1. ONE PAGE TO TEST THEM ALL ! Priti Biyani | @pritibiyani
 GTR 2016 1 A Cross platform mobile automation framework

2. U.S. AIRLINE MOBILE APP ๏ iOS, Android, iPad, Blackberry, Windows and Mobile Web

 ๏ Apple Appstore featured app (Travel)
 2
3. U.S. AIRLINE MOBILE APP 3
4. AUTOMATION ๏ Android
 Calabash Android
 ๏ iOS
 Calabash iOS ๏ Mobile Web
 Watir Webdriver
 4
5. 5 SOME GROUND RULES FOR AUTOMATION?
6. WE SHOULD REMEMBER… ! ๏ Easy to add tests.
 ๏ Allow Reuse of the code.
 ๏ Promote high level thinking.
 ๏ Simple to accommodate changes in framework
 ๏ Keep it simple.
 ๏ Keep it simple. 6
7. AUTOMATION PATTERN 7
8. PROBLEM STATEMENT 8
 Create a generic automation framework which could support each of the
 three UI automation tools and work seamlessly across both native and
 hybrid UI screens
9. 9 Feature File
 ———————
 Given ..
 When ..
 Then .. Step
 Definitions Android
 Pages iOS
 pages web
 pages PAGE OBJECT MODEL
10. SOLUTION ANALYSIS ๏ ADDING NEW AUTOMATION?
 ๏ CODE REUSABILITY?
 ๏ MAKE CHANGE AT ONLY ONE PLACE? ๏ CLASS EXPLOSION


 10
11. 11 Feature File
 ———————
 Given ..
 When ..
 Then .. Step
 Definitions Single
 Page
 for each
 Platform COMMON PAGE OBJECT
12. SOLUTION ANALYSIS ๏ ADDING NEW AUTOMATION?
 ๏ CODE REUSABILITY ?
 ๏ MAKE CHANGE AT ONLY ONE PLACE ? ๏ CLASS EXPLOSION


 12
13. 13 COMMON PAGE OBJECT — CONCERNS Single
 Page
 for each
 Platform Automation Tools Calabash droid Calabash iOS Watir Different UI actions touch click Locators Navigation Patterns Nav Drawer Menu Bar Tab Bar
14. OBJECT MODELING Lets try and do a Object Modeling exercise! Single page object class
 ➡ What are the key fields? ➡ What’s the key behavior? 14
15. PAGE IDENTIFIER 15 Page Name : String
 Id : Map Identify each page uniquely on the device
 {
 :web => "'#login_form'",
 :ios => "label marked:'LoginPageHeaderLabel'",
 :droid => "* id:'title_login'"
 }
16. ID EXISTS CHECK 16
 def exists?
 case platform
 when ANDROID
 query(ui_query).empty?
 when IOS
 query(ui_query).empty?
 when WEB
 Browser.element(:css => locator).present?
 end end

17. DRIVER ABSTRACTION 17 Page Name : String
 Id : PageId PageId Field : Map
 exists? ()
 PageId Driver Platform : droid
 exists? ()
 Driver Platform: ios exists? ()
 Driver Platform: web
 exists? ()
 def exists?(id_map) # ----- # DROID SPECIFIC CODE # ----- end
 def exists?(id_map) # ----- # iOS SPECIFIC CODE # ----- end def exists?(id_map) # ----- # web SPECIFIC CODE # ----- end

18. 18 COMMON PAGE OBJECT — CONCERNS Single
 Page
 for each
 Platform Automation Tools Calabash droid Calabash iOS Watir Different UI actions touch click Locators Navigation Patterns Nav Drawer Menu Bar Tab Bar
19. ELEMENTS 19 Page Name : String
 Id : PageId
 Elements
 Element.new({
 :web => ‘#save_and_continue_button’,
 :ios => "navigationButton marked:'DONE'",
 :droid => "* marked:'Done'"
 }
 Element Id: Map
 click () 19 def click
 case platform
 when ANDROID
 touch(query(locator))
 when IOS
 touch(query(locator))
 when WEB
 Browser.element(:css => locator).click()
 end end

20. ELEMENTS DELEGATE TO DRIVER 20 Page Name : String
 Id : Map Elements Element Id : Map
 Driver : Driver click() 20 Driver Platform: droid
 exists?
 click()
 Driver Platform: ios exists?
 click()
 def click(id_map)
 # ----- # DROID SPECIFIC CODE # ----- end
 def click(id_map)
 # ----- # iOS SPECIFIC CODE # ----- end
 def click(id_map)
 # ----- # WEB SPECIFIC CODE # ----- Driver Platform: web
 exists? click()
21. MORE ELEMENTS 21 Page Name : String
 Id : PageId
 Element 1: Element Element 2: Element …. 21 Driver Platform : droid
 exists?
 click()
 setText()
 getText()
 checked()

 Textbox setText()
 getText() id : map Checkbox checked?()
 check(item) id : map Dropdown select(item)
 id : map Driver Platform : ios
 exists?
 click()
 setText()
 getText()
 checked()

 Driver Platform : web
 exists?
 click()
 setText()
 getText()
 checked()

 Element Id : Map
 Driver : Driver exists? ()

22. 22 COMMON PAGE OBJECT — CONCERNS Single
 Page
 for each
 Platform Automation Tools Calabash droid Calabash iOS Watir Different UI actions touch click Locators Navigation Patterns Nav Drawer Menu Bar Tab Bar
23. 23 Feature File
 ———————
 Given ..
 When ..
 Then .. Step
 Definitions ONE PAGE OBJECT MODEL page page.service element.ui_interaction Driver
24. PAGE TRANSITION 24 24 Login Home Page def proceed
 click_login_button
 wait_for_user_page_to_load
 return HomePage.new
 end [ success ]
 def <action>
 click_button
 wait_for_<next_page>_to_load
 return <NextPage.new>
 end
25. TRANSITION MODELING 1. driver.click ๏ Driver should be responsible only for UI interaction. ๏ Driver should not know about higher level abstraction Page.
 2. element.click ๏ It will not be applicable to all elements.
 3. Transition Aware Element ➡ An element that understands page transitions. 25
26. TRANSITION ELEMENT 26 Page Name : String
 Id : PageId
 Elements Element 26 Driver Platform: droid
 exists?
 click()
 setText()
 getText()
 checked()

 Textbox setText()
 getText() id : map Checkbox checked?()
 check(item) id : map Dropdown select(item)
 id : map Id : Map
 Driver : Driver Driver Platform: ios
 exists?
 click()
 setText()
 getText()
 checked()

 Driver Platform: web
 exists?
 click()
 setText()
 getText()
 checked()

 exists? ()
 TransitionElement click(item)
 id : map
27. TRANSITION ELEMENT 27 @login_button = TransitionElement.new(
 {
 :web => '#continue_button',
 :ios => "* marked:'Login'",
 :droid => "* marked:'Login'"
 },
 {
 :to => HomePage,
 }
 )

 Next Page Class
28. TRANSITION ELEMENT - MULTIPLE TRANSITION 28 28 Login Admin Home Page Member Home Page userType? Adm in M em ber [success]
29. TRANSITION ELEMENT - MULTIPLE TRANSITION @login_button = TransitionElement.new(
 {
 :web => '#continue_button',
 :ios => "* marked:'Login'",
 :droid => "* marked:'Login'"
 },
 {
 :to => [AdminPage, UserPage],

 }
 )

 Multiple Transition
30. TRANSITION ELEMENT - ERROR TRANSITION Login Admin Home Page Member Home Page userType? Adm in [ SUCCESS ] [ FAIL ] M em ber
31. TRANSITION ELEMENT - ERROR TRANSITION @login_button = TransitionElement.new(
 {
 :web => '#continue_button',
 :ios => "* marked:'Login'",
 :droid => "* marked:'Login'"
 },
 {
 :to => [AdminPage, UserPage],
 :error => Login
 }
 )

 Error Representation
32. MULTIPLE TRANSITIONS - WRONG TRANSITION ‣ Scenario: If there is a bug in code, app transitions to wrong page from list of multiple transitions.


 ➡ Tests should take care for assertions of correct page, not the framework.


33. TRANSITION ELEMENT 33 def wait_till_next_page_loads(next_pages, error_page)

 has_error, found_next_page = false, false

 begin
 wait_for_element(timeout: 30) do
 found_next_page = next_pages.any? { |page| page.current_page?}
 has_error = error_page.has_error? if error_page
 found_next_page or has_error
 end
 has_error ? error_page : next_pages.find { |page| page.current_page?}

 rescue WaitTimeoutError
 raise WaitTimeoutError, "None of the next page transitions were found.”
 end

 end


34. 34 DEMO
35. 35 LOOK BACK .. Feature File
 ———————
 Given ..
 When ..
 Then .. Step
 Definitions page page.service element.ui_interaction Driver
36. IMPLEMENTATION NOTES ‣ We "require" specific driver class during test execution.
 ‣ Page registry, can be queried for page object instances. ‣ PageRegistry.get "Login Page”
 ‣ Rspec Unit Tests ‣ Rake task to create new page classes. 36
37. LEARNINGS ‣ QA/Dev Pairing
 ‣ Use case driven development
 ‣ Evolution 37
38. SUMMARY ๏ Good OO design is the key
 ๏ Good abstractions can help solve hard problems 38
39. CONCLUSION 39
 Today, to add automation to support new feature development across the three different platforms requires changes in just one place.
40. LINKS TO CODE SAMPLES 1. Github

 https://github.com/CrossPlatformPageObject/cross-platform-single-page- example
 2. Link of the talk given at VodQA Bangalore
 http://pritibiyani.github.io/blog/speaking-at-vodqa-banglore/ 40
41. Priti Biyani @pritibiyani


 https://pritibiyani.github.io/
 THANK YOU
