1. Simplify Challenging
   Software Problems with
   Rocket Science
   @bendyworks
   Brad Grzesiak — @listrophy


   View Slide

2. –Ashe Dryden
   “Whenever Brad is drinking, you
   wanna make sure you're sitting
   next to him, because instead of
   being obnoxious, he teaches you
   orbital mechanics.”


   View Slide

3. Heads up:
   1 Animated GIF


   View Slide

4. Agenda
   • Reduce Cognitive Load
   • Visualize Simulations with Graphics
   • Control and Respond to Real World Processes


   View Slide

5. Agenda
   • Reduce Cognitive Load
   • Visualize Simulations with Graphics
   • Control and Respond to Real World Processes


   View Slide

6. we
   are
   not
   superheros


   View Slide

7. Scalars & Collections
   Primitives & Arrays
   • x, y, z = 2, 3, 5
   • Math.sqrt(x**2 + y**2 + z**2)
   • array.zip(other).map{|(i,j)| i+j}
   • [m[0][0]*v[0]+m[0][1]*v[1],
   m[1][0]*v[0]+m[1][1]*v[1]]
   Vectors & Matrices
   • vector = Vector[2, 3, 5]
   • vector.magnitude # or vector.r
   • vector_1 + vector_2
   • matrix * vector



   View Slide

8. “matrix”
   “times”
   “vector?”


   View Slide

9. Linear Transformations
   • Scale, Rotate, Skew, Translate (with a trick)
   • Common in CSS3
   • Common in Kinetics & Kinematics


   View Slide

10. Matrix Times Vector
    1.  ⽷a    b⽹⽷x⽹
         ⽸c    d⽺⽸y⽺
    2.  ［x    y］
         ⽷a    b⽹
         ⽸c    d⽺
    3.  ⽷ax+by⽹
         ⽸cx+dy⽺


    View Slide

11. Matrix Times Vector
    def matrix_times_vector(m, v)
    a, b = m[0]
    c, d = m[1]
    x, y = v
    [
    a*x + b*y,
    c*x + d*y
    ]
    end
    require 'matrix'
    def matrix_times_vector(m, v)
    m * v
    end
    NOW
    WITH DIM
    CHECKS!


    View Slide

12. Rotation Matrix
    R(θ)  =  ⽷cosθ  -­‐sinθ⽹
                 ⽸sinθ    cosθ⽺
    R(30deg)*⟨1,0⟩  =  ⟨0.87,0.5⟩
    R(90deg)*⟨1,0⟩  =  ⟨0,1⟩


    View Slide

13. Rotation Matrix
    R(-­‐30deg)*                        =


    View Slide

14. Agenda
    • Reduce Cognitive Load
    • Visualize Simulations with Graphics
    • Control and Respond to Real World Processes


    View Slide

15. Why Graphic Simulations?
    • Complex Systems
    • High Sensitivity
    • Pattern Recognition Required
    • Seeking “Good Enough”


    View Slide

16. In Aerospace Engineering
    • Launch Vibration Testing
    • “Kick” tests
    • Thermal Equilibrium
    • Designing to Safety Factor


    View Slide

17. In Aerospace Engineering
    • Launch Vibration Testing
    • “Kick” tests
    • Thermal Equilibrium
    • Designing to Safety Factor
    • N-Body Orbital Trajectories


    View Slide

18. The n-Body Problem
    • Newton’s Laws + Gravity
    • Solved for N=2
    • For N>2, “no general analytical solution,” except for
    special cases (e.g., Lagrangian Points)


    View Slide

19. The n-Body Problem
    Gravity Force = x
    Newton’s 2nd Law Force = mass ⨉ acceleration
    Newton’s 3rd Law Force₁ = -Force₂
    Velocity-Acceleration
    Position-Velocity


    View Slide

20. Wait a minute.
    Derivatives?


    View Slide

21. Formal Derivative


    View Slide

22. Our Approximation


    View Slide

23. Our Approximation


    View Slide

24. Our Approximation


    View Slide

25. The n-Body Problem
    Gravity Force = x
    Newton’s 2nd Law Force = mass ⨉ acceleration
    Newton’s 3rd Law Force₁ = -Force₂
    Velocity-Acceleration
    Position-Velocity


    View Slide

26. The n-Body Problem
    Gravity Force = x
    Newton’s 2nd Law Force = mass ⨉ acceleration
    Newton’s 3rd Law Force₁ = -Force₂
    Velocity-Acceleration vnow = vprev + anow dt
    Position-Velocity xnow = xprev + vnow dt


    View Slide

27. The n-Body Problem
    Gravity Force = x
    Newton’s 2nd Law acceleration = Force ÷ mass
    Newton’s 3rd Law Force₁ = -Force₂
    Velocity-Acceleration vnow = vprev + anow dt
    Position-Velocity xnow = xprev + vnow dt


    View Slide

28. Gravity Fnow = x
    Newton’s 2nd Law anow = Fnow ÷ m
    Newton’s 3rd Law (loop over each mass-pair)
    Velocity-Acceleration vnow = vprev + anow dt
    Position-Velocity xnow = xprev + vnow dt
    The n-Body Problem


    View Slide

29. The n-Body Problem
    bodies.map do |body|
    [body, gravity(body, bodies-[body])]
    end.each do |(body, force)|
    accel = force / body.mass
    body.velocity += accel * dt
    body.position += body.velocity * dt
    end


    View Slide

30. The n-Body Problem
    def gravity(body, others)
    others.reduce(Vector[0,0]) do |memo, other|
    offset = other.position - body.position
    memo + offset * G * body.mass * other.mass / offset.r**3
    end
    end


    View Slide

31. (demo)


    View Slide

32. Agenda
    • Reduce Cognitive Load
    • Visualize Simulations with Graphics
    • Control and Respond to Real World Processes


    View Slide

33. The World is Complicated
    • “Assume no air resistance”
    • “Assume a frictionless surface”
    • “Assume perfect DC voltage”
    • “Assume no impact from general or special
    relativity”


    View Slide

34. You simply cannot predefine a
    specific solution to a problem that
    is perturbed by the real world


    View Slide

35. –Helmuth von Moltke the Elder
    “No battle plan ever survives
    contact with the enemy.”


    View Slide

36. The Answer: React


    View Slide

37. Feedback Controller


    View Slide

38. Feedback Controller


    View Slide

39. Feedback Controller


    View Slide

40. PID Controller


    View Slide

41. Controller
    P
    I
    D
    roportional
    ntegral
    erivative


    View Slide

42. Feedback Controller
    diff == error


    View Slide

43. Proportional
    P  =  error  =  desired  -­‐  actual


    View Slide

44. Derivative
    D  =  (error  -­‐  prev_error)/dt


    View Slide

45. Integral
    I  =  I  +  error*dt


    View Slide

46. Our PID Controller
    loop do
    sleep 0.2
    curr_time = Time.now
    dt = curr_time - prev_time
    p = error = desired - actual
    i = i + error * dt
    d = (error - prev_error)/dt
    setThrust(0.1*p + 0.003*i + 0.08*d)
    prev_error, prev_time = error, curr_time
    end


    View Slide

47. (demo)


    View Slide

48. Agenda
    • Reduce Cognitive Load
    • Visualize Simulations with Graphics
    • Control and Respond to Real World Processes


    View Slide

49. Photo Credits
    • “ABS/EUTELSAT-1 Launch” (Public Domain):

    http://www.spacex.com/media-gallery/detail/127081/4896
    • “Beer Actor” (CC-BY):

    https://www.flickr.com/photos/cogdog/21127813750/
    • “Up, up and away!” (CC-BY-SA):

    https://www.flickr.com/photos/kindercapes/5694816038
    • “I’m confused” (CC-BY-SA):

    https://www.flickr.com/photos/doctabu/342220423
    • “Cookie Monster Waiting” (no idea):

    https://www.google.com/search?q=cookie+monster+waiting
    • “Elmer Pump Heat Equation” (CC-BY-SA):

    https://commons.wikimedia.org/wiki/File:Elmer-pump-heatequation.png
    • “Owl Stuck” (CC-BY):

    https://www.flickr.com/photos/eben-frostey/7147015007



    View Slide

50. Thank You!
