Demystifying Vite Internals

Slides for Vue Fes Japan 2024

Transcript

1. Nozomu Ikuta 19th Oct 2024 Demystifying Vite Internals
2. @NozomuIkuta • Software Engineer • Vue.js-JP Core Sta ff • UnJS Member • Nuxt / Vite Contributor
4. Introduction
5. How Vite dev server is bootstrapped How Vite config is resolved How Vite handles HTTP requests How Vite plugins are made available in dev mode How Vite manages caches How Vite manages HMR How Vite builds application etc. Introduction Topics
6. How Vite dev server is bootstrapped How Vite config is resolved How Vite handles HTTP requests How Vite plugins are made available in dev mode How Vite manages caches How Vite manages HMR How Vite builds application etc. Introduction Topics
7. • Contents are based on Vite 5 • Core concepts are same in Vite 6
8. Dev Server Bootstrap
9. Dev Server Bootstrap Overview • Initialization • Con fi g resolution • Connect server setup • Dependency pre-bundling • Starting connect server
10. await createServer(inlineCon fi g) • Run Vite CLI or call exported function directly • These options are called inline con fi g in terms of con fi g resolution Vite CLI JavaScript API Pass
 CLI options Call with options Dev Server Bootstrap Initialization
11. loadCon fi gFromFile() Disk Dev Server Bootstrap Con fi g Resolution • Build user con fi g fi le by esbuild vite.con fi g.ts other.ts build() import .env
12. loadCon fi gFromFile() Disk Dev Server Bootstrap Con fi g Resolution • Build user con fi g fi le by esbuild • Write the code to disk vite.con fi other.ts build() writeFile() import temporal fi le .env
13. loadCon fi gFromFile() Disk Dev Server Bootstrap Con fi g Resolution • Build user con fi g fi le by esbuild • Write the code to disk and then import the fi le vite.con fi temporal fi le other.ts build() writeFile() import() import .env
14. loadCon fi gFromFile() Disk Dev Server Bootstrap Con fi g Resolution • Build user con fi g fi le by esbuild • Write the code to disk and then import the fi le and delete it vite.con fi temporal fi le other.ts build() writeFile() import() unlink() import .env
15. loadCon fi gFromFile() Disk Dev Server Bootstrap Con fi g Resolution • Build user con fi g fi le by esbuild • Write the code to disk and then import the fi le • Merge inline con fi g and user con fi g vite.con fi temporal fi other.ts build() writeFile() import() unlink() mergeCon fi g(userCon fi g, inlineCon fi g) import .env
16. loadCon fi Disk Dev Server Bootstrap Con fi g Resolution • Build user con fi g fi le by esbuild • Write the code to disk and then import the fi le • Merge inline con fi g and user con fi g • Resolve user plugins vite.con fi temporal fi other.ts build() writeFile() import() unlink() mergeCon fi import fl atten / sort user plugins .env
17. loadCon fi Disk Dev Server Bootstrap Con fi g Resolution • Build user con fi g fi le by esbuild • Write the code to disk and then import the fi le • Merge inline con fi g and user con fi g • Resolve user plugins • Load .env fi le vite.con fi temporal fi other.ts build() writeFile() import() unlink() mergeCon fi import fl loadEnv() .env
18. Dev Server Bootstrap Connect Server Setup • timeMiddleware • corsMiddleware • cachedTransformMiddleware • proxyMiddleware • baseMiddleware • launchEditorMiddleware • viteHMRPringMiddleware • servePublicMiddleware • transformMiddleware • serveRawFsMiddleware • serveStaticMiddleware • htmlFallbackMiddleware • indexHtmlMiddleware • notFoundMiddleware • errorMiddleware
19. Dev Server Bootstrap Connect Server Setup • timeMiddleware • corsMiddleware • cachedTransformMiddleware • proxyMiddleware • baseMiddleware • launchEditorMiddleware • viteHMRPringMiddleware • servePublicMiddleware • transformMiddleware • serveRawFsMiddleware • serveStaticMiddleware • htmlFallbackMiddleware • indexHtmlMiddleware • notFoundMiddleware • errorMiddleware
20. Dev Server Bootstrap Dependency Pre-Bundling • Dependencies in node_modules are transformed by esbuild as ESM • The results are cached • type=“module” is written in package.json for deps to be recognized as ESM Deps- Optimizer Disk node_modules dep A .vite/deps package.json dep B dep C _metadata.json dep A’ dep B’ dep C’
21. Server starts to listen
22. No application build
23. • Vite con fi g is built by esbuild • Dependencies are built by esbuild and stored as cache • No application build on dev server bootstrap
24. Requesting Files
25. indexHtml- Middleware GET /index.html Requesting index.html indexHtmlMiddleware • Replace environment variable placeholders with values • Transform other parts of index.html for performance (out of scope) Disk index.html Browser readFile() transform() send() index.html
26. Requesting JS Files Native ESM Module Resolution • JavaScript fi les are requested according to src attribute • What to be returned from the URL depends on the server • This is the starting point of partial application build Browser GET index.html <script type=“module” src=“…”></script> Vite dev server
27. Browser Disk src <script type=“module” src=“/src/main.ts” ></script> index.ts a.ts GET /src/main.ts Vite Dev Server transformMiddleware import A from ‘./a’ type MyType = true function fn(): void { console.log(‘Hi’) }
28. Browser Disk src <script type=“module” src=“/src/main.ts” ></script> index.ts a.ts Vite Dev Server transformMiddleware import A from ‘./a’ type MyType = true function fn(): void { console.log(‘Hi’) } GET /src/main.ts
29. Browser Disk src <script type=“module” src=“/src/main.ts” ></script> index.ts a.ts Vite Dev Server transformMiddleware import A from ‘./a’ type MyType = true function fn(): void { console.log(‘Hi’) } import A from ‘/src/a.ts’ function fn() { console.log(‘Hi’) } GET /src/index.ts
30. Browser Disk src <script type=“module” src=“/src/main.ts” ></script> Vite Dev Server transformMiddleware import A from ‘/src/a.ts’ function fn() { console.log(‘Hi’) } import A from ‘/src/a.ts’ index.ts a.ts import A from ‘./a’ type MyType = true function fn(): void { console.log(‘Hi’) }
31. Browser Disk src <script type=“module” src=“/src/main.ts” ></script> Vite Dev Server transformMiddleware import A from ‘/src/a.ts’ function fn() { console.log(‘Hi’) } import A from ‘/src/a.ts’ GET /src/a.ts index.ts a.ts import A from ‘./a’ type MyType = true function fn(): void { console.log(‘Hi’) }
32. Browser Disk src <script type=“module” src=“/src/main.ts” ></script> Vite Dev Server transformMiddleware import A from ‘/src/a.ts’ function fn() { console.log(‘Hi’) } import A from ‘/src/a.ts’ GET /src/a.ts index.ts a.ts import A from ‘./a’ type MyType = true function fn(): void { console.log(‘Hi’) }
33. Browser Disk src <script type=“module” src=“/src/main.ts” ></script> Vite Dev Server transformMiddleware import A from ‘/src/a’ function fn() { console.log(‘Hi’) } import A from ‘/src/a’ GET /src/a.ts Runnable JavaScript Code index.ts a.ts import A from ‘./a’ type MyType = true function fn(): void { console.log(‘Hi’) }
34. • File contents are transformed by plugins • Vite does not build your application with Rollup
35. Plugin System
36. Plugin System Vite vs. Rollup • Vite plugins extends Rollup's plugin interface • Most Rollup plugin can be used as Vite plugins: • if It doesn’t use moduleParsed hook • if it doesn't have strong coupling between bundle- phase hooks and output-phase hooks Rollup Plugins Vite Plugins https://vite.dev/guide/api-plugin.html
37. Plugin System The Missing Piece ? Vite Rollup Build Dev Vite plugins Vite plugins
38. Plugin Container Plugin System The Missing Piece Vite Rollup Build Dev Vite plugins Vite plugins
39. Plugin Container
40. Plugin Container Rollup Emulator • Implements Rollup plugin driver interface • Emulates Rollup plugin hooks in dev mode
41. That’s it
42. Plugin C Plugin Container resolveId Hook • resolveId hook of plugins are called sequentially • First non-nullable result is used as module ID Plugin A resolveId() Plugin Container resolveId() Returns null Returns string Plugin B
43. Plugin Container load Hook • load hook of plugins are called sequentially • First non-nullable result is used as source code Plugin C Plugin A load() Plugin Container load() Returns null Returns string Plugin B
44. Plugin Container transform Hook • transform hook of plugins are called sequentially • Final result is used as actual code Plugin C Plugin A transform() Plugin Container Returns A Plugin B transform() Returns B
45. • Vite makes up JavaScript code runnable in browser through 3 plugin hooks • Vite provides some built-in plugins • TypeScript is transpiled by esbuild
46. Summary
47. • Vite con fi g is built by esbuild • Dependencies are built by esbuild and stored as cache on dev server bootstrap • Vite does not build your application on dev server bootstrap, which is why it starts fast • index.html is the starting point from which your application is built • Plugin container makes it possible to partially build your application on demand
48. Acknowledgements Vite Study Members • aki • Jabelic • Jumpei Yamada • keigo • shoma mano • taka • ubugeeei • Yuma • ͍ͪΉΒ Ώ͏· • ͓ʔ͍͐͡ • ͔Β͜Ζ • πϊ In alphabetical order
49. Coming soon chibivite
50. Thank you
