When is a Secure Connection not encrypted? And other stories

Many organizations use a Service Mesh to secure traffic between apps. This may use Mutual TLS, with a proxy terminating connections on behalf of apps. mTLS starts with a handshake to authenticate endpoint identities, and exchange certificates for subsequent traffic encryption. When encryption is needed but app authentication is not, approaches like WireGuard or IPSec may be more suitable. What about scenarios where authentication is important but encryption adds too much latency? With demos to make concepts concrete, let’s dive into Cilium's approach to authentication and encryption, and the differences between mTLS and in-kernel alternatives.

- Explore the mTLS handshake step-by-step
- Contrast with transparent encryption using node identities
- Understand where encryption takes place in different models
- Discuss options for encrypting L7 protocols other than HTTP

With a clear picture of how authentication and encryption work, you’ll be better able to assess which approach best meets your needs.

Transcript

1. When is a secure connection not encrypted? And other stories Liz Rice | @lizrice Chief Open Source Officer, Isovalent Emeritus Chair, CNCF Technical Oversight Committee | CNCF & OpenUK boards
2. @lizrice What do we mean by “secure connection”? 🤔💸
3. @lizrice Hello, I’m Liz Hi! I’m your bank Great! Here’s $500 Authentication = establishing identity
4. @lizrice Hello, I’m Liz Hi! I’m your bank Great! Here’s $500 Encryption
5. @lizrice TLS and Mutual TLS
6. @lizrice SYN ACK Encrypted data Establishing TCP Handshake Client Hello Server Hello X.509 Server symmetric session key symmetric session key TLS handshake
7. @lizrice SYN ACK Encrypted data Establishing TCP Handshake Client Hello Server Hello X.509 Server X.509 Client symmetric session key symmetric session key mTLS handshake
8. @lizrice SYN ACK Encrypted data Establishing TCP Handshake Client Hello Server Hello X.509 Server X.509 Client symmetric session key symmetric session key mTLS handshake upgrades a TCP connection to be authenticated and encrypted
9. @lizrice Transparent encryption
10. @lizrice Transparent encryption between nodes 10.0.0.1 key pair 10.0.0.2 key pair 10.0.0.1 10.0.0.2
11. @lizrice WireGuard / IPsec WireGuard is a registered trademark of Jason A. Donenfeld “You add a WireGuard interface, configure it with your private key and your peers' public keys, and then you send packets across it.” Widely considered more secure but uses non-FIPS-compliant cryptography protocols Automated key rotation WireGuard Sets up and maintains tunnels between endpoints Can be FIPS-compliant IPsec Typically used for VPNs, tunnelling encrypted IP traffic encapsulated in UDP packets
12. @lizrice Photo by Mulyadi on Unsplash
13. @lizrice Droid conversation $ k get pods -o wide NAME READY STATUS RESTARTS AGE IP NODE c-3po 1/1 Running 0 3d17h 10.244.2.2 kind-worker2 r2-d2 1/1 Running 0 2d 10.244.1.16 kind-worker $ k exec -it c-3po -- curl r2-d2 beep! beep-bee-beep! beepeebeep!!
14. @lizrice Examine traffic flowing on eth0 port No encryption root@kind-worker:/# tcpdump -i eth0 -A | grep beep tcpdump: verbose output suppressed, use -v[v]... for full protocol decode listening on eth0, link-type EN10MB (Ethernet), snapshot length 262144 bytes beep! beep-bee-beep! beepeebeep!! With WireGuard enabled $ cilium upgrade --reuse-values --set encryption.enabled=true --set encryption.type=wireguard root@kind-worker:/# tcpdump -i eth0 -A | grep beep tcpdump: verbose output suppressed, use -v[v]... for full protocol decode listening on eth0, link-type EN10MB (Ethernet), snapshot length 262144 bytes
15. @lizrice Restrict traffic with Cilium Network Policy
16. @lizrice Network policy restricts traffic apiVersion: "cilium.io/v2" kind: CiliumNetworkPolicy metadata: name: "droid" namespace: farfaraway spec: description: "Droid communication policy" endpointSelector: matchLabels: class: droid ingress: - fromEndpoints: - matchLabels: org: rebel-alliance
17. @lizrice Cilium identity is derived from Kubernetes lables kubectl get ciliumidentities --show-labels NAME NAMESPACE AGE LABELS 2252 farfaraway 2d19h app=r2-d2,class=droid,io.cilium.k8s.policy.cluster=default, io.cilium.k8s.policy.serviceaccount=default, io.kubernetes.pod.namespace=farfaraway,org=rebel-alliance 32496 farfaraway 2d23h app.kubernetes.io/name=tiefighter,class=tiefighter, io.cilium.k8s.policy.cluster=default, io.cilium.k8s.policy.serviceaccount=default, io.kubernetes.pod.namespace=farfaraway,org=empire 60812 farfaraway 2d19h app.kubernetes.io/name=c-3po, class=droid,io.cilium.k8s.policy.cluster=default, io.cilium.k8s.policy.serviceaccount=default, io.kubernetes.pod.namespace=farfaraway,org=rebel-alliance
18. @lizrice Is this traffic allowed? - fromEndpoints: - matchLabels: org: rebel-alliance Traffic from 1.1.1.1 corresponds to Cilium ID 1234 1.1.1.1
19. @lizrice Photo by Josh Tere on Unsplash Rebel alliance?
20. @lizrice Identity / address spoofing - fromEndpoints: - matchLabels: org: rebel-alliance Traffic from 1.1.1.1 corresponds to Cilium ID 1234
21. @lizrice Let’s come back to Network Policy
22. @lizrice Network policy restricts traffic apiVersion: "cilium.io/v2" kind: CiliumNetworkPolicy metadata: name: "droid" namespace: farfaraway spec: description: "Droid communication policy" endpointSelector: matchLabels: class: droid ingress: - fromEndpoints: - matchLabels: org: rebel-alliance authentication: mode: "required"
23. @lizrice Is this traffic authenticated? - fromEndpoints: - matchLabels: org: rebel-alliance authentication: mode: "required" Traffic from 1.1.1.1 corresponds to Cilium ID 1234 1.1.1.1 should be on Node 10.0.0.1 1.1.1.1 10.0.0.1 10.0.0.2
24. @lizrice Is this traffic authenticated? 1.1.1.1 1.1.1.1 10.0.0.1 10.0.0.2 - fromEndpoints: - matchLabels: org: rebel-alliance authentication: mode: "required" Traffic from 1.1.1.1 corresponds to Cilium ID 1234 1.1.1.1 should be on Node 10.0.0.1
25. @lizrice SYN ACK Establishing TCP mTLS Handshake Client Hello Server Hello X.509 C-3PO X.509 R2-D2 Cilium agents use same handshake as mTLS Both endpoints are authenticated now Passes ingress network policy authentication check for R2-D2 <-> C-3PO Get R2-D2 X.509 Get C-3PO X.509
26. @lizrice Cilium + SPIRE - transparent certificate mangement
27. @lizrice Cilium Operator registers each identity with SPIRE kubectl exec -n cilium-spire spire-server-0 -c spire-server -- /opt/spire/bin/spire-server entry show -selector cilium:mutual-auth Found 10 entries Entry ID : 8e1cc610-69b0-474d-aa89-32fc2003fe81 SPIFFE ID : spiffe://spiffe.cilium/identity/2252 Parent ID : spiffe://spiffe.cilium/cilium-operator Revision : 0 X509-SVID TTL : default JWT-SVID TTL : default Selector : cilium:mutual-auth … Transparent certificate management
28. @lizrice Authenticated connection Nov 7 13:54:13.518: farfaraway/c-3po:44494 (ID:52452) -> farfaraway/r2-d2:80 (ID:18777) policy-verdict:L3-Only INGRESS ALLOWED (TCP Flags: SYN; Auth: SPIRE)
29. @lizrice Cilium next-gen mutual authentication
30. @lizrice After handshake, the traffic doesn’t have to be TCP
31. @lizrice Authenticated connections don’t have to be encrypted
32. @lizrice
33. Thank you cilium/cilium @ciliumproject cilium.io Download from isovalent.com
