API Design Hands-On Lab

Hand On Lab at Oracle Code One 2018. API Design & Testing using Apiary, API Blueprint and Dredd

Transcript

1. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted Accelerate Your Development
 with Design-First API Management Hand On Lab Emmanuel Paraskakis Sr. Director of Product Management Oracle API Platform @manp
2. apiary + 470,440 APIs 5.5M+ API Consumers 365,802 API Designers
3. Agenda 1. Introduction to API Design 2. Hands-On API Design Tutorial 3. Deploying an API 4. Next Steps

 Ends 16:45
4. What you will learn • Design a basic JSON API in API Blueprint • Use API Documentation and Mocking • Use Automated Testing Tools • Where to go from here
5. API Design Thinking Define
 Start with API Description Ideate
 Share with API Consumers Prototype
 Mock Server Test
 Implement and Deploy Empathize Research Needs
6. How we Built APIs & Services API as a by-product of building apps API documentation generated from code Design-first API Development
7. 2006: API as a By-Product API as a by-product of building apps API documentation generated from code Design-first API Development
8. 2010: API Docs from Code API documentation generated from code Design-first API Development API as a by-product of building apps
9. Developer Experience API as a Product
10. 2014: Design-first API Development Design-first API Development API as a by-product of building apps API documentation generated from code
11. 2018 API as a by-product of building apps API documentation generated from code Design-first API Development Layered API
 Descriptions
12. API Design Tutorial
13. Scenario ➡ You: API Designer (Developer, Architect, PM) ➡ Instructor: • Customer • Service Developer • DevOps ➡ Objective: Design an API you can use to publish polls and have users vote on
14. What you will need • Browser: • https://apiary.io • http://bit.ly/api-design-tutorial • Optional: • Git & GitHub • Node or Docker to run tests
15. Apiary - Free! • Source of Truth for API Design • Interactive API Documentation • Collaboration (invite others to edit) • GitHub Syncing • Mock Service • Traffic Inspector • Automated Tests https://help.apiary.io/
16. Register on apiary.io https://login.apiary.io/register
17. Tutorial Repo http://bit.ly/api-design-tutorial
18. API Blueprint https://apiblueprint.org/documentation/tutorial.html
19. Optional: Dredd Testing http://dredd.org/en/latest/ API Description Running Service Fail Pass
20. Install Dredd via npm $ npm install -g dredd $ dredd
21. Run Dredd with Docker $ docker run -it -v $PWD:/api -w /api apiaryio/dredd dredd
22. Running Dredd $ dredd <My API Design file> <My running service URL>
23. 0. Create a new API Design • Go into Apiary and “Create New API Project” • Keep “API Blueprint” Selected and name the API • You now have a working API using a template • Optional: Sync the API to GitHub: 1.Create a new repo in GitHub 2.In Apiary “Link this Project to GitHub” 3.On your Laptop: $ git clone your repo
24. 1. Multiple Responses • Find the /questions resource • Copy the response and paste above existing one • Change the 201 to a 200 - Save • Optional: 1.Push to GitHub from Apiary 2.$ git pull on your Laptop 3.test with
 $ dredd apiary.apib http://polls.apiblueprint.org/
25. 2. Add a query parameter • Add an optional {?page} numeric parameter with default value 1 to the /questions resource - Save • Optional: 1.Push to GitHub from Apiary 2.$ git pull on your Laptop 3.test with
 $ dredd apiary.apib http://polls.apiblueprint.org/
26. 3. Add a resource with path param • Add /questions/{question_id} as the first resource in your API. The parameter should be a number with default value 1 and is required • A GET method retrieves the question’s detail. Give an example JSON response
 (hint: it should be the same as an element in the /questions response array) • Optional: 1.Push to GitHub from Apiary 2.$ git pull on your Laptop 3.test with
 $ dredd apiary.apib http://polls.apiblueprint.org/
27. 4. Multiple path params • Add a resource to use as a voting mechanism on the choices of a question • Nesting parameters will work here:
 /questions/{question_id}/choices/{choice_id} • POST is a nice way to tell our service we are voting • Response should be a 201, no response body needed • Optional: push from Apiary, pull on your laptop and test
28. 5. Scratch the surface of Hypermedia • We want an easy way to discover what the API can do • Easiest way is to add a top-level root “/“ resource that tells us what other resources are available in the API • Response looks like:
 {"questions_url": "/questions"} • Optional: push from Apiary, pull on your laptop and test

29. 6. Different way to query • We want a quick way to list the choices to vote on • Add a resource
 /questions/{question_id}/choices • GET should return an array of choices
 (hint: look at the POST /questions request body) • Optional: test with dredd
30. Failing Tests • What we specced out has not been implemented! • $ echo $? gives exit code: 0=success, >1=failure • Hard to detect by eyeballing • Hard to write tests by hand and keep them in sync • Important to have so you don’t break clients • API Design + Dredd in your CI/CD
31. Homework: Missing functionality https://github.com/apiaryio/polls-api
32. Where you can go from here
33. 1. MSON • Extends API Blueprint with language for Data Structures • No more writing JSON payloads! Rendered for you • Compact, reusable, comment on data structures https://apiblueprint.org/documentation/mson/tutorial.html
34. 2. OpenAPI 2.0 • FKA Swagger 2.0 - supported in Apiary • Apiary will be supporting OpenAPI 3.0 in future • Industry standard - YAML https://help.apiary.io/api_101/swagger-tutorial/
35. 3. Deploy to Gateway • Oracle API Management - OCI • Gateways, API Deployments, Policies, Dev Portal • Understands API Design • Use $300 trial on Oracle Cloud https://myservices.us.oraclecloud.com/mycloud/signup
36. 4. Apiary Pro • Paid version, adds features: 1.Manage team’s access to API Designs 2.Style Guide for consistency across APIs 3.Advanced GitHub integration with branches 4.Use with Oracle API Platform • To get it: “Create a Team” from within Apiary • Can also get as part of Oracle Cloud Trial
37. Resources https://apiary.io http://bit.ly/api-design-tutorial https://apiblueprint.org/documentation/tutorial.html https://help.apiary.io/ http://dredd.org/en/latest/ http://bit.ly/learn-api https://apiary.io/how-to-build-api support@apiary.io
38. Copyright © 2018, Oracle and/or its affiliates. All rights reserved. | Confidential – Oracle Internal/Restricted/Highly Restricted Thank you! @manp 38 Thursday • OOW: The future of API Management with Oracle API Platform & Apiary
 [PRM6971] - Robert, Jakub, Emmanuel • OOW: How Rabobank Is Using Oracle API Platform to Achieve API Success
 [CAS4501] - Robert
