InspiringCon14: ElePHPants on speed: Running TYPO3 Flow on HipHop VM

License: CC BY-SA

The rise of increasingly complex PHP frameworks and applications in the past few years has also changed the requirements that are put on the performance of the PHP interpreter itself – a field in which PHP as an interpreted language has always had a conceptual disadvantage in comparison to compiled languages.

A common approach to optimize the performance of PHP applications is the use of opcode caches like APC or OpCache, which cache the interpreter-generated byte code. A different solution is provided by HipHop VM, which implements a just-in-time compiler that translates PHP code into native machine code.

This talk aims at exploring if and how the current state of HHVM can be used to run TYPO3 Flow applications like TYPO3 Neos, what limitations need to be considered and what performance gains can be achieved in comparison to the traditional Zend Engine in conjunction with various opcode caches.

Transcript

1. ElePHPants on speed

   Running TYPO3 Flow on HipHop VM

   Inspiring Conference, March 28th 2014
   Martin Helmich, Mittwald CM Service

   m.helmich@mittwald.de
   Photo: George Lamson, CC BY-NC-SA

   http://www.flickr.com/photos/lamsongf/6415913075/


   View Slide

2. YOUR SPEAKER
   Martin Helmich
   Software architect at Mittwald
   TYPO3 addicted since 2004

   Caffeine addicted since 2007


   View Slide

3. Sebastian Bergmann, CC BY-SA

   http://www.flickr.com/photos/sebastian_bergmann/2337231691/


   View Slide

4. Lexing
   Parsing
   Compilation
   Execution
   PHP execution,

   traditional


   View Slide

5. !
   $locations = [
   0 => "Kolbermoor",
   1 => "Espelkamp",
   2 => "Las Vegas"
   ];
   !
   $currentLoc = 0;
   $currentLocName = $locations[$currentLoc];
   !
   if ($currentLoc === 2) {
   $greeting = "%s, baby!";
   } else {
   $greeting = "Hello %s!";
   }
   !
   echo sprintf($greeting, $currentLocName) . "\n";
   Lexing
   Parsing
   Compilat
   Executio


   View Slide

6. T_OPEN_TAG
   T_VARIABLE
   T_LNUMBER
   T_DOUBLE_

   ARROW
   T_CONSTANT_ENCAPSED_STRING
   T_IF
   T_ELSE
   T_ECHO
   T_STRING
   Lexing
   Parsing
   Compilat
   Executio
   !
   $locations = [
   0 => "Kolbermoor",
   1 => "Espelkamp",
   2 => "Las Vegas"
   ];
   !
   $currentLoc = 0;
   $currentLocName = $locations[$currentLoc];
   !
   if ($currentLoc === 2) {
   $greeting = "%s, baby!";
   } else {
   $greeting = "Hello %s!";
   }
   !
   echo sprintf($greeting, $currentLocName) . "\n";


   View Slide

7. Lexing
   Parsing
   Compilat
   Executio
   Variable

   assignment
   Array

   constructor
   Array

   accessor
   Constant
   Conditional

   statement
   Boolean

   expression
   Function

   call
   Print

   statement
   !
   $locations = [
   0 => "Kolbermoor",
   1 => "Espelkamp",
   2 => "Las Vegas"
   ];
   !
   $currentLoc = 0;
   $currentLocName = $locations[$currentLoc];
   !
   if ($currentLoc === 2) {
   $greeting = "%s, baby!";
   } else {
   $greeting = "Hello %s!";
   }
   !
   echo sprintf($greeting, $currentLocName) . "\n";


   View Slide

8. Lexing
   Parsing
   Compilat
   Executio
   compiled vars: !0 = $locations, !1 = $currentLocationId, !2 = $currentLocationName,
   !3 = $greetingTemplate
   line # * op fetch ext return operands
   ----------------------------------------------------------------
   4 0 > EXT_STMT
   1 INIT_ARRAY ~0 'Kolbermoor', 0
   5 2 ADD_ARRAY_ELEMENT ~0 'Espelkamp', 1
   7 3 ADD_ARRAY_ELEMENT ~0 'Las+Vegas', 2
   4 ASSIGN !0, ~0
   9 5 EXT_STMT
   6 ASSIGN !1, 0
   10 7 EXT_STMT
   8 FETCH_DIM_R $3 !0, !1
   9 ASSIGN !2, $3
   12 10 EXT_STMT
   11 IS_IDENTICAL ~5 !1, 2
   12 > JMPZ ~5, ->16
   13 13 > EXT_STMT
   14 ASSIGN !3, '%25s%2C+baby%21'
   14 15 > JMP ->18
   15 16 > EXT_STMT
   17 ASSIGN !3, 'Hello+%25s%21'
   18 18 > EXT_STMT
   19 EXT_FCALL_BEGIN
   20 SEND_VAR !3
   21 SEND_VAR !2
   22 DO_FCALL 2 $8 'sprintf'
   23 EXT_FCALL_END
   24 CONCAT ~9 $8, '%0A'
   25 ECHO ~9
   19 26 > RETURN 1
   !


   View Slide

9. Lexing
   Parsing
   Compilat
   Executio


   View Slide

10. Lexing
    Parsing
    Compilation
    Execution
    PHP execution,

    traditional


    View Slide

11. Lexing
    Parsing
    Compilation
    Execution
    Opcode

    Cache
    PHP

    opcodes
    PHP execution,

    opcode cache
    opcodes executed

    by PHP interpreter


    View Slide

12. Lexing
    Parsing
    Compilation
    Execution
    HipHop

    bytecode
    JIT

    compiler
    HipHop

    intermediate

    representation
    Code

    repository
    x86-64/arm

    machine code
    PHP execution,

    HipHop VM
    executed as

    native machine code
    AST
    https://www.facebook.com/notes/facebook-engineering/the-hiphop-virtual-machine/10150415177928920

    http://www.hhvm.com/blog/2027/faster-and-cheaper-the-evolution-of-the-hhvm-jit


    View Slide

13. $whatAmI = "Dynamic typization is great!";
    !
    if ($whatAmI > 0) {
    $whatAmI = [
    "But in many PHP programs,",
    "this is not excessively used."
    ];
    } else {
    $whatAmI = FALSE;
    }


    View Slide

14. !
    $locations = [
    0 => "Kolbermoor",
    1 => "Espelkamp",
    2 => "Las Vegas"
    ];
    !
    $currentLoc = 0;
    $currentLocName = $locations[$currentLoc];
    !
    if ($currentLoc === 2) {
    $greeting = "%s, baby!";
    } else {
    $greeting = "Hello %s!";
    }
    !
    echo sprintf($greeting, $currentLocName) . "\n";
    Array of

    strings
    Integer
    String


    View Slide

15. How to install
    wget -O - http://dl.hhvm.com/conf/hhvm.gpg.key | apt-key add -
    echo deb http://dl.hhvm.com/debian wheezy main | tee /etc/apt/sources.list.d/hhvm.list
    sudo apt-get update
    sudo apt-get install hhvm
    https://github.com/facebook/hhvm/wiki/Prebuilt-Packages-on-Debian-7


    View Slide

16. View Slide

17. Running TYPO3 Flow

    on HHVM


    View Slide

18. One does not simply

    run TYPO3 Flow on
    HHVM.
    Flore Allemandou, CC BY-NC-SA

    http://www.flickr.com/photos/flore_frmoz/5031037626/


    View Slide

19. View Slide

20. View Slide

21. TYPO3.Flow/Classes/.../Core/Bootstrap.php ---|+++++++
    TYPO3.Flow/Classes/.../Error/ErrorHandler.php -|+
    TYPO3.Flow/Classes/.../Http/Headers.php |+++++
    TYPO3.Flow/Classes/.../Mvc/Routing/ObjectPathMappingRepository.php -----|++++
    TYPO3.Flow/Classes/.../Object/Configuration/ConfigurationArgument.php --|++++++++
    TYPO3.Flow/Classes/.../Object/Configuration/ConfigurationProperty.php --|++++++++
    TYPO3.Flow/Classes/.../Package/Package.php -|+
    TYPO3.Flow/Classes/.../Security/AccountRepository.php -----|++++
    TYPO3.Flow/Classes/.../Security/Policy/Role.php -|+++++
    TYPO3.Flow/Classes/.../Security/Policy/RoleRepository.php -----|+++++++
    TYPO3.Flow/Classes/.../Utility/Unicode/TextIterator.php -|+++++
    TYPO3.Party/Classes/TYPO3/Party/Domain/Repository/PartyRepository.php -|+++
    doctrine/dbal/lib/.../Driver/PDOConnection.php |+++++++++++++++++++++++++++++++++++++++
    doctrine/dbal/lib/.../Driver/PDOStatement.php -|+++++++++++++++++++++++++++++++++++++++
    Web/index.php |++
    TYPO3.Media/Classes/.../Domain/Model/Image.php -|++++
    TYPO3.Media/Classes/.../Domain/Model/ImageVariant.php -|++++
    TYPO3.Setup/Classes/.../Core/BasicRequirements.php -|
    TYPO3.Setup/Classes/.../Core/RequestHandler.php |+++
    TYPO3.TYPO3CR/Classes/.../Migration/Command/NodeCommandController.php -|+++++
    imagine/imagine/lib/.../Filter/Basic/Resize.php --|++
    imagine/imagine/lib/.../Filter/Basic/Thumbnail.php --|++
    Doctrine issue #372 (https://github.com/doctrine/dbal/pull/373),

    backported to 2.3
    Hacks around various HHVM glitches


    View Slide

22. TYPO3 Flow 2.1
    Unit tests, PHP 5.5
    Tests: 4186, Assertions: 10145, Failures: 1, Incomplete: 1, Skipped: 95
    Unit tests, HHVM

    (with compatibility patches)
    Tests: 4186, Assertions: 10057, Failures: 14, Errors: 21, Incomplete: 1, Skipped: 95
    99,98 %
    99,14 %


    View Slide

23. Configuration/Production.hdf
    Server {
    SourceRoot = /var/www/my-flow-site/Web
    DefaultDocument = index.php
    Port = 9000
    ThreadCount = 100
    }



    Eval {
    Jit = true
    }
    !
    VirtualHost {
    my-flow-site {
    Pattern = .*
    ServerVariables {
    FLOW_REWRITEURLS = 1
    FLOW_CONTEXT = Production
    }


    View Slide

24. Server {
    SourceRoot = /var/www/my-flow-site/Web
    DefaultDocument = index.php
    Port = 9000
    ThreadCount = 100
    }



    Eval {
    Jit = true
    }
    !
    VirtualHost {
    my-flow-site {
    Pattern = .*
    ServerVariables {
    FLOW_REWRITEURLS = 1
    FLOW_CONTEXT = Production
    }
    RewriteRules {
    persistentresources {
    pattern = ^/?(_Resources/Persistent/.{40})/.+(\..+)
    to = $1$2
    }
    !
    index {
    pattern = ^(.*)
    to = index.php/$1
    qsa = true
    }
    }
    }
    }
    !
    StaticFile {
    Extensions {
    css = text/css
    js = text/javascript
    png = image/png
    jpg = image/jpeg
    }
    }


    View Slide

25. TYPO3:
    Flow:
    core:
    phpBinaryPathAndFilename: /usr/bin/hhvm
    subRequestPhpIniPathAndFilename: false
    Configuration/Settings.yaml

    (configured for speed)
    Use HHVM on sub-requests, too

    for even more performance.
    Nico Kaiser, CC BY

    http://www.flickr.com/photos/nicokaiser/6070496071/


    View Slide

26. TYPO3:
    Flow:
    core:
    phpBinaryPathAndFilename: /usr/bin/php
    subRequestPhpIniPathAndFilename: /etc/php5/cli/php.ini
    Always specify a php.ini or “false”.

    Automatic detection will fail.
    Configuration/Settings.yaml

    (configured conservatively)


    View Slide

27. Start it
    > FLOW_CONTEXT=PRODUCTION hhvm -m server -c Configuration/Production.hdf


    View Slide

28. View Slide

29. 0
    20
    40
    60
    80
    Concurrency
    50 100 150 200 250 300 350 400 450 500
    PHP (Apache+opcache) HHVM (standalone)
    HHVM (FCGI+Apache) HHVM (FCGI+nginx)
    Requests per second

    TYPO3 Neos 1.0.2, production mode, with HHVM patches


    View Slide

30. 0
    4
    8
    12
    16
    Concurrency
    50 100 150 200 250 300 350 400 450 500
    PHP (Apache+opcache) HHVM (standalone)
    HHVM (FCGI+Apache) HHVM (FCGI+nginx)
    Response times

    TYPO3 Neos 1.0.2, production mode, with HHVM patches


    View Slide

31. 91 %
    93,25 %
    95,5 %
    97,75 %
    100 %
    Concurrency
    50 100 150 200 250 300 350 400 450 500
    PHP (Apache+opcache) HHVM (standalone)
    HHVM (FCGI+Apache) HHVM (FCGI+nginx)
    Availability

    TYPO3 Neos 1.0.2, production mode, with HHVM patches


    View Slide

32. Don't forget!

    Always enable production mode!


    View Slide

33. > composer create-project \
    mittwald-typo3/neos-hhvm-distribution
    > composer create-project \
    mittwald-typo3/flow-hhvm-distribution
    Contribute:

    https://github.com/mittwald/flow-hhvm


    View Slide

34. > composer create-project \
    mittwald-typo3/neos-hhvm-distribution
    Apply compatibility patches

    Adjust configuration

    Create appropriate HDF configuration file
    What does it do?


    View Slide

35. HHVM
    FastCGI
    Static

    files
    nginx


    View Slide

36. Use HHVM as FastCGI backend
    Server {
    Type = fastcgi
    FileSocket = /var/run/hhvm.sock
    SourceRoot = /var/www/my-flow-site/Web
    DefaultDocument = index.php
    ThreadCount = 100
    }
    configuration.hdf


    View Slide

37. Use HHVM as FastCGI backend
    ProxyPassMatch ^/_Resources !
    ProxyPass / fcgi://127.0.0.1:9000/var/www/flow/Web/
    Apache configuration
    location /_Resources {
    try_files $uri;
    }
    !
    location / {
    fastcgi_pass 127.0.0.1:9000;
    fastcgi_index index.php;
    fastcgi_param SCRIPT_FILENAME /var/www/flow/Web/$fastcgi_script_name;
    include fastcgi_params;
    }
    Nginx configuration


    View Slide

38. Tobias Schlitt, CC-BY-NC-SA

    http://www.flickr.com/photos/tobiasschlitt/2644905363/


    View Slide

39. Duncan

    View Slide

40. Reading
    The HipHop virtual machine

    https://www.facebook.com/notes/facebook-engineering/the-hiphop-virtual-machine/10150415177928920

    !
    Faster and cheaper: The evolution of the HHVM JIT

    http://www.hhvm.com/blog/2027/faster-and-cheaper-the-evolution-of-the-hhvm-jit

    !
    HHVM runtime options

    https://github.com/facebook/hhvm/wiki/Runtime-options

    !
    Running HHVM as FastCGI server

    https://github.com/facebook/hhvm/wiki/FastCGI

    !
    HipHop bytecode specification

    https://github.com/facebook/hhvm/blob/master/hphp/doc/bytecode.specification

    !
    HipHop intermediate representation specification

    https://github.com/facebook/hhvm/blob/master/hphp/doc/ir.specification

    !
    HHVM compatibility package for TYPO3 Flow and Neos

    https://github.com/mittwald/flow-hhvm

    !
    Alla breve: Serverlasten halbieren mit dem PHP-zu-C++-Konverter HipHop

    c't, 23/2010, p. 180
