Standalone Neutron: How we integrated it with Abiquo

Standalone Neutron: How we integrated it with Abiquo

This is a talk I gave at the OpenStack BCN 7th birthday meetup.
In it I explain how we integrated a standalone Neutron with Abiquo to implement an SDN solution w/o a full OpenStack.

Ignasi Barrera

July 20, 2017
Tweet

More Decks by Ignasi Barrera

Other Decks in Technology

Transcript

  1. Standalone Neutron
    How we integrated it with Abiquo
    Ignasi Barrera
    Senior So-ware Engineer, Abiquo
    Apache So-ware Founda:on Member

    View Slide

  2. The Abiquo use case
    20 July 2017 OpenStack BCN 7th birthday meetup 2
    Abiquo had a basic self-service networking
    model for KVM based on VLANs.
    We wanted to add support for:
    •  Firewalls
    •  Load Balancers
    •  Floa:ng Ips
    •  Other networking technologies (not a priority)

    View Slide

  3. Available op:ons
    20 July 2017 OpenStack BCN 7th birthday meetup 3
    •  Implement our own solu:on
    •  Explore the exis:ng SDN products
    – Highly customizable
    – Mul:-tenant
    – Open source
    – Good community support

    View Slide

  4. Choosing OpenStack
    20 July 2017 OpenStack BCN 7th birthday meetup 4
    OpenStack already had what we needed, but we
    only needed some parts of the relevant compute
    stack:
    •  Keystone – For access control and mul:-
    tenancy
    •  Neutron – To provide the SDN features
    •  Nova – We already had our own hypervisor
    agent and wanted to integrate it with Neutron

    View Slide

  5. Neutron implementa:on
    20 July 2017 OpenStack BCN 7th birthday meetup 5
    Our hypervisor agent already managed VLANs
    and Linux bridges, so we started using:
    •  VLANs for user defined networks
    •  The Linux bridges plugin
    •  Iptables for security groups
    •  The LBaaS API with HAProxy for load balancers

    View Slide

  6. Neutron with Linux bridges
    20 July 2017 OpenStack BCN 7th birthday meetup 6

    View Slide

  7. The controller node
    20 July 2017 OpenStack BCN 7th birthday meetup 7
    The controller node keeps the logical
    networking model. We directly manage it using
    the Neutron API to:
    •  Create networks and subnets
    •  Manage security groups
    •  Create and configure ports
    •  Manage floa:ng IPs
    •  Manage load balancers

    View Slide

  8. The compute node
    20 July 2017 OpenStack BCN 7th birthday meetup 8

    View Slide

  9. The compute agent
    20 July 2017 OpenStack BCN 7th birthday meetup 9
    We will rely on the Linux bridges agent to create
    all stuff

    View Slide

  10. The compute agent
    20 July 2017 OpenStack BCN 7th birthday meetup 10
    We will rely on the Linux bridges agent to create
    all stuff
    What needs to be done to let the agent know
    that the infrastructure is ready?

    View Slide

  11. The compute agent
    20 July 2017 OpenStack BCN 7th birthday meetup 11
    We will rely on the Linux bridges agent to create
    all stuff
    What needs to be done to let the agent know
    that the infrastructure is ready?
    How do we make the ports ACTIVE?

    View Slide

  12. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 12
    Create the network
    (neutron) net-create test --tenant-id b7de212040bc4518b9fe11b53e8cbed7
    Created a new network:
    +---------------------------+--------------------------------------+
    | Field | Value |
    +---------------------------+--------------------------------------+
    | admin_state_up | True |
    | id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | mtu | 0 |
    | name | test |
    | provider:network_type | vlan |
    | provider:physical_network | abq-vlans |
    | provider:segmentation_id | 78 |
    | router:external | False |
    | shared | False |
    | status | ACTIVE |
    | subnets | |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +---------------------------+--------------------------------------+

    View Slide

  13. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 13
    Create the subnet
    (neutron) subnet-create test 192.168.1.0/24 --name test-subnet --enable-dhcp
    --tenant-id b7de212040bc4518b9fe11b53e8cbed7
    Created a new subnet:
    +-------------------+--------------------------------------------------+
    | Field | Value |
    +-------------------+--------------------------------------------------+
    | allocation_pools | {"start": "192.168.1.2", "end": "192.168.1.254"} |
    | cidr | 192.168.1.0/24 |
    | dns_nameservers | |
    | enable_dhcp | True |
    | gateway_ip | 192.168.1.1 |
    | host_routes | |
    | id | c108f047-22f8-425c-9b33-305e74cc900e |
    | ip_version | 4 |
    | ipv6_address_mode | |
    | ipv6_ra_mode | |
    | name | test-subnet |
    | network_id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | subnetpool_id | |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-------------------+--------------------------------------------------+

    View Slide

  14. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 14
    Create the tenant router
    (neutron) router-create test-router --tenant-id b7de212040bc4518b9fe11b53e8cbed7
    Created a new router:
    +-----------------------+--------------------------------------+
    | Field | Value |
    +-----------------------+--------------------------------------+
    | admin_state_up | True |
    | distributed | False |
    | external_gateway_info | |
    | ha | False |
    | id | 7983a549-a08e-4928-9614-d06c13ef1cb3 |
    | name | test-router |
    | routes | |
    | status | ACTIVE |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-----------------------+--------------------------------------+
    (neutron) router-gateway-set test-router abq-external
    Set gateway for router test-router
    (neutron) router-interface-add test-router test-subnet
    Added interface 75809387-a8bb-4db4-a39e-8064e47927cc to router test-router.

    View Slide

  15. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 15
    Create the security group
    (neutron) security-group-create test-sg
    --tenant-id b7de212040bc4518b9fe11b53e8cbed7
    (neutron) security-group-rule-create --protocol tcp --direction ingress
    --port-range-min 22 --port-range-max 22
    --tenant-id b7de212040bc4518b9fe11b53e8cbed7 test-sg
    Created a new security_group_rule:
    +-------------------+--------------------------------------+
    | Field | Value |
    +-------------------+--------------------------------------+
    | direction | ingress |
    | ethertype | IPv4 |
    | id | e0358073-0aa4-442a-8276-c91b05e7cbff |
    | port_range_max | 22 |
    | port_range_min | 22 |
    | protocol | tcp |
    | remote_group_id | |
    | remote_ip_prefix | |
    | security_group_id | 9105859e-1838-416a-87b7-33b764785d9e |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-------------------+--------------------------------------+

    View Slide

  16. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 16
    Create the port
    (neutron) port-create --name test-port --device-owner compute:Abiquo --security-group test-sg
    --tenant-id b7de212040bc4518b9fe11b53e8cbed7 test
    Created a new port:
    +-----------------------+------------------------------------------------------------------------------------+
    | Field | Value |
    +-----------------------+------------------------------------------------------------------------------------+
    | admin_state_up | True |
    | allowed_address_pairs | |
    | binding:host_id | |
    | binding:profile | {} |
    | binding:vif_details | {} |
    | binding:vif_type | unbound |
    | binding:vnic_type | normal |
    | device_id | |
    | device_owner | compute:Abiquo |
    | fixed_ips | {"subnet_id": "c108f047-22f8-425c-9b33-305e74cc900e", "ip_address": "192.168.1.3"} |
    | id | 18365a93-63a5-4212-a23f-60adbff44024 |
    | mac_address | fa:16:3e:ff:e2:04 |
    | name | test-port |
    | network_id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | security_groups | 9105859e-1838-416a-87b7-33b764785d9e |
    | status | DOWN |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-----------------------+------------------------------------------------------------------------------------+

    View Slide

  17. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 17
    Create the port
    (neutron) port-create --name test-port --device-owner compute:Abiquo --security-group test-sg
    --tenant-id b7de212040bc4518b9fe11b53e8cbed7 test
    Created a new port:
    +-----------------------+------------------------------------------------------------------------------------+
    | Field | Value |
    +-----------------------+------------------------------------------------------------------------------------+
    | admin_state_up | True |
    | allowed_address_pairs | |
    | binding:host_id | |
    | binding:profile | {} |
    | binding:vif_details | {} |
    | binding:vif_type | unbound |
    | binding:vnic_type | normal |
    | device_id | |
    | device_owner | compute:Abiquo |
    | fixed_ips | {"subnet_id": "c108f047-22f8-425c-9b33-305e74cc900e", "ip_address": "192.168.1.3"} |
    | id | 18365a93-63a5-4212-a23f-60adbff44024 |
    | mac_address | fa:16:3e:ff:e2:04 |
    | name | test-port |
    | network_id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | security_groups | 9105859e-1838-416a-87b7-33b764785d9e |
    | status | DOWN |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-----------------------+------------------------------------------------------------------------------------+

    View Slide

  18. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 18
    Tell Neutron where the port is depoyed
    (neutron) agent-list -c agent_type -c host -c alive
    +--------------------+----------+-------+
    | agent_type | host | alive |
    +--------------------+----------+-------+
    | Linux bridge agent | neutron | :-) |
    | L3 agent | neutron | :-) |
    | Metadata agent | neutron | :-) |
    | Linux bridge agent | nacx-kvm | :-) |
    | Loadbalancer agent | neutron | :-) |
    | DHCP agent | neutron | :-) |
    +--------------------+----------+-------+

    View Slide

  19. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 19
    Tell Neutron where the port is depoyed
    (neutron) port-update --binding:host_id=nacx-kvm test-port
    Updated port: test-port
    (neutron) port-show test-port
    +-----------------------+------------------------------------------------------------------------------------+
    | Field | Value |
    +-----------------------+------------------------------------------------------------------------------------+
    | admin_state_up | True |
    | allowed_address_pairs | |
    | binding:host_id | nacx-kvm |
    | binding:profile | {} |
    | binding:vif_details | {"port_filter": true} |
    | binding:vif_type | bridge |
    | binding:vnic_type | normal |
    | device_id | |
    | device_owner | compute:Abiquo |
    | extra_dhcp_opts | |
    | fixed_ips | {"subnet_id": "c108f047-22f8-425c-9b33-305e74cc900e", "ip_address": "192.168.1.3"} |
    | id | 18365a93-63a5-4212-a23f-60adbff44024 |
    | mac_address | fa:16:3e:ff:e2:04 |
    | name | test-port |
    | network_id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | security_groups | 9105859e-1838-416a-87b7-33b764785d9e |
    | status | DOWN |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-----------------------+------------------------------------------------------------------------------------+

    View Slide

  20. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 20
    Tell Neutron where the port is depoyed
    (neutron) port-update --binding:host_id=nacx-kvm test-port
    Updated port: test-port
    (neutron) port-show test-port
    +-----------------------+------------------------------------------------------------------------------------+
    | Field | Value |
    +-----------------------+------------------------------------------------------------------------------------+
    | admin_state_up | True |
    | allowed_address_pairs | |
    | binding:host_id | nacx-kvm |
    | binding:profile | {} |
    | binding:vif_details | {"port_filter": true} |
    | binding:vif_type | bridge |
    | binding:vnic_type | normal |
    | device_id | |
    | device_owner | compute:Abiquo |
    | extra_dhcp_opts | |
    | fixed_ips | {"subnet_id": "c108f047-22f8-425c-9b33-305e74cc900e", "ip_address": "192.168.1.3"} |
    | id | 18365a93-63a5-4212-a23f-60adbff44024 |
    | mac_address | fa:16:3e:ff:e2:04 |
    | name | test-port |
    | network_id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | security_groups | 9105859e-1838-416a-87b7-33b764785d9e |
    | status | DOWN |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-----------------------+------------------------------------------------------------------------------------+

    View Slide

  21. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 21

    View Slide

  22. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 22
    Interfaces in the compute node
    [root@nacx-kvm ~]# ip link
    1: lo: mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT qlen 1
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    2: eth0: mtu 1500 qdisc pfifo_fast state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:1e:11:76 brd ff:ff:ff:ff:ff:ff
    3: eth1: mtu 1500 qdisc pfifo_fast state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:0c:55:0f brd ff:ff:ff:ff:ff:ff
    4: virbr0: mtu 1500 qdisc noqueue state DOWN
    mode DEFAULT qlen 1000
    link/ether 52:54:00:92:05:b4 brd ff:ff:ff:ff:ff:ff
    5: virbr0-nic: mtu 1500 qdisc pfifo_fast master virbr0 state DOWN
    mode DEFAULT qlen 1000
    link/ether 52:54:00:92:05:b4 brd ff:ff:ff:ff:ff:ff
    Interfaces are managed by the compute agent (Nova), our custom
    hypervisor agent in this case
    Our agent needs to create the right one

    View Slide

  23. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 23
    Link the port to an interface in the compute
    node
    +-----------------------+------------------------------------------------------------------------------------+
    | Field | Value |
    +-----------------------+------------------------------------------------------------------------------------+
    | admin_state_up | True |
    | allowed_address_pairs | |
    | binding:host_id | nacx-kvm |
    | binding:profile | {} |
    | binding:vif_details | {"port_filter": true} |
    | binding:vif_type | bridge |
    | binding:vnic_type | normal |
    | device_id | |
    | device_owner | compute:Abiquo |
    | extra_dhcp_opts | |
    | fixed_ips | {"subnet_id": "c108f047-22f8-425c-9b33-305e74cc900e", "ip_address": "192.168.1.3"} |
    | id | 18365a93-63a5-4212-a23f-60adbff44024 |
    | mac_address | fa:16:3e:ff:e2:04 |
    | name | test-port |
    | network_id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | security_groups | 9105859e-1838-416a-87b7-33b764785d9e |
    | status | DOWN |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-----------------------+------------------------------------------------------------------------------------+

    View Slide

  24. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 24
    Crea:ng the interface for the VM
    [root@nacx-kvm ~]# ip tuntap add name tap18365a93-63 mode tap
    [root@nacx-kvm ~]# ip link
    1: lo: mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT qlen 1
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    2: eth0: mtu 1500 qdisc pfifo_fast state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:1e:11:76 brd ff:ff:ff:ff:ff:ff
    3: eth1: mtu 1500 qdisc pfifo_fast state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:0c:55:0f brd ff:ff:ff:ff:ff:ff
    4: virbr0: mtu 1500 qdisc noqueue state DOWN
    mode DEFAULT qlen 1000
    link/ether 52:54:00:92:05:b4 brd ff:ff:ff:ff:ff:ff
    5: virbr0-nic: mtu 1500 qdisc pfifo_fast master virbr0 state DOWN
    mode DEFAULT qlen 1000
    link/ether 52:54:00:92:05:b4 brd ff:ff:ff:ff:ff:ff
    9: tap18365a93-63: mtu 1500 qdisc pfifo_fast state DOWN
    mode DEFAULT qlen 1000
    link/ether 4a:38:29:71:f4:8d brd ff:ff:ff:ff:ff:ff
    10: eth1.78@eth1: mtu 1500 qdisc noqueue master brq1a817eb7-ef state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:0c:55:0f brd ff:ff:ff:ff:ff:ff
    11: brq1a817eb7-ef: mtu 1500 qdisc noqueue state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:0c:55:0f brd ff:ff:ff:ff:ff:ff

    View Slide

  25. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 25
    Crea:ng the interface for the VM
    [root@nacx-kvm ~]# ip tuntap add name tap18365a93-63 mode tap
    [root@nacx-kvm ~]# ip link
    1: lo: mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT qlen 1
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    2: eth0: mtu 1500 qdisc pfifo_fast state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:1e:11:76 brd ff:ff:ff:ff:ff:ff
    3: eth1: mtu 1500 qdisc pfifo_fast state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:0c:55:0f brd ff:ff:ff:ff:ff:ff
    4: virbr0: mtu 1500 qdisc noqueue state DOWN
    mode DEFAULT qlen 1000
    link/ether 52:54:00:92:05:b4 brd ff:ff:ff:ff:ff:ff
    5: virbr0-nic: mtu 1500 qdisc pfifo_fast master virbr0 state DOWN
    mode DEFAULT qlen 1000
    link/ether 52:54:00:92:05:b4 brd ff:ff:ff:ff:ff:ff
    9: tap18365a93-63: mtu 1500 qdisc pfifo_fast state DOWN
    mode DEFAULT qlen 1000
    link/ether 4a:38:29:71:f4:8d brd ff:ff:ff:ff:ff:ff
    10: eth1.78@eth1: mtu 1500 qdisc noqueue master brq1a817eb7-ef state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:0c:55:0f brd ff:ff:ff:ff:ff:ff
    11: brq1a817eb7-ef: mtu 1500 qdisc noqueue state UP
    mode DEFAULT qlen 1000
    link/ether 52:54:00:0c:55:0f brd ff:ff:ff:ff:ff:ff

    View Slide

  26. Example: VM with a single
    IP and SSH access
    20 July 2017 OpenStack BCN 7th birthday meetup 26
    And the port is finally ac:ve!
    (neutron) port-show test-port
    +-----------------------+------------------------------------------------------------------------------------+
    | Field | Value |
    +-----------------------+------------------------------------------------------------------------------------+
    | admin_state_up | True |
    | allowed_address_pairs | |
    | binding:host_id | nacx-kvm |
    | binding:profile | {} |
    | binding:vif_details | {"port_filter": true} |
    | binding:vif_type | bridge |
    | binding:vnic_type | normal |
    | device_id | |
    | device_owner | compute:Abiquo |
    | extra_dhcp_opts | |
    | fixed_ips | {"subnet_id": "c108f047-22f8-425c-9b33-305e74cc900e", "ip_address": "192.168.1.3"} |
    | id | 18365a93-63a5-4212-a23f-60adbff44024 |
    | mac_address | fa:16:3e:ff:e2:04 |
    | name | test-port |
    | network_id | 1a817eb7-ef09-455a-95dc-75e24d7b3d13 |
    | security_groups | 9105859e-1838-416a-87b7-33b764785d9e |
    | status | ACTIVE |
    | tenant_id | b7de212040bc4518b9fe11b53e8cbed7 |
    +-----------------------+------------------------------------------------------------------------------------+

    View Slide

  27. Lessons learned
    20 July 2017 OpenStack BCN 7th birthday meetup 27
    •  Even though OpenStack is very modular, there
    are (hidden) hardcoded things that are
    important for integra:ons
    •  Open source is key when approaching new
    technology
    – Access to a community knowledge base of similar
    issues, use cases and experiences
    – Access to the source code is o-en the best way to
    understand technology

    View Slide

  28. THANK YOU!
    20 July 2017
    OpenStack BCN 7th birthday meetup 28

    View Slide
