It doesn't have to be REST: WebSockets in Go (Gopherfest Edition)

The speed of Go should make us reconsider well established paradigms. When developing APIs it is practically impossible not to mention REST yet many applications would benefit from real-time interactivity. This talk will give you headspace to consider WebSockets as an alternative communication protocol for your application over commercial messaging and data synchronization services, how to manage sessions and answer why it is so hard to scale a WebSocket architecture.

Transcript

1. It doesn’t have
   to be REST
   WebSockets in Go
   GOPHERFEST EDITION


   View Slide

2. REST
   GET
   DELETE
   POST
   PUT
   Resources
   ?


   View Slide

3. View Slide

4. Client-Server


   View Slide

5. Client-Server
   Stateless


   View Slide

6. Client-Server
   Stateless
   Cache


   View Slide

7. Client-Server
   Stateless
   Cache
   Uniform Interface


   View Slide

8. Client-Server
   Stateless
   Cache
   Uniform Interface
   Layered System


   View Slide

9. Client-Server
   Stateless
   Cache
   Uniform Interface
   Layered System
   Code on Demand


   View Slide

10. HTTP 0.9
    HTTP 1.0
    HTTP 1.1
    HTTP/2
    GraphQL
    WebSocket
    1991 1996 1999 2000 2005 2008 2013 2015 2016 2018
    REST
    React
    High React
    Adoption
    Towards Real-Time
    Rendering & Updating
    AJAX
    Expected
    Real-Time
    Singularity


    View Slide

11. WebSockets


    View Slide

12. Chats Games


    View Slide

13. View Slide

14. View Slide

15. View Slide

16. Server
    ws://…
    Client
    Messages
    Text/Binary


    View Slide

17. Server
    ws://…
    Client
    Messages
    Text/Binary
    - Message-oriented protocol
    - Messages are split into frames
    - Payload can be binary or text
    - Supports fragmentation


    View Slide

18. Server
    ws://…
    Client
    Messages
    Text/Binary
    - Message-oriented protocol
    - Messages are split into frames
    - Payload can be binary or text
    - Supports fragmentation


    View Slide

19. https://godoc.org/?q=websocket


    View Slide

20. github.com/gorilla/websocket
    3958 stars, 2393 imports
    golang.org/x/net/websocket
    1412 imports


    View Slide

21. View Slide

22. package main
    import (
    "log"
    "net/http"
    )
    func handleUpgrade(w http.ResponseWriter, r *http.Request) {
    // TODO
    }
    func main() {
    http.HandleFunc("/websocket", handleUpgrade)
    err := http.ListenAndServe(":4000", nil)
    if err != nil {
    panic(err)
    }
    }


    View Slide

23. package main
    import (
    "log"
    "net/http"
    )
    var upgrader = websocket.Upgrader{}
    func handleUpgrade(w http.ResponseWriter, r *http.Request) {
    // TODO
    }
    func main() {
    http.HandleFunc("/websocket", handleUpgrade)
    err := http.ListenAndServe(":4000", nil)
    if err != nil {
    panic(err)
    }
    }


    View Slide

24. package main
    import (
    "log"
    "net/http"
    )
    var upgrader = websocket.Upgrader{}
    func handleUpgrade(w http.ResponseWriter, r *http.Request) {
    conn, err := upgrader.Upgrade(w, r, nil)
    if err != nil {
    panic(err)
    }
    defer conn.Close()
    // TODO
    }
    func main() {
    http.HandleFunc("/websocket", handleUpgrade)
    // …


    View Slide

25. package main
    import (
    "log"
    "net/http"
    )
    var upgrader = websocket.Upgrader{}
    func handleUpgrade(w http.ResponseWriter, r *http.Request) {
    conn, err := upgrader.Upgrade(w, r, nil)
    if err != nil {
    panic(err)
    }
    defer conn.Close()
    handleConnection(conn)
    }
    func main() {
    http.HandleFunc("/websocket", handleUpgrade)
    // …


    View Slide

26. func handleConnection(conn *websocket.Conn) {
    for {
    messageType, message, err := c.ReadMessage()
    if err != nil {
    break
    }
    log.Println(message)
    err = c.WriteMessage(messageType, message)
    if err != nil {
    break
    }
    }
    }


    View Slide

27. This is a solved problem!


    View Slide

28. Parse, Firebase, Pusher
    - Data synchronization services offer an off-the-shelf software solution
    - Trade the cost of implementation against the cost of learning their API
    - Force an opinionated structure on your data
    - Limited querying capabilities
    - They manage sessions for you but you still need to integrate them
    - Upside: offers scalability out of the box


    View Slide

29. Backend Clients
    API
    Database
    HTTP


    View Slide

30. Backend Clients
    API
    Database
    HTTP
    Polling


    View Slide

31. Push
    Backend Clients
    API
    Database
    WebSocket
    Bus


    View Slide

32. Backend Clients
    API
    Database
    WebSocket
    Bus
    Subscribe
    Publish
    State change
    Push


    View Slide

33. Backend Clients
    API
    Database
    WebSocket
    Bus
    Subscribe
    Publish
    State change
    Push


    View Slide

34. Backend Clients
    API
    Database
    WebSocket
    {"cmd”:"listUsers"}
    Push


    View Slide

35. Backend Clients
    API
    Database
    WebSocket
    "CONNECT"
    "LIST_USERS"
    Push


    View Slide

36. type MessageEndpoint func(ctx context.Context, m Message, w *Writer) error
    type Router struct {
    endpoints map[string]MessageEndpoint
    writer map[string]*Writer
    }
    func (r *Router) HandleConnection(conn *websocket.Conn) {
    w := r.NewWriter(conn)
    for {
    _, message, err := conn.ReadMessage()
    if err != nil {
    break
    }
    request := string(message)
    r.writer[w.ID] = w
    r.Route(context.Background(), w, request)
    }
    delete(r.writer, r.ID(conn))
    }


    View Slide

37. type MessageEndpoint func(ctx context.Context, m Message, w *Writer) error
    type Router struct {
    endpoints map[string]MessageEndpoint
    writer map[string]*Writer
    }
    func (r *Router) HandleConnection(conn *websocket.Conn) {
    w := r.NewWriter(conn)
    for {
    _, message, err := conn.ReadMessage()
    if err != nil {
    break
    }
    request := string(message)
    r.writer[w.ID] = w
    go r.Route(context.Background(), w, request)
    }
    delete(r.writer, r.ID(conn))
    }


    View Slide

38. type Writer struct {
    ID int
    conn *websocket.Conn
    }
    func (w *Writer) Write(data []byte) (int, error) {
    err := w.conn.WriteMessage(websocket.TextMessage, data)
    if err != nil {
    return 0, err
    }
    return len(data), nil
    }


    View Slide

39. type Writer struct {
    ID int
    conn *websocket.Conn
    }
    func (w *Writer) Write(data []byte) (int, error) {
    err := w.conn.WriteMessage(websocket.TextMessage, data)
    if err != nil {
    return 0, err
    }
    return len(data), nil
    }
    panic: concurrent write to websocket connection


    View Slide

40. type Writer struct {
    ID int
    conn *websocket.Conn
    }
    func (w *Writer) Write(data []byte) (int, error) {
    err := w.conn.WriteMessage(websocket.TextMessage, data)
    if err != nil {
    return 0, err
    }
    return len(data), nil
    }


    View Slide

41. type Writer struct {
    ID int
    mu sync.RWMutex
    conn *websocket.Conn
    }
    func (w *Writer) Write(data []byte) (int, error) {
    w.mu.Lock()
    defer w.mu.Unlock()
    err := w.conn.WriteMessage(websocket.TextMessage, data)
    if err != nil {
    return 0, err
    }
    return len(data), nil
    }


    View Slide

42. Is it safe to send passwords in
    clear text over WebSockets?


    View Slide

43. Security
    - There are two modes: unencrypted ws:// and encrypted wss://
    - Encrypted mode uses TLS/SSL encryption to encrypt all data sent
    - This includes the initial hand-shake
    What about sessions?
    - WebSockets are stateful: we can and should make use of this.


    View Slide

44. Sessions
    - Naive approach: be stateless, send a session ID with every request
    - Alternative: make use of the persistent connection
    - Authenticate once through query parameter when connecting
    wss://example.com/api?sessionID=token
    - Protects much better against CSRF attacks


    View Slide

45. package main
    import (
    "log"
    "net/http"
    )
    var upgrader = websocket.Upgrader{}
    func handleUpgrade(w http.ResponseWriter, r *http.Request) {
    conn, err := upgrader.Upgrade(w, r, nil)
    if err != nil {
    panic(err)
    }
    defer conn.Close()
    handleConnection(conn)
    }


    View Slide

46. package main
    import (
    "log"
    "net/http"
    )
    var upgrader = websocket.Upgrader{}
    func handleUpgrade(w http.ResponseWriter, r *http.Request) {
    conn, err := upgrader.Upgrade(w, r, nil)
    if err != nil {
    panic(err)
    }
    sessionID := req.URL.Query().Get("sessionID")
    defer conn.Close()
    handleConnection(conn, sessionID)
    }


    View Slide

47. Scaling WebSocket Architectures
    When Client 1 persists data through Server 1 how will Client 2 learn about
    this who is connected to Server 2?
    - Publish/Subscribe Broker to implement message bus
    - This also takes care of handling failover
    - Load balancers like AWS ELB support Proxy Protocol for TCP mode
    - There is a hard limit of 65,535 ports per IP address
    - Combination of DNS and software load balancer


    View Slide

48. Client
    Server Server Server
    Load Balancer Load Balancer
    Client Client Client Client Client Client Client
    Server Server
    Message Bus
    DNS
    Server


    View Slide

49. https://github.com/gobwas/ws
    - Efficient low-level WebSocket library
    - Allow users to reuse I/O buffers between connections
    - Export efficient low-level interface for working with the protocol
    Zero-Copy Upgrade
    - Skips the need to use HTTP for upgrading
    - ws.Upgrade() accepts io.ReadWriter (net.Conn)


    View Slide

50. Summary
    - REST can be implemented using WebSockets
    - WebSockets allow us to implement a push architecture
    - Freedom in designing a sub-protocol tailored to your system’s needs
    - Also useful for connecting backend components
    - Gorilla WebSocket is a great implementation of RFC 6455
    - Rolling your own implementation can be costly
    - Scaling WebSockets is nontrivial
    - Bad compatibility to the outside world


    View Slide

51. Thank you.
    @konradreiche


    View Slide

52. Questions?
    @konradreiche


    View Slide
