ruote @ Rubyfuza

Overview of leveraging ruote for your business processes

Transcript

1. ruote the awesomeness that is a pure Ruby workflow engine from japan
2. Kenneth Kalmer CTO - Internet Exchange opensourcery.co.za @kennethkalmer github.com/kennethkalmer
3. ruote Developed by John Mettraux ruote.rubyforge.org github.com/jmettraux/ruote @jmettraux
4. ruote != state_machine
5. operating system for business processes
6. Engine Workers Human participants Autonomous participants All work to towards achieving a goal, defined in a process definition (aka participating in a workflow) Players
7. Process DSL Ruote.process_definition :name => 'fuza' do sequence do participant :alpha participant :bravo end end
8. Process definitions Expressions are used to build a workflow Workflows can be: Linear Parallel Nested and more...
9. Process instances Processes run in isolation The AST is stored in the engine Original code used to launch the process can be altered without affecting running processes Processes can be versioned
10. Workitems Set the initial “payload” when launching a process Workitems are passed between participants Participants can update workitems, or just read Process flow can be altered by workitem values
11. Workitems and flows Ruote.process_definition :name => 'loan_approval' do cursor do participant 'planning team' concurrence do participant 'ceo' :if => '${f:total} > 100000' do participant 'cfo' end rewind :unless => '${f:approved}' participant 'execution team' end end
12. Human participants Persist the workitem Load it from another application to present to a “human”, which should take action ruote-couch ruote-dm ruote-redis and more...
13. Autonomous participants Local participants Instantiated classes that respond to #consume() Remote participants ruote-amqp & daemon-kit Scatter your participants over different systems
14. Notes on participants They are abstractions They are stateless Once the engine hands over a workitem to a participant, it will wait indefinitely for a response (unless a timeout is specified) They rely on the workitem to know what is expected of them
15. Process administration Often overlooked! Canceling processes, or just part of a process (expression) Re-applying segments of processes Graceful error handling “Callbacks” for process lifecycle
16. ruote-kit RESTful wrapper around ruote Rich environment for exploring, perfectly capable of production use Can be used as rack middleware (preferably not) github.com/tosch/ruote-kit
17. In the wild Internet Exchange / ISP in a Box Huge number of processes running daily Mostly autonomous, humans handle exceptions Provisions dozens of services Some processes involve a dozen participants, running all over the globe and complete within 5 seconds :)
18. In the wild Meego BOSS Used to orchestrate the CI ecosystem for the OS http://wiki.meego.com/BOSS
19. In the wild Fermilab Rackspace Universidad Politécnica de Madrid Geographic Institute of the University of Zuerich and plenty more
20. ruote.rubyforge.org/quickstart.html
21. Thanks John Mettraux Torsten Schönebaum Plenty of other contributors Internet Exchange / ISP in a Box
