From YAML to TypeScript: Developer’s View on Cloud Automation

From YAML to TypeScript: Developer’s View on Cloud Automation

Modern cloud applications consist of many moving parts, so they are hard to manage without employing Infrastructure as Code approach. Traditionally, tools like CloudFormation, ARM templates and Terraform employ text-based formats, which tend to be tedious, repetitive and difficult to reuse. What if instead of configuration files you could use TypeScript? See how you can bring your favorite developer tools like code completion, types, components, and abstractions to cloud infrastructure definition.

Mikhail Shilkov

November 08, 2019
Tweet

More Decks by Mikhail Shilkov

Other Decks in Programming

Transcript

  1. LB Web Web DB LB DB LB Web Web DB

    LB DB Web DB Web + DB
  2. REST calls Content-Type: application/x-www-form-urlencoded; charset=UTF-8 X-Amz-Date: 20130813T150211Z Host: ec2.amazonaws.com Authorization:

    AWS4-HMAC-SHA256 Credential=AKIDEXAMPLE/20130813/us-east- 1/ec2/aws4_request, SignedHeaders=content-type;host;x-amz- date, Signature=ced6826de92d2bdeed8f846f0bf508e8559e98e4b0194b84example54174deb456c http://ec2.amazonaws.com/?Action=RunInstances ImageId=ami-2bb65342 &MaxCount=3 &MinCount=1 &Monitoring.Enabled=true &Placement.AvailabilityZone=us-east-1a &Version=2016-11-15
  3. var launchRequest = new RunInstancesRequest() { ImageId = amiID, InstanceType

    = "t1.micro", MinCount = 1, MaxCount = 1, KeyName = keyPairName, SecurityGroupIds = groups }; var launchResponse = ec2Client.RunInstances(launchRequest); var instances = launchResponse.Reservation.Instances; SDKs to call those REST endpoints
  4. az storage account create \ --location westus \ --name samplesa

    \ --resource-group myrg \ --sku LRS Command-line Tools
  5. Azure ARM Templates: JSON "resources": [ { "apiVersion": "2016-01-01", "type":

    "Microsoft.Storage/storageAccounts", "name": "mystorageaccount", "location": "westus", "sku": { "name": "Standard_LRS" }, "kind": "Storage", "properties": { } } ]
  6. AWS CloudFormation: YAML Resources: S3BucketForURLs: Type: "AWS::S3::Bucket" DeletionPolicy: Delete Properties:

    BucketName: !If [ "CreateNewBucket", !Ref "AWS::NoValue", !Ref S3BucketName ] WebsiteConfiguration: IndexDocument: "index.html" LifecycleConfiguration: Rules: - Id: DisposeShortUrls ExpirationInDays: !Ref URLExpiration Prefix: "u" Status: Enabled
  7. resource "azurerm_storage_account" "sa" { name = "mysa" location = azurerm_resource_group.rg.location

    resource_group_name = azurerm_resource_group.rg.name account_tier = "Standard" account_replication_type = "LRS" } Terraform: DSL (HashiCorp Configuration Language)
  8. { "Resources": { "InstanceSecurityGroup": { "Type": "AWS::EC2::SecurityGroup", "Properties": { "SecurityGroupIngress":

    [ ... ] } }, "EC2Instance": { "Type": "AWS::EC2::Instance", "Properties": { "InstanceType": "t2.micro", "SecurityGroups": [ { "Ref": "InstanceSecurityGroup" } ], "ImageId": "ami-0080e4c5bc078760e" } } } } References
  9. { "condition": "[equals(parameters('production'), 'Yes')]", "type": "Microsoft.Compute/availabilitySets", "apiVersion": "2017-03-30", "name": "[variables('availabilitySetName')]",

    "location": "[resourceGroup().location]", "properties": { "platformFaultDomainCount": 2, "platformUpdateDomainCount": 3 } } Conditionals
  10. locals { files = ["index.php","main.php"] } resource "aws_s3_bucket_object" "files" {

    count = "${length(local.files)}" key = "${local.files[count.index]}" bucket = "${aws_s3_bucket.examplebucket.id}" source = "./src/${local.files[count.index]}" } Loops
  11. IDEs Code completion Unit tests Types Functions Package managers Versioning

    Classes Code reviews Contracts SDKs Workflows Refactoring
  12. const resourceGroup = new azure.core.ResourceGroup("rg"); const storageAccount = new azure.storage.Account("storage",

    { resourceGroupName: resourceGroup.name, accountReplicationType: "LRS", accountTier: "Standard", }); TypeScript example
  13. const counterTable = new aws.dynamodb.Table("url-table", { attributes: [{ name: "id",

    type: "S" }], hashKey: "id", readCapacity: 5, }); const lambda = new aws.lambda.Function("mylambda", { code: new pulumi.asset.FileArchive("./app"), handler: "index.handler", environment: { variables: { "COUNTER_TABLE": counterTable.name, }}, }); const endpoint = new awsx.apigateway.API("short-url", { routes: [{ path: "/{route+}", method: "GET", eventHandler: lambda, }], }); Example: Serverless HTTP
  14. const counterTable = new aws.dynamodb.Table("url-table", { attributes: [{ name: "id",

    type: "S" }], hashKey: "id", readCapacity: 5, }); const lambda = new aws.lambda.Function("mylambda", { code: new pulumi.asset.FileArchive("./app"), handler: "index.handler", environment: { variables: { "COUNTER_TABLE": counterTable.name, }}, }); const endpoint = new awsx.apigateway.API("short-url", { routes: [{ path: "/{route+}", method: "GET", eventHandler: lambda, }], }); Example: Serverless HTTP
  15. const counterTable = new aws.dynamodb.Table("url-table", { attributes: [{ name: "id",

    type: "S" }], hashKey: "id", readCapacity: 5, }); const lambda = new aws.lambda.Function("mylambda", { code: new pulumi.asset.FileArchive("./app"), handler: "index.handler", environment: { variables: { "COUNTER_TABLE": counterTable.name, }}, }); const endpoint = new awsx.apigateway.API("short-url", { routes: [{ path: "/{route+}", method: "GET", eventHandler: lambda, }], }); Example: Serverless HTTP
  16. const counterTable = new aws.dynamodb.Table("url-table", { attributes: [{ name: "id",

    type: "S" }], hashKey: "id", readCapacity: 5, }); const lambda = new aws.lambda.Function("mylambda", { code: new pulumi.asset.FileArchive("./app"), handler: "index.handler", environment: { variables: { "COUNTER_TABLE": counterTable.name, }}, }); const endpoint = new awsx.apigateway.API("short-url", { routes: [{ path: "/{route+}", method: "GET", eventHandler: lambda, }], }); Still, Desired State!
  17. How Pulumi works CLI and Engine Last deployed state index.ts

    Language host AWS Azure GCP Kubernetes new Resource() Create, update, delete
  18. for (const az of aws.getAvailabilityZones().names) { const server = new

    aws.ec2.Instance(`web-${az}`, { instanceType: "t2.micro", securityGroups: [ group.id ], ami: "ami-0080e4c5bc078760e", availabilityZone: az, }); } Conditionals, loops
  19. class AksCluster extends pulumi.ComponentResource { constructor(name: string, args: AksClusterArgs, opts:

    pulumi.ComponentResourceOptions = {}) { super("examples:aks:AksCluster", name, args, opts); const password = new random.RandomPassword("password"/*, {...}*/); const sshPublicKey = new tls.PrivateKey("key"/*, {...}*/); const adApp = new azuread.Application("aks"/*, {...}*/); const adSp = new azuread.ServicePrincipal("aksSp"/*, {...}*/); const vnet = new azure.network.VirtualNetwork("vnet"/*, {...}*/); const subnet = new azure.network.Subnet("subnet"/*, {...}*/); const cluster = new azure.containerservice.KubernetesCluster("aksCluster"/*, {...}*/) } } Components
  20. const hello = new lambda.Function(this, 'HelloHandler', { runtime: lambda.Runtime.NODEJS_8_10, code:

    lambda.Code.asset('lambda'), handler: 'hello.handler' }); new apigw.LambdaRestApi(this, 'Endpoint', { handler: hello }); AWS CDK example
  21. const ecsScheduledTask = new ScheduledEc2Task(stack, 'ScheduledTask’, { schedule: events.Schedule.expression('rate(1 minute)’)

    scheduledEc2TaskImageOptions: { image: ecs.ContainerImage.fromRegistry('amazon/amazon-ecs-sample'), memoryLimitMiB: 256, environment: { name: 'TRIGGER', value: 'CloudWatch Events' }, }, }); Scheduled Tasks
  22. const tpsReports = new aws.s3.Bucket("tpsReports"); const tpsZips = new aws.s3.Bucket("tpsZips");

    tpsReports.onObjectCreated("zipTpsReports", (e) => { for (const rec of e.Records || []) { const [ buck, key ] = [ rec.s3.bucket.name, rec.s3.object.key ]; const data = await s3.getObject({ Bucket: buck, Key: key })); zip.addFile(key, data.Body); await s3.putObject({ Bucket: tpsZips.bucket.get(), Key: `${key}.zip`, Body: zip.toBuffer(), }); } }); Functions = Callbacks
  23. const tpsReports = new aws.s3.Bucket("tpsReports"); const tpsZips = new aws.s3.Bucket("tpsZips");

    tpsReports.onObjectCreated("zipTpsReports", (e) => { for (const rec of e.Records || []) { const [ buck, key ] = [ rec.s3.bucket.name, rec.s3.object.key ]; const data = await s3.getObject({ Bucket: buck, Key: key })); zip.addFile(key, data.Body); await s3.putObject({ Bucket: tpsZips.bucket.get(), Key: `${key}.zip`, Body: zip.toBuffer(), }); } }); Functions = Callbacks
  24. export const functions = new CosmosApp("urls", { resourceGroup, locations: ["WestEurope",

    "WestUS", "SouthEastAsia"], factory: ({location, cosmosdb}) => { const app = new azure.appservice.ArchiveFunctionApp("app", { location, archive: new pulumi.asset.FileArchive("./app"), appSettings: { COSMOSDB_ENDPOINT: cosmosdb.endpoint, }, }); return { id: app.functionApp.id }; }}); Global Apps
  25. export const functions = new CosmosApp("urls", { resourceGroup, locations: ["WestEurope",

    "WestUS", "SouthEastAsia"], factory: ({location, cosmosdb}) => { const app = new azure.appservice.ArchiveFunctionApp("app", { location, archive: new pulumi.asset.FileArchive("./app"), appSettings: { COSMOSDB_ENDPOINT: cosmosdb.endpoint, }, }); return { id: app.functionApp.id }; }}); Global Apps
