1. Amazon VPC qrtt1
2. Amazon VPC
 is the networking layer for Amazon EC2 configurable on-demand self-service
3. Old Account With Classic-EC2 & VPC
4. New Account Is VPC only
5. Scenarios for Amazon VPC • Scenario 1: VPC with a Public Subnet Only ! ! ! ! commons
6. Scenarios for Amazon VPC • Scenario 2: VPC with Public and Private Subnets ! ! ! ! commons
7. Scenarios for Amazon VPC • Scenario 3: VPC with Public and Private Subnets and Hardware VPN Access ! ! ! ! commons
8. Scenarios for Amazon VPC • Scenario 4: VPC with a Private Subnet Only and Hardware VPN Access Your VPC and Subnets ! ! ! ! commons
9. Default VPC commons
10. Default VPC commons • When
11. VPC the container for other sub elements define the max range for subnets by CIDR block 10.0.0.0/16 ~ 10.0.0.0/28 unchangeable after it created
12. region My First VPC 10.0.0.0/16 Non-Default VPC route table & network acl are created by vpc
13. region My First VPC 10.0.0.0/16 Non-Default VPC route table
 (and network ACL) route local traffic by default. This rule cannot be removed
14. region My First VPC 10.0.0.0/16 route table
 10.0.0.0/16 -> local Availability Zone 1a VPC subnet 10.0.1.0/24
15. region My First VPC 10.0.0.0/16 route table
 10.0.0.0/16 -> local Availability Zone 1a VPC subnet 10.0.1.0/24 subnet with a local traffic only route table
 called the private subnet. ! No traffic can reach outside,
 even the aws service, such as S3, EC2, …
16. region My First VPC 10.0.0.0/16 route table
 10.0.0.0/16 -> local Availability Zone 1a VPC subnet 10.0.1.0/24 How to make a public subnet ? create a internet gateway(IGW) for VPC,
 and attach the IGW to
 the existing or a new route table
 which associated with the subnets
18. region My First VPC 10.0.0.0/16 route table
 10.0.0.0/16 -> local
 0.0.0.0/0-> igw Availability Zone 1a VPC subnet 10.0.1.0/24 I am a public subnet
19. region My First VPC 10.0.0.0/16 route table
 10.0.0.0/16 -> local
 0.0.0.0/0-> igw Availability Zone 1a VPC subnet 10.0.1.0/24 I am a public subnet instances in the public subnet can access the internet
20. region My First VPC 10.0.0.0/16 route table
 10.0.0.0/16 -> local Availability Zone 1a VPC subnet 10.0.1.0/24 How does a private subnet access the internet ? I am a private subnet
21. VPC subnet 10.0.1.0/24 How does a private subnet access the internet ? I am a private subnet VPC subnet 10.0.2.0/24 I am a public subnet route table
 10.0.0.0/16 -> local
 0.0.0.0/0-> igw launch a NAT Instance
 in the public subnet route table
 10.0.0.0/16 -> local ami: amzn-ami-vpc-nat
22. VPC subnet 10.0.1.0/24 How does a private subnet access the internet ? I am a private subnet VPC subnet 10.0.2.0/24 I am a public subnet route table
 10.0.0.0/16 -> local
 0.0.0.0/0-> igw configurate private subnet route table using
 nat-instance-id route table
 10.0.0.0/16 -> local
 0.0.0.0/0 -> nat-instance-id
23. Demo • VPC with Public Subnet • VPC with Public Subnet & Private Subnet • NAT instance !
24. Demo: public subnet • Just a subnet with Internet Gateway ! ! ! !
25. Demo: private subnet + NAT • Just a subnet with 0.0.0.0/0 => NAT Instance ID • Tips: • AMI for NAT Instance • Disable Source/Desk. Check • Enable pass rule in Security Group
26. NAT Instance • What’s the magic in the nat-image ? • /etc/rc.local • /usr/local/sbin/configure-pat.sh • http:/ /bit.ly/1odhe63
27. Resources • http:/ /aws.amazon.com/documentation/vpc/ • From One to Many: Evolving VPC Design (ARC401) | AWS re:Invent 2013 • slide: http:/ /slidesha.re/1rGmtBv • video: http:/ /bit.ly/1rGmxkF • Selecting the Best VPC Network Architecture (CPN208) | AWS re:Invent 2013 • slide: http:/ /slidesha.re/1rGmoxQ • video: http:/ /bit.ly/1rGmC83
