1. Auto-generated Creation Form
   for Operator Managed Services
   1
   Tony Wu
   OpenShift Product Management
   tony.wu@redhat.com


   View Slide

2. In addition to enhanced YAML UX, a new
   and richer GUI UX to help reduce friction
   when deploying operator backed services with:
   1. basic data validation
   2. field description as help text
   3. highlights required fields
   4. user-friendly display name
   5. customizable help text
   6. custom UI widgets to assist inputs
   7. tailored form field ordering
   8. mark advanced fields
   9. exclude non-user facing fields
   10. markdown support for richer info
   Console Provides Richer GUI UX: for Operator-backed services
   Auto-generated Creation Form for Operator Managed Services


   View Slide

3. In addition to enhanced YAML UX, a new
   and richer GUI UX to help reduce friction
   when deploying operator backed services with:
   1. basic data type validation
   2. field description as help text
   3. highlights required fields
   4. user-friendly display name
   5. customizable help text
   6. custom UI widgets to assist input
   7. tailored form field ordering
   8. mark advanced fields
   9. exclude non-user facing fields
   10. markdown support for richer info
   UI Building Blocks + Automated Process: Creation Form for Operator Managed Services
   Auto-generated Creation Form for Operator Managed Services
   CRD
   structural schema
   CSV
   OLM descriptors
   CSV
   markdown
   See more in later slides


   View Slide

4. 1. OpenShift console automates the creation form
   generation for Operator managed services:
   ○ Auto-generates a basic "Creation Form" using
   Operand's structural schema in CRD’s YAML file.
   ○ Schema properties are mapped to appropriate UI
   components based on their types:
   i. type: string
   ii. type: string, with enum
   iii. type: integer
   iv. type: boolean
   v. type: object New in 4.5
   vi. type: array, with items New in 4.5
   ○ Check out Operator SDK for how to provide a “structural
   schema” for your CRD with API markers.
   2. Operator authors can further enhance the UI with OLM
   add-on to set them apart from the crowd:
   ○ The console overwrites the basic form fields with enhanced
   widgets associated to the added OLM descriptors in
   Operator’s CSV YAML file.
   i. Check out the reference guide for details and examples of
   how to use OLM descriptors.
   ○ Highlighted changes in 4.6 (see examples in the links):
   i. New: “hidden” - Exclude “non user facing” properties.
   ii. Improved: “advanced” - Advanced section “within schema
   object properties/group”.
   iii. Deprecated: “fieldGroup” and “arrayFieldGroup”
   → Now auto-generated per schema
   ○ Check out Operator SDK for how to generate OLM
   Descriptors using API markers when working on the CRD.
   4
   Auto-generated Creation Form for Operator Managed Services
   Declarative UI with OpenShift Console
   CRD
   structural schema
   CSV
   OLM descriptors


   View Slide

5. Enhanced “Create Operand Form”: for Operator-backed services
   Now default to the “Form View”, but you
   can always switch back to the YAML editor
   like a Pro.
   ● Reduces friction when deploying operator
   backed services.
   ● All data is stored when switching between
   the “Form” and “YAML” view.
   Auto-generated form now supports
   “nested schema properties”.
   ● CRD's nested “type: object/array”
   schema properties are mapped to
   appropriate form field UI components.
   ● Exclude “non user facing” schema
   properties from the auto generated form
   with a new “hidden” OLM descriptor.
   Auto-generated Creation Form for Operator Managed Services


   View Slide

6. 6
   Enhanced “Create Operand Form”
   = CRD schema + OLM Descriptors
   ● StorageCluster storageclusters.core.libopenstorage.org
   by Portworx
   Auto-generated Creation Form for Operator Managed Services


   View Slide

7. 7
   In CustomResourceDefinition manifest
   OCP Console maps spec properties
   under schema stanza to form fields:
   ■ type: string
   ■ type: integer
   ■ type: boolean
   ■ type: string, with enum
   ■ type: object New in 4.5
   ■ type: array, with items New in 4.5
   ■ renders property description as
   help text for each field New in
   4.6


   View Slide

8. OCP Console maps spec properties
   under schema stanza to form fields:
   ■ type: string
   ■ type: integer
   ■ type: boolean
   ■ type: string, with enum
   ■ type: object New in 4.5
   ■ type: array, with items New in 4.5
   ■ renders property description as
   help text for each field New in
   4.6
   Auto-generated Form - based on CRD schema (no OLM Descriptors involved)


   View Slide

9. ● Complex fields need more than
   OpenAPI validation info:
   ○ Needs a k8s object (e.g.
   Secret for pulling image) as a
   prerequisite.
   ○ Deeply nested fields, such as
   ResourceRequirements,
   UpdateStrategy,
   nodeAffinity, etc.
   ○ Exclude “non user facing”
   properties from the auto
   generated form with “hidden”
   x-descriptor.
   Customized Creation Form with OLM Descriptors - Richer UI Widgets


   View Slide

10. Customized Creation Form with OLM Descriptors - Ordering of Form Fields
    ● The ordering of form fields
    depends on whether a field:
    1. has a specDescriptor (sorted
    based on specDescriptors
    array order),
    2. is "required" (a ‘required:’
    property in the schema),
    3. "optional",
    4. or "advanced" (assigned with
    an advanced x-descriptor).
    ● In general, “fields with
    specDescriptors” will be sorted
    higher than those without, and
    “required fields” will be sorted
    higher than optional fields.
    ○ See full set of sorting rules.


    View Slide

11. ● OCP Console now provides
    markdown support for owned
    CRD’s description
    ○ In Operator CSV file’s
    spec.customresourcedefi
    nitions.owned[].descrip
    tion field. See in Portworx’s
    CSV file.
    ○ Provides instructions,
    prerequisites, or tutorials with
    external links to guide users
    how to create and manage an
    Operand instance.
    ○ CRD markdown will be shown
    in both “Admin” and “Dev”
    perspective in OCP Console.
    Customized Creation Form - CRD description markdown in CSV


    View Slide

12. ● Auto-generated Creation Form for Operator managed services
    ● Customized Creation Form with specDescriptors
    ○ x-descriptors reference
    ● OperatorFramework.io
    ○ Operator SDK
    ■ Provide a “structural schema” for your CRD with API markers.
    ■ Generate OLM Descriptors using API markers when working on the CRD.
    ○ Operator Lifecycle Manager
    12
    Auto-generated Creation Form for Operator Managed Services
    Useful Links
