Neatly Folding a Tree: Functional Perl5 AWS Glacier Hashes

When functional programming works it is elegant and efficient. The AWS "Tree Hash" used to validate uploads is nice fodder for recursion, but has problems with stack size. The Perl5 features for implementing tail call recursion that reduces the stack but they look ugly. Fortunately, Perl5 also has Keyword::Declare to wrap the the Tail Call Recursion into a neat package.

This talk describes the Glacier Tree Hash, Tail Call Elimination in general, implementing it in Perl5, and going a few steps further to implement the solution in fast, minimal functional code.

Transcript

1. Neatly Folding a Tree:
   Functional Perl5 AWS Glacier Hashes
   Steven Lembark
   Workhorse Computing
   lembark@wrkhors.com


   View Slide

2. In the beginning...
   There was Spaghetti Code.
   And it was bad.


   View Slide

3. In the beginning...
   There was Spaghetti Code.
   And it was bad.
   So we invented Objects.


   View Slide

4. In the beginning...
   There was Spaghetti Code.
   And it was bad.
   So we invented Objects.
   Now we have Spaghetti Objects.


   View Slide

5. Alternative: Fucntional Programming
   Based on Lambda Calculus.
   Few basic ideas:
   Transparency.
   Consistency.


   View Slide

6. Basic rules
   Constant data.
   Transparent transforms.
   Functions require input.
   Output determined fully by inputs.
   Avoid internal state & side effects.


   View Slide

7. Catch: It doesn't always work.
   time()
   random()
   readline()
   fetchrow_array()
   Result: State matters!
   Fix: Apply reality.


   View Slide

8. Where it does: Tree Hash
   Used with AWS “Glacier” service.
   $0.01/GiB/Month.
   Large, cold data (discounts for EiB, PiB).
   Uploads require lots of sha256 values.


   View Slide

9. Digesting large chunks
   Uploads chunked in multiples of 1MB.
   Digest for each chunk & entire upload.
   Result: tree-hash.


   View Slide

10. Image from Amazon Developer Guide (API Version 2012-06-01)
    http://docs.aws.amazon.com/amazonglacier/latest/dev/checksum-calculations.html


    View Slide

11. One solution from Net::Amazon::TreeHash
    sub calc_tree
    {
    my ($self) = @_;
    my $prev_level = 0;
    while (scalar @{ $self->{tree}->[$prev_level] } > 1) {
    my $curr_level = $prev_level+1;
    $self->{tree}->[$curr_level] = [];
    my $prev_tree = $self->{tree}->[$prev_level];
    my $curr_tree = $self->{tree}->[$curr_level];
    my $len = scalar @$prev_tree;
    for (my $i = 0; $i < $len; $i += 2) {
    if ($len - $i > 1) {
    my $a = $prev_tree->[$i];
    my $b = $prev_tree->[$i+1];
    push @$curr_tree, { joined => 0, start => $a->{start}, finish => $b->{finish},
    hash => sha256( $a->{hash}.$b->{hash} ) };
    } else {
    push @$curr_tree, $prev_tree->[$i];
    }
    }
    $prev_level = $curr_level;
    }


    View Slide

12. Possibly simpler?
    Trees are naturally recursive.
    Two-step generation:
    Split the buffer.
    Reduce the hashes.


    View Slide

13. Pass 1: Reduce the hashes
    Reduce pairs.
    Until one value
    remaining.
    sub reduce_hash
    {
    # undef for empty list
    @_ > 1 or return $_[0];
    my $count = @_ / 2 + @_ % 2;
    reduce_hash
    map
    {
    @_ > 1
    ? sha256 splice @_, 0, 2
    : shift
    }
    ( 1 .. $count )
    }


    View Slide

14. Pass 1: Reduce the hashes
    Reduce pairs.
    Until one value
    remaining.
    Catch:
    Eats Stack
    sub reduce_hash
    {
    # undef for empty list
    @_ > 1 or return $_[0];
    my $count = @_ / 2 + @_ % 2;
    reduce_hash
    map
    {
    @_ > 1
    ? sha256 splice @_, 0, 2
    : shift
    }
    ( 1 .. $count )
    }


    View Slide

15. Chasing your tail
    Tail recursion is common.
    "Tail call elimination" recycles stack.
    "Fold" is a feature of FP languages.
    Reduces the stack to a scalar.


    View Slide

16. Fold in Perl5
    Reset the
    stack.
    Restart the
    sub.
    my $foo =
    sub
    {
    @_ > 1 or return $_[0];
    @_ = … ;
    # new in v5.16
    goto __SUB__
    };


    View Slide

17. Pass 2: Reduce hashes
    Viola!
    Stack
    shrinks.
    sub reduce_hash
    {
    2 > @_ and return $_[0];
    my $count = @_ / 2 + @_ % 2;
    @_
    = map
    {
    @_ > 1
    ? sha256 splice @_, 0, 2
    : @_
    }
    ( 1 .. $count );
    goto __SUB__
    };


    View Slide

18. Pass 2: Reduce hashes
    Viola!
    Stack
    shrinks.
    @_ =
    is ugly.
    sub reduce_hash
    {
    2 > @_ and return $_[0];
    my $count = @_ / 2 + @_ % 2;
    @_
    = map
    {
    @_ > 1
    ? sha256 splice @_, 0, 2
    : @_
    }
    ( 1 .. $count );
    goto __SUB__
    };


    View Slide

19. Pass 2: Reduce hashes
    Viola!
    Stack
    shrinks.
    @_ =
    is ugly.
    goto scares
    people.
    sub reduce_hash
    {
    2 > @_ and return $_[0];
    my $count = @_ / 2 + @_ % 2;
    @_
    = map
    {
    @_ > 1
    ? sha256 splice @_, 0, 2
    : @_
    }
    ( 1 .. $count );
    goto __SUB__
    };


    View Slide

20. "Fold" is an FP Pattern.
    use Keyword::Declare;
    keyword tree_fold ( Ident $name, Block $new_list )
    {
    qq
    {
    sub $name
    {
    \@_ or return;
    ( \@_ = do $new_list ) > 1;
    and goto __SUB__;
    $_[0]
    }
    }
    }
    $new_list is
    source code
    not a subref!
    So is the
    result of
    interpolating
    it.


    View Slide

21. "Fold" is an FP Pattern.
    use Keyword::Declare;
    keyword tree_fold ( Ident $name, Block $new_list )
    {
    qq
    {
    sub $name
    {
    \@_ or return;
    ( \@_ = do $new_list ) > 1;
    and goto __SUB__;
    $_[0]
    }
    }
    }
    See K::D
    POD for
    {{{…}}}
    to avoid "\
    @_".


    View Slide

22. Minimal syntax
    tree_fold reduce_hash
    {
    my $count = @_ / 2 + @_ % 2;
    map
    {
    @_ > 1
    ? sha256 splice @_, 0, 2
    : @_
    }
    ( 1 .. $count )
    }
    User
    supplies
    generator
    a.k.a
    $new_list


    View Slide

23. Minimal syntax
    tree_fold reduce_hash
    {
    my $count = @_ / 2 + @_ % 2;
    map
    {
    @_ > 1
    ? sha256 splice @_, 0, 2
    : @_
    }
    ( 1 .. $count )
    }
    User
    supplies
    generator.
    NQFP:
    Hacks the
    stack.


    View Slide

24. Don't hack the stack
    Replace splice
    with offsets.
    tree_fold reduce_hash
    {
    my $last = @_ / 2 + @_ % 2 - 1;
    map
    {
    $_[ $_ + 1 ]
    ? sha256 @_[ $_, $_ + 1 ]
    : $_[ $_ ]
    }
    map
    {
    2 * $_
    }
    ( 0 .. $last )
    }


    View Slide

25. Don't hack the stack
    Replace splice
    with offsets.
    Still messy:
    @_,
    stacked map.
    tree_fold reduce_hash
    {
    my $last = @_ / 2 + @_ % 2 - 1;
    map
    {
    $_[ $_ + 1 ]
    ? sha256 @_[ $_, $_ + 1 ]
    : $_[ $_ ]
    }
    map
    {
    2 * $_
    }
    ( 0 .. $last )
    }


    View Slide

26. Using lexical variables
    Declare
    fold_hash with
    parameters.
    Caller uses
    lexical vars.
    keyword tree_fold
    (
    Ident $name,
    List $argz,
    Block $stack_op
    )
    {
    ...
    }


    View Slide

27. Boilerplate for lexical variables
    Extract lexical
    variables.
    See also:
    PPI::Token
    my @varz # ( '$foo', '$bar' )
    = map
    {
    $_->isa( 'PPI::Token::Symbol' )
    ? $_->{ content }
    : ()
    }
    map
    {
    $_->isa( 'PPI::Statement::Expression' )
    ? @{ $_->{ children } }
    : ()
    }
    @{ $argz->{ children } };


    View Slide

28. Boilerplate for lexical variables
    my $lexical = join ',' => @varz;
    my $count = @varz;
    my $offset = $count -1;
    sub $name
    {
    \@_ or return;
    my \$last
    = \@_ % $count
    ? int( \@_ / $count )
    : int( \@_ / $count ) - 1
    ;
    ...
    Count & offset
    used to extract
    stack.


    View Slide

29. Boilerplate for lexical variables
    \@_
    = map
    {
    my ( $lexical )
    = \@_[ \$_ .. \$_ + $offset ];
    do $stack_op
    }
    map
    {
    \$_ * $count
    }
    ( 0 .. \$last );
    Interpolate
    variable
    names, count,
    stack offset.


    View Slide

30. Chop shop
    Not much
    body left:
    tree_fold reduce_hash($left, $rite)
    {
    $rite
    ? sha2656 $left, $rite
    : $left
    }


    View Slide

31. FP uses constants
    Replace lexical var's with values.
    Constant module uses ties.
    Slow, only one tie per variable.


    View Slide

32. FP uses constants
    Replace lexical var's with values.
    Const::Fast handles scalar, array, hash.
    Uses SV magic struct.
    Conflicts with bless (magic gets set too early).


    View Slide

33. FP uses constants
    Replace lexical var's with values.
    Data::Lock sets the magic later.
    Co-exist with bless.


    View Slide

34. Fast perly constants
    lvalue
    wrapper
    delays dlock.
    Plays nice
    with bless.
    sub const : lvalue
    {
    dlock $_[0];
    $_[0]
    }


    View Slide

35. Putting the fun into Perl5
    Cannot modify
    $last, $_,
    return values.
    tree_fold reduce_hash
    {
    const my $last = @_ / 2 + @_ % 2 - 1;
    map
    {
    $_[ $_ + 1 ]
    ? const sha256 @_[ $_, $_ + 1 ]
    : const $_[ $_ ]
    }
    map
    {
    const 2 * $_
    }
    ( 0 .. $last )
    }


    View Slide

36. Consume the buffer.
    Prior to 5.20: Pass large string by ref.
    Example: File::Slurp returns ref-to-scalar.
    e.g., my $size = length $$buffer;
    That or use $_[$i] directly to avoid copies.


    View Slide

37. Magic constants
    Const for
    variable,
    subroutine
    results.
    use Glacier::Util::Const qw( const );
    keyword value( Var $var )
    {{{
    const my <{$var}>
    }}}
    keyword value
    {{{
    const
    }}}


    View Slide

38. value keyword
    Keywords can
    be nested:
    tree_fold reduce_hash
    {
    value $last = @_ / 2 + @_ % 2 - 1;
    map
    {
    $_[ $_ + 1 ]
    ? value sha256 @_[ $_, $_ + 1 ]
    : value $_[ $_ ]
    }
    map
    {
    value 2 * $_
    }
    ( 0 .. $last )
    }


    View Slide

39. value keyword
    Or just: tree_fold reduce_hash( $left, $rite )
    {
    value
    $rite
    ? sha256 $left, $rite
    : $left
    }


    View Slide

40. Avoid a copy: $$buffer
    Map input to
    chunks.
    Reduce them.
    Done.
    sub buffer_hash
    {
    state $mb = 2 ** 20;
    my $buffer = shift;
    my $size = length $$buffer;
    my $count
    = int $size / $mb + !!( $size % $mb );
    reduce_hash
    map
    {
    sha256
    substr $$buffer, 0, $mib, ''
    }
    ( 1 .. $count )
    }


    View Slide

41. ● Q: What is left after hash_buffer?
    A: An empty buffer.


    View Slide

42. ● Q: What is left after hash_buffer?
    A: An empty buffer.
    The caller's buffer!
    Oops... caller needs a copy to upload!
    Result: No memory savings at all.


    View Slide

43. Easier in v5.20+
    Pass buffer
    as‑is.
    COW preserves
    caller's buffer.
    No extra copy.
    sub buffer_hash
    {
    state $mb = 2 ** 20;
    my $buffer = shift;
    my $size = length $$buffer;
    my $count
    = int $size / $mb + !!( $size % $mb );
    reduce_hash
    map
    {
    sha256
    substr $$buffer, 0, $mib, ''
    }
    ( 1 .. $count )
    }


    View Slide

44. Now try it with FP
    Consuming $buffer breaks the rules.
    Find a way to extract the pieces.


    View Slide

45. Buffer hash with only copies
    unpack is the
    fastest way.
    Less code.
    One copy of
    buffer.
    sub buffer hash
    {
    state $format = '(a' . 2**20 . ')*';
    const my $buffer = shift;
    reduce_hash
    map
    {
    const sha256 $_
    }
    unpack $format => $buffer
    };


    View Slide

46. Public interface
    sub tree_hash
    {
    @_ > 1
    ? &reduce_hash
    : &buffer_hash
    }
    sub tree_hash_hex
    {
    unpack 'H*', &tree_hash
    }
    Multi-part:
    hash hashes.
    Single-part
    hashes buffer.
    Useful for
    tesing:


    View Slide

47. Buffer Size vs. Usr Time
    Explicit map,
    keyword with
    and without
    lexicals.
    8-32MiB are
    good chunk
    sizes.
    MiB Explicit Implicit Keyword
    1 0.02 0.01 0.02
    2 0.03 0.03 0.04
    4 0.07 0.07 0.07
    8 0.14 0.13 0.10
    16 0.19 0.18 0.17
    32 0.31 0.30 0.26
    64 0.50 0.51 0.49
    128 1.00 1.02 1.01
    256 2.03 2.03 2.03
    512 4.05 4.10 4.06
    1024 8.10 8.10 8.11


    View Slide

48. Result: FP in Perl5
    When FP works it is elegant.
    Core Perl5 syntax helps:
    lvalue
    __SUB__
    COW strings


    View Slide

49. Result: FP in Perl5d
    When FP works it is elegant.
    Keywords: True Lazyness ® at its best.
    Don't repeat boilerplate.
    Multimethods in Perl5.


    View Slide
