I know what you are reading

Kai
September 12, 2013

I know what you are reading

I know what you are reading – Recognition of Document Types Using Mobile Eye Tracking

Paper presented at http://iswc.net/

Reading is a ubiquitous activity that many people even per- form in transit, such as while on the bus or while walking. Tracking reading enables us to gain more insights about ex- pertise level and potential knowledge of users – towards a reading log tracking and improve knowledge acquisition. As a first step towards this vision, in this work we investigate whether different document types can be automatically de- tected from visual behaviour recorded using a mobile eye tracker. We present an initial recognition approach that com- bines special purpose eye movement features as well as ma- chine learning for document type detection. We evaluate our approach in a user study with eight participants and five Japanese document types and achieve a recognition perfor- mance of 74% using user-independent training.

The full pre-print version of the paper:
http://kaikunze.de/papers/2013Kunze-5.pdf

Kai

September 12, 2013
Tweet

More Decks by Kai

Other Decks in Research

Transcript

  1. Recognition of Document Types Using Mobile Eye Tracking I know

    what you are reading Kai Kunze, Andreas Bulling, Yuzuko Utsumi, Yuki Shiga, Koichi Kise Osaka Prefecture University Max Plank Institute Saarbrücken
  2. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Motivation Quantified approach to reading (knowledge acquisition) People who read more higher vocabulary skill higher general knowledge [1] If you give quantified feedback people can improve their habits similar to apps/devices that track fitness and health they have been shown to improve physical fitness Very Few In-Situ Studies [1] A. Cunningham and K. Stanovich. What reading does for the mind. Journal of Direct Instruction, 1(2):137–149, 2001. [2] A. Bulling, J. A. Ward, and H. Gellersen. Multimodal Recognition of Reading Activity in Transit Using Body-Worn Sensors. ACM Trans. on Applied Perception Tracking Reading Habits: How much do you read? How fast? How often? What do you read? How much do you understand? “Can I copy the habits of my thesis advisor to become a better researcher?”
  3. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Tracking Reading Habits How much do you read? How fast? How often? What do you read? How much do you understand? 3
  4. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Tracking Reading Habits How much do you read? How fast? How often? What do you read? How much do you understand? 4 K. Kunze, H. Kawaichi, K. Yoshimura, K. Kise. The Wordometer – Estimating the Number of Words Read Using Document Image Retrieval and Mobile Eye Tracking. Published at ICDAR 2013, Washington D.C. Best Paper K. Kunze, H. Kawaichi, K. Yoshimura, K. Kise Towards inferring language expertise using eye tracking published at Work In Progress CHI, Paris, 2013.
  5. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Tracking Reading Habits How much do you read? How fast? How often? What do you read? How much do you understand? 5 K. Kunze, H. Kawaichi, K. Yoshimura, K. Kise. The Wordometer – Estimating the Number of Words Read Using Document Image Retrieval and Mobile Eye Tracking. Published at ICDAR 2013, Washington D.C. Best Paper K. Kunze, H. Kawaichi, K. Yoshimura, K. Kise Towards inferring language expertise using eye tracking published at Work In Progress CHI, Paris, 2013.
  6. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Document Classification Differences in amount and layout of text, images Focus on Japanese documents reading in native tounge Reading directions: Yokogaki/Tategaki also in other parts of Asia China, Korea etc. 6 Yokogaki Tategaki
  7. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Using Eye Tracking Visual behavior is subject to a lot of influences task, document type, environment etc. Which features are helpful to distinguish document types? Sliding window approach (over 200 fixations and saccades) to calculate features 7
  8. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Features - Saccade Direction Count 8 direction counts for 4 different direction: a ) 335◦ and 25◦ b ) 65◦ and 115◦, c ) 155◦ and 205◦ d ) 245◦ and 295◦ info about the main reading direction, layout of text/images a b c d 0 0 0 0 1 1 1
  9. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Features - Saccade Direction Mean/Variance calculate the saccade direction “angle” of the saccade mean, variance as features also related to the layout / amount of text and images 9
  10. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Features - Quantile Distance and Slope 10 5% to 95% quantile distance some information about the average page size slope general reading direction
  11. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Experimental Setup 8 participants (4 male/female, age 21 -34 ) 10 min of reading using SMI mobile eye-tracker 30Hz binocular ( saccades up to 33 ms) 5 document types: novel, manga, fashion magazine, newspaper, text book 5 locations: office, coffee shop, home setting, library, lecture hall Latin Square Method assignment of document type, location and starting position 11
  12. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Natural Reading newspaper in office 12
  13. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Results user dependent: 99 % user independent (leave out one): 74 % frame by frame 90 % majority voting 14
  14. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Magazine and Textbook Miss-Classification The number of horizontal saccades for the “Textbook” class is higher than for “Magazine”. This holds also for data from Participant 8. Yet, all of the “Magazine” feature points of P8 are in the “Textbook” portion of the other participants. 15 a b c d
  15. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Conclusions how generalizable is it for other languages? we added a science paper (double column) for all 4 users no change in performance As long as the text and image layout significantly vary, our method should work. Can we quantify the amount of pictures vs. text? 16
  16. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking Future Work? 17 read.it words read word count Manga Science Papers Concentrated Reading 20 pages 15 pages Japanese Overview 30 min
  17. Kai Kunze - Recognition of Document Types Using Mobile Eye

    Tracking questions, remarks, violent dissent? http://kaikunze.de twitter: @k_garten facebook: kai.kunze app.net: @kkai [email protected] https://github.com/kkai/ 18 shameless advertisement: Augmented Human 2014, Kobe http://bit.ly/augmented2014 Paper Deadline: Jan 11, 2014 Conference: March 7-9, 2014
