How QCLean Works: Introduction to Browser Extensions

* Introduction to QCLean and browser extensions.
* How to write a simple chrome extension and how QCLean removes suggested pages and posts on Facebook newsfeed.
* How to inject code and override DOM prototype on webpages.

Transcript

1. How QCLean works? Introduction to Browser Extensions @qcl Code & Beer 2015.03.06
3. What is QCLean? • A browser extension/add-on that removing ads, suggested pages and posts on Facebook news feed for Chrome, Firefox, Safari, Opera and IE users. • http://qcl.github.io/QCLean/
4. History • Since 2013.02.28 (2 years old!) • Popular add-on (Firefox) 2013.04.06 • Popular extension (Chrome) 2013.08.21
5. Overview • Support 5 browsers ◦ Chrome/Chromium, Firefox, Safari, Opera, IE • More than 30,000 users over the world. ◦ GC ~30,000 ◦ FF ~8,500 • Donated mainly by Firefox user! ◦ Receive about $24 ◦ Donate NOW!
6. Overview • Rating ◦ ★★★★★ 4.5/5.0 Chrome ◦ ★★★★ 4.0/5.0 Firefox ◦ ★★★★ 4.0/5.0 Opera • Operating System ◦ 93% Windows • Languages ◦ Chrome 74% zh-tw ◦ Firefox 53% en-us
7. About icon
8. Extension/Add-on v.s. Plugin • Extension/Add-on ◦ Extensions are small software programs that can modify and enhance the functionality of the browser. You write them using web technologies such as HTML, JavaScript, and CSS. (Chrome) • Plugin ◦ Plugins are shared libraries that users can install to display content that the application itself can't display natively. (MDN)
9. Extensions • Written by HTML/JavaScript/CSS • chrome://extensions • about://addons
10. Plugins • Written by C/C++, depend on platform ◦ NPAPI, NaCl (Chrome) • chrome://plugins • about://plugins
11. Plugins • NPAPI ◦ PCManX GTK2 on Chrome using NPAPI @qcl, @JeromeWu, 2010
12. Extension developing 101 • Firefox ◦ http://blog.qcl.tw/2013/08/sdkfirefox-add-on.html • Chrome ◦ Create a file named manifest.json ◦ Open your Chrome, go to chrome://extensions ◦ Click Developer Mode ◦ Then import the folder which contains manifest.json
13. manifest.json { “manifest_version” : 2, “name” : “extension_name”, “version” : “version_string” , “description” : “extension_description” ... } • https://developer.chrome.com/extensions/manifest
14. manifest.json (QCLean)
15. Background background: { “script”:[“background.js”] } • It exists for the lifetime of your extension. • Only ONE instance of it at a time. • It can be used to manage some task or state.
16. Permissions • permissions: [“tabs”] • https://developer.chrome.com/extensions/declare_permissions • https://developer.chrome.com/extensions/permission_warnings
17. Content Scripts “content_scripts” : [ { “matches”: [match patterns], “css”: [“kerker.css”], “js”: [“haha.js”], “run_at”: “document_start” } ] • https://developer.chrome.com/extensions/content_scripts
18. Content Scripts • Content scripts are JS that run in the content of web page • Can not use chrome.* API of extension, i18n, runtime, storage • Can not use functions defined by extension page • Can not use functions defined by web page or other content script • Match Pattern ◦ https://developer.chrome.com/extensions/match_patterns
19. Content Script • run_at ◦ doucment_start ▪ Before any other DOM is constructed or any other script is run ◦ doucment_end ▪ After DOM is complete, but before subresources like images and frames have loaded ◦ doucment_idle (defualt) ▪ After window.onload
20. Remove Suggested Pages&Posts • First commit of QCLean
21. Remove Suggested Pages&Posts • What will happen when all posts on your newsfeed use the same class name? ◦ All the posts will be removed :p • Or the class name used by other elements on the page ◦ Those elements will be removed, too :p • Or you can not get Ad elements directly • Select elements that you can identify then try to do something.
22. Remove Suggested Pages&Posts • Select some special elements, try to find the Ad block, then remove it. • If Facebook changes the structure of page, this method will GG • It will run once when page did load. (run_at)
23. Facebook infinite scrolling • When to run the script? ◦ document_start? document_end? document_idle? ◦ setInterval? • When you scrolls down the page, it will load more and more post (and Ads) • Need to find a trigger point to remove Ads!
24. Override the prototype of DOM • Check Ads when appending new elements into the page. • Override the prototype of some DOM ◦ HTMLDivElement.prototype.appendChild ◦ HTMLUlElement.prototype.appendChild
25. Prevent Requesting Ads • Check AJAX requests by overriding XMLHttpRequest.prototype
26. Content Scripts • Can not override the prototype of HTML DOM in web page (directly) • But we can add new element into web page.
27. Override prototype is DANGEROUS
28. MutationObserver • QCLean-Chrome-Experiment https://developer.mozilla.org/en-US/docs/Web/API/MutationObserver
29. ClassName changed frequently • Static classnames list is not enough • I want to build a API for user, it can update classnames list.
30. Some QCLean API • Story API ◦ http://qcl.github.io/QCLean/api/story.js • Line Tagging API ◦ http://qcl.github.io/QCLean/api/lineTagging.js • XHR Cross-origin request issue • Content security policy issue
31. Content Security Policy “content_security_policy” : “policy” • It can not be show on permission warning • CSP works as a black/whitelisting mechanism for resources loaded or executed by your extension. https://developer.chrome.com/extensions/contentSecurityPolicy http://www.html5rocks.com/en/tutorials/security/content-security-policy/
32. Distribute Extensions Cost Review Publish Chrome $5 no directly publish Firefox free optional directly publish Opera free required after review Safari free required unknow*
33. Extension source • Web Store / Addon Center ◦ You don’t need to mantain a update server • Mantain your own update server
34. Update URL update_url : “http://qcl.github.io/QCLean/chrome_update.xml” • Packaging your extension (with key) ◦ extension.crx • Write update XML ◦ https://developer.chrome.com/extensions/autoupdate
35. How others write extensions? • Install the extension • Get the extension’s ID (chrome://extensions) • Go to ◦ ~/Library/Application Support/Google/Chrome/Default/Extensions (mac)
36. QCLean https://github.com/qcl/QCLean
