Building an Android CI Pipeline with GitHub Actions - Chicago Roboto 2020

Learn to build a multi-functional continuous integration pipeline for Android using GitHub Actions.

Learn More:
[Samples] GitHubActionsAutomationSandbox:
https://github.com/n8ebel/GitHubActionsAutomationSandbox

[YouTube] Setup CI for Android Using GitHub Actions:
https://www.youtube.com/watch?v=K9w01h4-Wnc

[Doc] GitHub Actions Quickstart Guide:
https://docs.github.com/en/free-pro-team@latest/actions/quickstart

[Browse] GitHub Actions Marketplace:
https://github.com/marketplace?type=actions

Transcript

1. ANDROID DEVELOPER
   @n8ebel www.goobar.io
   Nate Ebel
   BUILDING AN ANDROID

   CI PIPELINE WITH

   GITHUB ACTIONS
   #chicagoroboto
   ANDROID DEVELOPER
   @n8ebel www.goobar.io
   Nate Ebel


   View Slide

2. CHICAGO ROBOTO
   #chicagoroboto


   View Slide

3. GITHUB ACTIONS

   MAKES ANDROID CI

   EASY


   View Slide

4. CI

   What is it?


   View Slide

5. Continuous Integration:
   The process of regularly checking-in,
   building, and validating code


   View Slide

6. Consistently build the

   Right thing at the

   Right time


   View Slide

7. Automate the validation
   and distribution of your
   code


   View Slide

8. Save your team time,
   energy, and headaches


   View Slide

9. CONTINUOUS INTEGRATION PROVIDERS
   CircleCi Bitrise
   GitHub Actions


   View Slide

10. #// concepts are transferable


    View Slide

11. GitHub Actions

    How to start building?


    View Slide

12. Build:
    A set of repeatable, automated tasks run
    on a remote server


    View Slide

13. Github Actions:
    Self-contained commands that package
    specific, reusable functionality for your
    build


    View Slide

14. Workflow:
    A triggerable set of build commands.
    Different workflows can be used for
    different build types.


    View Slide

15. Job:
    A set of build steps run on the same
    virtual machine


    View Slide

16. Step:
    Smallest individual element of a
    workflow. Steps perform tasks using a
    GitHub Action or your own scripts/
    commands.


    View Slide

17. Building Blocks


    View Slide

18. Building Blocks
    Build Pull Request
    Create Workflow


    View Slide

19. Building Blocks
    Build Pull Request
    Add Job
    Job


    View Slide

20. Building Blocks
    Build Pull Request
    Add Multiple Jobs
    Job 1
    Job 2
    Job 3


    View Slide

21. Building Blocks
    Build Pull Request
    Job 1
    Job 2
    Job 3
    Add Multiple Jobs


    View Slide

22. Building Blocks
    Build Pull Request
    Job 1
    Job 2
    Job 3
    Step 1
    Step 2
    Step 3
    Add Steps


    View Slide

23. Building Blocks
    Build Pull Request
    Job 1
    Job 2
    Job 3
    Step 1 - Action
    Step 2 - Command
    Step 3 - Action
    Use Actions

    Use Commands


    View Slide

24. Building Pull Requests

    How to create our first

    Android CI workflow?


    View Slide

25. DEFINING A WORKFLOW


    View Slide

26. Create a Pull Request Workflow File
    .github/workflows/build_pull_request.yml
    name: Build Pull Request


    View Slide

27. Run on ‘push’
    .github/workflows/build_pull_request.yml
    name: Build Pull Request
    on: push


    View Slide

28. Run on ‘pull_request’
    .github/workflows/build_pull_request.yml
    name: Build Pull Request
    on: pull_request


    View Slide

29. Add a job
    .github/workflows/build_pull_request.yml
    name: Build Pull Request
    on: pull_request
    jobs:
    test_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:


    View Slide

30. Checkout the code
    .github/workflows/build_pull_request.yml
    name: Build Pull Request
    on: pull_request
    jobs:
    test_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2


    View Slide

31. Assemble your apk
    .github/workflows/build_pull_request.yml
    name: Build Pull Request
    on: pull_request
    jobs:
    test_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    - name: Assemble Debug
    run: ./gradlew assembleDebug


    View Slide

32. Push to GitHub
    .github/workflows/build_pull_request.yml
    name: Build Pull Request
    on: pull_request
    jobs:
    test_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    - name: Assemble Debug
    run: ./gradlew assembleDebug


    View Slide

33. EXPANDING OUR BUILD


    View Slide

34. Add Gradle caching
    .github/workflows/build_pull_request.yml
    name: Build Pull Request
    on: pull_request
    jobs:
    test_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    - name: Assemble Debug
    run: ./gradlew assembleDebug


    View Slide

35. Add Gradle caching
    .github/workflows/build_pull_request.yml
    jobs:
    test_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    - name: Assemble Debug
    run: ./gradlew assembleDebug
    - name: Restore Cache
    uses: actions/cache@v2
    with:
    path: |
    ~/.gradle/caches
    ~/.gradle/wrapper
    key: ${{ runner.os }}-gradle-${{ hashFiles('**/*.gradle*') }}
    restore-keys: |
    ${{ runner.os }}-gradle-


    View Slide

36. Send notification to Slack
    .github/workflows/build_pull_request.yml
    - name: Assemble Debug
    run: ./gradlew assembleDebug
    - uses: technote-space/workflow-conclusion-action@v1
    - uses: 8398a7/action-slack@v3
    with:
    status: ${{ env.WORKFLOW_CONCLUSION }}
    fields: commit,ref,workflow,eventName
    author_name: ${{ github.actor }}
    icon_emoji: ':robot_face:'
    username: "Pull Request Build Status"
    text: |
    ${{ env.WORKFLOW_CONCLUSION }}:
    https://github.com/n8ebel/GitHubActionsAutomationSandbox/actions/runs/${{ github.run_id }}
    env:
    GITHUB_TOKEN: ${{ secrets.GITHUB_TOKEN }}
    SLACK_WEBHOOK_URL: ${{ secrets.SLACK_WEBHOOK }}


    View Slide

37. Store keys, app ids, web hooks, etc using Secrets


    View Slide

38. #github-actions-demo in Chicago Roboto Slack community


    View Slide

39. Send notification to Slack
    .github/workflows/build_pull_request.yml
    - name: Assemble Debug
    run: ./gradlew assembleDebug
    - uses: technote-space/workflow-conclusion-action@v1
    - uses: 8398a7/action-slack@v3
    with:
    status: ${{ env.WORKFLOW_CONCLUSION }}
    fields: commit,ref,workflow,eventName
    author_name: ${{ github.actor }}
    icon_emoji: ':robot_face:'
    username: "Pull Request Build Status"
    text: |
    ${{ env.WORKFLOW_CONCLUSION }}:
    https://github.com/n8ebel/GitHubActionsAutomationSandbox/actions/runs/${{ github.run_id }}
    env:
    GITHUB_TOKEN: ${{ secrets.GITHUB_TOKEN }}
    SLACK_WEBHOOK_URL: ${{ secrets.SLACK_WEBHOOK }}


    View Slide

40. Add additional steps
    .github/workflows/build_pull_request.yml
    - name: Assemble Debug
    run: ./gradlew assembleDebug
    - name: Run Debug Tests
    run: ./gradlew testDebugUnitTest
    - name: Run Debug ktlint
    run: ./gradlew ktlintDebugCheck
    - name: Run Debug Lint
    run: ./gradlew lintDebug


    View Slide

41. Store build outputs as artifacts
    .github/workflows/build_pull_request.yml
    - name: Assemble Debug
    run: ./gradlew assembleDebug
    - name: Upload Test Reports
    if: ${{ always() }}
    uses: actions/upload-artifact@v2
    with:
    name: test-reports
    path: '**/build/reports/tests/'
    - name: Upload APK
    uses: actions/upload-artifact@v2
    with:
    name: apk
    path: app/build/outputs/apk/debug/**.apk


    View Slide

42. PARALLELIZING JOBS


    View Slide

43. Add a Test job
    .github/workflows/build_pull_request.yml
    test_job:
    name: Test
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    - name: Restore Cache
    uses: actions/cache@v2
    with:
    path: |
    ~/.gradle/caches
    ~/.gradle/wrapper
    key: ${{ runner.os }}-gradle-${{ hashFiles('**/*.gradle*') }}
    restore-keys: |
    ${{ runner.os }}-gradle-
    - name: Run Debug Tests
    run: ./gradlew testDebugUnitTest --continue
    - name: Upload Test Reports
    if: ${{ always() }}
    uses: actions/upload-artifact@v2
    with:
    name: test-reports
    path: '**/build/reports/tests/'


    View Slide

44. Add an Android Lint job
    .github/workflows/build_pull_request.yml
    lint_job:
    name: Lint
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    - name: Restore Cache
    uses: actions/cache@v2
    with:
    path: |
    ~/.gradle/caches
    ~/.gradle/wrapper
    key: ${{ runner.os }}-gradle-${{ hashFiles('**/*.gradle*') }}
    restore-keys: |
    ${{ runner.os }}-gradle-
    - name: Run Debug Lint
    run: ./gradlew lintDebug
    - name: Upload Lint Reports
    if: ${{ always() }}
    uses: actions/upload-artifact@v2
    with:
    name: lint-report
    path: '**/build/reports/lint-results-*'


    View Slide

45. Add an Assemble job
    .github/workflows/build_pull_request.yml
    assemble_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    - name: Restore Cache
    uses: actions/cache@v2
    with:
    path: |
    ~/.gradle/caches
    ~/.gradle/wrapper
    key: ${{ runner.os }}-gradle-${{ hashFiles('**/*.gradle*') }}
    restore-keys: |
    ${{ runner.os }}-gradle-
    - name: Assemble Debug
    run: ./gradlew assembleDebug
    - name: Upload APK
    uses: actions/upload-artifact@v2
    with:
    name: apk
    path: app/build/outputs/apk/debug/**.apk


    View Slide

46. Add a Slack notification job
    .github/workflows/build_pull_request.yml
    notification_job:
    needs: [test_job, lint_job, assemble_job]
    name: Notify Build Status
    runs-on: ubuntu-latest
    steps:
    - uses: technote-space/workflow-conclusion-action@v1
    - uses: 8398a7/action-slack@v3
    with:
    status: ${{ env.WORKFLOW_CONCLUSION }}
    fields: commit,ref,workflow,eventName
    author_name: ${{ github.actor }}
    icon_emoji: ':robot_face:'
    username: "Pull Request Build Status"
    text: |
    ${{ env.WORKFLOW_CONCLUSION }}:
    https://github.com/n8ebel/GitHubActionsAutomationSandbox/actions/runs/${{ github.run_id }}
    env:
    GITHUB_TOKEN: ${{ secrets.GITHUB_TOKEN }}
    SLACK_WEBHOOK_URL: ${{ secrets.SLACK_WEBHOOK }}


    View Slide

47. Handling job dependency failures
    .github/workflows/build_pull_request.yml
    notification_job:
    needs: [test_job, lint_job, assemble_job]
    name: Notify Build Status
    runs-on: ubuntu-latest
    steps:


    View Slide

48. Handling job dependency failures
    .github/workflows/build_pull_request.yml
    test_job:
    name: Test
    runs-on: ubuntu-latest
    steps:


    View Slide

49. Handling job dependency failures
    .github/workflows/build_pull_request.yml
    test_job:
    name: Test
    runs-on: ubuntu-latest
    continue-on-error: true
    steps:


    View Slide

50. SINGLE VS MULTIPLE JOBS
    Build

    Cost
    Build

    Measurement
    Build

    Times
    Build

    Complexity


    View Slide

51. Nightly Builds

    How to schedule
    workflows?


    View Slide

52. Create a Nightly build Workflow File
    .github/workflows/build_nightly.yml
    name: Nightly Build


    View Slide

53. Add a scheduled trigger using cron syntax
    .github/workflows/build_nightly.yml
    name: Nightly Build
    on:
    schedule:
    - cron: '0 0 * * *'


    View Slide

54. RUNNING UI TESTS


    View Slide

55. Add job for Android UI tests
    .github/workflows/build_nightly.yml
    android_test_job:
    name: Android Test
    runs-on: macos-latest
    steps:
    - name: Checkout
    uses: actions/checkout@v2
    …


    View Slide

56. Use android-emulator-runner action
    .github/workflows/build_nightly.yml
    - name: Run Android Tests
    uses: reactivecircus/android-emulator-runner@v2
    with:
    api-level: 29
    script: ./gradlew connectedDebugAndroidTest


    View Slide

57. Store test results
    .github/workflows/build_nightly.yml
    - name: Run Android Tests
    uses: reactivecircus/android-emulator-runner@v2
    with:
    api-level: 29
    script: ./gradlew connectedDebugAndroidTest
    - name: Upload Android Test Reports
    if: ${{ always() }}
    uses: actions/upload-artifact@v2
    with:
    name: android-test-reports
    path: '**/build/reports/androidTests/'


    View Slide

58. DISPLAYING BUILD STATUS


    View Slide

59. Building Feature Branches

    How to customize workflows
    for specific branches?


    View Slide

60. Create a Feature branch workflow
    .github/workflows/build_feature_branch.yml
    name: Build Feature Branch


    View Slide

61. Restrict workflow to specific branch naming
    pattern
    .github/workflows/build_feature_branch.yml
    name: Build Feature Branch
    on:
    push:
    branches: 'feature/**'


    View Slide

62. SETTING VERSION CODES


    View Slide

63. Pull VERSION_CODE from build environment
    app-versioning.gradle
    def DEFAULT_VERSION_CODE = 1
    ext.getUniqueVersionCode = {
    def code = System.getenv("VERSION_CODE")
    return (code != null && !code.isEmpty()) ? code.toInteger() : DEFAULT_VERSION_CODE
    }


    View Slide

64. Set VERSION_CODE from GitHub Run Id
    app-versioning.gradle
    - name: Assemble
    env:
    VERSION_CODE: ${{ github.run_id }}
    run: ./gradlew assembleDebug


    View Slide

65. DISTRIBUTING TO TESTERS


    View Slide

66. Upload to Firebase App Distribution
    app-versioning.gradle
    - name: Upload to Firebase App Distribution
    uses: wzieba/Firebase-Distribution-Github-Action@v1.2.1
    with:
    appId: ${{ secrets.FIREBASE_APP_ID }}
    token: ${{ secrets.FIREBASE_TOKEN }}
    groups: qa
    file: app/build/outputs/apk/debug/app-debug.apk


    View Slide

67. View Slide

68. Simplifying Releases

    How to automate release
    workflows?


    View Slide

69. Create a Release workflow
    .github/workflows/build_release.yml
    name: Build Release


    View Slide

70. Create a Release workflow
    .github/workflows/build_release.yml
    name: Build Release
    on:
    release:
    types: [published]


    View Slide

71. Assemble Release variant
    .github/workflows/build_release.yml
    name: Build Release
    on:
    release:
    types: [published]
    jobs:
    assemble_job:
    name: Assemble
    runs-on: ubuntu-latest
    steps:
    …
    - name: Assemble Release
    run: ./gradlew assembleRelease


    View Slide

72. Sign Release apk
    .github/workflows/build_release.yml
    …
    - name: Assemble Release
    run: ./gradlew assembleRelease
    - name: Sign Release
    uses: r0adkll/sign-android-release@v1
    with:
    releaseDirectory: app/build/outputs/apk/release
    signingKeyBase64: ${{ secrets.SIGNING_KEY }}
    alias: ${{ secrets.ALIAS }}
    keyStorePassword: ${{ secrets.KEY_STORE_PASSWORD }}
    keyPassword: ${{ secrets.KEY_PASSWORD }}


    View Slide

73. Add APK as Release binary
    .github/workflows/build_release.yml
    - name: Sign Release
    uses: r0adkll/sign-android-release@v1
    with:
    releaseDirectory: app/build/outputs/apk/release
    signingKeyBase64: ${{ secrets.SIGNING_KEY }}
    alias: ${{ secrets.ALIAS }}
    keyStorePassword: ${{ secrets.KEY_STORE_PASSWORD }}
    keyPassword: ${{ secrets.KEY_PASSWORD }}
    - name: Upload APK to Release
    uses: skx/github-action-publish-binaries@master
    env:
    GITHUB_TOKEN: ${{ secrets.GITHUB_TOKEN }}
    with:
    args: app/build/outputs/apk/release/**.apk


    View Slide

74. Upload APK to Google Play
    .github/workflows/build_release.yml
    - name: Upload APK to Release
    uses: skx/github-action-publish-binaries@master
    env:
    GITHUB_TOKEN: ${{ secrets.GITHUB_TOKEN }}
    with:
    args: app/build/outputs/apk/release/**.apk
    - name: Upload to Google Play
    uses: r0adkll/upload-google-play@v1
    with:
    serviceAccountJson: ${{ SERVICE_ACCOUNT_JSON }}
    packageName: com.n8ebel.githubactionsautomationsandbox
    releaseFile: app/build/outputs/apk/release/app-release-signed.apk
    track: internal
    whatsNewDirectory: distribution/whatsnew
    mappingFile: app/build/outputs/mapping/release/mapping.txt


    View Slide

75. GITHUB ACTIONS

    GO FAR BEYOND ANDROID


    View Slide

76. ACTION EXAMPLES
    First Time
    Contributors
    Danger
    Integration
    Semantic
    Versioning
    Auto

    Commit
    apk Size
    Comparison
    Code

    Coverage


    View Slide

77. Real World Experience

    How do GitHub Actions perform
    in production projects?


    View Slide

78. EXPERIENCES WITH GITHUB ACTIONS
    Faster

    Builds
    Reduced

    Complexity
    More

    Approachable
    Improved

    Failure

    Visibility
    Increased

    Automation
    Great

    Documentation


    View Slide

79. Where are the pain points?


    View Slide

80. Where is time lost?


    View Slide

81. Build only what you need
    to take action


    View Slide

82. #// where to go next?


    View Slide

83. LEARN MORE
    Marketplace

    https:#//github.com/marketplace?type=actions
    Documentation

    https:#//docs.github.com/en/free-pro-team@latest/actions


    View Slide

84. View Slide

85. THANKS FOR WATCHING
    ANDROID DEVELOPER
    @n8ebel www.goobar.io
    Nate Ebel
    #chicagoroboto


    View Slide
