Implementing Quota as a Service

* Describe Quota/RateLimit Algorithms
* Describe OSS Quota/RateLimit Packages / Services
* Describe How we developed Quota as a Service

Transcript

1. Implementing
   Quota as a Service
   @nasa9084


   View Slide

2. $ whoami
   • @nasa9084
   • LINE corp.
   • Go / Kubernetes / emacs
   • https://blog.web-apps.tech


   View Slide

3.


   View Slide

4. View Slide

5.


   View Slide

6. Quota as a Service


   View Slide

7. “Quota”


   View Slide

8. Quota /kwóʊṭə/
   1. ෼୲෼ɺׂΓ౰ͯ
   2. (੡଄ɾ༌ೖग़ͳͲͷ)طఆ[ׂΓ౰ͯ]਺ྔ
   3. (ड͚ೖΕΔҠຽɾձһɾֶੜͳͲͷ)ఆ਺ɾఆһ
   —https://ejje.weblio.jp/content/quota


   View Slide

9. WHY?


   View Slide

10. Why implement “Quota as a Service”?
    • We are developing / managing Monitoring system
    • Very many requests
    • Easy to abuse
    → We need Quota/Rate Limit for our services


    View Slide

11. Don’t use Quota / RateLimit lib simply?
    • LINE has many services (also our team)
    • Need Quota / RateLimit per services
    • Need manage configurations for each services
    • Need database for each services
    • Not want to manage extra DBs…


    View Slide

12. Algorithms


    View Slide

13. Token Bucket
    • Limit the average rate of traffic
    • Allow some burstiness
    • Bucket is an abstracted container
    • We can implement as buffer or queue


    View Slide

14. Token Bucket Algorithm
    1. Add Tokens into Bucket per 1/r seconds
    • Bucket can hold b Tokens
    2. When n bytes packet is coming, remove n Tokens and send the packet
    3. If Bucket does not have n Tokens, the packet becomes non-conformant
    • Drop the packet
    • Queue the packet until Bucket charges enough Tokens
    • Send with non-conformant flag


    View Slide

15. Leaky Bucket
    • Limit the peak rate of traffic
    • Not allow burstiness
    • Same as Generic Cell Rate Algorithm
    • Used for ATM Network


    View Slide

16. Leaky Bucket Algorithm
    • A fixed capacity bucket
    • If the bucket is empty, stops leaking
    • Packet is water
    • It is possible to add a specific amount of packet to the bucket
    • If the amount of packet would cause the bucket to exceed its
    capacity, then the packet is non-conformant


    View Slide

17. Fixed Window Counter
    • Limit requests per REAL time duration
    • Window is fixed
    • e.g. 100 requests / 10:00 - 10:59
    10:00
    11:00
    Requests


    View Slide

18. Fixed Window Counter
    • Over quota in configured duration
    • e.g. 5 requests/hour
    09:00 10:00 11:00
    6 requests/hour


    View Slide

19. Sliding Window Counter
    • Limit requests since ${window_size} ago
    • Window limitation window moves as time passes


    View Slide

20. Existing Solutions


    View Slide

21. QuotaLibs


    View Slide

22. vladimir-bukhtoyarov/bucket4j
    • Written in Java
    • Based on Token Bucket algorithm
    • Scalable for multi-threading


    View Slide

23. tomasbasham/ratelimit
    • Written in python
    • Implemented as decorator
    • Not using database!


    View Slide

24. QuotaService


    View Slide

25. square/quotaservice
    • Written in Go
    • gRPC service
    • Based on Token Bucket algorithm
    • Still WIP…


    View Slide

26. lyft/ratelimit
    • Written in Go
    • As gRPC service
    • Assumed to use with envoy


    View Slide

27. Quota as a Service for us


    View Slide

28. Implement Quota as a Service
    • (Of course) Write with Go
    • Clean Architecture (-like)
    • Standard Project Layout *
    ᵓᴷᴷ cmd/ # main.go
    ᵓᴷᴷ init/ # systemd
    ᵋᴷᴷ internal/
    ᵓᴷᴷ cmd/
    ᴹ ᵓᴷᴷ httpgen/ # generate http router
    ᴹ ᵋᴷᴷ mockgen/ # generate mock
    ᵋᴷᴷ pkg/
    ᵓᴷᴷ apiserver/
    ᵓᴷᴷ domain
    ᵓᴷᴷ errors/
    ᵓᴷᴷ infra/ # implementation
    ᵓᴷᴷ interceptor/ # gRPC middleware
    ᵓᴷᴷ interfaces/ # interfaces
    ᵓᴷᴷ middleware/ #http middleware
    ᵋᴷᴷ rpc/
    *golang-standards/project-layout


    View Slide

29. Reduce Management Cost
    • Generate Codes as possible as we can
    • Reduce middle-wares/services managed by ourselves


    View Slide

30. Generate Codes as possible as we can
    • gRPC + REST
    • gRPC: rate limiting
    • REST: registration
    • gRPC server/client code generated from Protocol Buffers
    • REST server/client code generated from OpenAPI spec
    • Mock from interfaces


    View Slide

31. Central Dogma
    • Service Configuration Repository by LINE
    • Highly available
    • Version Controlled based on Git
    • Can watch by client
    • Apply config change by event base
    • Can mirror GitHub to Central Dogma


    View Slide

32. Reduce Services We Should Manage
    • Configuration Management
    • GitHub Pull Request for WUI + Central Dogma as Database
    • User Authentication / User metadata DB
    • LDAP + session store (Redis)


    View Slide

33. Q?


    View Slide
