Go言語での排他制御/Mutual exclusion in Golang

Go言語での排他制御/Mutual exclusion in Golang

Geeks Who Drink in Fukuoka -Go Go Golang Edition!-
https://nulab.connpass.com/event/57238/

monochromegane

June 28, 2017
Tweet

More Decks by monochromegane

Other Decks in Programming

Transcript

  1. GoݴޠͰͷഉଞ੍ޚ
    monochromegane / Pepabo R&D Institute, GMO Pepabo, Inc.
    2017.06.28 Geeks Who Drink in Fukuoka -Go Go Golang Edition!-
    Mutual exclusion in Golang.

    View Slide

  2. ϓϦϯγύϧΤϯδχΞ
    ࡾ୐ ༔հ / @monochromegane
    2
    http://blog.monochromegane.com
    Yusuke Miyake
    ϖύϘݚڀॴ ݚڀһ

    View Slide

  3. 1. Motivation
    2. Mutual exclusion
    3. Resource locking
    3
    Contents

    View Slide

  4. 1.
    Motivation

    View Slide

  5. Gannoy
    Approximate nearest neighbor search server
    and dynamic index written in Golang.
    https://github.com/monochromegane/gannoy

    View Slide

  6. Similar images search system using Gannoy
    6
    Features Similar items
    Gannoy
    [2048]float64
    query
    by http
    find similar features
    mapping
    similar features
    to items
    response
    Deep CNN
    index
    Features
    [2048]float64
    Deep CNN
    register
    by http

    View Slide

  7. Many goroutines access one resource
    concurrently.

    View Slide

  8. 2.
    Mutual exclusion

    View Slide

  9. Many goroutines access one variable
    concurrently.

    View Slide

  10. • sync.Mutex
    • A Mutex is a mutual exclusion lock.
    • sync.RWMutex
    • An RWMutex is a reader/writer mutual exclusion lock. The lock can be held
    by an arbitrary number of readers or a single writer.
    10
    Mutual exclusion in Golang

    View Slide

  11. View Slide

  12. 12
    type Free struct {
    mu sync.Mutex
    free []int
    }
    func (f *Free) push(id int) {
    f.mu.Lock()
    defer f.mu.Unlock()
    f.free = append(f.free, id)
    }
    func (f *Free) pop() (int, error) {
    f.mu.Lock()
    defer f.mu.Unlock()
    if len(f.free) == 0 {
    return -1, fmt.Errorf("empty")
    }
    x, newFree := f.free[len(f.free)-1], f.free[:len(f.free)-1]
    f.free = newFree
    return x, nil
    }
    Free nodes stack using sync.Mutex
    Exclusive lock
    Exclusive lock

    View Slide

  13. 13
    type Maps struct {
    mu *sync.RWMutex
    keyToId map[int]int
    }
    func (m *Maps) add(id, key int) {
    m.mu.Lock()
    defer m.mu.Unlock()
    m.keyToId[key] = id
    }
    func (m Maps) getId(key int) (int, error) {
    m.mu.RLock()
    defer m.mu.RUnlock()
    if id, ok := m.keyToId[key]; !ok {
    return -1, fmt.Errorf("not found")
    } else {
    return id, nil
    }
    }
    Mapping id and key using sync.RWMutex
    Exclusive lock
    Shared lock

    View Slide

  14. • Mutex and RWMutex must not be copied after first use.
    14
    Caution
    type Maps struct {
    mu sync.RWMutex
    keyToId map[int]int
    }
    func (m Maps) getId(key int) (int, error) {
    fmt.Printf("mu address in getId: %p\n", &m.mu)
    m.mu.RLock()
    defer m.mu.RUnlock()
    if id, ok := m.keyToId[key]; !ok {
    return -1, fmt.Errorf("not found")
    } else {
    return id, nil
    }
    }
    If type of member isn’t a pointer
    receiver isn’t a pointer
    $ go run -race main.go
    mu address in getId: 0xc420010110
    mu address in getId: 0xc4200781c0
    ==================
    WARNING: DATA RACE
    wg.Add(4)
    for i := 0; i < 2; i++ {
    go func(i int) {
    maps.add(i, i)
    wg.Done()
    }(i)
    go func(i int) {
    maps.getId(i)
    wg.Done()
    }(i)
    }
    wg.Wait()
    and

    View Slide

  15. 3.
    Resource locking

    View Slide

  16. Many goroutines access one file
    concurrently.

    View Slide

  17. Data structure of Gannoy
    17
    Hyperplane
    Logical data structure Data structure on file system
    Bucket Bucket
    /PEF
    'FBUVSFT

    /PEF
    'FBUVSFT

    /PEF
    'FBUVSFT

    /PEF
    'FBUVSFT

    Node
    (Features)
    /PEF
    'FBUVSFT

    /PEF
    'FBUVSFT

    /PEF
    'FBUVSFT

    /PEF
    'FBUVSFT

    Node
    (Features)
    query
    features
    cosine similarity > 0
    <= 0
    B N
    H N
    free (1byte)
    number of descendants (4byte)
    key (4byte)
    parents (4byte * tree)
    children (4byte * K)
    or
    hyperplane / features (8byte* dim)

    View Slide

  18. • syscall.Flock
    • apply or remove an advisory lock on an open file.
    • syscall.FcntlFlock
    • file control. F_SETLK, F_SETLKW, and F_GETLK are used to acquire,
    release, and test for the existence of record locks.
    18
    Resource locking in Golang (using system call)
    locks associated with
    Flock file open file description
    Fcntl byte range process ID and i-node

    View Slide

  19. 19
    // Flock
    func flock(fd uintptr) {
    syscall.Flock(int(fd), syscall.LOCK_EX) // or LOCK_SH
    defer syscall.Flock(int(fd), syscall.LOCK_UN)
    }
    // Fcntl + F_SETLKW
    func fcntl(fd uintptr, start, len int64) {
    syscall.FcntlFlock(fd, syscall.F_SETLKW, &syscall.Flock_t{
    Start: start,
    Len: len,
    Type: syscall.F_WRLCK, // or syscall.F_RDLCK
    Whence: io.SeekStart,
    })
    defer syscall.FcntlFlock(fd, syscall.F_SETLKW, &syscall.Flock_t{
    Start: start,
    Len: len,
    Type: syscall.F_UNLCK,
    Whence: io.SeekStart,
    })
    }
    Flock
    Shared or Exclusive lock
    Fcntl + F_SETLKW
    Shared or Exclusive lock
    byte range

    View Slide

  20. 20
    file descriptor
    fd0
    fd1
    fd2
    Open file description
    0
    1
    2
    10
    20
    i-node
    1000
    1001
    1002
    2000
    3000
    file descriptor
    fd0
    fd1
    fd2
    fd10
    dup
    fork
    Process System System
    Goroutine
    Goroutine
    OFD
    0
    2
    ProcessID i-node
    100 1000
    101 1001
    Flock Fcntl + F_SETLKW
    Locks that associated with same
    one don’t block each other.

    View Slide

  21. 21
    file1, _ := os.OpenFile("dummy.txt", os.O_RDWR, 0)
    file2, _ := os.OpenFile("dummy.txt", os.O_RDWR, 0)
    fd1 := file1.Fd()
    fd2 := file2.Fd()
    var wg sync.WaitGroup
    wg.Add(2)
    locker := gannoy.Flock{}
    go lockAndProcess("fd1", fd1, locker, &wg)
    go lockAndProcess("fd2", fd2, locker, &wg)
    wg.Wait()
    fd2 processed something (1sec).
    fd2 processed something (2sec).
    fd2 processed something (3sec).
    fd1 processed something (1sec).
    fd1 processed something (2sec).
    fd1 processed something (3sec).
    locker := gannoy.Fcntl{}
    fd2 processed something (1sec).
    fd1 processed something (1sec).
    fd2 processed something (2sec).
    fd1 processed something (2sec).
    fd2 processed something (3sec).
    fd1 processed something (3sec).
    No blocking
    Blocking
    Flock
    Fcntl
    +
    F_SETLKW

    View Slide

  22. 22
    func lockAndProcess(name string, fd uintptr, locker gannoy.Locker, wg *sync.WaitGroup) {
    locker.WriteLock(fd, 0, 4)
    defer locker.UnLock(fd, 0, 4)
    t := time.NewTicker(1 * time.Second)
    count := 1
    loop:
    for {
    select {
    case <-t.C:
    fmt.Printf("%s processed something (%d sec).\n", name, count)
    count++
    if count > 3 {
    break loop
    }
    }
    }
    t.Stop()
    wg.Done()
    }

    View Slide

  23. Open file description lock
    open file description locks are associated with the open
    file description on which they are acquired,
    http://man7.org/linux/man-pages/man2/fcntl.2.html

    https://www.oreilly.co.jp/community/blog/2014/11/file-lock-and-new-ofd-lock.html

    View Slide

  24. 24
    type Fcntl struct {
    }
    const F_OFD_SETLKW = 38
    func (f Fcntl) ReadLock(fd uintptr, start, len int64) error {
    return f.fcntl(syscall.F_RDLCK, fd, start, len)
    }
    func (f Fcntl) WriteLock(fd uintptr, start, len int64) error {
    return f.fcntl(syscall.F_WRLCK, fd, start, len)
    }
    func (f Fcntl) UnLock(fd uintptr, start, len int64) error {
    return f.fcntl(syscall.F_UNLCK, fd, start, len)
    }
    func (f Fcntl) fcntl(typ int16, fd uintptr, start, len int64) error {
    return syscall.FcntlFlock(fd, F_OFD_SETLKW, &syscall.Flock_t{
    Start: start,
    Len: len,
    Type: typ,
    Whence: io.SeekStart,
    })
    }
    Command for working with
    open file description locks
    Exclusive lock
    Shared lock

    View Slide

  25. 25
    file1, _ := os.OpenFile("dummy.txt", os.O_RDWR, 0)
    file2, _ := os.OpenFile("dummy.txt", os.O_RDWR, 0)
    fd1 := file1.Fd()
    fd2 := file2.Fd()
    var wg sync.WaitGroup
    wg.Add(2)
    locker := gannoy.Flock{}
    go lockAndProcess("fd1", fd1, locker, &wg)
    go lockAndProcess("fd2", fd2, locker, &wg)
    wg.Wait()
    fd2 processed something (1sec).
    fd2 processed something (2sec).
    fd2 processed something (3sec).
    fd1 processed something (1sec).
    fd1 processed something (2sec).
    fd1 processed something (3sec).
    locker := gannoy.Fcntl{}
    Blocking!!
    Blocking
    Flock
    Fcntl
    +
    F_ODF_SETLKW
    fd2 processed something (1sec).
    fd2 processed something (2sec).
    fd2 processed something (3sec).
    fd1 processed something (1sec).
    fd1 processed something (2sec).
    fd1 processed something (3sec).

    View Slide

  26. 1. non-POSIX (Only Linux)
    2. kernel >= 3.15.0 (CentOS7.2 is 3.10.0…)
    26
    Caution
    func newLocker() Locker {
    bytes, err := exec.Command("uname", "-sr").Output()
    if err != nil {
    return Flock{}
    }
    kernel := strings.Split(strings.TrimRight(string(bytes), "\n"), " ")
    if len(kernel) != 2 {
    return Flock{}
    }
    if kernel[0] == "Linux" && !semver.New(kernel[1]).LessThan(*semver.New("3.15.0")) {
    return Fcntl{}
    }
    return Flock{}
    }
    kernel >= 3.15.0

    View Slide

  27. ݚڀһɺੵۃతʹืूதʂ
    http://rand.pepabo.com/

    View Slide
