Managing Multi-module Android Project with Gradle Plugin and Kotlin

©2020 Wantedly, Inc.
Managing Multi-module Project
with Gradle Plugin and Kotlin
.droidcon APAC 2020
15 Dec 2020 - Malvin Sutanto
Photo by Jan Antonin Kolar on Unsplash

View Slide

Introduction
Malvin Sutanto
Software Engineer - Android
Twitter/ Medium: @malvinsutanto

View Slide

Multi module setup
in Android projects

View Slide

BQQ
MJCOBWJHBUJPO
QSFGFSFODFT
MJCBOBMZUJDT
EBUB
OFUXPSL
GFBUVSFTFBSDI
GFBUVSFVTFS
Multi module setup in Android

View Slide

BQQ
MJCOBWJHBUJPO
QSFGFSFODFT
MJCBOBMZUJDT
EBUB OFUXPSL
GFBUVSFTFBSDI
GFBUVSFVTFS

View Slide


View Slide

• Faster build time

View Slide

• Easier to manage and work with

View Slide

• Easier to manage and work with
• New features
• Instant apps
• Dynamic feature modules

View Slide


View Slide

However

View Slide


View Slide

• Each module need a build.gradle file

View Slide

• Duplicate build script across modules

View Slide

• Duplicate build script across modules
• Build files became hard to maintain

View Slide

build.gradle file
for a library module
plugins {
id 'com.android.library'
id 'kotlin-android'
}
android {
compileSdkVersion 30
buildToolsVersion "30.0.2"
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
testInstrumentationRunner "androidx.test.runner.AndroidJUnitRunner"
consumerProguardFiles "consumer-rules.pro"
}
buildTypes {
release {
minifyEnabled false
proguardFiles getDefaultProguardFile('proguard-android-optimize.txt'),
'proguard-rules.pro'
}
}
compileOptions {
sourceCompatibility JavaVersion.VERSION_1_8
targetCompatibility JavaVersion.VERSION_1_8
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
implementation "org.jetbrains.kotlin:kotlin-stdlib:$kotlin_version"
implementation 'androidx.core:core-ktx:1.2.0'
implementation 'androidx.appcompat:appcompat:1.1.0'
implementation 'com.google.android.material:material:1.1.0'
testImplementation 'junit:junit:4.+'
androidTestImplementation 'androidx.test.ext:junit:1.1.1'
androidTestImplementation 'androidx.test.espresso:espresso-core:3.2.0'
}

View Slide

build.gradle file
for a library module
plugins {
id 'kotlin-android'
}
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
buildTypes {
release {
minifyEnabled false
}
}
compileOptions {
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
}
• Declares Gradle plugins
• Sets build parameters
• Declares dependencies

View Slide

Gradle plugin
Simpliﬁes build scripts

View Slide

What is Gradle?

View Slide

What is Gradle?
• “Generic” build automation tool

View Slide

What is Gradle?
• Declares input and output files

View Slide

What is Gradle?
• Declares input and output files
• Tasks as its core

View Slide

Gradle Build phases
Gradle build phases

View Slide

Gradle Build phases
Gradle build phases
*OJUJBMJ[BUJPO

View Slide

Gradle Build phases
Gradle build phases
*OJUJBMJ[BUJPO $POpHVSBUJPO

View Slide

Gradle Build phases
Gradle build phases
*OJUJBMJ[BUJPO $POpHVSBUJPO &YFDVUJPO

View Slide

build.gradle file
Domain Specific Language (DSL)
plugins {
id 'kotlin-android'
}
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
buildTypes {
release {
minifyEnabled false
}
}
compileOptions {
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
}
• Conﬁguration ﬁle
• Describes build steps
• Available in Groovy and Kotlin
Gradle Build.gradle file

View Slide

build.gradle file
plugins {
id 'kotlin-android'
}
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
buildTypes {
release {
minifyEnabled false
}
}
compileOptions {
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
}
Extension block

View Slide

build.gradle file
plugins {
id 'kotlin-android'
}
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
buildTypes {
release {
minifyEnabled false
}
}
compileOptions {
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
}
Gradle plugins
Extension block

View Slide

Gradle plugin

View Slide

Gradle Plugin

View Slide

Gradle Plugin
• Extends the Gradle model
• Adds new configuration block and options

View Slide

Gradle Plugin
• Configures project according conventions
• Adds new tasks
• Configures sensible defaults

View Slide

Gradle Plugin
• Configures project according conventions
• Adds new tasks
• Configures sensible defaults
• Applies specific configuration
• Enforces standards

View Slide

Types of Gradle Plugin
Gradle Plugin

View Slide

Script plugin
• Additional build script that is located separately.
• Can exist in local ﬁlesystem or remote location.
• Multiple script plugins can be applied.
• apply from: 'other.gradle'
Gradle Plugin

View Slide

Script plugin
• Additional build script that is located separately.
• Can exist in local ﬁlesystem or remote location.
• Multiple script plugins can be applied.
• apply from: 'other.gradle'
Binary plugin
• Written programmatically by implementing
Plugin interface,
• Applied using unique plugin id
• plugins {
id 'kotlin-android'
}
Gradle Plugin

View Slide

Creating a Gradle Plugin

View Slide

Gradle Plugin

View Slide

What will the plugin do?
Gradle Plugin

View Slide

For each module, it will:
Gradle Plugin

View Slide

Gradle Plugin

View Slide

• Apply other Gradle plugins
Gradle Plugin

View Slide

• Set common build parameters
Gradle Plugin

View Slide

• Specify default proguard files
Gradle Plugin

View Slide

• Enable Java 8 features
Gradle Plugin

View Slide

• Declare dependencies
Gradle Plugin

View Slide

• Configure Jacoco and custom extensions
Gradle Plugin

View Slide

my-lib/build.gradle.kts
Gradle Plugin

View Slide

plugins {
id("com.android.library") // or .application
id("my-custom-plugin-id")
}
android {
buildTypes {
getByName("debug") {
isTestCoverageEnabled = true
}
}
}
myPluginOptions {
jacoco {
isEnabled = true
}
}
dependencies { … }
Gradle Plugin

View Slide

plugins {
}
android {
buildTypes {
getByName(“debug") {
}
}
}
myPluginOptions {
jacoco {
isEnabled = true
}
}
Gradle Plugin

View Slide

plugins {
id("com.android.library")
}
android {
buildTypes {
}
}
}
myPluginOptions {
jacoco {
isEnabled = true
}
}
Gradle Plugin

View Slide

plugins {
}
android {
buildTypes {
}
}
}
myPluginOptions {
jacoco {
isEnabled = true
}
}
plugins {
id 'kotlin-android'
}
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
buildTypes {
release {
minifyEnabled false
}
}
compileOptions {
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
}
Gradle Plugin

View Slide

Gradle plugin
Setup

View Slide

my-project/
- buildSrc/
- build.gradle.kts
- src/main/kotlin/com/mypackage/
- MyCustomPlugin.kt
- app/
- my-lib/
Project Structure
Gradle Plugin

View Slide

my-project/
- buildSrc/
- build.gradle.kts
- src/main/kotlin/com/mypackage
- MyCustomPlugin.kt
- app/
- my-lib/
Project Structure
Gradle Plugin

View Slide

buildSrc/src/build.gradle.kts
plugins {
`java-gradle-plugin`
`kotlin-dsl`
}
repositories {
google()
mavenCentral()
}
dependencies {
implementation("com.android.tools.build:gradle:$agpVersion")
implementation(kotlin("gradle-plugin"))
}
Gradle Plugin

View Slide

plugins {
`kotlin-dsl`
}
repositories {
google()
mavenCentral()
}
dependencies {
}
Gradle Plugin

View Slide

plugins {
`kotlin-dsl`
}
repositories {
google()
mavenCentral()
}
dependencies {
}
https://android-developers.googleblog.com/2020/12/announcing-android-studio-arctic-fox.html
Gradle Plugin

View Slide

my-project/
- buildSrc/
- build.gradle.kts
- src/main/kotlin/com/mypackage/
- MyCustomPlugin.kt
- app/
- my-lib/
Project Structure
Gradle Plugin

View Slide

Gradle Plugin buildSrc/src/main/kotlin/com/mypackage/MyCustomPlugin.kt

View Slide

Gradle Plugin
class MyCustomPlugin : Plugin {
buildSrc/src/main/kotlin/com/mypackage/MyCustomPlugin.kt

View Slide

Gradle Plugin
Module

View Slide

Gradle Plugin
override fun apply(project: Project) {
// TODO: Write build configurations here.
}
}
Module

View Slide

Gradle plugin
Implementation

View Slide

Gradle Plugin

View Slide


View Slide

project.plugins.apply("kotlin-android")
}

View Slide

project.plugins.apply("kotlin-android")
}
Plugin id
// build.gradle
plugins {
id 'kotlin-android'
}

View Slide

Gradle Plugin

View Slide


View Slide

…
val androidExtension = project.extensions.getByName("android")
if (androidExtension is BaseExtension) {
androidExtension.applyAndroidSettings()
}
}
private fun BaseExtension.applyAndroidSettings() {
compileSdkVersion(30)
defaultConfig {
targetSdkVersion(30)
minSdkVersion(23)
// etc.
}
}

View Slide

…
}
}
defaultConfig {
minSdkVersion(23)
// etc.
}
}
// build.gradle
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
}

View Slide

…
}
}
defaultConfig {
minSdkVersion(23)
// etc.
}
}
// build.gradle
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
}
Base class for all Android plugin extension classes

View Slide

…
}
}
defaultConfig {
minSdkVersion(23)
// etc.
}
}
// build.gradle
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
}

View Slide

Gradle Plugin

View Slide

Types of plugin
Gradle Plugin

View Slide

Application module Library module
id("com.android.application") id("com.android.library")
Types of plugin
Gradle Plugin

View Slide

Application module
• Set isMinifyEnabled only on release
Library module
Types of plugin
Gradle Plugin

View Slide

Application module
• Specify proguard ﬁles using proguardFiles()
Library module
Types of plugin
Gradle Plugin

View Slide

Application module
• Specify proguard ﬁles using proguardFiles()
Library module
• Specify proguard ﬁles using
consumerProguardFiles()
Types of plugin
Gradle Plugin

View Slide


View Slide

…
val androidExtension = project.extensions.getByName(“android")
androidExtension.applyProguardSettings()
}
}

View Slide

private fun BaseExtension.applyProguardSettings() {
val proguardFile = "proguard-rules.pro"
when (this) {
is LibraryExtension -> defaultConfig {
consumerProguardFiles(proguardFile)
}
is AppExtension -> buildTypes {
getByName("release") {
isMinifyEnabled = true
isShrinkResources = true
proguardFiles(
getDefaultProguardFile("proguard-android-optimize.txt"),
proguardFile
)
}
}
}
}

View Slide

when (this) {
}
proguardFiles(
proguardFile
)
}
}
}
}
proguard-rules.pro files in each module’s root

View Slide

when (this) {
}
proguardFiles(
proguardFile
)
}
}
}
}

View Slide

when (this) {
}
proguardFiles(
proguardFile
)
}
}
}
}
// build.gradle
plugins {
id 'my-custom-plugin-id'
}

View Slide

when (this) {
}
proguardFiles(
proguardFile
)
}
}
}
}
// build.gradle
plugins {
}
// build.gradle
android {
defaultConfig {
...
consumerProguardFiles "proguard-rules.pro"
}
}

View Slide

when (this) {
}
proguardFiles(
proguardFile
)
}
}
}
}

View Slide

when (this) {
}
proguardFiles(
proguardFile
)
}
}
}
}
// build.gradle
plugins {
id 'com.android.application'
}

View Slide

when (this) {
}
proguardFiles(
proguardFile
)
}
}
}
}
Enable obfuscation only on "release" build
// build.gradle
plugins {
id 'com.android.application'
}

View Slide

Gradle Plugin

View Slide


View Slide

…
...
androidExtension.enableJava8(project)
}
}

View Slide


View Slide

private fun BaseExtension.enableJava8(project: Project) {
compileOptions {
isCoreLibraryDesugaringEnabled = true
sourceCompatibility = JavaVersion.VERSION_1_8
targetCompatibility = JavaVersion.VERSION_1_8
}
project.tasks.withType().configureEach {
kotlinOptions {
jvmTarget = "1.8"
}
}
}

View Slide

compileOptions {
}
project.tasks.withType().configureEach {
kotlinOptions {
jvmTarget = "1.8"
}
}
}
Java 8 core library desugaring

View Slide

Gradle Plugin

View Slide

compileOptions {
}
project.dependencies {
add("coreLibraryDesugaring", "com.android.tools:desugar_jdk_libs:1.0.9")
}
...
}

View Slide

compileOptions {
}
add("coreLibraryDesugaring", "com.android.tools:desugar_jdk_libs:1.0.9")
}
...
} Configuration name

View Slide

add("implementation", "androidx.core:core-ktx:1.2.0")
add("testImplementation", "junit:junit:4.12")
add("androidTestImplementation", "androidx.test.ext:junit:1.1.1")
}

View Slide

Gradle Plugin

View Slide

plugins {
}
android {
buildTypes {
getByName("debug") {
}
}
}
myPluginOptions {
jacoco {
isEnabled = true
}
}
Gradle Plugin

View Slide


View Slide

project.extensions.create("myPluginOptions")
…
…
androidExtension.configureJacoco(project)
}
}

View Slide

…
…
}
}
Extension class

View Slide

…
…
}
}
Extension class
// build.gradle.kts
myPluginOptions {
jacoco {
isEnabled = true
}
}

View Slide

open class MyPluginOptionExtension {
val jacoco: JacocoOptions = JacocoOptions()
fun jacoco(action: Action) {
action.execute(jacoco)
}
}
class JacocoOptions {
var isEnabled: Boolean = true
}
Gradle Plugin buildSrc/src/main/kotlin/com/mypackage/MyPluginOptionExtension.kt

View Slide

// build.gradle.kts
myPluginOptions {
jacoco {
isEnabled = true
}
}
}
}
} // build.gradle
myPluginOptions {
jacoco {
enabled true
}
}

View Slide

}
}
}
// build.gradle.kts
myPluginOptions {
jacoco {
isEnabled = true
}
}

View Slide

}
}
}
// build.gradle.kts
myPluginOptions {
jacoco {
isEnabled = true
}
}
https://docs.gradle.org/current/userguide/custom_gradle_types.html
https://docs.gradle.org/current/userguide/lazy_conﬁguration.html#lazy_conﬁguration

View Slide

…
…
}
}

View Slide

private fun BaseExtension.configureJacoco(project: Project) {
project.afterEvaluate {
val jacocoOptions = project.extensions.getByType()
.jacoco
if (jacocoOptions.isEnabled) {
project.plugins.apply("jacoco")
when (this@configureJacoco) {
is LibraryExtension -> configureJacocoTasks(project, libraryVariants)
is AppExtension -> configureJacocoTasks(project, applicationVariants)
}
}
}
}
private fun configureJacocoTasks(
project: Project,
variants: DomainObjectSet
) { ... }

View Slide

.jacoco
}
}
}
}
project: Project,
) { ... }
// build.gradle.kts
myPluginOptions {
jacoco {
isEnabled = true
}
}

View Slide

.jacoco
}
}
}
}
project: Project,
) { ... }

View Slide

.jacoco
}
}
}
}
project: Project,
) { ... }
"debug"
"release"

View Slide

.jacoco
}
}
}
}
project: Project,
) { ... }
"debug"
"release"
"debug"
"release"
"flavorDebug"
"flavorRelease"

View Slide

project: Project,
) {
variants.all {
val variantName = name
val isDebuggable = buildType.isDebuggable
if (!isDebuggable) return@all
project.tasks.register("jacoco${variantName.capitalize()}Report") {
// Set up the rest of the Jacoco tasks dependency, exec files, etc.
}
}
}

View Slide

project: Project,
) {
variants.all {
}
}
}
Skip non-debuggable builds

View Slide

project: Project,
) {
variants.all {
}
}
}

View Slide

project: Project,
) {
variants.all {
}
}
}
"debug"
"release"
"flavorDebug"
"flavorRelease"

View Slide

project: Project,
) {
variants.all {
}
}
}
./gradlew :lib:jacocoDebugReport
./gradlew :app:jacocoFlavorDebugReport
"debug"
"release"
"flavorDebug"
"flavorRelease"

View Slide

project: Project,
) {
variants.all {
}
}
}

View Slide

Apply Gradle plugin
on other modules

View Slide

plugins { ... }
gradlePlugin {
plugins {
register("my-custom-plugin") {
id = "my-custom-plugin-id"
implementationClass = "com.mypackage.MyCustomPlugin"
}
}
}
repositories { ... }
dependencies { ... }
Gradle Plugin

View Slide

plugins { ... }
gradlePlugin {
plugins {
}
}
}
// lib/build.gradle.kts
plugins {
}
Gradle Plugin

View Slide

plugins { ... }
gradlePlugin {
plugins {
}
}
}
// lib/build.gradle.kts
plugins {
}
class MyCustomPlugin : Plugin { ... }
Gradle Plugin

View Slide

Gradle plugin
Beneﬁts

View Slide

Benefits
Gradle Plugin

View Slide

Benefits
• Share build logic across modules
• Reduce maintenance cost when updating build scripts
Gradle Plugin

View Slide

Benefits
• Higher degree of modularization
• Better organization and comprehensibility
Gradle Plugin

View Slide

Benefits
• Higher degree of modularization
• Better organization and comprehensibility
• Encapsulates logic
• Declarative build scripts
• Automatically configures tasks and its dependencies
Gradle Plugin

View Slide

Our experience
Gradle Plugin

View Slide

• Helped migration to build.gradle.kts
Our experience
Gradle Plugin

View Slide

• Make use of Gradle API
• Apply Gradle plugin to build.gradle files written in Groovy
Our experience
Gradle Plugin

View Slide

• Make use of Gradle API
• Apply Gradle plugin to build.gradle files written in Groovy
• Gradually migrate to Kotlin build.gradle.kts files
Our experience
Gradle Plugin

View Slide

plugins {
id 'kotlin-android'
}
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
buildTypes {
release {
minifyEnabled false
}
}
compileOptions {
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
}
Our experience
Gradle Plugin

View Slide

plugins {
id 'kotlin-android'
}
android {
defaultConfig {
minSdkVersion 23
targetSdkVersion 30
versionCode 1
versionName "1.0"
}
buildTypes {
release {
minifyEnabled false
}
}
compileOptions {
}
kotlinOptions {
jvmTarget = '1.8'
}
}
dependencies {
}
// build.gradle
plugin {
}
myPluginOptions {
jacoco {
enabled true
}
}
Our experience
Gradle Plugin

View Slide

// build.gradle
plugin {
}
myPluginOptions {
jacoco {
enabled true
}
}
Our experience
Gradle Plugin

View Slide

// build.gradle
plugin {
}
myPluginOptions {
jacoco {
enabled true
}
}
// build.gradle.kts
plugin {
}
myPluginOptions {
jacoco {
isEnabled = true
}
}
Our experience
Gradle Plugin

View Slide

Our experience
Gradle Plugin

View Slide

• buildSrc vs standalone plugin
Our experience
Gradle Plugin

View Slide

• Plugin is very specific to each project
Our experience
Gradle Plugin

View Slide

• Plugin is very specific to each project
• But, split the plugins when necessary depending on its purpose
• e.g., Jacoco as its own plugin
Our experience
Gradle Plugin

View Slide

Summary

View Slide

Summary
Gradle Plugin

View Slide

Summary
• Maintaining build.gradle files can be tedious
Gradle Plugin

View Slide

Summary
• Gradle plugin can simplify the maintenance
process
Gradle Plugin

View Slide

Summary
• Gradle plugin can simplify the maintenance
process
• Make Gradle plugin configurable using
extension
Gradle Plugin

View Slide

Thank you
@MalvinSutanto

View Slide

Managing Multi-module Android Project with Gradle Plugin and Kotlin

Managing Multi-module Android Project with Gradle Plugin and Kotlin

Malvin Sutanto

More Decks by Malvin Sutanto

Other Decks in Programming

Featured

Transcript
