PyCon Ireland 2013: Creating Excel files with Python and XlsxWriter

(via http://python.ie/pycon/2013/talks/creating_excel_files_with_python_and_xlsxwriter/)
Speaker: John McNamara

XlsxWriter is a new Python module for creating Excel 2007+ XLSX files.

It supports a wide range of Excel features such as writing numbers, strings dates, formulas and hyperlinks, full cell formatting, charts, autofilters, tables, images, conditional formatting and much more. It uses standard modules and works with Python 2 and 3.

This talk will introduce the module and show how to quickly generate rich Excel reports.

The talk will also show alternative modules such as Xlwt and OpenPyXL.

See also:

https://xlsxwriter.readthedocs.org
https://github.com/jmcnamara/XlsxWriter
https://pypi.python.org/pypi/XlsxWriter

Transcript

1. Creating Excel files with Python and XlsxWriter John McNamara Emutex Ltd
2. whoami John McNamara Software developer at Emutex Ltd http://www.emutex.com http://github.com/jmcnamara
3. Why Excel • Bosses like it • Useful as a data source • More useful with formatting • Input/output source for Pandas • Can be misused: Excel as a database
4. Available Python modules • csv.py Readers and writers in core libs • xlwt/xlrd Mature, stable modules, mainly XLS support • openpyxl Reads and writes XLSX files • xlsxwriter New module from early 2013
5. Excel 2003 : xls Excel 2007 : xlsx Excel File Formats xlwt openpyxl xlsxwriter xlrd Read Write
6. XlsxWriter • Write Excel XLSX files only • Doesn’t read or re-write Excel files • Adds many new features • Uses core modules only • Python 2.5, 2.6, 2.7, 3.1, 3.2, 3.3, PyPy, Jython
7. Why another module • Why not? • Other modules support some but not all features • XlsxWriter adds support for: charts, autofilters, tables, data validation, merged cells, rich text, conditional formatting, defined names, images, cell comments, sparklines, outlines
8. Getting Started • Install: $ sudo pip install xlsxwriter • Clone or fork: $ git clone git@github.com:jmcnamara/XlsxWriter.git $ cd XlsxWriter $ make test $ sudo python setup.py install • Read: https://xlsxwriter.readthedocs.org
9. Hello World.xlsx
10. Hello World.xlsx import xlsxwriter workbook = xlsxwriter.Workbook('hello_world.xlsx') worksheet = workbook.add_worksheet() worksheet.write(0, 0, 'Hello world') workbook.close()
11. Hello World.xlsx import xlsxwriter workbook = xlsxwriter.Workbook('hello_world.xlsx') worksheet = workbook.add_worksheet() worksheet.write(0, 0, 'Hello world') workbook.close()
12. Hello World.xlsx import xlsxwriter workbook = xlsxwriter.Workbook('hello_world.xlsx') worksheet = workbook.add_worksheet() worksheet.write(0, 0, 'Hello world') worksheet.write(2, 1, 'Hello world') workbook.close()
13. Hello World.xlsx import xlsxwriter workbook = xlsxwriter.Workbook('hello_world.xlsx') worksheet = workbook.add_worksheet() worksheet.write(0, 0, 'Hello world') worksheet.write(2, 1, 'Hello world') worksheet.write('C5', 'Hello world') workbook.close()
14. Cell Formatting
15. Cell Formatting import xlsxwriter workbook = xlsxwriter.Workbook('formatting.xlsx') worksheet = workbook.add_worksheet() italic = workbook.add_format({'italic': True}) bold = workbook.add_format({'bold': True, 'font_color': '#9CB640'}) worksheet.write(0, 0, 'Hello') workbook.close()
16. Cell Formatting import xlsxwriter workbook = xlsxwriter.Workbook('formatting.xlsx') worksheet = workbook.add_worksheet() italic = workbook.add_format({'italic': True}) bold = workbook.add_format({'bold': True, 'font_color': '#9CB640'}) worksheet.write(0, 0, 'Hello') worksheet.write(1, 0, 'Hello', italic) workbook.close()
17. Cell Formatting import xlsxwriter workbook = xlsxwriter.Workbook('formatting.xlsx') worksheet = workbook.add_worksheet() italic = workbook.add_format({'italic': True}) bold = workbook.add_format({'bold': True, 'font_color': '#9CB640'}) worksheet.write(0, 0, 'Hello') worksheet.write(1, 0, 'Hello', italic) worksheet.write(2, 0, 'Hello', bold) workbook.close()
18. Cell Formatting set_font_name() set_font_size() set_font_color() set_bold() set_italic() set_underline() set_font_strikeout() set_font_script() set_num_format() set_locked() set_hidden() set_align() set_center_across() set_text_wrap() set_rotation() set_indent() set_shrink() set_text_justlast() set_pattern() set_bg_color() set_fg_color() set_border() set_bottom() set_top() set_left() set_right() set_border_color() set_bottom_color() set_top_color() set_left_color() set_right_color()
19. Types
20. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') workbook.close()
21. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') workbook.close()
22. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') workbook.close()
23. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') worksheet.write(2, 0, 123) workbook.close()
24. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') worksheet.write(2, 0, 123) worksheet.write(3, 0, 123.456) workbook.close()
25. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') worksheet.write(2, 0, 123) worksheet.write(3, 0, 123.456) worksheet.write(4, 0, date(2013, 10, 13), date_format) workbook.close()
26. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') worksheet.write(2, 0, 123) worksheet.write(3, 0, 123.456) worksheet.write(4, 0, date(2013, 10, 13), date_format) worksheet.write(5, 0, '=PI()') workbook.close()
27. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') worksheet.write(2, 0, 123) worksheet.write(3, 0, 123.456) worksheet.write(4, 0, date(2013, 10, 13), date_format) worksheet.write(5, 0, '=PI()') worksheet.write(6, 0, 'http://python.com') workbook.close()
28. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') worksheet.write(2, 0, 123) worksheet.write(3, 0, 123.456) worksheet.write(4, 0, date(2013, 10, 13), date_format) worksheet.write(5, 0, '=PI()') worksheet.write(6, 0, 'http://python.com') worksheet.write(7, 0, True) workbook.close()
29. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write(0, 0, 'Hello world') worksheet.write(1, 0, 'Это фраза на русском!') worksheet.write(2, 0, 123) worksheet.write(3, 0, 123.456) worksheet.write(4, 0, date(2013, 10, 13), date_format) worksheet.write(5, 0, '=PI()') worksheet.write(6, 0, 'http://python.com') worksheet.write(7, 0, True) workbook.close()
30. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write (0, 0, 'Hello world') worksheet.write (1, 0, 'Это фраза на русском!') worksheet.write (2, 0, 123) worksheet.write (3, 0, 123.456) worksheet.write (4, 0, date(2013, 10, 13), date_format) worksheet.write (5, 0, '=PI()') worksheet.write (6, 0, 'http://python.com') worksheet.write (7, 0, True) workbook.close()
31. Types from datetime import date import xlsxwriter workbook = xlsxwriter.Workbook('types.xlsx') worksheet = workbook.add_worksheet() date_format = workbook.add_format({'num_format': 'd mmm yyyy'}) worksheet.write_string (0, 0, 'Hello world') worksheet.write_string (1, 0, 'Это фраза на русском!') worksheet.write_number (2, 0, 123) worksheet.write_number (3, 0, 123.456) worksheet.write_datetime(4, 0, date(2013, 10, 13), date_format) worksheet.write_formula (5, 0, '=PI()') worksheet.write_url (6, 0, 'http://python.com') worksheet.write_boolean (7, 0, True) workbook.close()
32. Formulas
33. Formulas worksheet.write_formula('A1', '=1+2') worksheet.write_formula('A2', '=A1') worksheet.write_formula('A3', '{=SUM(B1:C1*B2:C2)}') worksheet.write_formula('A4', '=VLOOKUP("Acme", A2:D6, 3, FALSE)')
34. Images
35. Images import xlsxwriter workbook = xlsxwriter.Workbook('image.xlsx') worksheet = workbook.add_worksheet() worksheet.insert_image(0, 0, 'logo.png') workbook.close()
36. Conditional Formatting
37. Conditional Formatting import xlsxwriter wb = xlsxwriter.Workbook('conditional_format.xlsx') ws = wb.add_worksheet() high = wb.add_format({'bg_color': '#FFC7CE', 'font_color': '#9C0006'}) low = wb.add_format({'bg_color': '#C6EFCE', 'font_color': '#006100'}) data = [ [88, 25, 33, 23, 67, 13], [24, 100, 20, 88, 29, 33], [6, 57, 88, 28, 10, 26], [73, 78, 1, 96, 26, 45], [36, 54, 22, 66, 81, 90], ] for row, row_data in enumerate(data): ws.write_row(row, 0, row_data) ws.conditional_format('A1:F5', {'type': 'cell', 'criteria': '>=', 'value': 50, 'format': high}) ws.conditional_format('A1:F5', {'type': 'cell', 'criteria': '<', 'value': 50, 'format': low}) wb.close()
38. Charts
39. Charts Area stacked percent_stacked Bar stacked percent_stacked Column stacked percent_stacked Line Pie Radar with_markers filled Scatter straight_with_markers straight smooth_with_markers smooth Stock
40. Charts import xlsxwriter workbook = xlsxwriter.Workbook('chart.xlsx') worksheet = workbook.add_worksheet() # Add the worksheet data to be plotted. data = [10, 40, 50, 20, 10, 50] worksheet.write_column('A1', data) # Create a new chart object. chart = workbook.add_chart({'type': 'area'}) # Add a series to the chart. chart.add_series({'values': '=Sheet1!$A$1:$A$6'}) # Insert the chart into the worksheet. worksheet.insert_chart('C1', chart) workbook.close()
41. Charts chart = workbook.add_chart({'type': 'area'})
42. Charts chart = workbook.add_chart({'type': 'bar'})
43. Charts chart = workbook.add_chart({'type': 'column'})
44. Charts chart = workbook.add_chart({'type': 'line'})
45. Charts chart = workbook.add_chart({'type': 'pie'})
46. Charts chart = workbook.add_chart({'type': 'radar'})
47. Charts • Configurability
48. Charts Stacked chart with captions
49. Charts Change chart styles
50. Charts Add trendlines to charts
51. Charts Format data points
52. Charts Secondary axes
53. Autofilters
54. Autofilters import xlsxwriter workbook = xlsxwriter.Workbook('autofilter.xlsx') worksheet = workbook.add_worksheet() # Add a format for the headers. header_format = workbook.add_format({'bold': 1, 'bg_color': '#C6EFCE'}) # Populate the worksheet data. # See the xlsxwriter docs for a full example. ... # Make the columns wider. worksheet.set_column('A:D', 12) # Format the header row. worksheet.set_row(0, 20, header_format) # Set the autofilter. worksheet.autofilter('A1:D51') workbook.close()
55. Tables
56. Tables • Group a range of cells into a single entity • Apply a uniform formatting across the cells • Refer to the table in formulas worksheet.add_table('B3:F7', {options})
57. Data Validation
58. Data Validation • Restrict data entry to certain ranges • Raise errors/warning within Excel • Allow selection from drop down lists data_validation( 'B25', {'validate': 'integer', 'criteria': 'between', 'minimum': 1, 'maximum': 10})
59. Cell Comments
60. Cell Comments • Add comments to cells worksheet.write('A1', 'Hello') worksheet.write_comment('A1', 'This is a comment')
61. Sparklines
62. Sparklines • Mini charts within cells to show trends • Invented by Edward Tufte
63. Code All the Things! • Lots of features
64. Code All the Things! • Lots of features • Useful when you need them • Ignore them when you don’t • Plenty of examples and documentation to get you started
65. How does it work
66. How does it work • 20% of a studio audience guessed Witchcraft
67. How does it work • 20% of a studio audience guessed Witchcraft • Actually a collection of XML files in a Zip file • Can be unzipped using standard utilities • Even modified in-place (if you are desperate)
68. How does it work $ unzip -o -d hello_world hello_world.xlsx Archive: hello_world.xlsx inflating: hello_world/[Content_Types].xml inflating: hello_world/_rels/.rels inflating: hello_world/docProps/app.xml inflating: hello_world/docProps/core.xml inflating: hello_world/xl/sharedStrings.xml inflating: hello_world/xl/styles.xml inflating: hello_world/xl/workbook.xml inflating: hello_world/xl/_rels/workbook.xml.rels inflating: hello_world/xl/theme/theme1.xml inflating: hello_world/xl/worksheets/sheet1.xml
69. How does it work $ unzip -o -d hello_world hello_world.xlsx Archive: hello_world.xlsx inflating: hello_world/[Content_Types].xml inflating: hello_world/_rels/.rels inflating: hello_world/docProps/app.xml inflating: hello_world/docProps/core.xml inflating: hello_world/xl/sharedStrings.xml inflating: hello_world/xl/styles.xml inflating: hello_world/xl/workbook.xml inflating: hello_world/xl/_rels/workbook.xml.rels inflating: hello_world/xl/theme/theme1.xml inflating: hello_world/xl/worksheets/sheet1.xml
70. How does it work $ unzip -o -d hello_world hello_world.xlsx Archive: hello_world.xlsx inflating: hello_world/[Content_Types].xml inflating: hello_world/_rels/.rels inflating: hello_world/docProps/app.xml inflating: hello_world/docProps/core.xml inflating: hello_world/xl/sharedStrings.xml inflating: hello_world/xl/styles.xml inflating: hello_world/xl/workbook.xml inflating: hello_world/xl/_rels/workbook.xml.rels inflating: hello_world/xl/theme/theme1.xml inflating: hello_world/xl/worksheets/sheet1.xml
71. How does it work $ unzip -o -d hello_world hello_world.xlsx Archive: hello_world.xlsx inflating: hello_world/[Content_Types].xml inflating: hello_world/_rels/.rels inflating: hello_world/docProps/app.xml inflating: hello_world/docProps/core.xml inflating: hello_world/xl/sharedStrings.xml inflating: hello_world/xl/styles.xml inflating: hello_world/xl/workbook.xml inflating: hello_world/xl/_rels/workbook.xml.rels inflating: hello_world/xl/theme/theme1.xml inflating: hello_world/xl/worksheets/sheet1.xml $ xmllint --format hello_world/xl/worksheets/sheet1.xml
72. How does it work $ unzip -o -d hello_world hello_world.xlsx ... $ xmllint --format hello_world/xl/worksheets/sheet1.xml
73. How does it work $ unzip -o -d hello_world hello_world.xlsx ... $ xmllint --format hello_world/xl/worksheets/sheet1.xml <?xml version="1.0" encoding="UTF-8" standalone="yes"?> <worksheet xmlns="..." xmlns:r="..."> <dimension ref="A1"/> <sheetViews> <sheetView tabSelected="1" workbookViewId="0"/> </sheetViews> <sheetFormatPr defaultRowHeight="15"/> <sheetData> <row r="1" spans="1:1"> <c r="A1" t="s"> <v>0</v> </c> </row> </sheetData> <pageMargins left="0.7" right="0.7" top="0.75" bottom="0.75" header="0.3" footer="0.3"/> </worksheet>
74. How does it work $ unzip -o -d hello_world hello_world.xlsx ... $ xmllint --format hello_world/xl/worksheets/sheet1.xml <?xml version="1.0" encoding="UTF-8" standalone="yes"?> <worksheet xmlns="..." xmlns:r="..."> <dimension ref="A1"/> <sheetViews> <sheetView tabSelected="1" workbookViewId="0"/> </sheetViews> <sheetFormatPr defaultRowHeight="15"/> <sheetData> <row r="1" spans="1:1"> <c r="A1" t="s"> <v>0</v> </c> </row> </sheetData> <pageMargins left="0.7" right="0.7" top="0.75" bottom="0.75" header="0.3" footer="0.3"/> </worksheet>
75. How does it work $ unzip -o -d hello_world hello_world.xlsx ... $ xmllint --format hello_world/xl/worksheets/sheet1.xml <?xml version="1.0" encoding="UTF-8" standalone="yes"?> <worksheet xmlns="..." xmlns:r="..."> <dimension ref="A1"/> <sheetViews> <sheetView tabSelected="1" workbookViewId="0"/> </sheetViews> <sheetFormatPr defaultRowHeight="15"/> <sheetData> <row r="1" spans="1:1"> <c r="A1" t="s"> <v>0</v> </c> </row> </sheetData> <pageMargins left="0.7" right="0.7" top="0.75" bottom="0.75" header="0.3" footer="0.3"/> </worksheet>
76. How does it work $ unzip -o -d hello_world hello_world.xlsx ... $ xmllint --format hello_world/xl/worksheets/sheet1.xml <?xml version="1.0" encoding="UTF-8" standalone="yes"?> <worksheet xmlns="..." xmlns:r="..."> <dimension ref="A1"/> <sheetViews> <sheetView tabSelected="1" workbookViewId="0"/> </sheetViews> <sheetFormatPr defaultRowHeight="15"/> <sheetData> <row r="1" spans="1:1"> <c r="A1" t="s"> <v>0</v> </c> </row> </sheetData> <pageMargins left="0.7" right="0.7" top="0.75" bottom="0.75" header="0.3" footer="0.3"/> </worksheet>
77. How does it work $ unzip -o -d hello_world hello_world.xlsx ... $ xmllint --format hello_world/xl/worksheets/sheet1.xml <?xml version="1.0" encoding="UTF-8" standalone="yes"?> <worksheet xmlns="..." xmlns:r="..."> <dimension ref="A1"/> <sheetViews> <sheetView tabSelected="1" workbookViewId="0"/> </sheetViews> <sheetFormatPr defaultRowHeight="15"/> <sheetData> <row r="1" spans="1:1"> <c r="A1" t="s"> <v>0</v> </c> </row> </sheetData> <pageMargins left="0.7" right="0.7" top="0.75" bottom="0.75" header="0.3" footer="0.3"/> </worksheet>
78. How does it work $ unzip -o -d hello_world hello_world.xlsx ... $ xmllint --format hello_world/xl/worksheets/sheet1.xml <?xml version="1.0" encoding="UTF-8" standalone="yes"?> <worksheet xmlns="..." xmlns:r="..."> <dimension ref="A1"/> <sheetViews> <sheetView tabSelected="1" workbookViewId="0"/> </sheetViews> <sheetFormatPr defaultRowHeight="15"/> <sheetData> <row r="1" spans="1:1"> <c r="A1" t="s"> <v>0</v> </c> </row> </sheetData> <pageMargins left="0.7" right="0.7" top="0.75" bottom="0.75" header="0.3" footer="0.3"/> </worksheet>
79. How does it work • It works well • XlsxWriter does the hard work so you don’t have to
80. close() • Next time you need to write an Excel file with Python try XlsxWriter • Clone it on Github, submit issues, add stars http://github.com/jmcnamara/XlsxWriter • Read the documentation https://xlsxwriter.readthedocs.org PDF tutorial, cookbook and manual
81. Thank You John McNamara Emutex Ltd
