Licensing and Distributing a Paid Ruby CLI on macOS

A talk I gave at Rocky Mountain Ruby in Boulder, Colorado on October 6, 2023. I took the audience through my journey figuring out how to enforce licenses and limitations for my Ruby on Mac product, and how to generate a self-contained Ruby binary.

A blog post version of the talk will be coming soon on the Ruby on Mac blog, and the video should be available by the end of October.

Transcript

1. Moncef Belyamani / rubyonmac.dev / @monfresh
   Licensing and
   Distributing a Paid Ruby
   CLI on macOS
   Rocky Mountain Ruby / October 6, 2023


   View Slide

2. Moncef Belyamani
   @monfresh
   monfresh.com
   rubyonmac.dev


   View Slide

3. View Slide

4. View Slide

5. View Slide

6. I spent hours trying to get Jekyll to work
   on my new M2 Mac. Every time I thought
   I had it something else would break.
   Scott Lewis


   View Slide

7. If only I could get those 10 hours back
   from the last few days spent trying to get
   2.6.10 installed on this MacBook Air M1.
   Dan Weaver


   View Slide

8. I spent around 3 days trying to solve issues
   on a Rails app. I looked and tried and
   retried so many possible solutions from so
   many sources on the web... but nothing
   was working.
   Monica Randriamialy


   View Slide

9. I spent probably 4 hours trying to do
   exactly same setup as before and it
   never worked.
   Anton Podviaznikov


   View Slide

10. View Slide

11. • Xcode/Command Line Tools version

    • macOS version

    • Intel vs Apple Silicon

    • Installing things with and without Rosetta at the same time

    • The desired Ruby version

    • The current active Ruby version

    • The version manager used

    • Which OpenSSL versions are installed and which one you're trying to compile with

    • Missing, miscon
    fi
    gured, and outdated dev tools

    • PATH issues

    • Setting ENV vars and other compilation settings globally in shell startup
    fi
    le
    What can affect Ruby installation?


    View Slide

12. LDFLAGS


    CPPFLAGS


    RUBY_CFLAGS


    PKG_CONFIG_PATH


    --with-openssl-dir


    -Wno-error=implicit-function-declaration




    View Slide

13. View Slide

14. The script was such a life saver. Finally
    got my Flutter project working on my


    laptop after literally one year!
    Nicole Manson


    View Slide

15. This script is truly a lifesaver! I couldn't
    get any version managers to work
    properly.
    Gelo Rosel


    View Slide

16. You are a lifesaver, I was struggling
    with installing rails on my m1 MBP


    and your script saved all the hassle.
    Abdullah Ashraf


    View Slide

17. Your script was a lifesaver, thank you
    so much, I am incredibly grateful for
    your work.
    Justin Festa


    View Slide

18. • Painless Ruby dev setup in 15 minutes or less

    • Works with all version managers

    • Installs Ruby faster than any other version manager (2x as fast as
    rbenv/asdf)

    • Easily install Ruby versions as old as 2.1

    • Set up a new Mac in minutes with all your dev tools, Mac apps,
    fonts, Git preferences, macOS preferences, and GitHub repos.

    • Reset mode backs up and cleans up your dev setup in 1 minute
    rubyonmac.dev
    Ruby on Mac


    View Slide

19. • Prime customers: 1 year of updates, 1 Mac at a time
    Gotta Have Limits


    View Slide

20. View Slide

21. • Prime customers: 1 year of updates, 1 Mac at a time

    • Use Ruby for license veri
    fi
    cation code

    • License-related code can't be easily bypassed by customer

    • Scripts need to be able to run on a brand new Mac with no dev
    tools

    • Customer can reliably activate and deactivate Macs
    Gotta Have Limits


    View Slide

22. 💰
    👤


    View Slide

23. View Slide

24. github.com/neurobin/shc


    View Slide

25. test.sh shc test.sh.x.c ./test


    View Slide

26. View Slide

27. View Slide

28. View Slide

29. View Slide

30. View Slide

31. View Slide

32. github.com/jruby/warbler


    View Slide

33. github.com/phusion/
    traveling-ruby


    View Slide

34. github.com/pmq20/ruby-packer


    View Slide

35. • Supplies a patched Ruby

    • Compiles that Ruby locally (with native extensions)

    • Packs it into a squashfs archive

    • Ruby is patched to look inside the squashfs and the
    real
    fi
    lesystem
    How ruby-packer works


    View Slide

36. 👍 single file, works with all native
    extensions


    View Slide

37. 👎 no cross-packaging support


    View Slide

38. View Slide

39. github.com/ericbeland/
    ruby-packer


    View Slide

40. github.com/motor-admin/
    ruby-packer


    View Slide

41. View Slide

42. View Slide

43. View Slide

44. View Slide

45. unable to find ecdh parameters


    View Slide

46. View Slide

47. View Slide

48. View Slide

49. View Slide

50. HOLD UP


    View Slide

51. WAIT A
    MINUTE


    View Slide

52. rubyc --openssl-dir=/opt/homebrew/etc/openssl@1.1


    View Slide

53. rom script -m reset


    View Slide

54. certificate verify failed (OpenSSL::SSL::SSLError)


    View Slide

55. ➜ ls -la /opt/homebrew/etc/openssl@1.1


    total 0


    drwxr-xr-x@ 3 moncef admin 96B Sep 12 10:59 ./


    drwxrwxr-x@ 16 moncef admin 512B Sep 12 10:59 ../


    lrwxr-xr-x@ 1 moncef admin 42B Sep 12 10:59
    cert.pem@ -> /opt/homebrew/etc/ca-certificates/cert.pem


    View Slide

56. ➜ openssl version -a


    LibreSSL 3.3.6


    built on: date not available


    platform: information not available


    options: bn(64,64) rc4(ptr,int) des(idx,cisc,16,int)
    blowfish(idx)


    compiler: information not available


    OPENSSLDIR: "/private/etc/ssl"


    View Slide

57. rubyc --openssl-dir=/private/etc/ssl test.rb -o test


    View Slide

58. 🎉


    View Slide

59. bundle exec rake rubyc


    View Slide

60. rubyc --openssl-dir=/private/etc/ssl test.rb -o test


    View Slide

61. View Slide

62. View Slide

63. • Sign up for Apple Developer Program ($99/year)
    Gotta Be Legit


    View Slide

64. View Slide

65. • https://developer.apple.com/documentation/devicecheck
    One, Two, One, Two
    DeviceCheck


    View Slide

66. View Slide

67. View Slide

68. View Slide

69. import DeviceCheck


    public func getDeviceToken(completion: @escaping (String?) -> ()) {


    let currentDevice = DCDevice.current


    if currentDevice.isSupported


    {


    currentDevice.generateToken(completionHandler: { (data, error) in


    if let tokenData = data {


    let tokenString = tokenData.base64EncodedString()


    print("Device token generated 🎉")


    completion(tokenString)


    } else {


    print("Error generating token: \(error!.localizedDescription)")


    }


    })


    } else {


    print("Device is not supported") // Simulators or etc.


    }


    }


    View Slide

70. getDeviceToken { deviceToken in


    var request = URLRequest(url: "http://localhost:3000/test")


    request.httpMethod = "POST"




    // Header


    request.setValue(deviceToken, forHTTPHeaderField: "Device-Token")




    // Body


    request.setValue("application/json; charset=utf-8", forHTTPHeaderField: "Content-Type")


    let json = ["device_token": deviceToken] as [String : Any]


    let jsonData = try! JSONSerialization.data(withJSONObject: json)


    request.httpBody = jsonData as Data




    // Send it to server


    let downloadTask = URLSession.shared.dataTask(with: request, completionHandler: { data,
    response, error in


    ...


    })


    }


    View Slide

71. HOLD UP


    View Slide

72. WAIT A
    MINUTE


    View Slide

73. ??


    View Slide

74. View Slide

75. View Slide

76. View Slide

77. View Slide

78. let homeDirectory = NSHomeDirectory()




    let fileURL = URL(fileURLWithPath: "\(homeDirectory)/token.txt"


    if let data = token.data(using: .utf8) {


    do {


    try data.write(to: fileURL)


    } catch {


    print("Error writing token to the file: \(error)")


    }


    }


    View Slide

79. DeviceCheck Token ✅


    View Slide

80. Ruby script binary ✅


    View Slide

81. Bash script binary ✅


    View Slide

82. if ! ./verify_license; then


    exit


    fi


    View Slide

83. codesign --timestamp \


    --options=runtime \


    -s "5NB2AVZQPV" \


    -v verify_license


    View Slide

84. codesign --display --verbose=1 verify_license


    View Slide

85. Executable=/Users/moncef/projects/rubyonmac-prime/verify_license


    Identifier=verify_license


    Format=Mach-O thin (arm64)


    Signature size=8981


    Timestamp=Sep 9, 2023 at 16:52:16


    Info.plist=not bound


    TeamIdentifier=5NB2AVZQPV


    Runtime Version=13.3.0


    Sealed Resources=none




    View Slide

86. require 'json'


    result = `git for-each-ref --sort=-creatordate --format='%
    (creatordate:short) | %(contents)' refs/tags`


    tags = result.split("\n\n")


    versions = tags.each_with_object([]) do |tag, array|


    date = tag.split(" | ").first


    version = tag.split("Release ")[1]


    array.push({date:, version:})


    end


    File.write("prime-versions.json", JSON.generate(versions))




    View Slide

87. View Slide

88. codesign \


    --timestamp \


    --options=runtime \


    -s "5NB2AVZQPV" \


    --prefix="com.rubyonmac.2.0.22." \


    -v verify_license


    View Slide

89. Executable=/Users/moncef/projects/rubyonmac-prime/verify_license


    Identifier=com.rubyonmac.2.0.22.verify_license


    Format=Mach-O thin (arm64)


    Signature size=8981


    Timestamp=Sep 9, 2023 at 16:52:16


    Info.plist=not bound


    TeamIdentifier=5NB2AVZQPV


    Runtime Version=13.3.0


    Sealed Resources=none




    View Slide

90. View Slide

91. View Slide

92. View Slide

93. View Slide

94. View Slide

95. View Slide

96. View Slide

97. View Slide

98. View Slide

99. View Slide

100. View Slide

101. View Slide

102. View Slide

103. View Slide

104. 💰
     👤


     View Slide

105. View Slide

106. Customer.exists?(email:)
     ❌


     View Slide

107. Customer.find_by(email:).present?
     ❌


     View Slide

108. Customer.where(email:).reload.present?
     ❌


     View Slide

109. Customer.uncached { Customer.where(email:).to_a.present? }
     ✅


     View Slide

110. • Generate the license

     • Store it in S3 with ActiveStorage

     • Respond to Paddle with plain text containing link to the license

     • Paddle emails customer
     Go With the Flow


     View Slide

111. • Customer downloads license and latest Ruby on Mac release

     • Customer runs .pkg installer

     • Installer puts ROM Token Generator macOS app in /Applications

     • Installer unzips rubyonmac folder
     Go With the Flow


     View Slide

112. • Customer runs Bash script

     • Bash script checks that license veri
     fi
     cation binary exists and that it's
     signed by me

     • License is decrypted and email and product are extracted

     • ROM Token Generator app is opened in the background

     • Token gets saved to a
     fi
     le
     Go With the Flow


     View Slide

113. • Token is read from the
     fi
     le and stored in a variable

     • Token Generator app is quit

     • Script sends token, email, and product to the Rails app

     • Rails app performs validations
     Go With the Flow


     View Slide

114. • Send request to Apple's "query_two_bits" endpoint

     • "Failed to
     fi
     nd bit state" means ROM has not yet been run on this Mac

     • Send request to "update_two_bits" endpoint to set bit0 and bit1

     • If device already activated, Apple returns current bit0 and bit1 values
     Go With the Flow


     View Slide

115. • Verify current version was released before license expiration

     • Bash script can continue

     • License veri
     fi
     cation takes ~1 second
     Go With the Flow


     View Slide

116. View Slide

117. • MacBook Pro with Touch Bar (2016 and 2017) and Apple T1 Chip

     • Intel-based Mac computers with Apple T2 Security Chip

     • Mac computers with Apple silicon
     Secure Enclave


     View Slide

118. Copying latest Ruby on Mac files...


     cp: rom_arm64: No such file or directory


     View Slide

119. View Slide

120. Copying latest Ruby on Mac files...


     The rom-prime_arm64 file is missing!


     You are most likely running SentinelOne, which removed the file.


     Ruby on Mac Prime is not compatible with SentinelOne.


     Only the Ultimate version is.


     Please upgrade to Ruby on Mac Ultimate with coupon code FOOBAR:


     https://www.rubyonmac.dev/pricing


     If you're not running SentinelOne, please report this issue to
     moncef@rubyonmac.dev


     View Slide

121. • Testing
     Ruby Rewrite Benefits


     View Slide

122. • Testing

     • User Experience
     Ruby Rewrite Benefits


     View Slide

123. • Testing

     • User Experience

     • Future Proof
     Ruby Rewrite Benefits


     View Slide

124. Thank You!
     And a Gift
     5⃣ RMR50


     4⃣ RMR40


     3⃣ RMR30


     2⃣ RMR20


     1⃣ RMR10


     rubyonmac.dev/pricing


     View Slide
