What's New in JHipsterLand - DevNexus 2017

JHipster is an application generator that allows you to create monoliths or microservices based on Spring Boot and Angular. It leverages Spring Cloud for microservices and contains best-of-breed JavaScript and CSS libraries for creating your UI. In this session, you’ll learn about what’s new in JHipster. Topics explored include Angular 2, Progressive Web Apps, HTTP/2, JUnit 5, and Spring 5.

Transcript

1. WHAT’S NEW IN JHIPSTERLAND
   MATT RAIBLE / @MRAIBLE


   View Slide

2. Blogger on raibledesigns.com
   UI Architect and Java Champion
   Father, Skier, Mountain
   Biker, Whitewater Rafter
   Web Framework Connoisseur
   Who is Matt Raible?
   Bus Lover
   Stormpath Developer Evangelist


   View Slide

3. View Slide

4. Stormpath User Management


   View Slide

5. About You
   Are you a Java developer that likes Spring?

   Do you like JavaScript? TypeScript?

   Anyone using Angular?

   Have you used JHipster before?


   View Slide

6. JHipster jhipster.github.io


   View Slide

7. JHipster is Open Source
   Web Statistics, January 2017

   282K Page Views

   18K Downloads

   GitHub Statistics

   6229 Stars

   298 Contributors
   www.openhub.net/p/generator-jhipster


   View Slide

8. JHipster 4


   View Slide

9. How to use JHipster
   To install JHipster and Yeoman, use npm:

   npm install -g yo generator-jhipster
   Then create a directory and cd into it:

   mkdir myapp && cd myapp
   Then run Yeoman:

   yo jhipster


   View Slide

10. View Slide

11. Feature In JHipster 4?
    Angular
    ✅
    Progressive Web Apps
    ❌
    HTTP/2
    ✅
    JUnit 5
    ❌
    Spring 5
    ❌
    Bootstrap 4
    ✅
    What’s new in JHipsterLand?


    View Slide

12. View Slide

13. HTTP/2
    Binary, instead of textual

    Fully multiplexed, instead of ordered and blocking

    Can use one connection for parallelism

    Uses header compression to reduce overhead

    Allows servers to “push” responses proactively into client caches



    View Slide

14. HTTP/2 in JHipster
    /*
    * Enable HTTP/2 for Undertow - https://twitter.com/ankinson/status/829256167700492288
    * HTTP/2 requires HTTPS, so HTTP requests will fallback to HTTP/1.1.
    * See the JHipsterProperties class and your application-*.yml configuration files
    * for more information.
    */
    if (jHipsterProperties.getHttp().getVersion().equals(JHipsterProperties.Http.Version.V_2_0)) {
    if (container instanceof UndertowEmbeddedServletContainerFactory) {
    ((UndertowEmbeddedServletContainerFactory) container)
    .addBuilderCustomizers((builder) -> {
    builder.setServerOption(UndertowOptions.ENABLE_HTTP2, true);
    });
    }
    }


    View Slide

15. HTTP/2 in JHipster
    # ===============================================================================================
    # To enable SSL, generate a certificate using:
    # keytool -genkey -alias blog -storetype PKCS12 -keyalg RSA -keysize 2048 -keystore keystore.p12 -validity 3650
    #
    # You can also use Let's Encrypt:
    # https://maximilian-boehm.com/hp2121/Create-a-Java-Keystore-JKS-from-Let-s-Encrypt-Certificates.htm
    #
    # Then, modify the server.ssl properties so your "server" configuration looks like:
    #
    # server:
    # port: 8443
    # ssl:
    # key-store: keystore.p12
    # key-store-password:
    # keyStoreType: PKCS12
    # keyAlias: blog
    # ===============================================================================================
    jhipster:
    http:
    version: V_1_1 # To use HTTP/2 you will need SSL support (see above the "server.ssl" configuration)


    View Slide

16. View Slide

17. JUnit 5


    View Slide

18. Spring 5


    View Slide

19. Spring Boot 1.5
    Apache Kafka Support

    Cloud Foundry actuator extensions

    Spring Data Ingalls

    LDAP support

    Loggers endpoint

    Spring Security 4.2 Support


    View Slide

20. Bootstrap 4


    View Slide

21. Bootstrap 4


    View Slide

22. Build Tools
    Java: Maven or Gradle

    AngularJS: Gulp

    Angular: Webpack

    Web Dependencies:

    AngularJS: Bower

    Angular: npm or yarn


    View Slide

23. View Slide

24. Get Started with JHipster 4 Demo


    View Slide

25. AAA Sonar Rating


    View Slide

26. JHipster Libraries


    View Slide

27. Thoughtworks Radar


    View Slide

28. View Slide

29. View Slide

30. View Slide

31. View Slide

32. Continuous Integration and Deployment
    $ yo jhipster:ci-cd

    Supports:

    Jenkins pipeline

    Travis CI

    GitLab CI

    CircleCI jhipster.github.io/setting-up-ci/


    View Slide

33. View Slide

34. Deploying to Production
    Cloud Foundry

    Heroku

    Kubernetes

    AWS

    AWS with Boxfuse


    View Slide

35. Deploy to Google Cloud with Kubernetes
    1. Convert a monolith to a microservice gateway

    hibernateCache: “hazelcast”

    serviceDiscovery: “eureka”

    applicationType: “gateway”

    2. Create microservices app and generate entities

    3. Create UI for entities on gateway using yo jhipster:entity

    4. Clone JHipster Registry in same directory and prove it all works


    View Slide

36. Deploy to Google Cloud with Kubernetes
    5. Create a sub-directory alongside apps and run yo jhipster:kubernetes

    6. Create a Google Cloud project - console.cloud.google.com

    7. Set project using gcloud config set project $project-name

    8. Create a cluster:

    gcloud container clusters create demo --machine-type=n1-
    standard-2 --scopes cloud-platform
    9. Authenticate:

    gcloud auth application-default login --no-launch-browser


    View Slide

37. Deploy to Google Cloud with Kubernetes
    10. Run kubectl commands to deploy

    11. Use port-forwarding to see registry locally:

    kubectl port-forward jhipster-registry-0 8761:8761
    12. Scale microservice apps as needed:

    kubectl scale deployment store --replicas=3


    View Slide

38. Microservices with Docker Demo


    View Slide

39. Shortcut to becoming a JHipster Expert?
    JUST DO IT.


    View Slide

40. The JHipster Mini-Book
    2.0 Release on Dec 5, 2016

    jhipster-book.com

    21-points.com

    @jhipster_book

    Write your own InfoQ mini-book! github.com/mraible/infoq-mini-book


    View Slide

41. Keep in touch!

    raibledesigns.com

    @mraible

    Presentations

    slideshare.net/mraible

    Code

    github.com/mraible
    Questions?


    View Slide
