OpenShift.Run-2024-Medik8s

OpenShift.Run 2024でのMedik8sセッションの資料です。

Transcript

1. - Workload Availability for OpenShift - ノード障害時にStatefulSetも 自動回復したい！ そんなときは medik8s.io Manabu Ori Red Hat 1 OpenShift.Run 2024 2024-03-28
2. 2 ▸ worker-2で動いていたPodにEvictionが発動 ▸ k8sの自動復旧の仕組みにより、他のノードで自動的に ...起動してない子がいる？！ ▸ worker-2で動いていたPodは Terminating のまま こういう状況見たことありませんか？ ▸ worker-2でノード障害が発生！すると...
3. 3 こういう状況見たことありませんか？ ▸ ...といった状況を自動で復旧させる方法をご紹介します 勝手に復旧！
4. 4 ▸ デフォルト設定では、ノード障害発生からおよそ 5分40秒でPodのEvictionが始まる ノード障害時の動き ノード障害発生 Taint付与 Eviction発動 • node.kubernetes.io/not-ready • node.kubernetes.io/unreachable tolerationSecondsのデフォルトは 300秒 node-monitor-grace-period (40秒) default-not-ready-toleration-seconds default-unreachable-toleration-seconds (300秒)
5. 5 ▸ ノード障害時にPodが自動回復しないパターン: at-most-one semantics ･ StatefulSet ･ RWOなPVを持つPod ▸ KubeVirt/OpenShift Virtualizationでノード障害時にVMが別ノードで自動回復しない Kubernetesのありがちな悩み ▸ 本資料では、これを自動でなんとかするための仕組みをご紹介します ･ キーワード: ･ Workload Availability for OpenShift ･ Node Health Check Operator, Self Node Remediation Operator, ... ･ Medik8s https://www.medik8s.io/ ･ そういえば、最近(k8s v1.28で)Non Graceful Node Shutdownの機能がGAしましたね...
6. 6 ▸ Failure Detectionの仕組みでノード障害を検知 ･ Machine Health Check (OpenShift標準機能、IPI前提) ･ Node Health Check Operator (UPIでも使用可) ･ SIG ClusterのExternal Remediation APIを利用 ▸ 検知の結果を元に、Remediationの仕組みを使って自動復旧 ･ Self Node Remediation (IPMI/Redfish必要なし) ･ Fence Agents (IPMI/Redfish前提) ･ Machine Deletion (APIでノード削除) 概要 Failure Detection Remediation Machine Health Check Node Health Check Operator Self Node Remediation Operator Fence Agents Remediation Operator Machine Deletion Remediation Operator OpenShift標準機能 追加Operator Legend: 障害検知 自動復旧
7. 7 概要 Node Health Check Operator NodeHealthCheck SelfNode Remediation Self Node Remediation Operator SelfNode Remediation Config SelfNode Remediation Template Soft Watchdogに よる回復処理 FenceAgent Remediation Fence Agent Remediation Operator SelfNode Remediation Template FenceAgent Remediation Template IPMIによる フェンシング ノード障害を検知し、 Remediationが必要と判断する と、Templateから XXRemediation CRを生成 NHC Operatorがノード障害を検 知し、Remediationが必要と判断 すると、Templateから XXRemediation CRを生成 Self Node Remediation Fence Agent Remediation
8. 8 ▸ 処理の概要: ･ 各ノードのNodeConditionsを見て、NodeHealthCheckで定義した判断基準/しきい値にひっ かかるかを確認 ･ 障害発生と判断でき、かつRemediation処理を実施するべき状況であれば、 Remediation Request カスタムリソースを作成 ･ このCRを見てRemediation処理が走る ▸ ノードのラベルに応じて異なる対応が可能 ･ NodeHealthCheckでnodeSelectorを指定 ▸ もしクラスターのバージョンアップ中であれば、それが完了するまで remediation処理をスキップする ･ https://github.com/medik8s/node-healthcheck-operator/blob/2edb6fd6d1b0294f19 d62c2e91815e44b96b74f4/controllers/nodehealthcheck_controller.go#L249-L255 ･ 今のところOpenShiftのみ Node Healthcheck Operator
9. 9 ▸ NodeHealthCheck CRの例 Node Healthcheck Operator apiVersion: remediation.medik8s.io/v1alpha1 kind: NodeHealthCheck metadata: name: nodehealthcheck-sample spec: minHealthy: 51% pauseRequests: - <pause-test-cluster> remediationTemplate: apiVersion: self-node-remediation.medik8s.io/v1alpha1 name: self-node-remediation-resource-deletion-template namespace: openshift-workload-availability kind: SelfNodeRemediationTemplate escalatingRemediations: - remediationTemplate: apiVersion: self-node-remediation.medik8s.io/v1alpha1 name: self-node-remediation-resource-deletion-template namespace: openshift-workload-availability kind: SelfNodeRemediationTemplate order: 1 timeout: 300s selector: matchExpressions: - key: node-role.kubernetes.io/worker operator: Exists unhealthyConditions: - type: Ready status: "False" duration: 300s - type: Ready status: Unknown duration: 300s 最低限残す必要がある Healthyノード数 一時的にRemediationを止めたいときに使用 メインのRemediation処理のテンプレート Remediation処理を多重化したいときはここにリ ストする 適用するノードの指定 ノード障害と判断する条件
10. 10 ▸ MachineHealthCheck/NodeHealthCheckで障害を検知した際、自動復旧を行う仕 組 みのひとつ ･ MHC/NHCコントローラがSelfNodeRemediation CRを作成 ･ SelfNodeRemediation CRを見てSNR OperatorがRemediation処理を実行 ▸ IPMI/Redfishやノード操作のAPIを必要としない ･ Software Watchdogを使用 Self Node Remediation Operator apiVersion: self-node-remediation.medik8s.io/v1alpha1 kind: SelfNodeRemediation metadata: name: selfnoderemediation-sample namespace: openshift-operators spec: remediationStrategy: <remediation_strategy> status: lastError: <last_error_message> apiVersion: self-node-remediation.medik8s.io/v1alpha1 kind: SelfNodeRemediationConfig metadata: name: self-node-remediation-config namespace: openshift-operators spec: safeTimeToAssumeNodeRebootedSeconds: 180 watchdogFilePath: /dev/watchdog isSoftwareRebootEnabled: true apiServerTimeout: 15s apiCheckInterval: 5s maxApiErrorThreshold: 3 peerApiServerTimeout: 5s peerDialTimeout: 5s peerRequestTimeout: 5s peerUpdateInterval: 15m (次ページ参照)
11. 11 ▸ ResourceDeletion ･ ノード上のPodおよびPVCを削除する ▸ OutOfServiceTaint ･ KEP-2268: Non graceful node shutdownの機能を使用 ･ PVを持つPodが動いているノードに障害が発生した場合でも、 PVのデ タッチおよびPodの削除ができるようになる ･ ノードがNotReady状態かつ「node.kubernetes.io/out-of-service」 Taintが付与されている場合に、kube-controller-managerがPVのデ タッチ/Pod削除処理を行う ▸ Automatic ･ OutofServiceTaintが利用できる場合は使用し、そうでなければ ResourceDeletionを使用する (デフォルト設定) Remediation Strategy
12. 12 ▸ fence agentを使って電源オン/オフを行う ･ よく使われるのはfence_ipmilan Fence Agent Remediation Operator apiVersion: fence-agents-remediation.medik8s.io/v1alpha1 kind: FenceAgentsRemediationTemplate metadata: name: fence-agents-remediation-template-fence-ipmilan namespace: openshift-workload-availability spec: template: spec: agent: fence_ipmilan nodeparameters: --ipport: master-0-0: '6230' master-0-1: '6231' master-0-2: '6232' worker-0-0: '6233' worker-0-1: '6234' worker-0-2: '6235' sharedparameters: '--action': reboot '--ip': 192.168.123.1 '--lanplus': '' '--password': password '--username': admin retryCount: '5' retryInterval: '5' timeout: '60'
13. 13 ▸ 03:56:00 worker-2電源断 実際の動き (1) controllers.NodeHealthCheck Node is going to match unhealthy condition {"node": "worker-2", "condition type": "Ready", "condition status": "Unknown", "duration left": "4m59.920799888s"} controllers.NodeHealthCheck.resource manager Creating a remediation CR {"CR name": "worker-2", "CR kind": "SelfNodeRemediation", "namespace": "openshift-workload-availability"} ▸ 03:56:35 [node-healthcheck-controller-manager] Unhealhtyノードの検出 ▸ 04:01:35 [node-healthcheck-controller-manager] SelfNodeRemediation作成 node-monitor-grace-period default-not-ready-toleration-seconds default-unreachable-toleration-seconds
14. 14 ▸ 04:04:37 [node-healthcheck-controller-manager] SelfNodeRemediation更新 (phase: Reboot-Completed) ▸ 04:04:38 [self-node-remediation-controller] out-of-service taint add 実際の動き(2) kube-controller-manager-master-2 kube-controller-manager I0328 04:04:47.598293 1 reconciler.go:277] "attacherDetacher.DetachVolume started: node has out-of-service taint, force detaching" node="worker-2" volumeName="kubernetes.io/csi/openshift-storage.rbd.csi.ceph.com^0001-0011-openshift-storage-0000000000000002-67bda59f-cf8f-4ad3-9ad9-df681d058b9c" kube-controller-manager-master-2 kube-controller-manager I0328 04:04:47.634199 1 reconciler.go:277] "attacherDetacher.DetachVolume started: node has out-of-service taint, force detaching" node="worker-2" volumeName="kubernetes.io/csi/openshift-storage.rbd.csi.ceph.com^0001-0011-openshift-storage-0000000000000002-25426b29-4dfa-48bf-8099-e7827b7cdca1" controllers.SelfNodeRemediation out-of-service taint added {"selfnoderemediation": "openshift-workload-availability/worker-2", "new taints": [{"key":"node.kubernetes.io/unreachable","effect":"NoSchedule","timeAdded":"2024-03-28T03:56:35Z"},{"key":"node.kubernetes.io/unreachable","effect":"NoExecute","time Added":"2024-03-28T03:56:40Z"},{"key":"medik8s.io/remediation","value":"self-node-remediation","effect":"NoExecute","timeAdded":"2024-03-28T04:01:36Z"},{"key":"node. kubernetes.io/unschedulable","effect":"NoSchedule","timeAdded":"2024-03-28T04:01:36Z"},{"key":"node.kubernetes.io/out-of-service","value":"nodeshutdown","effect":"No Execute","timeAdded":"2024-03-28T04:04:38Z"}]} ▸ 04:04:47 [kube-controller-manager] force detaching ▸ 04:01:37 [node-healthcheck-controller-manager] SelfNodeRemediation更新 (phase: Pre-Reboot-Completed) safeTimeToAssumeNodeRebootedSeconds
15. 15 ▸ 04:04:48 [node-healthcheck-controller-manager] SelfNodeRemediation更新 (phase: Fencing-Completed) ▸ 04:04:48 [self-node-remediation-controller] out-of-service taint remove 実際の動き (3) controllers.SelfNodeRemediation out-of-service taint removed {"selfnoderemediation": "openshift-workload-availability/worker-2", "new taints": [{"key":"node.kubernetes.io/unreachable","effect":"NoSchedule","timeAdded":"2024-03-28T03:56:35Z"},{"key":"node.kubernetes.io/unreachable","effect":"NoEx ecute","timeAdded":"2024-03-28T03:56:40Z"},{"key":"medik8s.io/remediation","value":"self-node-remediation","effect":"NoExecute","timeAdded":"2024-03-28T0 4:01:36Z"},{"key":"node.kubernetes.io/unschedulable","effect":"NoSchedule","timeAdded":"2024-03-28T04:01:36Z"}]}
16. 16 ▸ Workload Availability for Red Hat OpenShift ･ https://access.redhat.com/documentation/en-us/workload_availability_for_red_hat_openshift ▸ Node Health Check Operator ･ https://www.redhat.com/en/blog/node-health-check-operator ▸ Medik8s ･ https://www.medik8s.io/ ▸ Ø Kubernetes Failover Improvement: Non-Graceful Node Shutdown - Yuiko Mori, NEC Solution Innovators ･ https://www.youtube.com/watch?v=28dbE24j_zc&list=PLbzoR-pLrL6q7ytV2im0AoNcJcADAeBtm ･ https://jpn.nec.com/oss/community/blog/kubernetes-failover-improvement-non-graceful-node-sh utdown.html ･ https://qiita.com/y-mo/items/ecb9207175543392ffbe 参考文献
17. 17 ▸ KEP-2268: Non graceful node shutdown ･ https://github.com/kubernetes/enhancements/tree/master/keps/sig -storage/2268-non-graceful-shutdown ･ https://github.com/kubernetes/kubernetes/pull/108486 ▸ External Remediation API ･ https://github.com/kubernetes-sigs/cluster-api/pull/3190 参考文献
