Migrating from TYPO3 CMS to TYPO3 Neos

Migrating from TYPO3 CMS to TYPO3 Neos

Moving from TYPO3 CMS to TYPO3 Neos is not for everyone. This presentation looks briefly at the key factors of the usefulness of a migration. Then it covers migration of things like TypoScript, templates and configuration as well as look at what to do with extensions and existing content. Afterwards you should be able to confidently judge if a migration is worth the effort.

Karsten Dambekalns

March 28, 2014
Tweet

More Decks by Karsten Dambekalns

Other Decks in Programming

Transcript

  1. M I G R AT I N G F R O M
    T Y P O 3 C M S T O N E O S
    I N S P I R I N G C O N F E R E N C E 2 0 1 4

    View Slide

  2. A B O U T M E
    • TYPO3 Neos and Flow developer
    • 36 years old
    • lives in Lübeck
    • works at TechDivision
    • 1 wife, 3 sons
    • 1 espresso machine
    • likes canoeing & climbing
    K A R S T E N D A M B E K A L N S

    View Slide

  3. • Decision
    • Preparation
    • Migration of

    TypoScript, Templates, Extensions, Content

    View Slide

  4. W H Y D O Y O U N E E D T O
    M I G R AT E ?
    D E C I S I O N

    View Slide

  5. T Y P O 3 V E R S I O N
    R E A C H E D E O L
    • You want to use a
    supported (LTS) version
    • Are you happy with TYPO3?
    • Are your extensions ready
    for the next LTS?
    • Why not migrate to the
    next LTS version?

    View Slide

  6. H O W M U C H W O R K I S I T ?
    I H A V E N O I D E A

    View Slide

  7. W E B S I T E I S
    B E I N G R E D O N E
    • No longer happy with
    TYPO3?
    • Looking at alternatives
    already?
    • Are you eager to learn
    something new?
    • Migrate to Neos!
    F L I C K R . C O M – K O N N E X U S

    View Slide

  8. H O W M U C H W O R K I S I T ?
    W E W I L L L O O K A T T H A T D U R I N G T H I S TA L K

    View Slide

  9. F I R S T S O M E B L O C K E R S
    B U T, L E T ’ S B E H O N E S T
    ( I F T I M E I S A N I S S U E )

    View Slide

  10. B L O C K E R S F O R U S I N G N E O S
    !
    • fine-grained access control for editors
    • front end user access control
    • multi-language aware user interface
    • tools for working with large amounts of data
    Neos 1.1 will not have

    View Slide

  11. T H E F U T U R E I S N E A R
    • Internal support for content dimensions
    Neos 1.1 will have
    • Content Dimension support in the UI
    • Fine-grained permissions / ACL support
    Neos 1.2 will have one of

    View Slide

  12. C O N T E N T F I R S T
    P R E PA R A T I O N

    View Slide

  13. C O N T E N T
    I N V E N T O RY
    • Most important task!
    • Look at your content
    • Categorize it
    • Prioritize it
    F L I C K R . C O M – B E S S E R E _ Z U K U N F T _ E V

    View Slide

  14. C O N T E N T
    S T R U C T U R E
    • Most important task, too!
    • Plan your content structure
    • Use freely defined node
    types for your content
    • If you need blocks or
    columns on your site, give
    them a meaning
    F L I C K R . C O M – S N A P S I 4 2

    View Slide

  15. M I G R AT I O N
    D O I N G T H E
    F L I C K R . C O M – J A C K A L 1

    View Slide

  16. T Y P O S C R I P T
    M I G R A T I O N

    View Slide

  17. D O N ’ T D O I T.
    Q U I C K A N D E A S Y A N S W E R

    View Slide

  18. T Y P O S C R I P T I N N E O S
    • Neos uses it only for configuring the rendering
    • New syntax, other possibilities
    • Use of templates for content, less tweaks needed
    • Most sites will need less TypoScript

    View Slide

  19. D E S I G N & T E M P L AT E S
    M I G R A T I O N

    View Slide

  20. D E S I G N & T E M P L AT E S
    • If you redesign: wait, do content first
    • Reusing HTML templates & CSS is no problem
    • No more marker templates: Fluid and TypoScript

    • see IntegratorGuide/AdjustingOutput.html

    View Slide

  21. D E S I G N & T E M P L AT E S
    • Basically you can do whatever you like!
    • HTML5, jQuery, Bootstrap, Zurb Foundation, …
    • But watch out for
    • JavaScript conflicts
    • Media Queries / Responsive Design

    View Slide



  22. !



    !





    !



    !


    View Slide

  23. page.body {
    templatePath = 'resource://Acme.Demo/Private/Templates/Page/Default.html'
    sectionName = 'body'
    !
    parts {
    menu = Menu
    menu {
    templatePath = 'resource://Acme.Cemo/Private/Templates/Menu.html'
    }
    }
    !
    content {
    masthead = ContentCollection
    masthead.nodePath = 'masthead'
    !
    main = PrimaryContent
    main.nodePath = 'main'
    }
    }

    View Slide

  24. E X T E N S I O N S
    M I G R A T I O N

    View Slide

  25. E X T E N S I O N S
    • Your new content may not even need extensions
    • Use NodeTypes and TypoScript instead of extensions
    • Write custom Eel helpers or Fluid ViewHelpers
    • Implement a custom node type in PHP

    View Slide

  26. View Slide

  27. E X T E N S I O N S
    • You might still need a “real plugin”
    • Flow is the base for extensions to Neos
    • For business logic code reuse is possible
    !
    • see IntegratorGuide/CreatingAPlugin.html

    View Slide

  28. C O N T E N T
    M I G R A T I O N
    F L I C K R . C O M – M A R C G O E RT Z

    View Slide

  29. U S I N G X M L
    WA Y S T O M I G R A T E

    View Slide

  30. • Use the impexp extension
    to export to XML
    • Use XSLT to transform into
    the XML format of Neos
    • Import into Neos
    string
    dddf74f333c1655240381a30e
    http://www.yaml.de/




    690
    403
    Padomi, kā iepirkties. Ja kas, zvani 277...
    3952




    string
    618089b60ec48edc6433fdc60
    http://www.motolietas.


    <field>bodytextfield>
    typolink_tag
    e-pasts.html _blank externa




    706

    View Slide

  31. • impexp exports way more than we need
    • XSLT knowledge needed
    • Does not work for huge sites
    !
    • see https://github.com/crusoe/TYPO3-Transition-Tool

    View Slide

  32. R A W D ATA B A S E
    A C C E S S
    WA Y S T O M I G R A T E

    View Slide

  33. • Read from the TYPO3 database directly
    • Apply transformations as needed
    • Create nodes in Neos from that data

    View Slide

  34. CREATE TABLE `tt_content` (
    `uid` int(11) NOT NULL AUTO_INCREMENT,
    `pid` int(11) NOT NULL DEFAULT '0',
    `t3ver_oid` int(11) NOT NULL DEFAULT '0',
    `t3ver_id` int(11) NOT NULL DEFAULT '0',
    `t3ver_wsid` int(11) NOT NULL DEFAULT '0',
    `t3ver_label` varchar(255) NOT NULL DEFAULT '',
    `t3ver_state` tinyint(4) NOT NULL DEFAULT '0',
    `t3ver_stage` int(11) NOT NULL DEFAULT '0',
    `t3ver_count` int(11) NOT NULL DEFAULT '0',
    `t3ver_tstamp` int(11) NOT NULL DEFAULT '0',
    `t3_origuid` int(11) NOT NULL DEFAULT '0',
    `tstamp` int(11) unsigned NOT NULL DEFAULT '0',
    `hidden` tinyint(4) unsigned NOT NULL DEFAULT '0',
    `sorting` int(11) unsigned NOT NULL DEFAULT '0',
    `CType` varchar(30) NOT NULL DEFAULT '',
    `header` varchar(255) NOT NULL DEFAULT '',
    `header_position` varchar(6) NOT NULL DEFAULT '',
    `bodytext` mediumtext,
    `image` text,
    `imagewidth` mediumint(11) unsigned NOT NULL DEFAULT '0',
    `imageorient` tinyint(4) unsigned NOT NULL DEFAULT '0',
    `imagecaption` text,
    `imagecols` tinyint(4) unsigned NOT NULL DEFAULT '0',
    `imageborder` tinyint(4) unsigned NOT NULL DEFAULT '0',
    `media` text,
    `layout` tinyint(3) unsigned NOT NULL DEFAULT '0',
    `deleted` tinyint(4) unsigned NOT NULL DEFAULT '0',
    `cols` tinyint(3) unsigned NOT NULL DEFAULT '0',
    `records` text,
    `pages` tinytext,
    `starttime` int(11) unsigned NOT NULL DEFAULT '0',
    `endtime` int(11) unsigned NOT NULL DEFAULT '0',
    `colPos` tinyint(3) unsigned NOT NULL DEFAULT '0',
    `subheader` varchar(255) NOT NULL DEFAULT '',
    `spaceBefore` smallint(5) unsigned NOT NULL DEFAULT '0',
    `spaceAfter` smallint(5) unsigned NOT NULL DEFAULT '0',
    `fe_group` varchar(100) NOT NULL DEFAULT '0',
    `header_link` varchar(255) NOT NULL DEFAULT '',
    `imagecaption_position` varchar(6) NOT NULL DEFAULT '',
    • Do not migrate
    everything!
    • Which content types are
    needed?
    • Which fields are really
    used?
    • Which are misused?

    View Slide

  35. R E A D I N G T H E D ATA
    • Use plain PDO, Doctrine DBAL, …
    • Fetch only the needed fields
    • Return raw data

    View Slide

  36. R E A D I N G T H E D ATA
    /**
    * Returns raw tt_content data for the article uid
    *
    * @param integer $articleUid
    * @return array
    */
    public function getArticleContent($articleUid) {
    $sql = sprintf('SELECT
    uid, hidden, CType, header, header_layout, bodytext, tx_templavoila_to,
    image, imageorient, imagecaption, imagecols, image_link, altText, titleText,
    pi_flexform
    FROM tt_content
    WHERE deleted = 0 AND irre_parenttable = \'tx_t3blog_post\' AND irre_parentid = %u
    ORDER BY sorting ASC', $articleUid);
    $statement = $this->connection->prepare($sql);
    $statement->execute();
    !
    return $statement->fetchAll(\PDO::FETCH_ASSOC);
    }

    View Slide

  37. R E A D I N G T H E D ATA
    /**
    * Returns an array of raw article data
    *
    * @return array
    */
    public function getArticles() {
    $sql = sprintf('SELECT
    p.uid, p.uuid, p.hidden, p.title, p.subtitle, p.date, p.starttime, p.endtime, p.top_3_image,
    u.realName AS author,
    c.uid AS maincategory, c.catname AS maincategoryname,
    GROUP_CONCAT(c.uid ORDER BY mm.sorting DESC SEPARATOR \',\') AS categories,
    p.searchwords,
    r.value_alias as realurl_uniqalias
    FROM tx_t3blog_post p
    LEFT JOIN be_users u ON p.author=u.uid
    LEFT JOIN tx_t3blog_post_cat_mm mm ON p.uid=mm.uid_local
    LEFT JOIN tx_t3blog_cat c ON c.uid=mm.uid_foreign
    LEFT JOIN tx_realurl_uniqalias r ON r.value_id=p.uid AND r.tablename=\'tx_t3blog_post\'
    WHERE p.pid=%u AND p.deleted=0
    GROUP BY p.uid
    ORDER BY p.date DESC, mm.sorting ASC', $this->settings['articles']['storagePid']);
    !
    $statement = $this->connection->prepare($sql);
    $statement->execute();
    !
    return $statement->fetchAll(\PDO::FETCH_ASSOC);
    }

    View Slide

  38. H A N D L E D C O N T E N T T Y P E S
    • text: TYPO3.Neos.NodeTypes:Headline, TYPO3.Neos.NodeTypes:Text
    • html: TYPO3.Neos.NodeTypes:Html
    • textpic: TYPO3.Neos.NodeTypes:Headline,
    TYPO3.Neos.NodeTypes:TextWithImage, TYPO3.Neos.NodeTypes:Text
    • templavoila_pi1: TYPO3.Neos.NodeTypes:Html
    • image: TYPO3.Neos.NodeTypes:Headline,
    TYPO3.Neos.NodeTypes:Image
    • media: Journal.Commons:FlashVideo
    • div, list, uploads: skipped
    I N T H E C E N T U R I O N M A G A Z I N E M I G R A T I O N

    View Slide

  39. switch ($contentRecord['CType']) {
    case 'list':
    case 'div':
    case 'uploads':
    // no support needed, as these are not used in articles
    continue;
    case ‘text':
    !

    View Slide

  40. A P P LY I N G T R A N S F O R M AT I O N S
    • Skip unusable items
    • Clean up the data
    • Transform raw data to nodes

    View Slide

  41. C L E A N U P
    protected function cleanBodyText($content) {
    // remove leftover ###META###
    $content = str_replace('###META###', '', $content);
    !
    // prune empty tags
    $content = preg_replace('@<(p|div|span|i|b|strong|em)[^>]*>\1>@ui', '', $content);
    !
    // wrap lines in p tags
    $content = preg_replace('/^((?!).+)$/uim', '$1', $content);
    !
    // convert TYPO3 link tag
    $splitContent = preg_split('|(]*>[^<]+)|', $content, -1,
    PREG_SPLIT_DELIM_CAPTURE);
    $content = '';
    foreach ($splitContent as $part) {
    if (substr($part, 0, 5) === 'preg_match('|[^\s>]+)(?:\s(?P[^\s>]+))?(?:\s(?P[^
    \s>]+))?(?:\s"(?P[^">]+)")?>(?P[^<]*)|xui', $part, $matches);
    if ($matches !== array()) {
    $content .= '

    View Slide

  42. C O N T E N T T R A N S F O R M AT I O N
    • Create Headline nodes from header
    • Create Image and Text nodes from textpic
    • Order Text and Image nodes based on orientation
    • Create image carousel from image with multiple
    images

    View Slide

  43. H O W T O C R E AT E T H E N O D E S
    • Create XML for import into Neos
    • Add nodes to the content repository

    View Slide

  44. C R E AT E A N H T M L N O D E
    case 'html':
    if (!empty($contentRecord['bodytext'])) {
    $nodeTemplate = new NodeTemplate();
    $nodeTemplate->setName(uniqid('html'));
    $nodeTemplate->setNodeType(
    $this->nodeTypeManager->getNodeType(‘TYPO3.Neos.NodeTypes:Html')
    );
    $nodeTemplate->setHidden((boolean)$contentRecord['hidden']);
    $nodeTemplate->setProperty('source', $contentRecord['bodytext']);
    !
    $mainContentCollectionNode->createNodeFromTemplate($nodeTemplate);
    }
    break;

    View Slide

  45. C R E AT E A H E A D E R N O D E
    protected function createHeaderIfNeeded(NodeInterface $targetNode, array $contentRecord) {
    // header_layout 100 means hidden, so skip it
    if (!empty($contentRecord['header']) && $contentRecord['header_layout'] !== 100) {
    $nodeTemplate = new NodeTemplate();
    $nodeTemplate->setName(uniqid('header'));
    $nodeTemplate->setHidden((boolean)$contentRecord['hidden']);
    $nodeTemplate->setNodeType(
    $this->nodeTypeManager->getNodeType(‘TYPO3.Neos.NodeTypes:Headline')
    );
    $wrap = explode('|', $this->settings['headline']['defaultWrap']);
    $nodeTemplate->setProperty('title', $wrap[0] . $contentRecord['header'] . $wrap[1]);
    !
    $targetNode->createNodeFromTemplate($nodeTemplate);
    }
    }

    View Slide

  46. C R E AT E A N I M A G E N O D E
    • image elements can have multiple images
    • Image nodes hold exactly one image
    • How to deal with that? It is project specific

    View Slide

  47. F U T U R E
    A L O O K I N T O T H E
    F L I C K R . C O M – L I T T L E _ B L A C K _ C H E R RY

    View Slide

  48. N E X T S T E P S
    • Clean up the existing code
    • remove project specific parts
    • make modular and reusable
    • Write documentation
    • Publish as a package!

    View Slide

  49. Q U E S T I O N S
    N O W I S T H E T I M E F O R
    ?

    View Slide

  50. S O M E P O I N T E R S
    • These slides

    speakerdeck.com/kdambekalns
    • TYPO3 Neos

    neos.typo3.org
    • TYPO3 Neos documentation

    docs.typo3.org/neos/TYPO3NeosDocumentation
    • karsten.dambekalns.de | [email protected]

    View Slide

  51. T H A N K Y O U !
    E N J O Y T H E C O N F E R E N C E !

    View Slide
