SPAAAAAAAAACE

listrophy
August 12, 2014

 SPAAAAAAAAACE

Let's learn us a space exploration! In this talk, Brad will wax poetic on the particulars of getting into space, getting around in space, and getting things done in space. PID controllers, orbital insertion, and how rockets work by smashing molecules together. There may or may not be any math, programming, or vacuum-induced hypoxia in this talk.

listrophy

August 12, 2014
Tweet

More Decks by listrophy

Other Decks in Science

Transcript

  1. Carl Sagan
    Pale Blue Dot
    Photo in public domain via Wikimedia Commons

    View full-size slide

  2. Photos in public domain via Wikimedia Commons

    View full-size slide

  3. Photos in public domain via Wikimedia Commons
    Charlie Duke photo courtesy of charlieduke.net

    View full-size slide

  4. Apollo Guidance Computer
    Compared to iPhone 5S:
    • 284 times heavier
    • 2600 times slower (Hz)
    • 17 million times less memory
    Photo in public domain via Wikimedia Commons

    View full-size slide

  5. image credit: imgur.com/Cuwy6wZ

    View full-size slide

  6. image courtesy: kickstarter.com
    image courtesy: louxfamilyblog.com

    View full-size slide

  7. image courtesy: mic.com
    image courtesy: atlantablackstar.com

    View full-size slide

  8. Boeing
    Lockheed Martin
    United Space Alliance
    SpaceX
    Bigelow Aerospace
    Armadillo Aerospace
    Hamilton Sundstrand

    View full-size slide

  9. Brad Grzesiak
    CEO, Bendyworks
    @listrophy

    View full-size slide

  10. A Fire Upon the Deep
    Ashes of Victory
    At All Costs
    Earth Unaware
    Echoes of Honor
    Ender’s Game
    Children of the Mind
    Ender’s Shadow
    First Meetings
    Flag in Exile
    Honor Among Enemies
    Field of Dishonor
    An Incomplete List
    In Enemy Hands
    Mission of Honor
    On Basilisk Station
    Shadow Puppets
    Shadow of the Giant
    Shadow of the Hegemon
    Red Mars
    Speaker for the Dead
    The Short Victorious War
    War of Honor
    Wool
    The Honor of the Queen

    View full-size slide

  11. Pre-Bendyworks
    Photos courtesy NASA & Michael Fidler

    View full-size slide

  12. Launch
    Orbit
    Landing

    View full-size slide

  13. “Rocket Science”

    View full-size slide

  14. Orbital Requirements
    • 1 Large Body, 1 Small Body
    • Circumferential Velocity
    • Only Gravity
    • No Intersection

    View full-size slide

  15. Let’s Do a Physics!

    View full-size slide

  16. Photo in public domain via Wikimedia Commons

    View full-size slide

  17. Portland
    Seattle
    2.1º

    View full-size slide

  18. Portland → Seattle
    • 145 miles
    • 30 seconds
    • >17,000 mph

    View full-size slide

  19. Kinetic Energy
    Ek = ½ m v2
    Ek / kg = ½ (17,000 mph)2
    Ek / kg = 29.6 MJ

    View full-size slide

  20. Potential Energy
    Ep = mgh
    Ep / kg = (9.81 m/s2)(330 km)
    Ep / kg = 3.2 MJ

    View full-size slide

  21. Kinetic (speed)
    vs.
    Potential (height)
    Speed = 29.6 MJ
    Height = 3.2 MJ

    View full-size slide

  22. Equatorial Surface Speed
    • 1,040 mph
    • With help: 16,000 mph
    • Without help: 17,000 mph
    • Savings: ~5.4%

    View full-size slide

  23. Conservation of
    Momentum

    View full-size slide

  24. Momentum
    # p = mv!
    !
    def momentum(grams, meters_per_second)!
    grams * meters_per_second!
    end

    View full-size slide

  25. Conservation of Momentum
    def system_momentum(objects)!
    objects.reduce(0) do |sum, (mass, velocity)|!
    sum + momentum(mass, velocity)!
    end!
    end!
    !
    !
    assert_equal \!
    system_momentum([[100 , 0 ], [100_000 , 0 ]]),!
    system_momentum([[100 , -10 ], [100_000 , 0.01 ]])!
    # g m/s g m/s

    View full-size slide

  26. Conservation of Momentum
    def system_momentum(objects)!
    objects.reduce(0) do |sum, (mass, velocity)|!
    sum + momentum(mass, velocity)!
    end!
    end!
    !
    K = 1_000!
    assert_equal \!
    system_momentum([[100*K, 0*K], [100_000*K, 0*K ]]),!
    system_momentum([[100*K, -10*K], [100_000*K, 0.01*K]])!
    # kg km/s kg km/s
    (modified for rocketry)

    View full-size slide

  27. One Weird Trick!

    View full-size slide

  28. Converging-Diverging
    Nozzle
    choke
    SPEED!
    LIMIT
    1
    MACH
    Mach!
    13
    High
    Pressure

    View full-size slide

  29. Kepler’s Laws of
    Planetary Motion

    View full-size slide

  30. Kepler’s First Law
    Diagrams will not be to scale

    View full-size slide

  31. Eccentricity
    def type_of_trajectory(e)!
    case e!
    when 0.0 then :circle!
    when 0.0...1.0 then :ellipse!
    when 1.0 then :parabola!
    else :hyperbola!
    end!
    end

    View full-size slide

  32. Eccentricities
    Eccentricities = {!
    earth: 0.0167,!
    venus: 0.0067,!
    neptune: 0.00868,!
    # ...!
    }

    View full-size slide

  33. Orbital Points of Interest
    peri- apo-
    Closest Farthest
    Earth Perigee Apogee
    Sun Perihelion Aphelion
    Any Periapsis Apoapsis

    View full-size slide

  34. Kepler’s Second Law
    Fastest
    Slowest

    View full-size slide

  35. Kepler’s Third Law
    # P₁² P₂²!
    # --- = ---!
    # a₁³ a₂³!
    !
    def solar_period(distance_in_au)!
    Math.sqrt(!
    365.26**2 / # earth's period!
    1**3 * # earth's distance in AU!
    distance_in_au**3!
    )!
    end

    View full-size slide

  36. Orbital Periods
    Distance (AU) Duration (days)
    Earth 1.0 365.26
    Venus 0.73 (-27%) 226.5 (-38%)
    Mars 1.52 (+52%) 686.7 (+88%)

    View full-size slide

  37. Kepler’s Laws of
    Planetary Motion
    1. Orbits are elliptical
    2. Faster when closer; Slower when farther
    3. Big orbits take longer

    View full-size slide

  38. Trip to Mars

    View full-size slide

  39. 29.8 km/s
    32.7 km/s
    Leaving Earth

    View full-size slide

  40. Arriving at Mars
    21.5 km/s
    24.1 km/s
    Trip Length: 8.5 months

    View full-size slide

  41. Hohmann Transfer
    Orbit

    View full-size slide

  42. Landing
    • Moon
    • Mars
    • Earth (return trip)

    View full-size slide

  43. Earth Mars

    View full-size slide

  44. Aerobraking
    • Distance so far: 364 million miles
    • Aerobraking window: <100 miles?

    View full-size slide

  45. Retrorockets

    View full-size slide

  46. Kerbal Space
    Program

    View full-size slide

  47. require 'excon'!
    require 'kuby'!
    !
    link = Kuby::Link.new!
    link.connect! or fail 'Could not connect'!
    !
    link.throttle_full!
    link.toggle_sas!
    !
    link.stage! and sleep 2!
    !
    prev_err = error =!
    integral = derivative = 0.0!
    !
    prev_time = link.mission_time
    gitlab.com/listrophy/spaaaaaaaaace

    View full-size slide

  48. loop do!
    cur_time = link.mission_time!
    dt = cur_time - prev_time!
    error = 150.0 - link.altitude!
    integral = integral + error * dt!
    derivative = (error - prev_err)/dt!
    !
    kp, ki, kd = 0.1, 0.003, 0.08!
    new_throttle = (kp*error + ki*integral + kd*derivative)!
    !
    new_throttle = 1.0 if new_throttle > 1.0!
    new_throttle = 0.0 if new_throttle < 0.0!
    !
    link.set_throttle new_throttle!
    !
    prev_err, prev_time = error, cur_time!
    sleep 0.2!
    end
    gitlab.com/listrophy/spaaaaaaaaace

    View full-size slide

  49. Throttle → Height
    • Force = mass * acceleration
    • ∫ acceleration dt = velocity
    • ∫ velocity dt = height

    View full-size slide

  50. loop do!
    cur_time = link.mission_time!
    dt = cur_time - prev_time!
    error = 150.0 - link.altitude!
    integral = integral + error * dt!
    derivative = (error - prev_err)/dt!
    !
    kp, ki, kd = 0.1, 0.003, 0.08!
    new_throttle = (kp*error + ki*integral + kd*derivative)!
    !
    new_throttle = 1.0 if new_throttle > 1.0!
    new_throttle = 0.0 if new_throttle < 0.0!
    !
    link.set_throttle new_throttle!
    !
    prev_err, prev_time = error, cur_time!
    sleep 0.2!
    end
    gitlab.com/listrophy/spaaaaaaaaace

    View full-size slide

  51. Launch, Orbit,
    Landing
    Nuclear Pulse Propulsion

    View full-size slide

  52. Photo in public domain via Wikimedia Commons

    View full-size slide

  53. Thank You
    @listrophy
