Real-Time applications in Phoenix

A talk about building real time applications in phoenix and elixir with examples for both the client side and server side.

Transcript

1. REAL-TIME
   APPLICATIONS
   IN PHOENIX
   @ChrisKeathley / keathley@carbonfive.com / keathley.io


   View Slide

2. Chris Keathley
   @ChrisKeathley / keathley@carbonfive.com / keathley.io


   View Slide

3. Lets talk about
   Realtime


   View Slide

4. Rails + Faye


   View Slide

5. Rails
   Faye


   View Slide

6. Node + socket.io


   View Slide

7. socket.io
   socket.io
   Redis


   View Slide

8. Complexity


   View Slide

9. Balance


   View Slide

10. View Slide

11. 2 million connections per server


    View Slide

12. 2 million connections per server
    400 million users


    View Slide

13. 2 million connections per server
    400 million users
    30 Engineers


    View Slide

14. Erlang


    View Slide

15. Heroku
    RabbitMQ
    Riak
    Facebook


    View Slide

16. Elixir


    View Slide

17. Types
    iex> 1 # integer
    iex> 0x1F # integer
    iex> 1.0 # float
    iex> true # boolean
    iex> :atom # atom / symbol
    iex> "elixir" # string
    iex> [1, 2, 3] # list
    iex> {1, 2, 3} # tuple
    iex> %{:a => 1, 2 => :b} # map


    View Slide

18. Pattern Matching
    iex(1)> x = 3
    3


    View Slide

19. Pattern Matching
    iex(1)> x = 3
    3
    iex(2)> y = x
    3


    View Slide

20. Pattern Matching
    iex(1)> x = 3
    3
    iex(2)> y = x
    3
    iex(3)> 3 = x
    3


    View Slide

21. Pattern Matching is
    an assertion


    View Slide

22. Pattern Matching
    iex(3)> 3 = x
    3


    View Slide

23. Pattern Matching
    iex(4)> %{a: a, b: b} = %{a: "hello", b: "world"}
    %{a: "hello", b: "world"}
    iex(5)> a
    "hello"
    iex(6)> b
    "world"
    iex(7)>


    View Slide

24. Immutability


    View Slide

25. Processes
    iex(9)> pid = spawn fn -> 1 + 2 end
    #PID<0.68.0>
    iex(10)> self()
    #PID<0.57.0>


    View Slide

26. Processes
    iex> parent = self()
    #PID<0.41.0>
    iex> spawn fn -> send(parent, {:hello, self()}) end
    #PID<0.48.0>
    iex> receive do
    ...> {:hello, pid} ->
    "Got hello from #{inspect pid}"
    ...> end
    "Got hello from #PID<0.48.0>"


    View Slide

27. Processes
    C# Thread: 4Mb


    View Slide

28. Processes
    C# Thread: 4Mb
    Java Thread: 256k


    View Slide

29. Processes
    C# Thread: 4Mb
    Java Thread: 256k
    Erlang Process: 1k


    View Slide

30. OTP
    GenServer
    Supervisors
    GenFSM
    GenEvent
    Observer
    Dialyzer


    View Slide

31. Let It Crash


    View Slide

32. View Slide

33. ❤
    Real-time


    View Slide

34. http://www.phoenixframework.org/blog/the-road-to-2-million-
    websocket-connections


    View Slide

35. Demo
    http://bit.ly/1OEWVQ2


    View Slide

36. Lets build an app
    Controllers & Channels
    Models
    Supervisor Trees
    Changesets


    View Slide

37. Lets build an app
    Controllers & Channels
    Models
    Supervisor Trees
    Changesets


    View Slide

38. Controllers
    defmodule Conflicted.PageController do
    use Conflicted.Web, :controller
    def index(conn, _params) do
    render conn, "index.html"
    end
    end


    View Slide

39. Controllers



    Conflicted


    <%= render Conflicted.PageView, "index.html" %>
    <%= if Mix.env == :dev do %>

    <% else %>
    ">
    <% end %>




    View Slide

40. import { Socket } from 'phoenix-socket'
    let socket = new Socket("/socket")
    socket.connect()


    View Slide

41. Sockets
    defmodule Conflicted.UserSocket do
    use Phoenix.Socket
    ## Channels
    channel "tweets:*", Conflicted.TweetChannel
    ## Transports
    transport :websocket, Phoenix.Transports.WebSocket
    transport :longpoll, Phoenix.Transports.LongPoll
    def connect(_params, socket) do
    {:ok, socket}
    end
    def id(_socket), do: nil
    end


    View Slide

42. ## Channels
    channel "tweets:*", Conflicted.TweetChannel


    View Slide

43. defmodule Conflicted.TweetChannel do
    use Phoenix.Channel
    def join("tweets:stream", _message, socket) do
    tweets = Conflicted.Repo.all(Conflicted.Tweet)
    {:ok, tweets, socket}
    end
    def join("tweets:" <> _private_room_id, _params, _socket) do
    {:error, %{reason: "unauthorized"}}
    end
    # …
    end


    View Slide

44. def join("tweets:stream", _message, socket) do


    View Slide

45. def join("tweets:stream", _message, socket) do
    When a client “joins” the channel


    View Slide

46. def join("tweets:stream", _message, socket) do
    When a client “joins” the channel
    Pattern matching on the channel name


    View Slide

47. def join("tweets:stream", _message, socket) do
    When a client “joins” the channel
    Pattern matching on the channel name
    The client socket connection


    View Slide

48. def join("tweets:stream", _message, socket) do


    View Slide

49. def join("tweets:stream", _message, socket) do
    tweets = Repo.all(Tweet)
    {:ok, tweets, socket}
    end


    View Slide

50. def join("tweets:stream", _message, socket) do
    tweets = Repo.all(Tweet)
    {:ok, tweets, socket}
    end
    Retrieves all “tweets” from the database


    View Slide

51. def join("tweets:stream", _message, socket) do
    tweets = Repo.all(Tweet)
    {:ok, tweets, socket}
    end
    Retrieves all “tweets” from the database
    Return a tuple including the socket


    View Slide

52. def join("tweets:stream", _message, socket) do
    tweets = Repo.all(Tweet)
    {:ok, tweets, socket}
    end


    View Slide

53. defmodule Conflicted.TweetChannel do
    use Phoenix.Channel
    def join("tweets:stream", _message, socket) do
    tweets = Repo.all(Tweet)
    {:ok, tweets, socket}
    end
    def join("tweets:" <> _private_room_id, _params, _socket) do
    {:error, %{reason: "unauthorized"}}
    end
    # …
    end
    Return an error if the client tries to join any other channel


    View Slide

54. Lets build an app
    Controllers & Channels
    Models
    Supervisor Trees
    Changesets


    View Slide

55. defmodule Conflicted.Tweet do
    use Conflicted.Web, :model
    schema "tweets" do
    field :author, :string
    field :content, :string
    field :source_url, :string
    field :image_url, :string
    field :likes, :integer, default: 0
    timestamps
    end
    end


    View Slide

56. DB
    Repo
    Query
    Data


    View Slide

57. query = from t in Tweet,
    select: [t.text, t.likes],
    where: [t.author == “@chriskeathley”],
    order_by: [desc: t.inserted_at],
    limit: 30
    tweets = Conflicted.Repo.all(query)


    View Slide

58. defmodule Conflicted.TweetChannel do
    use Phoenix.Channel
    def join("tweets:stream", _message, socket) do
    tweets = Repo.all(Tweet)
    {:ok, tweets, socket}
    end
    def join("tweets:" <> _private_room_id, _params, _socket) do
    {:error, %{reason: "unauthorized"}}
    end
    # …
    end


    View Slide

59. Lets build an app
    Controllers & Channels
    Models
    Supervisor Trees
    Changesets


    View Slide

60. import { Socket } from 'phoenix-socket'
    let socket = new Socket("/socket")
    socket.connect()
    let channel = socket.channel("tweets:stream", {})
    channel.join()
    .receive("ok", resp => {
    store.dispatch(setState(resp))
    })
    .receive("error", resp => {
    console.log("Unable to join", resp);
    })


    View Slide

61. Channel infrastructure
    Phoenix Server
    Phoenix Server


    View Slide

62. Phoenix Server
    Phoenix Server


    View Slide

63. Phoenix Server
    Phoenix Server
    Clients Channels


    View Slide

64. Phoenix Server
    Channel Channel


    View Slide

65. Phoenix Server Repo
    Supervisor
    Channel Channel


    View Slide

66. Phoenix Server Repo
    Supervisor
    Channel Channel


    View Slide

67. Phoenix Server Repo
    Supervisor
    Channel


    View Slide

68. Phoenix Server Repo
    Supervisor
    Channel Channel


    View Slide

69. Phoenix Server Repo
    Supervisor
    Channel Channel
    TwitterClient


    View Slide

70. defmodule Conflicted do
    use Application
    def start(_type, _args) do
    import Supervisor.Spec, warn: false
    children = [
    supervisor(Conflicted.Endpoint, []),
    worker(Conflicted.Repo, []),
    worker(Task, [fn -> stream_task("elixirfriends") end])
    ]
    opts = [strategy: :one_for_one, name: Conflicted.Supervisor]
    Supervisor.start_link(children, opts)
    end
    defp stream_task(term) do
    Conflicted.TweetStreamer.stream(term)
    |> Enum.to_list
    end
    end


    View Slide

71. defmodule Conflicted.TweetStreamer do
    alias Conflicted.Repo
    import Ecto.Query, only: [from: 2]
    def stream(search_term) do
    ExTwitter.stream_filter(track: search_term)
    |> Stream.filter(&has_images?/1)
    |> Stream.filter(&new_tweet?/1)
    |> Stream.map(&store_tweet/1)
    end
    defp store_tweet(raw_tweet) do
    tweet =
    raw_tweet
    |> new_tweet
    |> Repo.insert!
    |> IO.inspect
    Conflicted.Endpoint.broadcast!("tweets:stream", "state", tweet)
    end
    # …
    end


    View Slide

72. def stream(search_term) do
    ExTwitter.stream_filter(track: search_term)
    |> Stream.filter(&has_images?/1)
    |> Stream.filter(&new_tweet?/1)
    |> Stream.map(&store_tweet/1)
    end


    View Slide

73. def stream(search_term) do
    ExTwitter.stream_filter(track: search_term)
    |> Stream.filter(&has_images?/1)
    |> Stream.filter(&new_tweet?/1)
    |> Stream.map(&store_tweet/1)
    end
    defp store_tweet(raw_tweet) do
    tweet =
    raw_tweet
    |> new_tweet
    |> Repo.insert!
    |> IO.inspect
    Conflicted.Endpoint.broadcast!("tweets:stream", "state", tweet)
    end


    View Slide

74. channel.on("state", tweet => {
    store.dispatch(setState([tweet]))
    })


    View Slide

75. Lets build an app
    Controllers & Channels
    Models
    Supervisor Trees
    Changesets


    View Slide

76. export function setState(state) {
    return {
    type: SET_STATE,
    state
    }
    }
    export function likeTweet(id) {
    return {
    meta: {remote: true},
    type: LIKE_TWEET,
    id
    }
    }


    View Slide

77. export default channel => store => next => action => {
    if (action.meta && action.meta.remote)
    channel.push('action', action)
    return next(action)
    }


    View Slide

78. import { Map } from 'immutable'
    import { SET_STATE, LIKE_TWEET } from '../actions'
    const setState = (state, newState) => {
    let tweets = newState.map((tweet) => [tweet.id, tweet])
    return state.merge(tweets)
    }
    const likeTweet = (state, id) => {
    return state.updateIn([id, 'likes'], val => val + 1)
    }
    export default function tweetsReducer(state=Map({}), action) {
    switch(action.type) {
    case SET_STATE:
    return setState(state, action.state)
    case LIKE_TWEET:
    return likeTweet(state, action.id)
    default:
    return state
    }
    }


    View Slide

79. def handle_in("action", %{"type" => "LIKE_TWEET", "id" => id}, socket) do
    changeset =
    Tweet
    |> Repo.get!(id)
    |> Tweet.changeset(%{"likes" => tweet.likes+1})
    case Repo.update(changeset) do
    {:ok, tweet} ->
    broadcast!(socket, "state", tweet)
    {:error, changeset} ->
    IO.puts "SOMETHING WENT WRONG"
    IO.inspect changeset
    end
    {:noreply, socket}
    end


    View Slide

80. Pattern match on the action
    def handle_in("action", %{"type" => "LIKE_TWEET", "id" => id}, socket) do
    changeset =
    Tweet
    |> Repo.get!(id)
    |> Tweet.changeset(%{"likes" => tweet.likes+1})
    case Repo.update(changeset) do
    {:ok, tweet} ->
    broadcast!(socket, "state", tweet)
    {:error, changeset} ->
    IO.puts "SOMETHING WENT WRONG"
    IO.inspect changeset
    end
    {:noreply, socket}
    end


    View Slide

81. Increment the likes by 1
    Pattern match on the action
    def handle_in("action", %{"type" => "LIKE_TWEET", "id" => id}, socket) do
    changeset =
    Tweet
    |> Repo.get!(id)
    |> Tweet.changeset(%{"likes" => tweet.likes+1})
    case Repo.update(changeset) do
    {:ok, tweet} ->
    broadcast!(socket, "state", tweet)
    {:error, changeset} ->
    IO.puts "SOMETHING WENT WRONG"
    IO.inspect changeset
    end
    {:noreply, socket}
    end


    View Slide

82. Increment the likes by 1
    Send a message back to all of the clients
    Pattern match on the action
    def handle_in("action", %{"type" => "LIKE_TWEET", "id" => id}, socket) do
    changeset =
    Tweet
    |> Repo.get!(id)
    |> Tweet.changeset(%{"likes" => tweet.likes+1})
    case Repo.update(changeset) do
    {:ok, tweet} ->
    broadcast!(socket, "state", tweet)
    {:error, changeset} ->
    IO.puts "SOMETHING WENT WRONG"
    IO.inspect changeset
    end
    {:noreply, socket}
    end


    View Slide

83. defmodule Conflicted.Tweet do
    use Conflicted.Web, :model
    schema "tweets" do
    field :author, :string
    field :content, :string
    field :source_url, :string
    field :image_url, :string
    field :likes, :integer, default: 0
    timestamps
    end
    @required_fields ~w(author content source_url image_url)
    @optional_fields ~w(likes)
    def changeset(model, params \\ []) do
    model
    |> cast(params, @required_fields, @optional_fields)
    |> validate_number(:likes, greater_than_or_equal_to: 0)
    end
    end


    View Slide

84. @required_fields ~w(author content source_url image_url)
    @optional_fields ~w(likes)
    def changeset(model, params \\ []) do
    model
    |> cast(params, @required_fields, @optional_fields)
    |> validate_number(:likes, greater_than_or_equal_to: 0)
    end
    Transform into changeset


    View Slide

85. @required_fields ~w(author content source_url image_url)
    @optional_fields ~w(likes)
    def changeset(model, params \\ []) do
    model
    |> cast(params, @required_fields, @optional_fields)
    |> validate_number(:likes, greater_than_or_equal_to: 0)
    end
    Transform into changeset
    Provide some validation


    View Slide

86. def handle_in("action", %{"type" => "LIKE_TWEET", "id" => id}, socket) do
    changeset =
    Tweet
    |> Repo.get!(id)
    |> Tweet.changeset(%{"likes" => tweet.likes+1})
    case Repo.update(changeset) do
    {:ok, tweet} ->
    broadcast!(socket, "state", tweet)
    {:error, changeset} ->
    IO.puts "SOMETHING WENT WRONG"
    IO.inspect changeset
    end
    {:noreply, socket}
    end


    View Slide

87. Create a changeset
    def handle_in("action", %{"type" => "LIKE_TWEET", "id" => id}, socket) do
    changeset =
    Tweet
    |> Repo.get!(id)
    |> Tweet.changeset(%{"likes" => tweet.likes+1})
    case Repo.update(changeset) do
    {:ok, tweet} ->
    broadcast!(socket, "state", tweet)
    {:error, changeset} ->
    IO.puts "SOMETHING WENT WRONG"
    IO.inspect changeset
    end
    {:noreply, socket}
    end
    Execute the change


    View Slide

88. Create a changeset
    def handle_in("action", %{"type" => "LIKE_TWEET", "id" => id}, socket) do
    changeset =
    Tweet
    |> Repo.get!(id)
    |> Tweet.changeset(%{"likes" => tweet.likes+1})
    case Repo.update(changeset) do
    {:ok, tweet} ->
    broadcast!(socket, "state", tweet)
    {:error, changeset} ->
    IO.puts "SOMETHING WENT WRONG"
    IO.inspect changeset
    end
    {:noreply, socket}
    end
    Execute the change
    Handle the response


    View Slide

89. So much more!


    View Slide

90. Web
    Android
    Windows (C#)
    iOS


    View Slide

91. Monitoring


    View Slide

92. Getting started
    • http://elixir-lang.org/
    • http://www.phoenixframework.org/docs/installation
    • http://www.phoenixframework.org/
    • https://github.com/keathley/conflicted


    View Slide

93. Thanks
    @Chris Keathley / keathley@carbonfive.com / keathley.io


    View Slide
