1. Hitchhiker’s Guide to Compose
   Snapshots, Compiler Plugins and Appliers
   @mvndy_hd @jossiwolf #hg2compose


   View Slide

2. #hg2compose
   TextView(text = "")
   FrameLayout
   FrameLayout
   @mvndy_hd @jossiwolf


   View Slide

3. #hg2compose
   setText("Bob")
   TextView(text = "")
   FrameLayout
   FrameLayout
   @mvndy_hd @jossiwolf


   View Slide

4. #hg2compose
   FrameLayout
   setText("Bob")
   FrameLayout
   TextView(text = "Bob")
   @mvndy_hd @jossiwolf


   View Slide

5. #hg2compose
   FrameLayout
   FrameLayout
   TextView(text = "Bob") getDisplayList()
   draw()
   @mvndy_hd @jossiwolf


   View Slide

6. #hg2compose
   FrameLayout
   FrameLayout
   TextView(text = "Bob")
   getDisplayList()
   getDisplayList()
   @mvndy_hd @jossiwolf


   View Slide

7. #hg2compose
   FrameLayout
   FrameLayout
   TextView(text = "Bob")
   getDisplayList()
   getDisplayList()
   getDisplayList()
   @mvndy_hd @jossiwolf


   View Slide

8. #hg2compose
   FrameLayout
   FrameLayout
   TextView(text = "Bob")
   draw()
   Bob
   @mvndy_hd @jossiwolf


   View Slide

9. #hg2compose
   Text(text = name)
   Layout
   Layout
   name by remember
   { mutableStateOf("") }
   @mvndy_hd @jossiwolf


   View Slide

10. #hg2compose
    Text(text = name)
    Layout
    Layout
    name by remember
    { mutableStateOf("Bob") }
    @mvndy_hd @jossiwolf


    View Slide

11. #hg2compose
    Text(text = name)
    Layout
    Layout
    name by remember
    { mutableStateOf("Bob") }
    @mvndy_hd @jossiwolf


    View Slide

12. #hg2compose
    Text(text = name)
    Layout
    Layout
    name by remember
    { mutableStateOf("Bob") }
    Bob
    @mvndy_hd @jossiwolf


    View Slide

13. "Jetpack Compose is Android's modern toolkit
    for building native UI."
    #hg2compose
    - developer.android.com
    @mvndy_hd @jossiwolf


    View Slide

14. Compiler Runtime UI
    #hg2compose
    !=
    @mvndy_hd @jossiwolf


    View Slide

15. A Composable is a restartable function that emits
    nodes into a tree.
    #hg2compose
    Glossary
    @mvndy_hd @jossiwolf


    View Slide

16. Recomposition is the process of re-executing a
    Composable function to produce an updated slot
    table
    #hg2compose
    Glossary
    @mvndy_hd @jossiwolf


    View Slide

17. The Composition holds the Slot Table,
    invalidations and a Composer.
    #hg2compose
    Glossary
    @mvndy_hd @jossiwolf


    View Slide

18. The Slot Table is used to store the current state of
    the Composition.
    #hg2compose
    Glossary
    @mvndy_hd @jossiwolf


    View Slide

19. A Composer connects Composables to Runtime,
    keeps track of groups that are used to build the
    Slot Table and positions it.
    #hg2compose
    Glossary
    @mvndy_hd @jossiwolf


    View Slide

20. Recomposers manage the Snapshot and
    Compositions
    #hg2compose
    Glossary
    @mvndy_hd @jossiwolf


    View Slide

21. @Composable

    fun HitchhikerApp() {

    var name by remember { mutableStateOf("Bob") }

    HelloWorld(greeting = name)

    name = "Chet"

    }

    @Composable

    fun HelloWorld(greeting: String) {

    Text("Hello, $greeting!")

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

22. Snapshots 📸
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

23. "A Snapshot is a lot like a save point in a video
    game: it represents the state of your entire
    program at a single point in history."
    #hg2compose
    https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn
    - "Introduction to the Compose Snapshot System" by Zach Klippenstein
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

24. #hg2compose
    https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn
    class Dog {

    var name: MutableState = mutableStateOf(“”)

    }

    fun main() {

    val dog = Dog()

    dog.name.value = "Spot"

    val snapshot = Snapshot.takeSnapshot()

    dog.name.value = "Fido"

    println(dog.name.value)

    }
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

25. #hg2compose
    https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn
    fun main() {

    val dog = Dog()

    dog.name.value = "Spot"

    val snapshot = Snapshot.takeSnapshot()

    dog.name.value = "Fido"

    println(dog.name.value)
    //
    Fido

    snapshot.enter {

    println(dog.name.value)
    / /
    Spot

    }

    println(dog.name.value)
    //
    Fido

    }
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

26. #hg2compose
    Snapshot.takeSnapshot()
    Dog(name = "Spot")
    📸
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

27. #hg2compose
    Snapshot.takeSnapshot()
    📸
    Dog(name = "Spot")
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

28. #hg2compose
    Snapshot.takeSnapshot()
    1
    2
    📸
    Dog(name = "Spot")
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

29. #hg2compose
    Snapshot.takeSnapshot()
    dog.name.value = "Fido"
    📸
    1
    2 Dog(name = "Spot")
    Dog(name = "Fido")
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

30. #hg2compose
    Snapshot.takeSnapshot()
    dog.name.value = "Fido"
    📸
    1
    2 Dog(name = "Spot")
    Dog(name = "Fido")
    snapshot.enter {

    .
    .
    .


    }

    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

31. #hg2compose
    Snapshot.takeSnapshot()
    dog.name.value = "Fido"
    📸
    1
    2 Dog(name = "Spot")
    Dog(name = "Fido")
    snapshot.enter {

    dog.name.value = "Taco"

    }

    ❌
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

32. #hg2compose
    Snapshot.takeSnapshot()
    dog.name.value = "Fido"
    📸
    1
    2 Dog(name = "Spot")
    Dog(name = "Fido")
    snapshot.enter {

    dog.name.value = "Taco"

    }

    ❌
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

33. #hg2compose
    Snapshot.takeMutableSnapshot()
    dog.name.value = "Fido"
    📸
    1
    2 Dog(name = "Spot")
    Dog(name = "Fido")
    snapshot.enter {

    dog.name.value = "Taco"

    }

    ❌
    Snapshots 📸
    (and dogs🐕)
    @mvndy_hd @jossiwolf


    View Slide

34. #hg2compose
    @mvndy @jossiwolf
    Snapshots 📸
    (and dogs🐕)
    Snapshot.takeMutableSnapshot()
    📸
    1
    2
    dog.name.value = "Fido"
    Dog(name = "Fido")
    snapshot.enter {

    dog.name.value = "Taco"

    }

    Dog(name = "Spot")


    View Slide

35. #hg2compose
    @mvndy @jossiwolf
    Snapshots 📸
    (and dogs🐕)
    Snapshot.takeMutableSnapshot()
    📸
    1
    2
    dog.name.value = "Fido"
    Dog(name = "Fido")
    snapshot.enter {

    dog.name.value = "Taco"

    }

    Dog(name = "Spot")


    View Slide

36. #hg2compose
    @mvndy @jossiwolf
    Snapshots 📸
    (and dogs🐕)
    Snapshot.takeMutableSnapshot()
    📸
    1
    2
    dog.name.value = "Fido"
    Dog(name = "Fido")
    snapshot.enter {

    dog.name.value = "Taco"

    }

    Dog(name = "Spot") Dog(name = "Taco")
    ✔


    View Slide

37. #hg2compose
    @mvndy @jossiwolf
    Snapshots 📸
    (and dogs🐕)
    snapshot.apply()
    Snapshot.takeMutableSnapshot()
    dog.name.value = "Fido"
    📸
    1
    2
    snapshot.enter {

    dog.name.value = "Taco"

    }

    Dog(name = "Spot") Dog(name = "Taco")
    Dog(name = "Fido") Dog(name = "Taco")


    View Slide

38. #hg2compose
    @mvndy @jossiwolf
    Snapshots 📸
    (and dogs🐕)
    snapshot.apply()
    Snapshot.takeMutableSnapshot()
    dog.name.value = "Fido"
    📸
    1
    2
    snapshot.enter {

    dog.name.value = "Taco"

    }

    Dog(name = "Spot") Dog(name = "Taco")
    Dog(name = "Fido") Dog(name = "Taco")


    View Slide

39. #hg2compose
    @mvndy @jossiwolf https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn
    fun main() {

    val dog = Dog()

    dog.name.value = "Spot"

    val snapshot = Snapshot.takeSnapshot(

    readObserver = { value
    ->


    ...


    }

    )

    dog.name.value = "Fido"

    println(dog.name.value)
    //
    Fido

    snapshot.enter {

    println(dog.name.value)
    //
    Spot

    }

    }
    Snapshots 📸
    (and dogs🐕)


    View Slide

40. #hg2compose
    @mvndy @jossiwolf
    fun main() {

    val dog = Dog()

    dog.name.value = "Spot"

    val snapshot = Snapshot.takeSnapshot(

    readObserver = { value
    ->


    println(value)
    //
    MutableState(value=Spot)@
    ...


    }

    )

    dog.name.value = "Fido"

    println(dog.name.value)
    //
    Fido

    snapshot.enter {

    println(dog.name.value)
    //
    Spot

    }

    }
    Snapshots 📸
    (and dogs🐕)


    View Slide

41. #hg2compose
    @mvndy @jossiwolf
    fun main() {

    val dog = Dog()

    dog.name.value = "Spot"

    val snapshot = Snapshot.takeSnapshot(

    readObserver = { value
    ->


    println(value)
    //
    MutableState(value=Spot)@
    ...


    }

    )

    dog.name.value = "Fido"

    println(dog.name.value)
    //
    Fido

    snapshot.enter {

    println(dog.name.value)
    //
    Spot

    }

    }
    Snapshots 📸
    (and dogs🐕)


    View Slide

42. #hg2compose
    @mvndy @jossiwolf
    fun main() {

    val dog = Dog()

    dog.name.value = "Spot"

    val snapshot = Snapshot.takeMutableSnapshot(

    readObserver = { value
    ->


    println(value)
    //
    MutableState(value=Spot)@
    ...


    },

    writeObserver = { value
    -> ...
    }

    )

    dog.name.value = "Fido"

    snapshot.enter {

    dog.name.value = "Taco"

    }

    }
    Snapshots 📸
    (and dogs🐕)


    View Slide

43. (Snapshot) State
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

44. #hg2compose
    interface State {

    val value: T

    }
    package androidx.compose.runtime
    @mvndy_hd @jossiwolf


    View Slide

45. #hg2compose
    interface State {

    val value: T

    }

    interface MutableState : State {

    override var value: T

    operator fun component1(): T

    operator fun component2(): (T)
    ->
    Unit

    }
    package androidx.compose.runtime
    @mvndy_hd @jossiwolf


    View Slide

46. #hg2compose
    /**

    * Return the current readable state record for the [snapshot].

    * It is assumed that [this] is the first record of [state]

    */


    fun T.readable(state: StateObject, snapshot: Snapshot): T {

    //
    invoke the observer associated with the current snapshot.

    snapshot.readObserver
    ?.
    invoke(state)

    return readable(this, snapshot.id, snapshot.invalid)
    ?:
    readError()

    }
    package androidx.compose.runtime
    @mvndy_hd @jossiwolf


    View Slide

47. #hg2compose
    /**

    * Return the current readable state record for the [snapshot].

    * It is assumed that [this] is the first record of [state]

    */


    fun T.readable(state: StateObject, snapshot: Snapshot): T {

    //
    invoke the observer associated with the current snapshot.

    snapshot.readObserver
    ?.
    invoke(state)

    return readable(this, snapshot.id, snapshot.invalid)
    ?:
    readError()

    }
    package androidx.compose.runtime
    @mvndy_hd @jossiwolf


    View Slide

48. @Composable

    fun HitchhikerApp() {

    var name = remember { mutableStateOf("Bob") }

    HelloWorld(greeting = name.value)

    }

    @Composable

    fun HelloWorld(greeting: String) {

    println("Hello, $greeting!")

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

49. #hg2compose
    suspend fun runApp() {

    val composer = Recomposer()

    GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) {

    composer.runRecomposeAndApplyChanges()

    }

    Composition(NodeApplier(RootNode()), composer).apply {

    setContent {

    Content()

    }

    }

    }
    @mvndy_hd @jossiwolf


    View Slide

50. #hg2compose
    suspend fun runApp() {

    val composer = Recomposer()

    GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) {

    composer.runRecomposeAndApplyChanges()

    }

    Composition(NodeApplier(RootNode()), composer).apply {

    setContent {

    Content()

    }

    }

    }
    medium.com/@takahirom/inside-jetpack-compose-2e971675e55e
    @mvndy_hd @jossiwolf


    View Slide

51. Recomposers manage the Snapshot and
    Compositions, i.e. composing initially and
    recomposing.
    #hg2compose
    Glossary
    @mvndy_hd @jossiwolf


    View Slide

52. #hg2compose
    suspend fun runApp() {

    val composer = Recomposer()

    GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) {

    composer.runRecomposeAndApplyChanges()

    }

    Composition(NodeApplier(RootNode()), composer).apply {

    setContent {

    Content()

    }

    }

    }
    medium.com/@takahirom/inside-jetpack-compose-2e971675e55e
    @mvndy_hd @jossiwolf


    View Slide

53. #hg2compose
    suspend fun runApp() {

    val composer = Recomposer()

    GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) {

    composer.runRecomposeAndApplyChanges()

    }

    Composition(NodeApplier(RootNode()), composer).apply {

    setContent {

    Content()

    }

    }

    }
    medium.com/@takahirom/inside-jetpack-compose-2e971675e55e
    @mvndy_hd @jossiwolf


    View Slide

54. #hg2compose
    suspend fun runApp() {

    val composer = Recomposer()

    GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) {

    composer.runRecomposeAndApplyChanges()

    }

    Composition(NodeApplier(RootNode()), composer).apply {

    setContent {

    Content()

    }

    }

    }
    medium.com/@takahirom/inside-jetpack-compose-2e971675e55e
    @mvndy_hd @jossiwolf


    View Slide

55. #hg2compose
    suspend fun runApp() {

    val composer = Recomposer()

    GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) {

    composer.runRecomposeAndApplyChanges()

    }

    Composition(NodeApplier(RootNode()), composer).apply {

    setContent {

    Content()

    }

    }

    }
    medium.com/@takahirom/inside-jetpack-compose-2e971675e55e
    @mvndy_hd @jossiwolf


    View Slide

56. #hg2compose
    private inline fun composing(

    composition: ControlledComposition,

    modifiedValues: IdentityArraySet?,

    block: ()
    ->
    T

    ): T {

    val snapshot = Snapshot.takeMutableSnapshot(

    readObserverOf(composition),

    writeObserverOf(composition, modifiedValues)

    )

    try {

    return snapshot.enter(block)

    } finally {

    applyAndCheck(snapshot)

    }

    }
    Recomposer
    @mvndy_hd @jossiwolf


    View Slide

57. #hg2compose
    private inline fun composing(

    composition: ControlledComposition,

    modifiedValues: IdentityArraySet?,

    block: ()
    ->
    T

    ): T {

    val snapshot = Snapshot.takeMutableSnapshot(

    readObserverOf(composition),

    writeObserverOf(composition, modifiedValues)

    )

    try {

    return snapshot.enter(block)

    } finally {

    applyAndCheck(snapshot)

    }

    }
    Recomposer
    @mvndy_hd @jossiwolf


    View Slide

58. #hg2compose
    private inline fun composing(

    composition: ControlledComposition,

    modifiedValues: IdentityArraySet?,

    block: ()
    ->
    T

    ): T {

    val snapshot = Snapshot.takeMutableSnapshot(

    readObserverOf(composition),

    writeObserverOf(composition, modifiedValues)

    )

    try {

    return snapshot.enter(block)

    } finally {

    applyAndCheck(snapshot)

    }

    }
    Recomposer
    @mvndy_hd @jossiwolf


    View Slide

59. #hg2compose
    private fun readObserverOf(

    composition: ControlledComposition

    ): (Any)
    ->
    Unit {

    return { value
    ->
    composition.recordReadOf(value) }

    }
    Recomposer
    @mvndy_hd @jossiwolf


    View Slide

60. #hg2compose
    //
    Invalidate any recompose scopes that read this value.

    observations.forEachScopeOf(value) { scope
    ->


    if (scope.invalidateForResult(value)
    ==
    InvalidationResult.IMMINENT) {
    observationsProcessed.add(value, scope)

    }

    }
    Composition
    @mvndy_hd @jossiwolf


    View Slide

61. #hg2compose
    RecomposeScope
    /**

    * Invalidate the group which will cause [composition] to request

    * this scope be recomposed

    */


    fun invalidateForResult(value: Any?): InvalidationResult =

    composition
    ?.
    invalidate(this, value)
    ?:
    InvalidationResult.IGNORED
    @mvndy_hd @jossiwolf


    View Slide

62. @Composable

    fun HitchhikerApp() {

    var name = remember { mutableStateOf("Bob") }

    HelloWorld(greeting = name.value)

    }

    @Composable

    fun HelloWorld(greeting: String) {

    println("Hello, $greeting!")

    }
    #hg2compose
    S

    N

    A

    P

    S

    H

    O

    T
    @mvndy_hd @jossiwolf


    View Slide

63. @Composable

    fun HelloWorld(greeting: String) {

    Text("Hello, $greeting!")

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

64. @Composable

    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    val %dirty = %changed

    if (%changed and 0b1110
    ===
    0) {

    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100

    else 0b0010

    }

    if (%dirty and 0b1011 xor 0b0010
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello, $greeting!")

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()

    ?.
    updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(greeting, %composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

65. @Composable

    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    val %dirty = %changed

    if (%changed and 0b1110
    ===
    0) {

    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100

    else 0b0010

    }

    if (%dirty and 0b1011 xor 0b0010
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello, $greeting!")

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()

    ?.
    updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(greeting, %composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

66. @Composable

    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    val %dirty = %changed

    if (%changed and 0b1110
    ===
    0) {

    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100

    else 0b0010

    }

    if (%dirty and 0b1011 xor 0b0010
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello, $greeting!")

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()

    ?.
    updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(greeting, %composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

67. @Composable

    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    val %dirty = %changed

    if (%changed and 0b1110
    ===
    0) {

    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100

    else 0b0010

    }

    if (%dirty and 0b1011 xor 0b0010
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello, $greeting!")

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()

    ?.
    updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(greeting, %composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

68. @Composable

    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    val %dirty = %changed

    if (%changed and 0b1110
    ===
    0) {

    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100

    else 0b0010

    }

    if (%dirty and 0b1011 xor 0b0010
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello, $greeting!")

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()

    ?.
    updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(greeting, %composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

69. @Composable

    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    val %dirty = %changed

    if (%changed and 0b1110
    ===
    0) {

    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100

    else 0b0010

    }

    if (%dirty and 0b1011 xor 0b0010
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello, $greeting!")

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()

    ?.
    updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(greeting, %composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

70. @Composable

    fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    val %dirty = %changed

    if (%changed and 0b1110
    ===
    0) {

    %dirty = %dirty or if (%composer.changed(greeting)) 0b0100

    else 0b0010

    }

    if (%dirty and 0b1011 xor 0b0010
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello, $greeting!")

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()

    ?.
    updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(greeting, %composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

71. Restartable Groups
    @Composable

    fun HelloWorld(greeting: String) {

    Text("Hello, $greeting!")

    }
    @mvndy_hd @jossiwolf


    View Slide

72. @Composable

    fun HelloWorld(names: List) {

    names.forEach { name
    ->


    key(name) {

    Text(name)

    }

    }

    }
    Moveable Groups
    @mvndy_hd @jossiwolf


    View Slide

73. @Composable

    fun HelloWorld(name: String) {

    if (name
    ==
    "Amanda") {

    Text("Hello!")

    else if (name
    ==
    "Jossi") {

    Text("Hallo!")

    } else {

    Text("Uhm
    ..
    hi?")

    }

    }
    Replaceable Groups
    @mvndy_hd @jossiwolf


    View Slide

74. #hg2compose
    .kt
    Lexer (Scanner)
    Syntax Analysis
    Parsing Phase
    Generates tokens - Generates tokens to
    create an AST

    - PSI lays over AST
    Resolution
    Codegen
    Resolution
    performed on AST
    tree
    - PSI gets enhanced with
    descriptors

    - Symbol table generated;
    associated node w/
    descriptor via BindingTrace
    Frontend
    Backend
    - Takes optimized IR and performs more analysis,
    transformations + optimisations speci
    fi
    c to target CPU
    architecture

    - Multithreading
    Machine-Dependent
    Optimisations
    IR Transform
    Compiler Analysis
    Middle End “Lower”
    - Performs optimisations on IR

    - Removes dead code

    - Refactors the code

    - Improves
    performance

    - Analyzes IR for data needed
    to create

    - Call graph

    - Control-
    fl
    ow graph
    < >
    Bytecode
    Target Program
    FUN

    BLOCK_BODY

    CALL

    VAR

    IR
    Unoptimized IR
    Codegen


    IR to Bytecode


    Optimized IR
    FUN

    BLOCK_BODY

    CALL

    VAR

    IR
    Backend
    The Kotlin
    compiler
    @mvndy_hd @jossiwolf


    View Slide

75. #hg2compose
    .kt
    Lexer (Scanner)
    Syntax Analysis
    Parsing Phase
    Generates tokens - Generates tokens to
    create an AST

    - PSI lays over AST
    Resolution
    Codegen
    Resolution
    performed on AST
    tree
    - PSI gets enhanced with
    descriptors

    - Symbol table generated;
    associated node w/
    descriptor via BindingTrace
    Frontend
    Backend
    - Takes optimized IR and performs more analysis,
    transformations + optimisations speci
    fi
    c to target CPU
    architecture

    - Multithreading
    Machine-Dependent
    Optimisations
    IR Transformations
    Compiler Analysis
    Middle End “Lower”
    - Performs optimisations on IR

    - Removes dead code

    - Refactors the code

    - Improves
    performance

    - Analyzes IR for data needed
    to create

    - Call graph

    - Control-
    fl
    ow graph
    < >
    Bytecode
    Target Program
    FUN

    BLOCK_BODY

    CALL

    VAR

    IR
    Unoptimized IR
    Codegen


    IR to Bytecode


    Optimized IR
    FUN

    BLOCK_BODY

    CALL

    VAR

    IR
    Backend
    Compose
    compiler
    plugin
    Backend
    - Takes optimized IR and performs more analysis,
    transformations + optimisations speci
    fi
    c to target CPU
    architecture

    - Multithreading
    Machine-Dependent
    Optimisations
    IR Transform
    Compiler Analysis
    Middle End “Lower”
    - Performs optimisations on IR

    - Removes dead code

    - Refactors the code

    - Improves
    performance

    - Analyzes IR for data needed
    to create

    - Call graph

    - Control-
    fl
    ow graph
    < >
    Bytecode
    Target Program
    FUN

    BLOCK_BODY

    CALL

    VAR

    IR
    Unoptimized IR
    Codegen


    IR to Bytecode


    Optimized IR
    FUN

    BLOCK_BODY

    CALL

    VAR

    IR
    Backend
    @mvndy_hd @jossiwolf


    View Slide

76. #hg2compose
    .kt
    Lexer (Scanner)
    Syntax Analysis
    Parsing Phase
    Generates tokens
    - Generates tokens to
    create an AST

    - PSI lays over AST
    Semantic Analysis
    Codegen
    Semantic Analysis
    performed on AST
    - PSI gets enhanced with
    descriptors

    - Symbol table generated;
    associated node w/ descriptor
    via BindingTrace
    Kotlin Compiler
    Frontend
    @mvndy_hd @jossiwolf


    View Slide

77. #hg2compose
    .kt
    Lexer (Scanner)
    Syntax Analysis
    Parsing Phase
    Generates tokens
    - Generates tokens to
    create an AST
    - PSI lays over AST
    Resolution
    Codegen
    Semantic Analysis
    performed on AST
    - PSI gets enhanced with
    descriptors

    - Symbol table generated;
    associated node w/ descriptor
    via BindingTrace
    Kotlin Compiler
    Frontend
    @mvndy_hd @jossiwolf


    View Slide

78. Element.FUN
    Element.BLOCK
    Element.CALL_EXPRESSION
    Token.L_BRACE Token.R_BRACE
    Element.REFERENCE_EXPRESSION Element.VALUE_ARGUMENT_LIST
    Token.IDENTIFIER Token.LPAR Token.RPAR
    Element.STRING_TEMPLATE
    Element.LITERAL_STRING_TEMPLATE_ENTRY
    Token.OPEN_QUOTE
    Element.REGULAR_STRING_PART
    Token.OPEN_QUOTE
    #hg2compose
    @mvndy_hd @jossiwolf
    Text("Hello, World!")
    AST


    View Slide

79. #hg2compose
    .kt
    Lexer (Scanner)
    Syntax Analysis
    Parsing Phase
    Generates tokens
    - Generates tokens to
    create an AST

    - PSI lays over AST
    Resolution
    Codegen
    Semantic Analysis
    performed on AST
    - PSI gets enhanced with
    descriptors

    - Symbol table generated;
    associated node w/ descriptor
    via BindingTrace
    Kotlin Compiler
    Frontend
    @mvndy_hd @jossiwolf


    View Slide

80. KtBlockExpression
    KtCallExpression
    KtReferenceExpression KtValueArgument
    Token.IDENTIFIER
    Element.REGULAR_STRING_PART #hg2compose
    @mvndy_hd @jossiwolf
    Text("Hello, World!")
    KtValueArgument
    KtStringTemplateExpression
    PSI


    View Slide

81. #hg2compose
    .kt
    Lexer (Scanner)
    Syntax Analysis
    Parsing Phase
    Generates tokens
    - Generates tokens to
    create an AST

    - PSI lays over AST
    Resolution
    Codegen
    Semantic Analysis
    performed on AST
    - PSI gets enhanced with
    descriptors

    - Symbol table generated;
    associated node w/ descriptor
    via BindingTrace
    Kotlin Compiler
    Frontend
    @mvndy_hd @jossiwolf


    View Slide

82. #hg2compose
    func()
    IR Transform
    Compiler Analysis
    Middle End “Lower”
    - Performs optimisations on IR

    - Removes dead code

    - Refactors the code

    - Improves performance

    - Analyzes IR for data needed to
    create

    - Call graph

    - Control-
    fl
    ow graph
    Backend
    - Takes optimized IR and performs more analysis,
    transformations + optimisations speci
    fi
    c to target
    CPU architecture

    - Multithreading
    func()
    Optimized IR
    < >
    Bytecode
    Target Program
    @mvndy_hd @jossiwolf


    View Slide

83. #hg2compose
    func()
    IR Transform
    Compiler Analysis
    Middle End “Lower”
    - Performs optimisations on IR

    - Removes dead code

    - Refactors the code

    - Improves performance

    - Analyzes IR for data needed to
    create

    - Call graph

    - Control-
    fl
    ow graph
    Backend
    - Takes optimized IR and performs more analysis,
    transformations + optimisations speci
    fi
    c to target
    CPU architecture

    - Multithreading
    func()
    Optimized IR
    < >
    Bytecode
    Target Program
    @mvndy_hd @jossiwolf


    View Slide

84. FUN name:HelloWorld visibility:public modality:FINAL
    <>
    (greeting:kotlin.String,
    $composer:androidx.compose.runtime.Composer?, $changed:kotlin.Int)
    returnType:kotlin.Unit

    annotations:

    Composable

    VALUE_PARAMETER name:greeting index:0 type:kotlin.String

    VALUE_PARAMETER name:$composer index:1 type:androidx.compose.runtime.Composer? [assignable]


    VALUE_PARAMETER name:$changed index:2 type:kotlin.Int


    BLOCK_BODY

    BLOCK type=kotlin.Unit origin=null


    SET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in .HelloWorld' type=kotlin.Unit origin=null


    CALL 'public abstract fun startRestartGroup (key: kotlin.Int): androidx.compose.runtime.Composer declared in androidx.compose.runtime.Composer' type=androidx.compose.runtime.Composer origin=null


    $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in .HelloWorld' type=androidx.compose.runtime.Composer? origin=null


    key: CONST Int type=kotlin.Int value=734305942


    CALL 'public final fun sourceInformation (composer: androidx.compose.runtime.Composer, sourceInformation: kotlin.String): kotlin.Unit declared in androidx.compose.runtime.ComposerKt' type=kotlin.Unit origin=null


    composer: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in .HelloWorld' type=androidx.compose.runtime.Composer? origin=null


    sourceInformation: CONST String type=kotlin.String value="C(HelloWorld):Test.kt"


    WHEN type=kotlin.Unit origin=IF


    BRANCH


    if: WHEN type=kotlin.Boolean origin=OROR


    BRANCH


    if: CALL 'public final fun not (): kotlin.Boolean [operator] declared in kotlin.Boolean' type=kotlin.Boolean origin=null


    $this: CALL 'public final fun EQEQEQ (arg0: kotlin.Any?, arg1: kotlin.Any?): kotlin.Boolean declared in kotlin.internal.ir' type=kotlin.Boolean origin=null


    arg0: CALL 'public final fun and (other: kotlin.Int): kotlin.Int [infix] declared in kotlin.Int' type=kotlin.Int origin=null


    $this: GET_VAR '$changed: kotlin.Int declared in .HelloWorld' type=kotlin.Int origin=null


    other: CONST Int type=kotlin.Int value=1


    arg1: CONST Int type=kotlin.Int value=0


    then: CONST Boolean type=kotlin.Boolean value=true


    BRANCH


    if: CONST Boolean type=kotlin.Boolean value=true


    then: CALL 'public final fun not (): kotlin.Boolean [operator] declared in kotlin.Boolean' type=kotlin.Boolean origin=null


    $this: CALL 'public abstract fun (): kotlin.Boolean declared in androidx.compose.runtime.Composer' type=kotlin.Boolean origin=null


    $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in .HelloWorld' type=androidx.compose.runtime.Composer? origin=null


    then: BLOCK type=kotlin.Unit origin=null


    CALL 'public final fun println (message: kotlin.Any?): kotlin.Unit [inline] declared in
    kotlin.io.ConsoleKt' type=kotlin.Unit origin=null

    message: CONST String type=kotlin.String value="Hello"

    BRANCH


    if: CONST Boolean type=kotlin.Boolean value=true


    then: CALL 'public abstract fun skipToGroupEnd (): kotlin.Unit declared in androidx.compose.runtime.Composer' type=kotlin.Unit origin=null


    $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in .HelloWorld' type=androidx.compose.runtime.Composer? origin=null


    BLOCK type=kotlin.Unit origin=null


    BLOCK type=kotlin.Unit origin=SAFE_CALL


    VAR IR_TEMPORARY_VARIABLE name:tmp0_safe_receiver type:androidx.compose.runtime.ScopeUpdateScope? [val]


    CALL 'public abstract fun endRestartGroup (): androidx.compose.runtime.ScopeUpdateScope? declared in androidx.compose.runtime.Composer' type=androidx.compose.runtime.ScopeUpdateScope? origin=null


    $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in .HelloWorld' type=androidx.compose.runtime.Composer? origin=null


    WHEN type=kotlin.Unit origin=IF


    BRANCH


    if: CALL 'public final fun EQEQEQ (arg0: kotlin.Any?, arg1: kotlin.Any?): kotlin.Boolean declared in kotlin.internal.ir' type=kotlin.Boolean origin=null


    arg0: GET_VAR 'val tmp0_safe_receiver: androidx.compose.runtime.ScopeUpdateScope? [val] declared in .HelloWorld' type=androidx.compose.runtime.ScopeUpdateScope? origin=null


    arg1: CONST Null type=kotlin.Any? value=null


    then: CONST Null type=kotlin.Any? value=null


    BRANCH


    if: CONST Boolean type=kotlin.Boolean value=true


    then: CALL 'public abstract fun updateScope (block: kotlin.Function2): kotlin.Unit declared in androidx.compose.runtime.ScopeUpdateScope' type=kotlin.Unit origin=null


    $this: GET_VAR 'val tmp0_safe_receiver: androidx.compose.runtime.ScopeUpdateScope? [val] declared in .HelloWorld' type=androidx.compose.runtime.ScopeUpdateScope? origin=null


    block: BLOCK type=kotlin.Function2 origin=LAMBDA


    FUN LOCAL_FUNCTION_FOR_LAMBDA name
    :
    <
    anonymous> visibility:local modality:FINAL
    <
    >
    ($composer:androidx.compose.runtime.Composer?, $force:kotlin.Int) returnType:kotlin.Unit


    VALUE_PARAMETER name:$composer index:0 type:androidx.compose.runtime.Composer?


    VALUE_PARAMETER name:$force index:1 type:kotlin.Int


    BLOCK_BODY


    RETURN type=kotlin.Nothing from='local final fun ($composer: androidx.compose.runtime.Composer?, $force: kotlin.Int): kotlin.Unit declared in .HelloWorld'


    CALL 'public final fun HelloWorld (greeting: kotlin.String, $composer: androidx.compose.runtime.Composer?, $changed: kotlin.Int): kotlin.Unit declared in ' type=kotlin.Unit origin=null


    greeting: GET_VAR 'greeting: kotlin.String declared in .HelloWorld' type=kotlin.String origin=null


    $composer: GET_VAR '$composer: androidx.compose.runtime.Composer? declared in .HelloWorld.' type=androidx.compose.runtime.Composer? origin=null


    $changed: CALL 'public final fun or (other: kotlin.Int): kotlin.Int [infix] declared in kotlin.Int' type=kotlin.Int origin=null


    $this: GET_VAR '$changed: kotlin.Int declared in .HelloWorld' type=kotlin.Int origin=null


    other: CONST Int type=kotlin.Int value=1




    @mvndy_hd @jossiwolf


    View Slide

85. @Composable

    fun HelloWorld() {

    Text("Hello World!")

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

86. @Composable

    fun HelloWorld(%composer: Composer?, %changed: Int) {

    %composer = %composer.startRestartGroup(
    <>
    )

    if (%changed
    !==
    0
    ||
    !%composer.skipping) {

    Text("Hello World”)

    } else {

    %composer.skipToGroupEnd()

    }

    %composer.endRestartGroup()?

    .updateScope { %composer: Composer?, %force: Int
    ->


    HelloWorld(%composer, %changed or 0b0001)

    }

    }
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

87. A Composer connects Composables to Runtime,
    keeps track of groups that are used to build the
    Slot Table and positions it.
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

88. #hg2compose
    var name by remember { mutableStateOf("Bob") }

    @Composable

    fun Greeting(greeting: String) {

    Text("Hello, $greeting!")

    }

    Greeting(name)

    name = "Jossi"

    //
    Hello, Bob!

    //
    Hello, Jossi!
    Slot Table by Example
    @mvndy_hd @jossiwolf


    View Slide

89. #hg2compose
    EMPTY
    EMPTY
    Group(4)
    State(“Bob”)
    var name by remember { mutableStateOf("Bob") }
    Slot Table by Example
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    @mvndy_hd @jossiwolf


    View Slide

90. #hg2compose
    Group(4)
    State(“Bob”)
    Group(5)
    var name by remember { mutableStateOf("Bob") }
    Slot Table by Example
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    EMPTY
    @Composable

    fun Greeting(greeting: String) {

    }

    Greeting(name)

    @mvndy_hd @jossiwolf


    View Slide

91. #hg2compose
    EMPTY
    EMPTY
    Group(4)
    State(“Bob”)
    Group(5)
    Group(6)
    Group(7)
    Group(8)
    “Hello, Bob!”
    var name by remember { mutableStateOf("Bob") }
    Slot Table by Example
    @Composable

    fun Greeting(greeting: String) {

    Text("Hello, $greeting!”)

    }

    Greeting(name)

    @mvndy_hd @jossiwolf


    View Slide

92. #hg2compose
    EMPTY
    EMPTY
    Group(4)
    State(“Bob”)
    Group(5)
    Group(6)
    Group(7)
    Group(8)
    “Hello, Jossi!”
    var name by remember { mutableStateOf("Bob") }
    @Composable

    fun Greeting(greeting: String) {

    Text("Hello, $greeting!”)

    }

    Greeting(name)

    name = "Jossi"
    Slot Table by Example
    @mvndy_hd @jossiwolf


    View Slide

93. UI
    #hg2compose
    @mvndy_hd @jossiwolf


    View Slide

94. #hg2compose
    Text(text = name)
    Layout
    Layout
    name by remember
    { mutableStateOf("Bob") }
    Bob
    @mvndy_hd @jossiwolf


    View Slide

95. #hg2compose
    @mvndy_hd @jossiwolf
    interface Applier {

    val current: N

    fun onBeginChanges() {}

    fun onEndChanges() {}

    fun down(node: N)

    fun up()

    fun insertTopDown(index: Int, instance: N)

    fun insertBottomUp(index: Int, instance: N)

    fun remove(index: Int, count: Int)

    fun move(from: Int, to: Int, count: Int)

    fun clear()

    }


    View Slide

96. #hg2compose
    Text(text = name)
    Layout
    Layout
    @mvndy_hd @jossiwolf
    LayoutNode
    LayoutNode
    LayoutNode


    View Slide

97. 🏃Efficient Codegen Tips🏃
    #hg2compose
    The point of Compose transformations is to reduce as many groups +
    group executions as possible - but you can help too!
    @mvndy_hd @jossiwolf


    View Slide

98. #hg2compose
    Use key to make
    recomposition of lists cheaper!
    This helps Compose generate moveable groups, avoiding
    recomposition i.e. when the position of a list item changes.
    @mvndy_hd @jossiwolf


    View Slide

99. #hg2compose
    Make sure to read state values at
    the lowest node of the tree possible
    You only want to recompose where you actually need the state :)
    @mvndy_hd @jossiwolf


    View Slide

100. • Jorge Castillo for writing "Compose Internals"


     • Leland Richardson for sitting down with us and
     patiently answering our questions!
     #hg2compose
     Thank you!!!
     @mvndy_hd @jossiwolf


     View Slide

101. #hg2compose
     linktr.ee/hg2compose
     @mvndy_hd @jossiwolf


     View Slide
