Transcript
Can You Keep a Secret Drupal HackCamp 2018 - București
Nick Santamaria • Drupal developer since 2006 • SysOps Engineer
at PreviousNext • Based in Melbourne, Australia • @nicksanta • drupal.org/user/87915 • github.com/nicksantamaria
Secret Management Crash Course
Are you in the right place?
What are Secrets?
Passwords • Database • Cache Backend • Search Index •
Document Store
API Keys • Cloud Platform • Payment Processor • Email
Marketing • CI / CD Pipeline
Cryptographic Keys • SSH Key Pairs • TLS Certificates •
AES Encryption Keys
Not Technically Secrets • Financial Credentials • Confidential Data •
Personally Identifiable Information (PII)
Telling Secrets to the Application
Stored in Repo
Stored in Repo
Stored in Database
Placed by Config Management • Puppet • Ansible • CloudFormation
• Terraform Variation Complication Baked into AMI AMI per security boundary Encrypted secrets in code Orchestrating key distribution
Hand Crafted Config
So What's the Problem?
"Secret Sprawl"
Impossible to Audit
Difficulty Rotating Keys
What Happens When You're Compromised?
None
Secret Management The Solution
Secret Management SOLUTION Centralise storage PROBLEM "Secret Sprawl"
Secret Management SOLUTION Authentication layer Standardised policy framework PROBLEM Who
has access?
Secret Management SOLUTION Audit logs PROBLEM Who accessed what and
when did they do it?
SOLUTION Centralised storage Leases Dynamic secrets Secret Management PROBLEM Rotating
secrets is time consuming and error prone
SOLUTION Well-defined "break-glass" procedure Secret Management PROBLEM
Drupal Recipes
Store API Tokens in Lockr Recipe #1
Setup - Services • Lockr - lockr.io • MailChimp -
mailchimp.com
Setup - Code • Drupal 8 • drupal.org/project/mailchimp • drupal.org/project/lockr
• drupal.org/project/key
Demo
Config Export - Before
Config Export - After ←
Config Export - After } Key safely stored in lockr
storage provider
Config Export - After } mailchimp.api_key config now overridden by
key.repository.mailchimp_token
• Attackers can't obtain API keys from ◦ DB leaks
◦ Codebase leaks ◦ Stolen developer machine Advantages
Alternative Storage Providers • drupal.org/project/aws_secrets_manager • drupal.org/project/vault_key_kv
Crypto Keys with Kubernetes Secrets Recipe #2
• Kubernetes Cluster Setup - Services
Setup - Code • Drupal 8 • drupal.org/project/key • drupal.org/project/encrypt
• drupal.org/project/real_aes
Generate AES Key
Add Secret Resource
Add Secret Resource
Add Secret Resource
Mount Secret into App Container
Create Encryption Key Entity
• Not baking secrets into image. • Simplifies key distribution.
• Key encrypted at rest. • Filesystem mount = dev/prod parity. Advantages
• Docker Swarm docs.docker.com/engine/swarm/secrets/ • Elastic Container Service EC2 Parameter
Store • Nomad HashiCorp Vault Other Orchestrators
Dynamic Database Credentials with Vault Recipe #3
Setup • Drupal • HashiCorp Vault ◦ vaultproject.io • Consul
Template ◦ github.com/hashicorp/consul-template
Setup - Vault Mount the database secret backend
Setup - Vault Give Vault root access to database
Setup - Vault Create "drupal" role in Vault
Setup - Vault Test credentials are being generated }Created on
the fly
Setup - Consul Template
Setup - Consul Template Run Consul Template
Demo
• Constant rotation of secrets • Credentials probably junk by
time Attacker tries to use them. • Risk posed by "Hoarders" mitigated. Advantages
• Audit your application for insecurely stored secrets. Fix! •
“Data Security in Drupal 8” at 2pm. • Key in Drupal Core?? What Next?
@nicksanta drupal.org/user/87915 Thank You!
