Slides of my lecture "Migration of a containerized Legacy Application to the Cloud" at Global Big Data Conference 2022

Patrick Koch

August 01, 2022
Tweet

More Decks by Patrick Koch

Other Decks in Technology

Transcript

  1. Welcome To

    View Slide

  2. Patrick Koch
    AVL List GmbH (Headquarters) Public
    Don't give up just because it's legacy
    Migration of a containerized Legacy
    Application to the Cloud

    View Slide

  3. Patrick Koch | | 26 July 2022 |
    / 3
    Public
    Today’s Agenda
    4
    3
    2
    Who am I? My employer, our legacy
    software application
    Introduction
    1
    Once upon a time ... and it‘s still
    What happened before the cloud?
    Why the hell Windows containers?
    1st Challenge – Let’s do a PoC
    Linux containers, finally!
    Next logical step
    What’s next? We are still at the beginning ...
    Conclusion & Outlook
    5

    View Slide

  4. Patrick Koch | | 26 July 2022 |
    / 4
    Public
    AVL List GmbH
    Founded 1948
    More than 11,000 worldwide
    4,000 in Graz (headquarters)
    45 affiliates worldwide
    Export quota of 97%
    AVL List GmbH (“AVL”) is the world’s largest independent company for development,
    simulation and testing in the automotive industry, and in other sectors. Drawing on its
    pioneering spirit, the company provides concepts, solutions and methodologies to shape future
    mobility trends.”

    View Slide

  5. Patrick Koch | | 26 July 2022 |
    / 5
    Public
    Who am I?
    Patrick Koch
    DevOps / Integration Engineer Software
    Specialized in:
    CI/CD, Container, K8s, Cloud
    • Improving CI/CD Pipelines
    • Containerization of the Infrastructure/Software
    Components
    • Establishing Cloud Solutions
    • Development and Maintenance of our intern Testing
    Tools
    • Provides good Suggestions for Department Events ;)

    View Slide

  6. Patrick Koch | | 26 July 2022 |
    / 6
    Public
    Evolved to
    platform product
    Container,
    K8s
    Automation
    Framework
    Web
    components
    AVL CONCERTO
    Why legacy?
    Started >
    25 years
    ago
    Python support
    REST interface
    2014
    New Generation
    (unmanaged legacy (C++) and
    managed (C#) code).
    Windows®
    application
    (component & full integration in
    internal products)
    2018
    ~ 8200 files
    ~ 2,9 Mio LOC
    Linux components
    (data, Python)
    2022 ...
    “A legacy system is outdated computing
    software and/or hardware that is still in use. ”
    Source of icon: https://commons.wikimedia.org/wiki/File:Windows_Logo_(1992-2001).svg
    ~ 800 customers
    ~ 23000 users

    View Slide

  7. Public
    Once upon a time ...
    What happened before
    the cloud, k8s, container?

    View Slide

  8. Patrick Koch | | 26 July 2022 |
    / 8
    Public
    Traditional Use Case: The Engine Test Bed

    View Slide

  9. Patrick Koch | | 26 July 2022 |
    / 9
    Public
    Data Processing with Concerto on Windows 10 Client

    View Slide

  10. Public
    how and why the 1st challenge started …

    View Slide

  11. Patrick Koch | | 26 July 2022 |
    / 11
    Public
    An evolution happens – why even more automation?
    2021 ..
    ~ 30 years
    Huge testbed for single unit under test (UUT)
    1 Operator per testbed
    Very high costs
    Exchanging of unit is labour-intesive
    How to increase the degree of automation?
    One testing unit for multiple UUTs (Battery Cells)
    1 Operator for whole lab
    Costs per UUT are much lower
    UUT exchange works automated
    2021 ..

    View Slide

  12. Patrick Koch | | 26 July 2022 |
    / 12
    Public
    The Mission (impossible?)
    Move your custom
    legacy application into
    the
    cloud. Find a
    migration strategy
    that works! Right
    now!

    View Slide

  13. Patrick Koch | | 26 July 2022 |
    / 13
    Public
    Short-term approach for migrating to the cloud
    Run your legacy SW as a Windows container on a
    hybrid cloud platform!
    Lift & Shift (Rehost)
    Whole application is taken
    and pushed into container
    not possible / would
    cause to much costs
    Refactoring
    Rebuild

    View Slide

  14. Patrick Koch | | 26 July 2022 |
    / 14
    Public
    The mixed cloud architecture -
    an example
    What is already supported?
    Managed
    Cloud Service
    On Premise
    Public Cloud
    Data Server
    CONCERTO
    Message
    Broker
    VPN
    Report

    View Slide

  15. Patrick Koch | | 26 July 2022 |
    / 15
    Public
    Start lightweight - Serverless

    View Slide

  16. Patrick Koch | | 26 July 2022 |
    / 16
    Public
    Azure K8s Service – Deployment of a Kubernetes Workload
    Source: https://docs.microsoft.com/de-de/azure/architecture/solution-ideas/articles/migrate-existing-applications-with-aks
    “Easily migrate existing application to container(s) and run within the Azure managed Kubernetes service (AKS)”

    View Slide

  17. Patrick Koch | | 26 July 2022 |
    / 17
    Public
    Azure K8s Service – Deployment of a Kubernetes Workload

    View Slide

  18. Patrick Koch | | 26 July 2022 |
    / 18
    Public
    Azure – Automated Resource Provisioning with Azure
    DevOps Server and Terraform
    Terraform
    .tf
    .tfstate
    Azure
    Azure DevOps Server

    View Slide

  19. Public
    What’s next? Cloud
    Windows Containers

    View Slide

  20. Patrick Koch | | 26 July 2022 |
    / 20
    Public
    mid-term approach for migrating to the cloud & automation
    Refactor core parts of your monolith and run them
    as Linux container
    Lift & Shift (Rehost)
    Whole application is taken
    and pushed into container
    Next logical step
    Refactoring
    Rebuild

    View Slide

  21. Patrick Koch | | 26 July 2022 |
    / 21
    Public
    Determine the core components selected for refactoring
    Native Data
    management subsytem
    COM
    .Net
    Managed
    subsytem
    Native
    application
    Managed
    GUI
    Native GUI
    COM
    REST
    Python
    Python
    pybind
    Python
    Python
    Python
    Python
    Native Data
    management subsytem

    View Slide

  22. Patrick Koch | | 26 July 2022 |
    / 22
    Public
    Future Use Case: Architecture
    3
    4
    5
    6
    1 2
    Logo/Picture Sources:
    Azure: azure.microsoft.com | Prefect: docs.prefect.io | AKS: sharepointeurope.com | ACR: azure.microsoft.com
    Linux: linuxfoundation.org | Python: python.org | docs.dask.org

    View Slide

  23. Patrick Koch | | 26 July 2022 |
    / 23
    Public
    Prefect Flow as Kubernetes Job

    View Slide

  24. Patrick Koch | | 26 July 2022 |
    / 24
    Public
    Outlook / Roadmap
    2019
    • Containerization
    • Concerto runs
    within a
    (Windows)
    Container
    2020
    • Deployment and
    Hosting at
    Rancher
    • CI/CD Pipeline
    Integration for
    Container at
    Azure DevOps
    2021
    • Proof of Concept
    at Microsoft‘s
    Kubernetes
    Service within
    Azure Cloud with
    Windows and
    Linux Container
    Workloads
    2022
    • First
    development of
    Linux container
    • Python
    Integration
    • Prefect as
    Workflow
    Automation
    •Established IaC
    2023 – 202?
    • Become a Data
    Analytics
    Platform based
    on Python and
    Linux
    • SaaS
    • Less focus on
    Windows
    desktop

    View Slide

  25. Patrick Koch | | 26 July 2022 |
    / 25
    Public
    Key Learnings of Social and Technical Aspects
    DON‘T
    REINVENT
    THE WHEEL
    GET OUT OF
    YOUR COMFORT
    ZONE
    INFRASTRUCTURE
    AS CODE
    MVP
    FIRST
    ARCHITECTURE DRIVEN
    BY BUSINESS
    DON‘T COPY/REBUILD
    ESTABLISHED
    TOOLS
    STAY
    CURIOUS
    Neglect of cloud
    security
    Internal
    resistance to
    adoption
    Adopt due to wrong
    reasons
    Skills
    deficit
    WORKLOAD:
    PROPER DEPLOYMENT
    RULES
    AKS:
    CONTAINER IMAGE CAN NOT
    BE PULLED
    WHICH SERVICES TO
    CHOOSE?
    DO NOT WAIT,
    START
    IMMEDIATELY

    View Slide

  26. www.avl.com
    Public
    Thank you
    Change is the Essence of Innovation.
