  1. CACHE ME
    IF YOU CAN
    Guillaume Ardaud

    @gardaud | gardaud.fr

    [email protected]
    Friday April 11th

    PyCon2014

    Montreal

    View full-size slide

  2. MEMCACHED
    -What is it?

    -How does it work?

    -Patterns & Best Practices

    View full-size slide

  3. Key/Object Store
    • Give it an object, identified by a key

    • Ask for a key

    • If it isn’t expired, you get the object

    View full-size slide

  4. O(1) EVERYTHING

    View full-size slide

  5. primary data:

    relational database
    data you can lose, regenerate fast:

    RAM store
    data you can lose, regenerate slowly:

    persistent store
    Where does memcached fit?

    View full-size slide

  6. Typical memcached API

    View full-size slide

  7. Key names
    - ASCII based

    - Not crazy long…

    - … but explicit enough

    View full-size slide

  8. Good naming
    e.g.:

    json.users.

    View full-size slide

  9. Bad naming
    e.g.:

    md5(sql_query)

    View full-size slide

  10. HOW DO I LIST ALL KEYS IN
    MEMCACHED?
    YOU DON’T
    (or all keys matching a regex, or all...)

    View full-size slide

  11. it’s a cache

    not a database

    View full-size slide

  12. memcached docs:

    View full-size slide

  13. memcached is distributed

    View full-size slide

  14. your amazing
    application
    memcached
    box A
    memcached
    box B
    memcached
    box C
    memcached client

    View full-size slide

  15. your amazing
    application
    memcached
    box A
    memcached
    box B
    memcached
    box C
    memcached client
    set $KEY
    send $KEY

    to box C
    Received!

    View full-size slide

  16. your amazing
    application
    memcached
    box A
    memcached
    box B
    memcached client
    set $KEY
    send $KEY

    to box A

    View full-size slide

  17. ~ some memcached subtleties ~

    View full-size slide

  18. EXPIRATION
    It’s 8am, a request stores an
    object under the key ‘foo’, with
    a 2 hour expiration time.
    What happens at 10am?

    View full-size slide

  19. But what happens when a client tries to access 'foo'

    at 1pm?
    …'foo' gets removed.
    NOTHING

    View full-size slide

  20. Q: Sometimes
    fetching a key returns
    None even though it’s
    not supposed to have
    expired yet?

    View full-size slide

  21. Memcached has a fixed amount
    of memory."
    If you try to store data when
    memory is full, data will get
    evicted.

    View full-size slide

  22. How does memcached determine what to
    evict?
    Object 1 Object 2
    timestamp:

    1378399504
    timestamp:

    137839983
    Object 3
    timestamp:

    1378399939
    Object 4
    timestamp:

    13783992932
    Object 5
    timestamp:

    13783993829

    View full-size slide

  23. Q: Sometimes fetching a
    key returns None
    even though it’s not
    supposed to have expired
    yet…
    … AND memcached still
    has free memory?

    View full-size slide

  24. page
    1
    page
    2
    page
    3
    page
    4
    page
    5
    page
    6
    page
    7
    ...
    1 page = 1MB

    View full-size slide

  25. page
    chunk
    chunk
    chunk chunk chunk chunk chunk chunk chunk
    chunk chunk chunk chunk chunk chunk chunk
    1st_slab_chunk_size = 80 bytes!
    2nd_slab_chunk_size = 80 * 1.25 = 100 bytes!
    3rd_slab_chunk_size = 100 * 1.25 = 125 bytes!
    . . .!
    last_slab_chunk_size = 1048576 bytes
    Last slab has 1 chunk of 1 MB.

    View full-size slide

  26. page
    1
    page
    2
    page
    3
    page
    4
    page
    5
    page
    6
    page
    7
    ...
    class 1 class 2 class 3 class 4 class 5 free page free page

    View full-size slide

  27. If all pages of the needed class are full:

    get a free page and give it the needed class.
    If there are no more free pages:

    the LRU kicks in and evicts data.
    Each slab class has its own LRU!
    "
    If your data needs class 3 and:

    - there are no free pages

    - all class 3 pages are full

    - some class 4 pages have free chunks

    Data in a class 3 page will still be evicted.

    View full-size slide

  28. Q: Sometimes fetching a
    key returns None
    even though it’s not
    supposed to have expired
    yet…
    … AND memcached still
    has free memory?

    View full-size slide

  29. some useful command line flags
    memcached -v : verbose output (more verbose: -vv)

    memcached -M: doesn’t evict when out of memory, but errors

    "
    memcached -I1k : change slab page size (1k - 128m)

    memcached -I1m!
    memcached -I128m!
    "
    memcached -f1.5 : change growth factor (def. 1.25, >1)

    "
    "
    man memcached is your friend

    View full-size slide

  30. Let’s get our
    hands dirty.
    common memcached patterns &
    practices in Python

    View full-size slide

  31. MODEL VERSIONING

    View full-size slide

  32. FETCH STRAIGHT FROM CACHE

    View full-size slide

  33. THUNDERING HERD

    View full-size slide

  34. CACHING LARGE VALUES

    View full-size slide

  35. 2-PHASE FETCH

    View full-size slide

  36. 1. Break big object in smaller chunks

    (for example chunks of 10 books)
    PAGINATED CACHE
    2. Store each chunk as a separate

    object in memcached
    3. Store the list of keys
    To fetch the data, fetch the list of keys,

    iterate through it, and concatenate all fetched lists.

    View full-size slide

  37. Questions?
    THANKS!

    View full-size slide

  38. Great memcached resources
    Memcached doc:
    http://code.google.com/p/memcached/wiki/NewStart?tm=6

    "
    Especially those 2 pages:
    http://code.google.com/p/memcached/wiki/NewProgrammingTricks

    http://code.google.com/p/memcached/wiki/NewUserInternals

    "
    Various articles/posts about internals etc.:
    http://stackoverflow.com/questions/6868256/memcached-eviction-prior-to-key-
    expiry

    http://www.adayinthelifeof.nl/2011/02/06/memcache-internals/

    http://work.tinou.com/2011/04/memcached-for-dummies.html

    http://returnfoo.com/2012/02/memcached-memory-allocation-and-optimization-2/
