  1. A Cross platform mobile automation framework
 Created & Presented by,

    Priti Biyani

 http://pritibiyani.github.io/ @pritibiyani ONE PAGE TO TEST THEM ALL
  2. WE SHOULD REMEMBER… ! ๏ Easy to add tests.


    ๏ Allow Reuse of the code.
 ๏ Promote high level thinking.
 ๏ Simple to accommodate changes in framework
 ๏ Keep it simple. 2
  3. U.S. AIRLINE MOBILE APP ๏ iOS, Android, iPad, Blackberry, Windows

    and Mobile Web

 ๏ Apple Appstore featured app (Travel)
 4
  4. CALATRAVA Custom open source cross platform javascript framework - Calatrava.

    https://github.com/calatrava/calatrava ‣ Pure native screens ‣ Pure HTML ‣ HTML + Native widgets ‣ Native + HTML Webviews 6
  5. AUTOMATION ๏ Android
 Calabash Android
 ๏ iOS


    Calabash iOS ๏ Mobile Web
 Watir Webdriver
 7
  6. PROBLEM STATEMENT 8
 Create a generic automation framework which

    could support each of the
 three UI automation tools and work seamlessly across both native and
 hybrid UI screens
  7. 9 Feature File
 ———————
 Given ..
 When ..


    Then .. Step
 Definitions Android
 Pages iOS
 pages web
 pages PAGE OBJECT MODEL
  8. SOLUTION ANALYSIS ๏ ADDING NEW AUTOMATION?
 ๏ CODE REUSABILITY?


    ๏ MAKE CHANGE AT ONLY ONE PLACE? ๏ CLASS EXPLOSION


 10
  9. 11 Feature File
 ———————
 Given ..
 When ..


    Then .. Step
 Definitions Single
 Page
 for each
 Platform COMMON PAGE OBJECT
  10. SOLUTION ANALYSIS ๏ ADDING NEW AUTOMATION?
 ๏ CODE REUSABILITY ?


    ๏ MAKE CHANGE AT ONLY ONE PLACE ? ๏ CLASS EXPLOSION


 12
  11. 13 COMMON PAGE OBJECT — CONCERNS Single
 Page
 for

    each
 Platform Automation Tools Calabash droid Calabash iOS Watir Different UI actions touch click Locators Navigation Patterns Nav Drawer Menu Bar Tab Bar
  12. OBJECT MODELING Lets try and do a Object Modeling exercise!

    Single page object class
 ➡ What are the key fields? ➡ What’s the key behavior? 14
  13. PAGE IDENTIFIER 15 Page Name : String
 Id : Map

    Identify each page uniquely on the device
 {
 :web => "//div[@id='payment_info']",
 :ios => "all webView css:'#payment_info'",
 :droid => "all webView css:'#payment_info'"
 }
  14. PAGE ID CLASS 16 PageId Id : Map
 exists? ()

    Check if locator specified by id exists on the UI Calabash Android and IOS:
 query(locator).empty?


 Mobile Web (Watir):

 Browser.element(:css => locator).present?
  15. ID EXISTS CHECK 17
 def exists?
 case platform
 when

    ANDROID
 query(ui_query).empty?
 when IOS
 query(ui_query).empty?
 when WEB
 Browser.element(:css => locator).present?
 end end

  16. DRIVER ABSTRACTION 18 Page Name : String
 Id : PageId

    PageId Field : Map
 exists? ()
 PageId Driver Platform : droid
 exists? ()
 Driver Platform: ios exists? ()
 Driver Platform: web
 exists? ()
 def exists?(id_map) # ----- # DROID SPECIFIC CODE # ----- end
 def exists?(id_map) # ----- # iOS SPECIFIC CODE # ----- end def exists?(id_map) # ----- # web SPECIFIC CODE # ----- end

  17. 19 COMMON PAGE OBJECT — CONCERNS Single
 Page
 for

    each
 Platform Automation Tools Calabash droid Calabash iOS Watir Different UI actions touch click Locators Navigation Patterns Nav Drawer Menu Bar Tab Bar
  18. ELEMENTS 20 Page Name : String
 Id : PageId
 Elements


 Element.new({
 :web => ‘#save_and_continue_button’,
 :ios => "navigationButton marked:'DONE'",
 :droid => "* marked:'Done'"
 }
 Element Id: Map
 click () 20 def click
 case platform
 when ANDROID
 touch(query(locator))
 when IOS
 touch(query(locator))
 when WEB
 Browser.element(:css => locator).click()
 end end

  19. ELEMENTS DELEGATE TO DRIVER 21 Page Name : String
 Id

    : Map Elements Element Id : Map
 Driver : Driver click() 21 Driver Platform: droid
 exists?
 click()
 Driver Platform: ios exists?
 click()
 def click(id_map)
 # ----- # DROID SPECIFIC CODE # ----- end
 def click(id_map)
 # ----- # iOS SPECIFIC CODE # ----- end
 def click(id_map)
 # ----- # WEB SPECIFIC CODE # ----- Driver Platform: web
 exists? click()
  20. MORE ELEMENTS 22 Page Name : String
 Id : PageId


    Element 1: Element Element 2: Element …. 22 Driver Platform : droid
 exists?
 click()
 setText()
 getText()
 checked()

 Textbox setText()
 getText() id : map Checkbox checked?()
 check(item) id : map Dropdown select(item)
 id : map Driver Platform : ios
 exists?
 click()
 setText()
 getText()
 checked()

 Driver Platform : web
 exists?
 click()
 setText()
 getText()
 checked()

 Element Id : Map
 Driver : Driver exists? ()

  21. 23 COMMON PAGE OBJECT — CONCERNS Single
 Page
 for

    each
 Platform Automation Tools Calabash droid Calabash iOS Watir Different UI actions touch click Locators Navigation Patterns Nav Drawer Menu Bar Tab Bar
  22. 24 Feature File
 ———————
 Given ..
 When ..


    Then .. Step
 Definitions PAGE OBJECT MODEL page page.service element.ui_interaction Driver
  23. PAGE TRANSITION 25 25 Login Home def login
 click_login_button
 wait_for_home_page_to_load


    return HomePage.new
 end [ success ]
 def <action>
 click_button
 wait_for_<next_page>_to_load
 return <NextPage.new>
 end
  24. TRANSITION MODELING 1. driver.click ๏ Driver should be responsible only

    for UI interaction. ๏ Driver should not know about higher level abstraction Page.
 2. element.click ๏ It will not be applicable to all elements.
 3. Transition Aware Element ➡ An element that understands page transitions. 26
  25. TRANSITION ELEMENT 27 Page Name : String
 Id : PageId


    Elements Element 27 Driver Platform: droid
 exists?
 click()
 setText()
 getText()
 checked()

 Textbox setText()
 getText() id : map Checkbox checked?()
 check(item) id : map Dropdown select(item)
 id : map Id : Map
 Driver : Driver Driver Platform: ios
 exists?
 click()
 setText()
 getText()
 checked()

 Driver Platform: web
 exists?
 click()
 setText()
 getText()
 checked()

 exists? ()
 TransitionElement click(item)
 id : map
  26. TRANSITION ELEMENT 28 @login_button = TransitionElement.new(
 {
 :web =>

    '#continue_button',
 :ios => "* marked:'Login'",
 :droid => "* marked:'Login'"
 },
 {
 :to => HomePage,
 }
 )

 Next Page Class
  27. TRANSITION ELEMENT - MULTIPLE TRANSITION 29 29 Login Admin Home

    Page Member Home Page userType? Adm in M em ber [success]
  28. TRANSITION ELEMENT - MULTIPLE TRANSITION @login_button = TransitionElement.new(
 {


    :web => '#continue_button',
 :ios => "* marked:'Login'",
 :droid => "* marked:'Login'"
 },
 {
 :to => [AdminPage, UserPage],

 }
 )
 Multiple Transition
  29. TRANSITION ELEMENT - ERROR TRANSITION Login Admin Home Page Member

    Home Page userType? Adm in [ SUCCESS ] [ FAIL ] M em ber
  30. TRANSITION ELEMENT - ERROR TRANSITION @login_button = TransitionElement.new(
 {


    :web => '#continue_button',
 :ios => "* marked:'Login'",
 :droid => "* marked:'Login'"
 },
 {
 :to => [AdminPage, UserPage],
 :error => Login
 }
 )

 Error Representation
  31. MULTIPLE TRANSITIONS - WRONG TRANSITION ‣ Scenario: If there is

    a bug in code, app transitions to wrong page from list of multiple transitions.


 ➡ Tests should take care for assertions of correct page, not the framework.


  32. TRANSITION ELEMENT 34 def wait_till_next_page_loads(next_pages, error_page)

 has_error, found_next_page =

    false, false

 begin
 wait_for_element(timeout: 30) do
 found_next_page = next_pages.any? { |page| page.current_page?}
 has_error = error_page.has_error? if error_page
 found_next_page or has_error
 end
 has_error ? error_page : next_pages.find { |page| page.current_page?}
 rescue WaitTimeoutError
 raise WaitTimeoutError, "None of the next page transitions were found. Checked for: => #{next_page_transitions.join(' ,')}"
 end
 end



  33. 35 COMMON PAGE OBJECT — CONCERNS Single
 Page
 for

    each
 Platform Automation Tools Calabash droid Calabash iOS Watir Different UI actions touch click Locators Navigation Patterns Nav Drawer Menu Bar Tab Bar
  34. IMPLEMENTATION NOTES ‣ We "require" specific driver class during test

    execution.
 ‣ Page registry, can be queried for page object instances. ‣ PageRegistry.get "Login Page”
 ‣ Rspec Unit Tests ‣ Rake task to create new page classes. 36
  35. SUMMARY ๏ Good OO design is the key
 ๏

    Good abstractions can help solve hard problems 38
  36. CONCLUSION 39
 Today, to add automation to support new

    feature development across the three different platforms requires changes in just one place.
  37. LINKS TO CODE SAMPLES 1. Github

 https://github.com/pritibiyani/cross-platform-single-page-example
 2.

    Link of the talk given at VodQA Bangalore

 http://pritibiyani.github.io/blog/speaking-at-vodqa-banglore/ 40
  38. Reach out to us at Priti Biyani @pritibiyani




    http://pritibiyani.github.io/
 THANK YOU
