Akka in Practice

Real World Application Design Patterns for the Intermediate Akka Developer, Scala Exchange 2013

Transcript

1. PRACTICE AKKA Real World Application Design Patterns for the Intermediate Akka Developer @agemooij !@rayroestenburg ! age@scalapenos.com ✉ray@scalapenos.com ✉ in Scala Exchange December 2nd 2013
2. Introduction ➡ BUILD A REST API WITH AKKA ➡ HANDLE REQUESTS ➡ EXECUTE EVENT-DRIVEN (BACKGROUND) TASKS The context for this talk..
3. Introduction Solutions for typical scenarios ➡ STRUCTURE THE ACTOR HIERARCHY? ➡ CONFIGURE ACTORS? ➡ KEEP TESTING SIMPLE? ➡ HANDLE REQUESTS? ➡ BUILD BACKGROUND SERVICES? ➡ DECOUPLE REQUESTS FROM BACKGROUND SERVICES? ➡ AND SOME MORE… How do I:
4. Agenda ➡ BOOTING UP ➡ THE RECEPTIONIST ➡ CREATING CHILDREN ➡ BECOME ➡ CONFIGURATION BY EXTENSION ➡ STREAMING EVENTS ➡ EVENT-DRIVEN SERVICES ➡ REQUEST/RESPONSE
5. Booting Up: it is that easy :)
6. The Receptionist: ➡ How do we get Akka to actually do some work? ➡ We need to talk to the actor system from the “outside” ➡ We need a “receptionist” to take our calls “Just use a socket!” Akka IO supports TCP, UDP, and HTTP We will use Spray, a.k.a. akka-http
7. The Receptionist: Spray exposes your entry-point actor to the outside world as an HTTP (REST) API
8. The Receptionist: Your entry-point actor can use Spray’s routing DSL to handle requests “But who is going to do the work?”
9. Creating Children: ➡ Every actor should do one thing and one thing only! ➡ When it all gets too much, use child labor! ➡ Children help with separation of concerns ➡ Use supervision to deal with failure
10. Creating Children: ➡ Create a child to do the hard work ➡ Here we use the “ask” pattern and futures in order to produce an HTTP response ➡ There are other ways! “But how do you MOCK this?”
11. Creating Children: ➡ Direct use of context.actorOf is hard to stub/mock ➡ This is OK for simple children because Akka TestKit is awesome ➡ But for more complex child hierarchies, it would be nice if we could stub/mock child actors
12. Creating Children: ➡ Layer traits based on least required dependency ➡ ActorCreationSupport can be mixed with anything ➡ ActorContextCreationSupport requires context
13. Creating Children: ➡ Mix in a trait for creating children ➡ Override during testing “How to test the http ROUTES?”
14. Creating Children: ➡ Put the routes in a separate Routes trait! ➡ Routes says: “I need ExecutionContext & CreationSupport!”
15. Creating Children: ➡ Layer traits based on least required dependency ➡ ActorCreationSupport can be mixed with anything ➡ ActorContextCreationSupport requires context TestCreationSupport creates a FakeProcessJobActor
16. Creating Children: ➡ Mix in TestsCreationSupport into Routes trait ➡ Ready to stub!
17. Initializing Actor State: ➡ Say an Actor uses a “Stuff” library ➡ Stuff needs some time to start… (returns Future) “VARS? Concurrent Access?”
18. ➡ Initialize the actor using messages ➡ Only process messages once initialized ➡ Possibly stash messages away until ready ➡ Crash when initialization fails (parent handles failure) Initializing Actor State:
19. Initialization using become: ➡ Allows you to build simple state machines ➡ Use multiple receive functions and switch behavior ➡ No need for vars!
20. Become is powerful sh*t: ➡ Allows you to build simple state machines ➡ Switch behaviour at runtime based on internal state ➡ Makes it possible to model processes and flows
21. Configuring Akka Apps: ➡ We all know hardcoding configuration is evil ➡ We don’t want to use a heavyweight DI library for some simple settings ➡ How can we configure our Akka apps?
22. ➡ Start by using the popular typesafe-config library Configuring Akka Apps:
23. Configuration by Extension: ➡ Use the Akka extension mechanism to access settings for the actor system
24. Using Settings: ➡ Access your Settings wherever you have a reference to an ActorSystem or an ActorContext
25. Test Settings? ➡ Use ConfigFactory.parseString ➡ Specify the settings using a string in your test
26. Test Settings: ➡ Some Test Support for Specs2
27. Settings extension: ➡ A simple example of an Akka extension ➡ Simple to use ➡ Configure for test, dev or production
28. Using Akka’s EventStream: ➡ How to communicate between disconnected actors? ➡ You don’t always have (or need) a reference to all actors in the system who might care about your messages
29. Using Akka’s EventStream: ➡ Publish messages on the Akka EventStream ➡ Anyone can subscribe to receive these
30. Using Akka’s EventStream: ➡ Messages that you have subscribed to are routed to your receive method like any other actor messages
31. A background service: ➡ Is started by the Receptionist ➡ Is supervised by the Receptionist ➡ Subscribes to events / commands on startup ➡ Unsubscribe can be put in a trait, mix in with background service
32. An activation email background service : ➡ Sending scheduled activation and reminder emails ➡ Coordinator subscribes to Registration Events ➡ ActivationEmailSender schedules mails ➡ Emailer sends mail using SMTP “How do I test this stuff?”
33. Expect events! ➡ Don’t try to assert intermediate messages ➡ Events should occur as the result of the process ➡ Subscribe the testActor to specific Events ➡ Expect the events with the TestKit
34. Using Akka’s EventStream: ➡ The EventStream is great for monitoring what happens in your system ➡ Actors can easily subscribe to events ➡ It is also great for making your application easier to test
35. Complex request/response ➡ So far we have used the “ask” pattern and futures to do request/response with actors ➡ But what happens when the request handling flow gets a bit more complex?
36. Complex request/response ➡ Define traits that return Futures ➡ combine the futures with map, flatMap & friends ➡ Implementation asks Actors (or uses Futures directly)
37. Complex request/response ➡ This might or might not be your cup of tea… ➡ There are other ways to model a sequential flow of information…
38. Complex request/response ➡ We can use our old friend Become in a single-use actor ➡ We do need to make sure it gets killed after it is done ➡ We also need to take care of timeouts ourselves “Worth the complexity?”
39. Request / Response: ➡ ‘Future Traits’ ➡ Use Actors or Future supporting API directly ➡ Mixin into Routes ➡ Single Purpose Actors also possible ➡ setReceiveTimeout ➡ Kill afterwards
40. QUESTIONS Got ? ask away!
41. MORE Want ? do THE exercises! https://github.com/RayRoestenburg/scala-io-exercise-1
42. HAKKING Happy manning.com/roestenburg ! @agemooij !@rayroestenburg ! age@scalapenos.com ✉ray@scalapenos.com ✉
43. Backup Slides
44. HTTP and domain ➡ Separate HTTP logic and domain logic ➡ Spray JSON ➡ Routes trait handles HTTP ➡ Deserialization (parameter values) ➡ Unmarshalling (entity body) ➡ Complete the response (StatusCodes, JSON)
45. Spray JSON ➡ A simple example ➡ To JSON and back
46. Custom Directives ➡ Great for reusing HTTP logic ➡ User it in your routes:
47. Custom Deserializers ➡ Great for handling ‘formatted’ parameters ➡ Use it in your Routes:
