NEWT Architecture Evolution

Transcript

1. © 2023 Reiwa Travel, Inc.
 NEWT Architecture Evolution How we scaled and improved our architecture over time
2. © 2023 Reiwa Travel, Inc.
 Profile • Nationality: Argentinian • Language: Spanish, English, Japanese • Full Stack Developer (+10y) Career • 󰎆 2006~: Freelance • 󰎆 2008~: PowerSite ( CTO/CEO ) ◦ Email Marketing SaaS • 󰏦 2015~: Travelience ( CTO ) ◦ Tour Guide Marketplace • 󰏦 2021~: ReiwaTravel ( Senior Engineer ) Senior Engineer / Product-Dev Rodrigo Ramirez
3. © 2023 Reiwa Travel, Inc.
 NEWT Architecture Evolution How we scaled and improved our architecture over time
4. AGENDA
 © 2023 Reiwa Travel, Inc.
 1. Prototyping (まず動かす ) 2. Pre-Release (リリースに備える ) 3. Post-Release (良くする) 4. Product & Team Scaling (チーム・サービスをスケールする ) 5. Future (進化し続ける ) Architecture Phases
5. AGENDA
 © 2023 Reiwa Travel, Inc.
 1. Prototyping (まず動かす ) 2. Pre-Release (リリースに備える ) 3. Post-Release (良くする) 4. Product & Team Scaling (チーム・サービスをスケールする ) 5. Future (進化し続ける ) Architecture Phases
6. 1. Prototyping まず動かす • Phase: 0~1 • Goal: Create NEWT MVP • Priority: Initial Development Speed • Decisions: 1. Infrastructure 2. Development 3. Scope
7. 1 Infrastructure • Self Managed • Vercel to Host our API and Admin UI • We didn’t have a production env • DB hosted on GCP (Vercel didn’t offer that solution) 1. Prototyping まず動かす
8. 2 Development • Monolithic API • Full-Stack Developers = Unified Programming Language ◦ Backend: TypeScript / GraphQL ◦ Frontend: Next.JS / TypeScript / React / GraphQL 1. Prototyping まず動かす
9. 3 Scope • Reduce initial features scope • Make things that do not scale 1. Prototyping まず動かす
10. アーキテクチャの概要 Architecture Overview Cloud SQL Instance #1 Native Apps iOS Android Third Party Firebase Environments: Dev API ADMIN UI WEBVIEW UI Webflow
11. AGENDA
 © 2023 Reiwa Travel, Inc.
 1. Prototyping (まず動かす ) 2. Pre-Release (リリースに備える ) 3. Post-Release (良くする) 4. Product & Team Scaling (チーム・サービスをスケールする ) 5. Future (進化し続ける ) Architecture Phases
12. • Phase: Pre-Release • Timeline: 2022年3月~2023年4月 • Goal: Production Ready • Priority: 1. Production Environment 2. Performance 3. Security 2. Pre-Release リリースに備える
13. 1 Production Environment • Created Production ENV ◦ Vercel→GCP ◦ Terraform 2. Pre-Release リリースに備える
14. ２ Performance • Runned Load tests and optimized API and DB Queries • Added DB read-replicas to distribute load • Setup Monitoring and Alerts 2. Pre-Release リリースに備える
15. 2 Security • Hired a Security Company to audit our service • Applied GraphQL Security Best Practices • Services & Application logs 2. Pre-Release リリースに備える
16. アーキテクチャの概要 Architecture Overview Cloud Run Cloud SQL Instance #1 reader 1 reader 2 reader N Cloud Trace Cloud Monitoring … Native Apps iOS Android API ADMIN UI Third Party Firebase Webflow Environments: Production, Staging … Webview UI
17. アーキテクチャの概要 Architecture Overview Cloud Run Cloud SQL Instance #1 reader 1 reader 2 reader N Cloud Trace Cloud Monitoring … Native Apps iOS Android API ADMIN UI Third Party Firebase Webflow Environments: Production, Staging … Webview UI
18. AGENDA
 © 2023 Reiwa Travel, Inc.
 1. Prototyping (まず動かす ) 2. Pre-Release (リリースに備える ) 3. Post-Release (良くする) 4. Product & Team Scaling (チーム・サービスをスケールする ) 5. Future (進化し続ける ) Architecture Phases
19. • Phase: Post-Release (First Year) • Goal: Improve our Service/Operations • Actions: 1. Improve NEWT functionality 2. Expand our services 3. Process Automation 3.Post-Release 良くする
20. 1 Improve NEWT functionality • Feedback from Customers → Improve current features • Develop missing core features (NEWT Point, …) 3.Post-Release 良くする
21. 2 Expand our services • NEWT Web • NEWT Magazine • NEWT Hotel ◦ Mobile App ◦ Web 3.Post-Release 良くする
22. 3 Process Automation • Connect with external providers (Hotel & Flight APIs) ◦ Inventory daily updates ◦ Booking Arrangement Automations 3.Post-Release 良くする
23. アーキテクチャの概要 Architecture Overview Cloud Run Cloud SQL Instance #1 … reader 1 reader 2 reader N … Cloud Trace Cloud Monitoring Cloud Task Big Query … Native Apps iOS Android NEWT NEWT-HOTEL MAGAZINE … API ADMIN UI Third Party Firebase Flight APIs Hotel APIs … Environments: Production, Staging Webflow
24. アーキテクチャの概要 Architecture Overview Cloud Run Cloud SQL Instance #1 … reader 1 reader 2 reader N … Cloud Trace Cloud Monitoring Cloud Task Big Query … Native Apps iOS Android NEWT NEWT-HOTEL MAGAZINE … API ADMIN UI Third Party Firebase Flight APIs Hotel APIs … Environments: Production, Staging Webflow
25. Micro-Frontend Web: Micro-Frontend /(*.) newt.net /hotel/(*.) /mag/(*.) /lp(*.) /tour/(*.) newt-web newt-hotel newt-magazine webflow Domain Path Apps Repository NEWT Web ( Monorepo )
26. AGENDA
 © 2023 Reiwa Travel, Inc.
 1. Prototyping (まず動かす ) 2. Pre-Release (リリースに備える ) 3. Post-Release (良くする) 4. Product & Team Scaling (チーム・サービスをスケールする ) 5. Future (進化し続ける ) Architecture Phases
27. • Phase: Current • Goal: Scale our service and product team organization • Actions: 1. Team Structure 2. Traffic Spike Support 4.Product & Team Scaling チーム・サービスをスケールする
28. 1 Team Structure • From 1 team to multiple teams ◦ Parallel Development → Multiple Dev Environments ◦ Increase Releases → Git Branch Strategy Backend Frontend Mobile PM … Backend Frontend Mobile PM … Team 1 Team 2 Team 3 Team 4 4.Product & Team Scaling チーム・サービスをスケールする
29. 2 Traffic Spike Support • Database Bottlenecks ◦ Tour Search from RDS to Elasticsearch ◦ Web Caching Strategies 4.Product & Team Scaling チーム・サービスをスケールする
30. アーキテクチャの概要 Architecture Overview Cloud Run Cloud SQL Instance #1 … reader 1 reader 2 reader N … Cloud Trace Cloud Monitoring Cloud Task Big Query … Native Apps iOS Android NEWT NEWT-HOTEL MAGAZINE … API ADMIN UI Third Party Firebase Flight APIs Hotel APIs Elastic Cloud Webflow Environments: Production, Staging, Dev 1…N …
31. 技術スタック Technology Stack
32. AGENDA
 © 2023 Reiwa Travel, Inc.
 1. Prototyping (まず動かす ) 2. Pre-Release (リリースに備える ) 3. Post-Release (良くする) 4. Product & Team Scaling (チーム・サービスをスケールする ) 5. Future (進化し続ける ) Architecture Phases
33. • Phase: ( Next ) Future Challenges • Goal: Prepare System to support NEWT evolution • Challenges: 1. Team/Code Isolation 2. Smarter Solutions using AI/LMM 3. Global Expansion 4. … 5. Future 進化し続ける
34. 1 Team/Code Isolation • Reduce Code Conflicts • Reduce Cognitive Load • Isolate Data & Deployments 5. Future 進化し続ける
35. 5. Future 進化し続ける
36. 5. Future 進化し続ける
37. 5. Future 進化し続ける
38. 2 Smarted Solutions using AI/LLM • Incorporate more AI/LLM into NEWT service ◦ Deliver Better and Smarter Features to Customers ◦ Optimize Internal processes 5. Future 進化し続ける
39. 3 Global Expansion • Multi-Language • Multi-Currency • Timezone Support • … 5. Future 進化し続ける
40. AGENDA
 © 2023 Reiwa Travel, Inc.
 1. Prototyping (まず動かす ) 2. Pre-Release (リリースに備える ) 3. Post-Release (良くする) 4. Product & Team Scaling (チーム・サービスをスケールする ) 5. Future (進化し続ける ) Architecture Phases
41. © 2023 Reiwa Travel, Inc.
 We are hiring!!!! reiwatravel.co.jp/engineers
42. Thank you!
