Swift Mocks

Slides for plSwift presentation about writing a mocking framework for Swift.

Transcript

1. Building
   a robust Swift
   mocking Framework
   Pawel Dudek


   View Slide

2. View Slide

3. So you wanted to
   mock types
   in Swift...


   View Slide

4. The Why


   View Slide

5. Seams


   View Slide

6. enum ReleaseType {
   case production
   case debug
   }
   class ReleaseTypeService {
   var releaseType: ReleaseType {
   switch Bundle.main.bundleIdentifier {
   case "productionBundleId":
   return .production
   case "debugBundleId":
   return .debug
   }
   }
   }
   Missing default case on purpose 6


   View Slide

7. enum ReleaseType {
   case production
   case debug
   }
   class ReleaseTypeService {
   var releaseType: ReleaseType {
   switch Bundle.main.bundleIdentifier {
   case "productionBundleId":
   return .production
   case "debugBundleId":
   return .debug
   }
   }
   }
   Missing default case on purpose 7


   View Slide

8. protocol BundleIdProvider {
   var bundleIdentifier: String? { get }
   }
   8


   View Slide

9. protocol BundleIdProvider {
   var bundleIdentifier: String? { get }
   }
   extension Bundle: BundleIdProvider {}
   9


   View Slide

10. class ReleaseTypeService {
    let bundleIdProvider: BundleIdProvider
    init(bundleIdProvider: BundleIdProvider) {
    self.bundleIdProvider = bundleIdProvider
    }
    var releaseType: ReleaseType {
    switch bundleIdProvider.bundleIdentifier {
    case "productionBundleId":
    return .production
    case "debugBundleId":
    return .debug
    }
    }
    }
    Missing default case on purpose 10


    View Slide

11. class ReleaseTypeService {
    let bundleIdProvider: BundleIdProvider
    init(bundleIdProvider: BundleIdProvider) {
    self.bundleIdProvider = bundleIdProvider
    }
    var releaseType: ReleaseType {
    switch bundleIdProvider.bundleIdentifier {
    case "productionBundleId":
    return .production
    case "debugBundleId":
    return .debug
    }
    }
    }
    Missing default case on purpose 11


    View Slide

12. The Journey
    through
    Land of Swift Mocks


    View Slide

13. Hand
    written
    mocks


    View Slide

14. protocol Foo {
    func bar()
    }
    14


    View Slide

15. class MockFoo: Foo {
    var barCalled = false
    func bar() {
    barCalled = true
    }
    }
    XCTAssertTrue(mockFoo.barCalled)
    15


    View Slide

16. class MockFoo: Foo {
    var timesBarCalled = 0
    func bar() {
    timesBarCalled += 1
    }
    }
    XCTAssertEqual(mockFoo.timesBarCalled, 1)
    16


    View Slide

17. But what about arguments?
    protocol ArgumentFoo {
    func bar(arg1: Int, arg2: UIViewController)
    }
    17


    View Slide

18. class MockArgumentFoo: ArgumentFoo {
    var timesBarCalled = 0
    var barArgments: [(Int, UIViewController)] = []
    func bar(arg1: Int, arg2: UIViewController) {
    timesBarCalled += 1
    barArgments.append((arg1, arg2))
    }
    }
    18


    View Slide

19. class MockArgumentFoo: ArgumentFoo {
    var barArgments: [(Int, UIViewController)] = []
    func bar(arg1: Int, arg2: UIViewController) {
    barArgments.append((arg1, arg2))
    }
    }
    19


    View Slide

20. class MockArgumentFoo: ArgumentFoo {
    var barArgments: [(Int, UIViewController)] = []
    func bar(arg1: Int, arg2: UIViewController) {
    barArgments.append((arg1, arg2))
    }
    }
    XCTAssert // ???
    20


    View Slide

21. OCMockito
    // mock creation
    NSMutableArray *mockArray = mock([NSMutableArray class]);
    // using mock object
    [mockArray removeObject:@"This is a test"];
    // verification
    [verify(mockArray) removeObject:startsWith(@"This is")];
    21


    View Slide

22. class MockArgumentFoo: ArgumentFoo {
    var barArgments: [(Int, UIViewController)] = []
    func bar(arg1: Int, arg2: UIViewController) {
    barArgments.append((arg1, arg2))
    }
    var bar2Argments: [(CFTimeInterval, Float)] = []
    func bar2(arg1: CFTimeInterval, arg2: Float) {
    bar2Argments.append((arg1, arg2))
    }
    }
    22


    View Slide

23. Function + Arguments
    =
    Invocation


    View Slide

24. struct Invocation {
    let identifier: String
    let arguments: [Any?]?
    }
    24


    View Slide

25. class Storage {
    var recordedInvocations: [Invocation] = []
    func recordInvocation(
    withIdentifier identifier: String,
    arguments: [Any?]?
    ) {
    recordedInvocations.append(.init(
    identifier: identifier,
    arguments: arguments
    ))
    }
    }
    25


    View Slide

26. class StorageMockArgumentFoo: ArgumentFoo {
    let storage = Storage()
    func bar(arg1: Int, arg2: UIViewController) {
    storage.recordInvocation(
    withIdentifier: "bar",
    arguments: [arg1, arg2]
    )
    }
    func bar2(arg1: CFTimeInterval, arg2: Float) {
    storage.recordInvocation(
    withIdentifier: "bar2",
    arguments: [arg1, arg2]
    )
    }
    }
    26


    View Slide

27. Matching
    arguments


    View Slide

28. let arguments: [Any?]? = [value1, value2]
    let expectedArguments: [???] = ???
    // Won't compile, but we want something similar to this
    XCTEqual(arguments, expectedArguments)
    28


    View Slide

29. Any?


    View Slide

30. Ability to
    match values
    against a varienty of
    different rules


    View Slide

31. protocol Matcher {
    func matches(argument: Any?) -> Bool
    }
    31


    View Slide

32. class EqualTo: Matcher {
    private let object: T?
    init(_ object: T?) {
    self.object = object
    }
    func matches(argument: Any?) -> Bool {
    if let otherObject = argument as? T {
    return object == otherObject
    }
    return argument == nil && object == nil
    }
    }
    32


    View Slide

33. class EqualTo: Matcher {
    private let object: T?
    init(_ object: T?) {
    self.object = object
    }
    func matches(argument: Any?) -> Bool {
    if let otherObject = argument as? T {
    return object == otherObject
    }
    return argument == nil && object == nil
    }
    }
    33


    View Slide

34. class IdenticalTo: Matcher { ... }
    class InstanceOf: Matcher { ... }
    class NotMatcher: Matcher { ...}
    class CaptureArgumentMatcher: Matcher { ... }
    class AnyMatcher: Matcher {}
    class SimulateCallbackMatcher: Matcher { ... }
    34


    View Slide

35. Usage
    35


    View Slide

36. let matchers: [Matcher] = [
    EqualTo(Int(42)),
    IdenticalTo(viewController),
    ]
    let arguments: [Any?] = storage.(...)
    // Missing edge cases like different argument count
    let match = zip(matchers, arguments)
    .allSatisfy { $0.matches(argument: $1) }
    XCTAssertTrue(match)
    36


    View Slide

37. let matchers: [Matcher] = [
    EqualTo(Int(42)),
    IdenticalTo(viewController),
    ]
    let arguments: [Any?] = storage.(...)
    // Missing edge cases like different argument count
    let match = zip(matchers, arguments)
    .allSatisfy { $0.matches(argument: $1) }
    XCTAssertTrue(match)
    37


    View Slide

38. let matchers: [Matcher] = [
    EqualTo(Int(42)),
    IdenticalTo(viewController),
    ]
    let arguments: [Any?] = storage.(...)
    // Missing edge cases like different argument count
    let match = zip(matchers, arguments)
    .allSatisfy { $0.matches(argument: $1) }
    XCTAssertTrue(match)
    38


    View Slide

39. Fitting all of this
    together


    View Slide

40. protocol Mock: AnyObject {
    var storage: Storage { get }
    }
    40


    View Slide

41. extension Mock {
    func recordInvocation(
    withIdentifier callIdentifier: String,
    arguments: [Any?]?
    ) {
    storage.recordInvocation(
    withIdentifier: callIdentifier,
    arguments: arguments
    )
    }
    }
    41


    View Slide

42. extension Mock {
    func verifyInvocation(
    withIdentifier callIdentifier: String,
    arguments: [Matcher?]?
    ) {
    let invocations = storage.filter {
    $0.identifier == callIdentifier
    }
    let candidate = invocations.first { match(
    arguments: $0.arguments,
    matchers: arguments
    ) }
    if candidate == nil { XCTFail() }
    }
    }
    42


    View Slide

43. extension Mock {
    func verifyInvocation(
    withIdentifier callIdentifier: String,
    arguments: [Matcher?]?
    ) {
    let invocations = storage.filter {
    $0.identifier == callIdentifier
    }
    let candidate = invocations.first { match(
    arguments: $0.arguments,
    matchers: arguments
    ) }
    if candidate == nil { XCTFail() }
    }
    }
    43


    View Slide

44. extension Mock {
    func verifyInvocation(
    withIdentifier callIdentifier: String,
    arguments: [Matcher?]?
    ) {
    let invocations = storage.filter {
    $0.identifier == callIdentifier
    }
    let candidate = invocations.first { match(
    arguments: $0.arguments,
    matchers: arguments
    ) }
    if candidate == nil { XCTFail() }
    }
    }
    44


    View Slide

45. extension Mock {
    func verifyInvocation(
    withIdentifier callIdentifier: String,
    arguments: [Matcher?]?
    ) {
    let invocations = storage.filter {
    $0.identifier == callIdentifier
    }
    let candidate = invocations.first { match(
    arguments: $0.arguments,
    matchers: arguments
    ) }
    if candidate == nil { XCTFail() }
    }
    }
    45


    View Slide

46. extension StorageMockArgumentFoo: Mock {
    func verifyBar(_ arg1: Matcher?, _ arg2: Matcher?) {
    verifyInvocation(
    withIdentifier: "bar",
    arguments: [arg1, arg2]
    )
    }
    }
    storageMockArgumentFoo.verifyBar(
    EqualtTo(Int(52)),
    IdenticalTo(someViewController)
    )
    46


    View Slide

47. Mimus
    is born
    https://github.com/mimus-swift/Mimus 47


    View Slide

48. The good
    » Reusable matcher logic shared across different
    test suites
    » Unified framework for writing mocks
    48


    View Slide

49. The ugly
    49


    View Slide

50. A lot of
    manual
    work
    50


    View Slide

51. One thing we all
    programmers
    love is...
    51


    View Slide

52. Automation
    52


    View Slide

53. class StorageMockArgumentFoo: Mock {
    let storage: Storage = Storage()
    func bar(arg1: Int, arg2: UIViewController) {
    recordInvocation(
    withIdentifier: "bar",
    arguments: [arg1, arg2]
    )
    }
    func verifyBar(_ arg1: Matcher?, _ arg2: Matcher?) {
    verifyInvocation(
    withIdentifier: "bar",
    arguments: [arg1, arg2]
    )
    }
    }
    53


    View Slide

54. Enter
    Sourcery
    54


    View Slide

55. “Sourcery is a code generator
    for Swift language, built on
    top of Apple's own
    SwiftSyntax. It extends the
    language abstractions to
    allow you to generate
    boilerplate code
    automatically.”
    Krzysztf Zablocki
    55


    View Slide

56. // sourcery: automockable
    protocol ArgumentFoo {
    func bar(arg1: Int, arg2: UIViewController)
    }
    56


    View Slide

57. class GeneratedMockArgumentFoo: ArgumentFoo, Mock {
    let storage: Storage = Storage()
    func bar(arg1: Int, arg2: UIViewController) {
    recordInvocation(withIdentifier: "barArg1Arg2", arguments: [arg1, arg2])
    }
    class InstanceVerifier: Verifier {
    func bar(arg1: Matcher?, arg2: Matcher?) {
    mock.verifyInvocation(
    withIdentifier: "barArg1Arg2",
    arguments: [arg1, arg2]
    )
    }
    }
    func verify() -> InstanceVerifier {
    return InstanceVerifier(mock: self)
    }
    }
    57


    View Slide

58. class GeneratedMockArgumentFoo: ArgumentFoo, Mock {
    let storage: Storage = Storage()
    func bar(arg1: Int, arg2: UIViewController) {
    recordInvocation(withIdentifier: "barArg1Arg2", arguments: [arg1, arg2])
    }
    class InstanceVerifier: Verifier {
    func bar(arg1: Matcher?, arg2: Matcher?) {
    mock.verifyInvocation(
    withIdentifier: "barArg1Arg2",
    arguments: [arg1, arg2]
    )
    }
    }
    func verify() -> InstanceVerifier {
    return InstanceVerifier(mock: self)
    }
    }
    58


    View Slide

59. class GeneratedMockArgumentFoo: ArgumentFoo, Mock {
    let storage: Storage = Storage()
    func bar(arg1: Int, arg2: UIViewController) {
    recordInvocation(withIdentifier: "barArg1Arg2", arguments: [arg1, arg2])
    }
    class InstanceVerifier: Verifier {
    func bar(arg1: Matcher?, arg2: Matcher?) {
    mock.verifyInvocation(
    withIdentifier: "barArg1Arg2",
    arguments: [arg1, arg2]
    )
    }
    }
    func verify() -> InstanceVerifier {
    return InstanceVerifier(mock: self)
    }
    }
    59


    View Slide

60. let mock = GeneratedMockArgumentFoo()
    (...)
    mock.verify().bar(
    arg1: EqualTo(Int(10)),
    arg2: IdenticalTo(someViewController)
    )
    60


    View Slide

61. Mimus
    +
    Sourcery
    =
    ❤
    61


    View Slide

62. func verify(
    mode: VerificationMode = .times(1),
    file: StaticString = #file,
    line: UInt = #line
    ) -> InstanceVerifier {
    return InstanceVerifier(mock: self, mode: mode, file: file, line: line)
    }
    public enum VerificationMode {
    case never
    case atLeast(Int)
    case atMost(Int)
    case times(Int)
    }
    62


    View Slide

63. let mock = GeneratedMockArgumentFoo()
    (...)
    mock.verify(mode: .atLeast(1)).bar(
    arg1: AnyMatcher(),
    arg2: IdenticalTo(viewController)
    )
    63


    View Slide

64. Mimus Stencil also offers
    » Functions with return values1
    » Throwing functions1
    » Vars
    1 Currently fairly basic implementation, more advanced usage is in the works
    64


    View Slide

65. That's all
    folks!
    65


    View Slide

66. Other Notable Frameworks
    » SwiftMockGeneratorForXcode
    » Parrot
    » SwiftMock
    » SwiftyMocky
    » Cuckoo
    66


    View Slide

67. Useful links
    » https://github.com/paweldudek/good-tdd-stuff
    » https://github.com/mimus-swift/Mimus
    » https://speakerdeck.com/paweldudek/swift-mocks
    67


    View Slide
