  1. getting touchy EVERYTHING YOU (N)EVER WANTED TO KNOW ABOUT TOUCH

    AND POINTER EVENTS Patrick H. Lauke / JavaScript Days 2017 / 22 March 2017 / Munich
  2. about me... •  senior accessibility consultant at The Paciello Group

    •  previously developer relations at Opera •  co-editor Touch Events Level 2 •  WG chair and co-editor Pointer Events Level 2
  3. github.com/patrickhlauke/getting-touchy-presentation "evergreen" expanded version of this presentation (and branches for

    specific conferences)
  4. patrickhlauke.github.io/touch

  5. None
  6. Touch/pointer events test results

  7. CodePen: Basic slider - from mouse-only to mouse/touch/stylus enabled

  8. my JavaScript sucks... (but will hopefully convey the right concepts)

  9. “how can I make my website work on touch devices?”

  10. you don't need touch events browsers emulate regular mouse events

  11. patrickhlauke.github.io/touch/tests/event-listener_mouse-only.html

  12. patrickhlauke.github.io/touch/tests/event-listener_mouse-only.html

  13. compatibility mouse events (mouseenter) > mouseover > mousemove* > mousedown

    > (focus) > mouseup > click * only a single “sacrificial” mousemove event fired
  14. on first tap (mouseenter) > mouseover > mousemove > mousedown

    > (focus) > mouseup > click subsequent taps mousemove > mousedown > mouseup > click tapping away (mouseout) > (blur) focus / blur only on focusable elements; subtle differences between browsers Mobile/tablet touchscreen activation/tap event order
  15. emulation works, but is limiting/problematic

  16. 1.  delayed event dispatch 2.  mousemove doesn't track

  17. 1.  delayed event dispatch 2.  mousemove doesn't track

  18. patrickhlauke.github.io/touch/tests/event-listener_show-delay.html less of a problem in modern browsers, but for

    iOS < 9.3 or older Androids still relevant
  19. patrickhlauke.github.io/touch/tests/event-listener_show-delay.html

  20. 1.  delayed event dispatch 2.  mousemove doesn't track

  21. patrickhlauke.github.io/touch/particle/2

  22. patrickhlauke.github.io/touch/particle/2

  23. “we need to go deeper...”

  24. touch events introduced by Apple, adopted in Chrome/Firefox/Opera (and belatedly

    IE/Edge – more on that later) www.w3.org/TR/touch-events
  25. caniuse.com: Can I use touch events?

  26. touchstart touchmove touchend touchcancel

  27. patrickhlauke.github.io/touch/tests/event-listener_all-no-timings.html

  28. patrickhlauke.github.io/touch/tests/event-listener_all-no-timings.html Bug 128534 - 'mouseenter' mouse compat event not fired...

  29. events fired on tap touchstart > [touchmove]+ > touchend >

    (mouseenter) > mouseover > mousemove > mousedown > (focus) > mouseup > click (mouse events only fired for single-finger tap)
  30. on first tap touchstart > [touchmove]+ > touchend > (mouseenter)

    > mouseover > mousemove > mousedown > (focus) > mouseup > click subsequent taps touchstart > [touchmove]+ > touchend > mousemove > mousedown > mouseup > click tapping away mouseout > (mouseleave) > (blur)
  31. •  too many touchmove events prevent mouse compatibility events after

    touchend (not considered a "clean" tap) •  too many touchmove events on activatable elements can lead to touchcancel (in old Chrome/Browser versions) •  not all browsers consistently send touchmove •  differences in focus / blur and some mouse compatibility events (e.g. mouseenter / mouseleave ) •  some events may only fire when tapping away to another focusable element (e.g. blur ) some browsers outright weird...
  32. Browser/Android 4.3 mouseover > mousemove > touchstart > touchend >

    mousedown > mouseup > click Browser/Blackberry PlayBook 2.0 touchstart > mouseover > mousemove > mousedown > touchend > mouseup > click UC Browser 10.8/Android 6 mouseover > mousemove > touchstart > (touchmove)+ > touchend > mousedown > focus > mouseup > click
  33. Touch/pointer events test results

  34. shouldn't affect your code, unless you're expecting a very specific

    sequence...
  35. <interlude > simple feature detection for touch events

  36. /* feature detection for touch events */ if ( 'ontouchstart'

    in window ) { /* some clever stuff here */ } /* older browsers have flaky support so more hacky tests needed...use Modernizr.touch or similar */
  37. patrickhlauke.github.io/touch/tests/touch-feature-detect.html

  38. /* conditional "touch OR mouse/keyboard" event binding */ if ('ontouchstart'

    in window) { // set up event listeners for touch ... } else { // set up event listeners for mouse/keyboard ... }
  39. don't make it touch-exclusive

  40. hybrid devices touch + mouse + keyboard

  41. None
  42. None
  43. @patrick_h_lauke showing a naive "touch or mouse" issue on Flickr

    (which has since been fixed)
  44. Bug 888304 - touch-events on Firefox-desktop should be disabled until

    we can support them...
  45. Issue 392584: TouchEvent API should be enabled consistently

  46. Chrome now returns window.TouchEvent on non-touch devices patrickhlauke.github.io/touch/tests/touch-feature-detect.html

  47. even on "mobile" we can have multiple inputs...

  48. None
  49. None
  50. Windows 10 "Continuum" (mobile device acting as desktop)

  51. Android + mouse – like touch (mouse emulating touch) touchstart

    > touchend > mouseover > mousemove > mousedown > (focus) > mouseup > click
  52. Android + Chrome 58 + mouse – like desktop mouse

    events (+ pointer events) + click
  53. Blackberry PlayBook 2.0 + mouse – like desktop mouseover >

    mousedown > (mousemove)+ > mouseup > click
  54. Blackberry Leap (BBOS 10.1) + mouse – like desktop mouseover

    > mousedown > (mousemove)+ > mouseup > click
  55. Windows 10 Mobile/Microsoft Edge + mouse – like desktop mouse

    events (+ pointer events) + click
  56. Windows 10 Mobile/Microsoft Edge + keyboard – like desktop focus

    / click / blur
  57. Android + keyboard – like desktop focus / click /

    blur
  58. iOS keyboard only works in same situations as on-screen keyboard

    (e.g. text inputs, URL entry)
  59. VoiceOver enables full keyboard access on iOS

  60. iOS + keyboard – similar to touch (using VO +

    SPACE ) focus / touchstart > touchend > (mouseenter) > mouseover > mousemove > mousedown > blur > mouseup > click
  61. iOS + keyboard – like desktop (using ENTER ) focus

    / click / blur
  62. mobile Assistive Technologies (e.g. screen readers on touchscreen devices)

  63. iOS + VoiceOver (with/without keyboard) – similar to touch focus

    / touchstart > touchend > (mouseenter) > mouseover > mousemove > mousedown > blur > mouseup > click
  64. Android 4.3/Chrome + TalkBack – keyboard/mouse hybrid focus / blur

    > mousedown > mouseup > click > focus
  65. Android 6.1/Chrome + TalkBack – like touch touchstart > touchend

    > mouseover > mouseenter > mousemove > mousedown > focus > mouseup > click
  66. Android 6.1/Firefox + TalkBack – similar to touch touchstart >

    mousedown > focus > touchend > mouseup > click
  67. further scenarios? •  desktop with external touchscreen •  touchscreen laptop

    with non-touch second screen •  touchscreen laptop with trackpad/mouse •  ...and other permutations?
  68. note on trackpad gestures •  trackpads that allow multi-finger gestures

    (e.g. recent MacBooks, Magic Mouse/Trackpad, Windows precision trackpad, ASUS Smart Gesture, Wacom Intuos Pro gestures etc) don't fire touch events / expose touch points •  these gestures are handled directly by the OS/driver and don't reach the browser as raw touches •  Wacom Intuos Pro touch input exposed as mouse to OS •  OS X/Safari 9.1+ does fire Apple's proprietary gesture* events (for pinch-to-zoom, rotation)
  69. no way to detect these cases...

  70. Modernizr.touch detects touch events not touch devices

  71. Modernizr: Detecting a mouse user

  72. Stu Cox: You can't detect a touchscreen

  73. hacks.mozilla.org - Detecting touch [...]

  74. /* feature detection for touch events */ if ('ontouchstart' in

    window) { /* browser supports touch events but user is not necessarily using touch (exclusively) */ /* it could be a mobile, tablet, desktop, fridge ... */ }
  75. touch or mouse or keyboard

  76. touch and mouse and keyboard

  77. what about CSS4 Media Queries?

  78. W3C Media Queries Level 4 (Editor's Draft)

  79. Interaction Media Features pointer / hover relate to “primary” pointing

    device any-pointer / any-hover relate to all pointing devices /* the primary input is ... */ @media (pointer: fine) { /* a mouse, stylus, ... */ } @media (pointer: coarse) { /* a touchscreen, ... */ } @media (pointer: none) { /* not a pointer (e.g. d-pad) */ } @media (hover: hover) { /* hover-capable */ } @media (hover: none) { /* not hover-capable */ } hover: on-demand / any-hover: on-demand removed in recent drafts
  80. Interaction Media Features pointer / hover relate to “primary” pointing

    device any-pointer / any-hover relate to all pointing devices /* across all detected pointing devices at least one is ... */ @media (any-pointer: fine) { /* a mouse, stylus, ... */ } @media (any-pointer: coarse) { /* a touchscreen, ... */ } @media (any-pointer: none) { /* none of them are pointers */ } @media (any-hover: hover) { /* hover-capable */ } @media (any-hover: none) { /* none of them are hover-capable */ } hover: on-demand / any-hover: on-demand removed in recent drafts
  81. caniuse.com: Can I use interaction media features?

  82. Media Features and JavaScript if (window.matchMedia("(any-pointer:coarse)").matches) { ... } /*

    listen for dynamic changes */ window.matchMedia("(any-pointer:coarse)")↵ .onchange = function(e) { ... } window.matchMedia("(any-pointer:coarse)")↵ .addEventListener("change", function(e) { ... } , false } window.matchMedia("(any-pointer:coarse)")↵ .removeEventListener("change", function(e) { ... } , false }
  83. caniuse.com: Can I use matchMedia ?

  84. dev.opera - Interaction Media Features and their potential (for incorrect

    assumptions)
  85. patrickhlauke.github.io/touch/pointer-hover-any-pointer-any-hover primary input is unchanged (and Chrome/Android required full restart

    – Issue 442418)
  86. /* Naive uses of Interaction Media Features */ @media (pointer:

    fine) { /* primary input has fine pointer precision... so make all buttons/controls small? */ } @media (hover: hover) { /* primary input has hover...so we can rely on it? */ } /* pointer and hover only check "primary" input, but what if there's a secondary input that lacks capabilities? */
  87. /* Better uses of Interaction Media Features */ @media (any-pointer:

    coarse) { /* at least one input has coarse pointer precision... provide larger buttons/controls for touch */ } /* test for *any* "least capable" inputs (primary or not) */ Limitation: [mediaqueries-4] any-hover can't be used to detect mixed hover and non-hover capable pointers. Also, pointer / hover / any-pointer / any-hover don't cover non-pointer inputs (e.g. keyboards) – always assume non-hover-capable inputs @media (any-hover: none) { /* at least one input lacks hover capability... don't rely on it or avoid altogether */ }
  88. detect which input the users is using right now...

  89. GitHub: ten1seven / what-input

  90. Demo: What Input?
