog.name.value)
    }
    }
    Snapshots 📸
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

15. #hg2compose
    fun main() {
    val dog = Dog()
    dog.name.value = "Spot"
    val snapshot = Snapshot.takeSnapshot(
    readObserver = { readObject .>
    ./ MutableState(value = "Spot")
    }
    )
    snapshot.enter {
    println(dog.name.value)
    }
    }
    Snapshots 📸
    @mvndy_hd @jossiwolf https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn


    View Slide

16. Managing state in
    Compose
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

17. @Composable
    fun HelloWorld(greeting: String) {
    Text("Hello, $greeting!")
    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

18. @Composable
    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {
    %composer = %composer.startRestartGroup(.>)
    val %dirty = %changed
    if (%changed and 0b1110 ..= 0) {
    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100
    else 0b0010
    }
    if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) {
    Text("Hello, $greeting!")
    } else {
    %composer.skipToGroupEnd()
    }
    %composer.endRestartGroup()
    ..updateScope { %composer: Composer?, %force: Int .>
    HelloWorld(greeting, %composer, %changed or 0b0001)
    }
    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

19. @Composable
    fun HelloWorld(greeting: String) {
    Text("Hello, $greeting!")
    }
    @mvndy_hd @jossiwolf
    Restartable Groups
    #hg2compose


    View Slide

20. @Composable
    fun HelloWorld(names: List) {
    names.forEach { name .>
    key(name) {
    Text(name)
    }
    }
    }
    Moveable Groups
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

21. @Composable
    fun HelloWorld(name: String) {
    if (name .= "Amanda") {
    Text("Hello!")
    else if (name .= "Jossi") {
    Text("Hallo!")
    } else {
    Text("Uhm.. hi?")
    }
    }
    Replaceable Groups
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

22. Groups are generated by
    the Compose compiler
    plugin
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

23. #hg2compose
    @mvndy_hd @jossiwolf
    The Kotlin Compiler


    View Slide

24. #hg2compose
    @mvndy_hd @jossiwolf
    Compiler plugins can
    intercept compiler
    behavior at any phase


    View Slide

25. .kt
    Lexer Analysis
    Syntax Analysis
    Parsing Phase
    Generates tokens
    Kotlin Compiler
    Frontend
    Build PSI tree
    Add info to nodes
    Analysis Resolution Phase
    Generate descriptors for
    PSI + Symbol Tables
    +
    +
    Enhance PSI Elements w/
    Descriptors
    +
    Symbol table maps
    PSI to descriptor +
    IR calls
    Run static analysis,
    type verification,
    diagnostics
    Resolve
    +
    +
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

26. @mvndy_hd @jossiwolf #hg2compose


    View Slide

27. #hg2compose
    - Performs optimisations on IR
    - Removes dead code
    - Refactors the code
    - Improves performance
    - Analyzes IR for data needed to
    create
    - Call graph
    - Control-flow graph
    CPU-related IR
    Transformations
    IR Transform
    Compiler Analysis
    Middle End “Lower”
    Backend
    - Takes optimized IR and performs more analysis,
    transformations + optimisations specific to target
    CPU architecture
    - Multithreading
    < >
    Bytecode
    Target Program
    - Performs optimisations on IR
    - Removes dead code
    - Refactors the code
    - Improves performance
    - Analyzes IR for data needed to
    create
    - Call graph
    - Control-flow graph
    CPU-related IR
    Transformations
    FUNC
    VAL_PARAM
    VAL_PARAM
    VA:_PARAM
    Unoptimized IR
    @mvndy_hd @jossiwolf


    View Slide

28. @Composable
    fun HelloWorld(greeting: String) {
    Text("Hello, $greeting!")
    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

29. @Composable
    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {
    %composer = %composer.startRestartGroup(.>)
    val %dirty = %changed
    if (%changed and 0b1110 ..= 0) {
    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100
    else 0b0010
    }
    if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) {
    Text("Hello, $greeting!")
    } else {
    %composer.skipToGroupEnd()
    }
    %composer.endRestartGroup()
    ..updateScope { %composer: Composer?, %force: Int .>
    HelloWorld(greeting, %composer, %changed or 0b0001)
    }
    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

30. View Slide

31. var name by remember { mutableStateOf("Bob") }
    @Composable
    fun Greeting(greeting: String) {
    Text("Hello, $greeting!")
    }
    Greeting(name)
    name = "Jossi"
    ./ Hello, Bob!
    ./ Hello, Jossi!
    @mvndy_hd @jossiwolf
    Slot Table by Example
    #hg2compose


    View Slide

32. EMPTY
    EMPTY
    Group(4)
    State(“Bob”)
    var name by remember { mutableStateOf("Bob") }
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    @mvndy_hd @jossiwolf
    Slot Table by Example
    #hg2compose


    View Slide

33. Group(4)
    State(“Bob”)
    Group(5)
    var name by remember { mutableStateOf("Bob") }
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    @Composable
    fun Greeting(greeting: String) {
    }
    Greeting(name)
    @mvndy_hd @jossiwolf
    Slot Table by Example
    #hg2compose


    View Slide

34. EMPTY
    EMPTY
    Group(4)
    State(“Bob”)
    Group(5)
    Group(6)
    Group(7)
    Group(8)
    “Hello, Bob!”
    var name by remember { mutableStateOf("Bob") }
    @Composable
    fun Greeting(greeting: String) {
    Text("Hello, $greeting!”)
    }
    Greeting(name)
    @mvndy_hd @jossiwolf
    Slot Table by Example
    #hg2compose


    View Slide

35. EMPTY
    EMPTY
    Group(4)
    State(“Bob”)
    Group(5)
    Group(6)
    Group(7)
    Group(8)
    “Hello, Jossi!”
    var name by remember { mutableStateOf("Bob") }
    @Composable
    fun Greeting(greeting: String) {
    Text("Hello, $greeting!”)
    }
    Greeting(name)
    name = "Jossi"
    @mvndy_hd @jossiwolf
    Slot Table by Example
    #hg2compose


    View Slide

36. interface Applier {
    val current: N
    fun onBeginChanges() {}
    fun onEndChanges() {}
    fun down(node: N)
    fun up()
    fun insertTopDown(index: Int, instance: N)
    fun insertBottomUp(index: Int, instance: N)
    fun remove(index: Int, count: Int)
    fun move(from: Int, to: Int, count: Int)
    fun clear()
    }
    The Applier
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

37. interface Applier {
    val current: N
    fun onBeginChanges() {}
    fun onEndChanges() {}
    fun down(node: N)
    fun up()
    fun insertTopDown(index: Int, instance: N)
    fun insertBottomUp(index: Int, instance: N)
    fun remove(index: Int, count: Int)
    fun move(from: Int, to: Int, count: Int)
    fun clear()
    }
    The Applier
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

38. LayoutNode! ..and then what?
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

39. LayoutNode! ..and then what?
    D
    @mvndy_hd @jossiwolf #hg2compose


    View Slide

40. LayoutNode! ..and then what?
    @mvndy_hd @jossiwolf #hg2compose
    class AndroidComposeView(context: Context) :
    ViewGroup(context), ... {
    override fun dispatchDraw(canvas: Canvas) {
    ...
    measureAndLayout()
    ...
    }
    }


    View Slide

41. • Jorge Castillo, author of "Compose Internals"
    • Leland Richardson for his work and sitting down with us to
    interview him
    • Zach Klippenstein's 5-part series on Compose state explained
    • George Mount for his explanation of Compose UI fundamentals
    • Matvei Malkov, Simona Stojanovic for reviews!
    #hg2compose
    @mvndy_hd @jossiwolf
    Thank you!!


    View Slide
