Ur/Web: lightning fast prototyping for the web

Ur/Web Vlad Ki @darkproger lightning fast prototyping for the web

Stuff you have to do sometimes: web apps

Stuff you sometimes have to do in web apps: tons
of forms and validation

Runtime errors on typos

Rather have ugly type errors early than fancy runtime errors
late

Want types out of the box haskell-servant/servant

protobuf.load("awesome.proto", function(err, root) { if (err) throw err; // Obtain
a message type var AwesomeMessage = root.lookupType("awesomepackage.AwesomeMessage"); // Exemplary payload var payload = { awesomeField: "AwesomeString" }; // Verify the payload if necessary (i.e. when possibly incomplete or invalid) var errMsg = AwesomeMessage.verify(payload); if (errMsg) throw Error(errMsg); // Create a new message var message = AwesomeMessage.create(payload); // or use .fromObject if conversion is necessary // Encode a message to an Uint8Array (browser) or Buffer (node) var buffer = AwesomeMessage.encode(message).finish(); // ... do something with buffer // Decode an Uint8Array (browser) or Buffer (node) to a message var message = AwesomeMessage.decode(buffer); // ... do something with message // If the application uses length-delimited buffers, there is also encodeDelimited and decodeDelimited. // Maybe convert the message back to a plain object var object = AwesomeMessage.toObject(message, { longs: String, enums: String, bytes: String, // see ConversionOptions }); });

protobuf.load("awesome.proto", function(err, root) { if (err) throw err; // Obtain
a message type var AwesomeMessage = root.lookupType("awesomepackage.AwesomeMessage"); // Exemplary payload var payload = { awesomeField: "AwesomeString" }; // Verify the payload if necessary (i.e. when possibly incomplete or invalid) var errMsg = AwesomeMessage.verify(payload); if (errMsg) throw Error(errMsg); // Create a new message var message = AwesomeMessage.create(payload); // or use .fromObject if conversion is necessary // Encode a message to an Uint8Array (browser) or Buffer (node) var buffer = AwesomeMessage.encode(message).finish(); // ... do something with buffer // Decode an Uint8Array (browser) or Buffer (node) to a message var message = AwesomeMessage.decode(buffer); // ... do something with message // If the application uses length-delimited buffers, there is also encodeDelimited and decodeDelimited. // Maybe convert the message back to a plain object var object = AwesomeMessage.toObject(message, { longs: String, enums: String, bytes: String, // see ConversionOptions }); }); Want to avoid encoding/decoding values all over the place google/protobuf

{-# LANGUAGE DeriveGeneric, DeriveAnyClass #-} module Db where import Elm
import GHC.Generics data Person = Person { id :: Int , name :: Maybe String } deriving (Show, Eq, Generic, ElmType) import Data.Proxy import Db import Elm spec :: Spec spec = Spec ["Db", "Types"] [ "import Json.Decode exposing (..)" , "import Json.Decode.Pipeline exposing (..)" , toElmTypeSource (Proxy :: Proxy Person) , toElmDecoderSource (Proxy :: Proxy Person) ] main :: IO () main = specsToDir [spec] "some/where/output" Or write typing glue every time krisajenkins/elm-export

<body> <textarea id="chat-log" cols="100" rows="20"></textarea><br/> <input id="chat-message-input" type="text" size="100"/><br/> <input
id="chat-message-submit" type="button" value="Send"/> </body> <script> var roomName = {{ room_name_json }}; var chatSocket = new WebSocket( 'ws://' + window.location.host + '/ws/chat/' + roomName + '/'); chatSocket.onmessage = function(e) { var data = JSON.parse(e.data); var message = data['message']; document.querySelector('#chat-log').value += (message + '\n'); }; chatSocket.onclose = function(e) { console.error('Chat socket closed unexpectedly'); }; </script>

<body> <textarea id="chat-log" cols="100" rows="20"></textarea><br/> <input id="chat-message-input" type="text" size="100"/><br/> <input
id="chat-message-submit" type="button" value="Send"/> </body> <script> var roomName = {{ room_name_json }}; var chatSocket = new WebSocket( 'ws://' + window.location.host + '/ws/chat/' + roomName + '/'); chatSocket.onmessage = function(e) { var data = JSON.parse(e.data); var message = data['message']; document.querySelector('#chat-log').value += (message + '\n'); }; chatSocket.onclose = function(e) { console.error('Chat socket closed unexpectedly'); }; </script> Stuff you hate doing in a web app: serialization, APIs and URLs

Let's try something else

N2O: a Nitrogen fork that lets you avoid JavaScript

Pretty much everything is Erlang process-like and records are everywhere

But you still need a full-time frontend hacker synrc/n2o

Shout out to Pyjamas

Not Contenders Elm / PureScript / Fable Python in the
Browser Everything that "shares code"

Contenders meteor.js Ocsigen / Eliom Ur/Web

Ur/Web

The language part http:/ /www.impredicative.com/ur/tutorial/

The Language Almost like SML Fun with declaration ordering and
mutual recursion ML modules and functors “header” files Compiler generates JS for you as well C and JS FFI, SQL and XML is sugar No REPL :D

fun id [a] (x : a) : a = x
fun compose [a] [b] [c] (f : b -> c) (g : a -> b) (x : a) : c = f (g x) “-XUndecidableInstances”: type inference is undecidable by default so watch out

fun mp [a] [b] (f : a -> b) :
list a -> list b = let fun loop (ls : list a) = case ls of [] => [] | x :: ls' => f x :: loop ls' in loop end

datatype tree a = Leaf of a | Node of
tree a * tree a fun size [a] (t : tree a) : int = case t of Leaf _ => 1 | Node (t1, t2) => size t1 + size t2

signature S = sig val client_id : string val client_secret
: string val https : bool val onLogin : profile -> transaction page end Module signatures

functor Make(M : S) : sig val authorize : transaction
page val whoami : transaction (option string) val loadProfile : string -> transaction profile val logout : transaction unit end Functors: parametrized modules

val x = { A = 0, B = True
} x.A type somerec = { A : int, B : bool } fun getA (r : somerec) = r.A getA (x -- #A ++ {A = 4}) Row types

val doStuff : transaction page = error <xml>oops</xml> IO =
transaction

#war-room bot: jenkins is down dev: phew, no more tyre
fires dev: can finally have a weekend off dev: make sure nobody brings it back up ¯\_(ツ)_/¯

code: proger/urc

fun main () : transaction page = {User = user,
Header = hdr} <- userHeader; textId <- fresh; text <- source ""; init <- prefetch (); ch <- subscribe; rest <- source <xml/>; received <- source []; let (* ... *) in return (Def.page "Urc" hdr (onload ()) <xml> <section> <h2>chatroom</h2> <div> <ctextbox id={textId} source={text} /> <button value="Send" onclick={fn _ => submit ()} /><br/> </div> </section> <section> <dyn signal={signal rest} /> {init} </section> </xml>) end transaction generates both client and server code

fun main () : transaction page = {User = user,
Header = hdr} <- userHeader; textId <- fresh; text <- source ""; init <- prefetch (); ch <- subscribe; rest <- source <xml/>; received <- source []; let (* ... *) in return (Def.page "Urc" hdr (onload ()) <xml> <section> <h2>chatroom</h2> <div> <ctextbox id={textId} source={text} /> <button value="Send" onclick={fn _ => submit ()} /><br/> </div> </section> <section> <dyn signal={signal rest} /> {init} </section> </xml>) end

fun listen () = s <- recv ch; xs <-
get received; set received (s :: xs); set rest (List.foldr join <xml/> (List.mp format (s :: xs))); listen () and onload () = _ <- reset (); listen () and submit () : transaction unit = message <- get text; time <- now; rpc (publish' {Author = user, Timestamp = time, Message = message}); _ <- reset (); return ()

transaction generates both client and server code No POST, No
GET No URLs No HTTP status codes (200 or 500) Client-to-server (rpc) Server-to-client (channel, signal + source + dyn)

Limited HTTP access Read-write Cookies Read-write Headers

Relax!

% cat test.ur table users : { Bobby: bool, Id:
int }

% urweb -dumpSource -timing test parseJob: 3.14E~4 parse: 1.87E~4 elaborate:
0.601906 unnest: 0.002338 explify: 0.002041 corify: 0.002383 core_untangle: 2.81E~4 shake1: 2.23E~4 especialize1': 1.8E~5 shake1': 3E~6 rpcify: 1.9E~5 core_untangle2: 0 shake2: 2E~6 especialize1: 1E~6 core_untangle3: 0 shake3: 1E~6 tag: 3.3E~5 reduce: 4.4E~5 shakey: 1E~6 unpoly: 1.7E~5 specialize: 1.7E~5 shake4: 1E~6 especialize2: 1E~6 shake4': 1E~6 unpoly2: 1E~6 specialize2: 0 shake4': 0

val spinner : xbody = <xml> <div class="sk_cube-grid"> <div class="sk_cube
sk_cube1"></div> <div class="sk_cube sk_cube2"></div> <div class="sk_cube sk_cube3"></div> <div class="sk_cube sk_cube4"></div> <div class="sk_cube sk_cube5"></div> <div class="sk_cube sk_cube6"></div> <div class="sk_cube sk_cube7"></div> <div class="sk_cube sk_cube8"></div> <div class="sk_cube sk_cube9"></div> </div> </xml>

ok <- oneRowE1 (SELECT COUNT( * ) > 0 FROM
secrets WHERE secrets.Login = {[r.Login]} AND secrets.Secret = {[r.Secret]});

urweb -dumpSource -dumpTypes -stop elaborate test

% urweb -dumpSource -dumpTypes -stop tag test <Test> </Test> con
int :: Type = FFI(Basis.int) con bool :: Type = FFI(Basis.bool) table users as Test_users : [#Bobby = bool, #Id = int] keys FFI(Basis.no_primary_key) [[#Bobby = bool, #Id = int]] constraints FFI(Basis.no_constraint) [[#Bobby = bool, #Id = int]]

Metaprogramming

x metaclasses x generating AST v type-safe functors!

structure Admin = Crud.Make(struct con key = #Login val tab
= GH.users val title = "Authenticated Users" val everything = { Login = Crud.string "Login", AvatarUrl = Crud.string "Avatar URL", Nam = Crud.option_string "Name", (* ... *) } type task_type = {} val runTask = fn _ username => redirect (bless ("https://github.com/" ^ username)) val taskTitle = fn _ => "[Visit]" val allTasks = () :: [] val header = { User = _, Header = hdr } <- userHeader; return hdr end)

uw_Basis_string uw_WorldFfi_post(uw_context ctx, uw_Basis_string url, uw_Basis_string body) { CURL *c
= curl(ctx); curl_easy_reset(c); curl_easy_setopt(c, CURLOPT_POSTFIELDS, body); uw_Basis_string ret = doweb(ctx, c, url, 1); return ret; }

val post : url -> string -> transaction string val
get : url -> option string -> transaction string

Packaging and Deployment

Compiler generates C code Outputs a single binary Configuration is
usually compiled in

{ stdenv, fetchgit, autoreconfHook, curl, urweb }: stdenv.mkDerivation { name
= "urweb-curl"; buildInputs = [ autoreconfHook urweb ]; propagatedBuildInputs = [ curl ]; preConfigure = '' export CFLAGS="-I${urweb}/include/urweb" ''; src = fetchgit { inherit (builtins.fromJSON (builtins.readFile ./urweb-curl.json) ) url rev sha256; }; }

Getting Information

http:/ /www.impredicative.com/ur/demo/

Woot! [email protected]

twitter.com/kievfprog kievfprog.net
