The World of RecyclerView. ENG (Droidcon Krakow, 2017)

Version with Animations - https://docs.google.com/presentation/d/1P_JAw4SmVu2vYOxSWtVv__xr_e544CF0JbQHZ_tTcEg

RecyclerView has been a common part of every Android application's development process since Google released the support library with optimized ListView replacement. Besides improvements made by the Google team, there are some techniques which can be applied to RecyclerView to make it more efficient. Some of these approaches were introduced by the creators, some were discovered by enthusiastic developers. I have gathered all these best practices together, added my own ones and some experiments on top of them.

Transcript

1. The World of RecyclerView Oleksandr Tolstykh @a_tolstykh
2. RecyclerView vs ListView - Animations - Advanced API - Performance - Other improvements @a_tolstykh
3. RecyclerView vs ListView @a_tolstykh - Animations - Advanced API - Performance - Other improvements @a_tolstykh
4. How to measure UI performance? • FPS https://github.com/friendlyrobotnyc/TinyDancer • Profile GPU rendering https://developer.android.com/studio/profile/dev-options-rendering.html • Aggregate frame stats https://developer.android.com/training/testing/performance.html • Many others... @a_tolstykh
5. How to measure UI performance? • FPS https://github.com/friendlyrobotnyc/TinyDancer • Profile GPU rendering https://developer.android.com/studio/profile/dev-options-rendering.html • Aggregate frame stats https://developer.android.com/training/testing/performance.html • Many others... @a_tolstykh
6. Sample App - Travel With Us City guides Base city info Data is loaded from server RecyclerView! @a_tolstykh
7. Optimize Cells hierarchies Avoid deep hierarchy Save level with <merge> when <include> Layout matters! android.support.constraint.ConstraintLayout com.google.android.flexbox.FlexboxLayout https://developer.android.com/topic/performance/rendering/optimizing-view-hierarchies.html @a_tolstykh
8. Minimize onBindViewHolder() Make onBindViewHolder() as cheap as possible Avoid item instantiations (memory allocations) Do as much as you can in onCreateViewHolder() @a_tolstykh
9. Correct images scale Make sure their size and compression are optimal. Scaling images may also affect the performance. Do not reinvent the wheel. Picasso, ImageLoader, Fresco, Glide. Picasso v/s Imageloader v/s Fresco vs Glide [closed] http://stackoverflow.com/q/29363321/2308720 @a_tolstykh
10. Update only the affected items adapter.notifyItemRemoved(position) adapter.notifyItemChanged(position) adapter.notifyItemInserted(position) * only if you know position of updated item @a_tolstykh
11. Profit! Animations for free! Optimizations for free! @a_tolstykh
12. Remove an item with swipe: val touchCallback = object : SimpleCallback(0, LEFT or RIGHT) { // ... override fun onSwiped(viewHolder: ViewHolder, swipeDir: Int) { adapter.remove(viewHolder.getAdapterPosition()) adapter.notifyItemRemoved(viewHolder.getAdapterPosition()) } } // attaching the touch helper to recycler view ItemTouchHelper(touchCallback).attachToRecyclerView(recyclerView); @a_tolstykh
13. Nested RecyclerView Override the LinearLayoutManager#getInitialPrefetchItemCount() RecyclerView is nested inside another RecyclerView @a_tolstykh
14. Items cache recyclerView.setItemViewCacheSize(size: Int) Documentation: “Set the number of offscreen views to retain before adding them to the potentially shared recycled view pool.” static final int DEFAULT_CACHE_SIZE = 2; // supportVersion = 25.3.0 @a_tolstykh
15. Prefetch Use latest version of support library to use native prefetch optimizations supportVersion >= 25.1.0 // (enabled by default) RecyclerView Prefetch by Chet Haase https://medium.com/google-developers/c2f269075710 *Lollipop and newer @a_tolstykh
16. Advanced prefetch Override the LinearLayoutManager#getExtraLayoutSpace(RecyclerView.State s) protected int getExtraLayoutSpace (RecyclerView.State state) Returns the amount of extra space that should be laid out by LayoutManager. @a_tolstykh
17. Advanced prefetch class PreCachingLayoutManager(context: Context) : LinearLayoutManager(context) { private var customExtraLayoutSpace: Int = -1 set(value) { field = value } override fun getExtraLayoutSpace(state: RecyclerView.State): Int { return if (customExtraLayoutSpace >= 0) customExtraLayoutSpace else super.getExtraLayoutSpace(state) } } @a_tolstykh
18. BUT... Expensive if done while the user may change scrolling direction. Laying out invisible elements generally comes with significant performance cost. Useless without increasing cache size (setItemViewCacheSize). BUT it improves USER EXPERIENCE! Need to find a balance. Maybe 1 extra screen (=default) is The Balance? @a_tolstykh
19. Even more advanced prefetch... Prefetch images! (on wi-fi only) Picasso.with(context).load(url).fetch() Glide.with(context).load(url).downloadOnly(width, height) @a_tolstykh
20. Without images prefetch With images prefetch Images prefetch @a_tolstykh
21. class CitiesAdapter : RecyclerView.Adapter<CityViewHolder>() { fun updateData(cities: List<City>) { if (onWifi()) prefetch(cities) // TODO update adapter data } private fun prefetch(cities: List<City>) { for (city in cities) { val prefetcher = city.getPrefetcher() if (prefetcher != null) { prefetcher.prefetch(mContext) } } } } @a_tolstykh
22. class ImagePrefetcher(private val images: List<Image>) : PreFetcher { fun prefetch(context: Context) { for (image in images) { Picasso.with(context).load(image.url()).fetch() } } } @a_tolstykh
23. class TweetPrefetcher(private val tweetIds: List<Int>) : PreFetcher { fun prefetch(context: Context) { TwitterHelper.loadTweets(tweetIds, object : Callback<List<Tweet>>() { fun success(result: Result<List<Tweet>>) { for (tweet in result.data) { TwitterHelper.preFetchTweetImage(tweet) } } }) } } @a_tolstykh
24. Displayed data pre-calculations Displayed items are POJOs (Kotlin data classes). Pre-format date, time, other strings during data parsing. Pre-calculate immutable values during data parsing. Profit: + Minor performance optimisations. + Formatting is done in BG thread. + Formatting is done in single place. @a_tolstykh
25. Displayed data pre-calculations (formatting) @WorkerThread private fun createRating(value: Float, count: Int): Rating { val ratingFormatted = String.format(Locale.US, "%.1f", value) val countFormatted = formatWithMetricPrefix(count) return Rating.create(value, ratingFormatted, count, countFormatted) } @UiThread fun setRating(rating: Rating) { ratingText.setText(rating.ratingFormatted()) reviewsCount.setText(rating.numberOfReviewsFormatted()) } @a_tolstykh
26. DiffUtil *since support library version 24.2.0 https://developer.android.com/reference/android/support/v7/util/DiffUtil.html @a_tolstykh
27. android.support.v7.util.DiffUtil Documentation: “DiffUtil is a utility class that can calculate the difference between two lists and output a list of update operations that converts the first list into the second one. It can be used to calculate updates for a RecyclerView Adapter.” @a_tolstykh
28. DiffUtil.Callback public boolean areItemsTheSame(int oldItemPosition, int newItemPosition) public boolean areContentsTheSame(int oldItemPosition, int newItemPosition) @a_tolstykh
29. DiffUtil.Callback class DiffCallback(val newList: List<City>, val oldList: List<City>) : DiffUtil.Callback() { override fun getOldListSize(): Int = oldList.size override fun getNewListSize(): Int = newList.size override fun areItemsTheSame(oldItemPos: Int, newItemPos: Int): Boolean = oldList.get(oldItemPos).itemId == newList.get(newItemPos).itemId override fun areContentsTheSame(oldItemPos: Int, newItemPos: Int): Boolean = oldList.get(oldItemPos) == newList.get(newItemPos) @a_tolstykh
30. DiffUtil.Callback val cb = YourDiffCallback(oldList, newList) val diffResult = DiffUtil.calculateDiff(cb) diffResult.dispatchUpdatesTo(adapter) @a_tolstykh
31. Without DiffUtil With DiffUtil Lenovo Vibe X Android OS, v4.2 1080 x 1920 pixels Quad-core 1.5 GHz @a_tolstykh
32. DiffUtil.Callback public Object getChangePayload(int oldItemPosition, int newItemPosition) @a_tolstykh
33. DiffUtil animated values change override fun getChangePayload(oldItemPosition: Int, newItemPosition: Int): Any? { val diff = Bundle() val newRating = newList.get(newItemPosition).rating() val oldRating = oldList.get(oldItemPosition).rating() if (newRating.numberOfReviews() !== oldRating.numberOfReviews()) { diff.putString(KEY_NUMBER_OF_REVIEWS, newRating.numberOfReviewsFormatted()) } if (newRating.rating().compareTo(oldRating.rating()) != 0) { diff.putString(KEY_RATING_FORMATTED, newRating.ratingFormatted()) } return if (diff.size() == 0) null else diff } @a_tolstykh
34. override fun onBindViewHolder(holder: CityViewHolder, index: Int, p: List<Any>) { if (p.isEmpty()) { onBindViewHolder(holder, index) return } val payload = p[0] as Bundle for (key in payload.keySet()) { if (key == CitiesDiffCallback.KEY_NUMBER_OF_REVIEWS) { holder.animateReviews(payload.getString(key)) } else if (key == CitiesDiffCallback.KEY_RATING_FORMATTED) { holder.animateRating(payload.getString(key)) } } } @a_tolstykh
35. Use any animation you want! • android.widget.TextSwitcher • com.hanks.htextview.HTextView • custom... DiffUtil per field items update @a_tolstykh
36. DiffUtil - average runtimes • 100 items and 10 modifications: avg: 0.39 ms, median: 0.35 ms • 100 items and 100 modifications: 3.82 ms, median: 3.75 ms • 100 items and 100 modifications without moves: 2.09 ms, median: 2.06 ms • 1000 items and 50 modifications: avg: 4.67 ms, median: 4.59 ms • 1000 items and 50 modifications without moves: avg: 3.59 ms, median: 3.50 ms • 1000 items and 200 modifications: 27.07 ms, median: 26.92 ms • 1000 items and 200 modifications without moves: 13.54 ms, median: 13.36 ms tests are run on Nexus 5X with M @a_tolstykh
37. DiffUtil May take significant time for large dataset... Use it on a background thread! @a_tolstykh
38. DiffUtil. Summary Avoid unnecessary UI updates! Animated values change! @a_tolstykh
39. Android TextView with rich support of compound drawables. This is a tiny library which empowers TextView's compound drawables with: • size specifying • vector support • tinting https://github.com/a-tolstykh/textview-rich-drawable TextViewRichDrawable @a_tolstykh
40. • Optimized layout TextViewRichDrawable • More readable code • Better User Experience @a_tolstykh https://github.com/a-tolstykh/textview-rich-drawable
41. <TextView android:id="@+id/reviews_count" android:layout_width="wrap_content" android:layout_height="wrap_content" /> <ImageView android:layout_width="@dimen/icon_small_size" android:layout_height="@dimen/icon_small_size" android:layout_marginEnd="@dimen/space_medium" android:src="@drawable/ic_person" /> <TextView android:id="@+id/rating_value" android:layout_width="wrap_content" android:layout_height="wrap_content" /> <ImageView android:layout_width="@dimen/icon_small_size" android:layout_height="@dimen/icon_small_size" android:src="@drawable/ic_star" /> <com.tolstykh.textviewrichdrawable.TextViewRichDrawable android:id="@+id/reviews_count" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_marginEnd="@dimen/space_medium" android:drawableRight="@drawable/ic_person" app:compoundDrawableHeight="@dimen/icon_small_size" app:compoundDrawableWidth="@dimen/icon_small_size" /> <com.tolstykh.textviewrichdrawable.TextViewRichDrawable android:id="@+id/rating_value" android:layout_width="wrap_content" android:layout_height="wrap_content" android:drawableRight="@drawable/ic_star" app:compoundDrawableHeight="@dimen/icon_small_size" app:compoundDrawableWidth="@dimen/icon_small_size" /> Before After @a_tolstykh https://github.com/a-tolstykh/textview-rich-drawable
42. Simplify your layout 4 Views 2 Views @a_tolstykh https://github.com/a-tolstykh/textview-rich-drawable Before After
43. RecyclerView Performance Tuning Prefetch. Cache. Reuse! @a_tolstykh
44. RecyclerView Performance Tuning Do not over engineer. Keep it simple! @a_tolstykh
45. RecyclerView Performance Tuning Avoid premature optimizations. Think about optimizations when you need them. @a_tolstykh
46. Thanks @a_tolstykh @a_tolstykh +OleksandrTolstykh
