StockholmCpp23 - Variant Visitation Variations

std::variant<> and std::visit() are arguably among the most important new features of C++17, allowing for the type safe flexibility provided by virtual functions, without the coupling from inheritance. But some say visit() is slow. Let's find out, and try a few different techniques to implement visit() and see what the standard says.

Transcript

1. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 1/50
   Variant Visitation Variations
   Björn Fahller


   View Slide

2. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 2/50

   std::variant


   View Slide

3. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 3/50

   std::variant
   – In C++ 17


   View Slide

4. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 4/50

   std::variant
   – In C++ 17
   – Is a sum-type


   View Slide

5. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 5/50

   std::variant
   – In C++ 17
   – Is a sum-type
   using V = std::variant;
   Instances of V can hold
   either the values from A, or the
   values from B. i.e., the value space
   of V is the sum of the value spaces
   of A and B.


   View Slide

6. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 6/50

   std::variant
   – In C++ 17
   – Is a sum-type
   – Is type safe


   View Slide

7. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 7/50

   std::variant
   – In C++ 17
   – Is a sum-type
   – Is type safe
   using V = std::variant;
   V v{A{}};


   View Slide

8. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 8/50

   std::variant
   – In C++ 17
   – Is a sum-type
   – Is type safe
   using V = std::variant;
   V v{A{}};
   if (std::holds_alternative(v))
   func(std::get(v));


   View Slide

9. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 9/50

   std::variant
   – In C++ 17
   – Is a sum-type
   – Is type safe
   using V = std::variant;
   V v{A{}};
   if (std::holds_alternative(v))
   func(std::get(v));
   std::get(v); // throws


   View Slide

10. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 10/50

    std::variant
    – In C++ 17
    – Is a sum-type
    – Is type safe
    – Is a value type


    View Slide

11. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 11/50

    auto std::visit(visitor, variants...)
    – Calls visitor with the actual types held by the variants
    – visitor must have overloads that spans the entire type
    space


    View Slide

12. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 12/50

    auto std::visit(visitor, variants...)
    – Calls visitor with the actual types held by the variants
    – visitor must have overloads that spans the entire type
    space
    struct add {};
    struct subtract {};
    struct constant { int value; };
    struct variable { std::string name; };
    using expression = std::variant<
    add, subtract, constant, variable>;
    expression evaluate(expression e)
    {
    struct visitor {
    expression operator()(add) { … }
    expression operator()(subtract) { … }
    expression operator()(constant c) { … c.value; }
    expression operator()(variable v) { … lookup(v.name); }
    };
    return std::visit(visitor{}, e);
    }


    View Slide

13. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 13/50

    auto std::visit(visitor, variants...)
    – Calls visitor with the actual types held by the variants
    – visitor must have overloads that spans the entire type
    space
    struct add {};
    struct subtract {};
    struct constant { int value; };
    struct variable { std::string name; };
    using expression = std::variant<
    add, subtract, constant, variable>;
    expression evaluate(expression e)
    {
    struct visitor {
    expression operator()(add) { … }
    expression operator()(subtract) { … }
    expression operator()(constant c) { … c.value; }
    expression operator()(variable v) { … lookup(v.name); }
    };
    return std::visit(visitor{}, e);
    }
    Note that the types in the
    variant are only conceptually
    related, they are not related
    in the type system.


    View Slide

14. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 14/50

    auto std::visit(visitor, variants...)
    – Calls visitor with the actual types held by the variants
    – visitor must have overloads that spans the entire type
    space


    View Slide

15. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 15/50

    Mateusz Pusz
    ACCU 2019
    20 minutes
    https://www.youtube.com/watch?v=JGYxOieiZnY


    View Slide

16. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 16/50

    Some say generated code is inefficient


    View Slide

17. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 17/50

    Some say generated code is inefficient
    – Let’s have a look


    View Slide

18. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 18/50

    Some say generated code is inefficient
    – Let’s have a look
    https://gcc.godbolt.org/z/51ufc6


    View Slide

19. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 19/50

    Some say generated code is inefficient
    – Let’s have a look
    – Why the check for index==-1?
    https://gcc.godbolt.org/z/51ufc6


    View Slide

20. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 20/50
    Throws: bad_­
    variant_­
    access if any variant in vars is valueless_­
    by_­
    exception().
    http://eel.is/c++draft/variant.visit#4


    View Slide

21. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 21/50
    http://eel.is/c++draft/variant.variant#variant.status
    20.7.3.5 Value status [variant.status]
    constexpr bool valueless_by_exception() const noexcept;
    Effects: Returns false if and only if the variant holds a value.
    [ Note: A variant might not hold a value if an exception is thrown during a type-changing
    assignment or emplacement. The latter means that even a variant can become
    valueless_­
    by_­
    exception(), for instance by
    struct S { operator int() { throw 42; }};
    variant v{12.f};
    v.emplace<1>(S());
    — end note ]
    Throws: bad_­
    variant_­
    access if any variant in vars is valueless_­
    by_­
    exception().
    http://eel.is/c++draft/variant.visit#4


    View Slide

22. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 22/50
    http://eel.is/c++draft/variant.variant#variant.status
    20.7.3.5 Value status [variant.status]
    constexpr bool valueless_by_exception() const noexcept;
    Effects: Returns false if and only if the variant holds a value.
    [ Note: A variant might not hold a value if an exception is thrown during a type-changing
    assignment or emplacement. The latter means that even a variant can become
    valueless_­
    by_­
    exception(), for instance by
    struct S { operator int() { throw 42; }};
    variant v{12.f};
    v.emplace<1>(S());
    — end note ]
    Throws: bad_­
    variant_­
    access if any variant in vars is valueless_­
    by_­
    exception().
    http://eel.is/c++draft/variant.visit#4


    View Slide

23. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 23/50
    http://eel.is/c++draft/variant.variant#variant.status
    20.7.3.5 Value status [variant.status]
    constexpr bool valueless_by_exception() const noexcept;
    Effects: Returns false if and only if the variant holds a value.
    [ Note: A variant might not hold a value if an exception is thrown during a type-changing
    assignment or emplacement. The latter means that even a variant can become
    valueless_­
    by_­
    exception(), for instance by
    struct S { operator int() { throw 42; }};
    variant v{12.f};
    v.emplace<1>(S());
    — end note ]
    Throws: bad_­
    variant_­
    access if any variant in vars is valueless_­
    by_­
    exception().
    http://eel.is/c++draft/variant.visit#4


    View Slide

24. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 24/50
    http://eel.is/c++draft/variant.variant#variant.status
    20.7.3.5 Value status [variant.status]
    constexpr bool valueless_by_exception() const noexcept;
    Effects: Returns false if and only if the variant holds a value.
    [ Note: A variant might not hold a value if an exception is thrown during a type-changing
    assignment or emplacement. The latter means that even a variant can become
    valueless_­
    by_­
    exception(), for instance by
    struct S { operator int() { throw 42; }};
    variant v{12.f};
    v.emplace<1>(S());
    — end note ]
    Throws: bad_­
    variant_­
    access if any variant in vars is valueless_­
    by_­
    exception().
    http://eel.is/c++draft/variant.visit#4


    View Slide

25. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 25/50
    http://eel.is/c++draft/variant.variant#variant.status
    20.7.3.5 Value status [variant.status]
    constexpr bool valueless_by_exception() const noexcept;
    Effects: Returns false if and only if the variant holds a value.
    [ Note: A variant might not hold a value if an exception is thrown during a type-changing
    assignment or emplacement. The latter means that even a variant can become
    valueless_­
    by_­
    exception(), for instance by
    struct S { operator int() { throw 42; }};
    variant v{12.f};
    v.emplace<1>(S());
    — end note ]
    Throws: bad_­
    variant_­
    access if any variant in vars is valueless_­
    by_­
    exception().
    http://eel.is/c++draft/variant.visit#4


    View Slide

26. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 26/50

    Some say generated code is inefficient
    – Let’s have a look
    – Why the check for index==-1?
    – Why calls through function pointers?
    https://gcc.godbolt.org/z/51ufc6


    View Slide

27. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 27/50
    http://eel.is/c++draft/variant.visit#5
    template
    constexpr see below visit(Visitor&& vis, Variants&&... vars);
    1. Let n be sizeof...(Variants)…
    …
    5. Complexity: For n ≤ 1, the invocation of the callable object is implemented in constant time,
    i.e., for n = 1, it does not depend on the number of alternative types of Variants
    0
    . For n > 1,
    the invocation of the callable object has no complexity requirements.


    View Slide

28. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 28/50
    http://eel.is/c++draft/variant.visit#5
    template
    constexpr see below visit(Visitor&& vis, Variants&&... vars);
    1. Let n be sizeof...(Variants)…
    …
    5. Complexity: For n ≤ 1, the invocation of the callable object is implemented in constant time,
    i.e., for n = 1, it does not depend on the number of alternative types of Variants
    0
    . For n > 1,
    the invocation of the callable object has no complexity requirements.


    View Slide

29. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 29/50
    http://eel.is/c++draft/variant.visit#5
    template
    constexpr see below visit(Visitor&& vis, Variants&&... vars);
    1. Let n be sizeof...(Variants)…
    …
    5. Complexity: For n ≤ 1, the invocation of the callable object is implemented in constant time,
    i.e., for n = 1, it does not depend on the number of alternative types of Variants
    0
    . For n > 1,
    the invocation of the callable object has no complexity requirements.


    View Slide

30. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 30/50

    Some say generated code is inefficient
    – Let’s have a look
    – Why the check for index==-1?
    – Why calls through function pointers?
    – Let’s break the rules!
    https://gcc.godbolt.org/z/51ufc6


    View Slide

31. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 31/50
    A non-conforming visit()
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }


    View Slide

32. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 32/50
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }


    View Slide

33. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 33/50
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }


    View Slide

34. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 34/50
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }


    View Slide

35. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 35/50
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }


    View Slide

36. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 36/50
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }


    View Slide

37. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 37/50
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }
    http://tiny.cc/sxaw7y
    cppinsights.io


    View Slide

38. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 38/50
    template <
    typename Vi,
    typename Va,
    size_t idx = std::variant_size_v> - 1
    >
    auto visit(Vi&& vi, Va&& va)
    {
    if (idx == va.index()) {
    return std::invoke( std::forward(vi),
    std::get(std::forward(va)) );
    }
    if constexpr (idx > 0) {
    return visit( std::forward(vi),
    std::forward(va) );
    }
    else throw std::bad_variant_access();
    }
    http://tiny.cc/sxaw7y
    cppinsights.io
    https://gcc.godbolt.org/z/0mtCdY


    View Slide

39. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 39/50

    Is visit() slow?


    View Slide

40. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 40/50

    Is visit() slow?


    View Slide

41. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 41/50

    Is visit() slow?
    – Not really


    View Slide

42. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 42/50

    Is visit() slow?
    – Not really, but it’s not as fast as it could be.


    View Slide

43. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 43/50

    Is visit() slow?
    – Not really, but it’s not as fast as it could be.
    – It’s surprisingly easy to write a fast(er) visit.


    View Slide

44. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 44/50

    Is visit() slow?
    – Not really, but it’s not as fast as it could be.
    – It’s surprisingly easy to write a fast(er) visit.
    – The performance guarantees from the standard
    actually hurts the performance.


    View Slide

45. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 45/50

    Is visit() slow?
    – Not really, but it’s not as fast as it could be.
    – It’s surprisingly easy to write a fast(er) visit.
    – The performance guarantees from the standard
    actually hurts the performance.
    – LLVMs if-else sequence to jump table optimization
    makes a non-complying implementation compliant!


    View Slide

46. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 46/50
    Resources


    View Slide

47. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 47/50
    Resources
    “Variant Visitation V2” - Michael Park
    https://mpark.github.io/programming/2019/01/22/variant-visitation-v2/


    View Slide

48. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 48/50
    Resources
    “Variant Visitation V2” - Michael Park
    https://mpark.github.io/programming/2019/01/22/variant-visitation-v2/
    “When performance guarantees hurts
    performance – std::visit” - Björn Fahller
    https://playfulprogramming.blogspot.com/2018/12/when-performance-guarantees-hu
    rts.html


    View Slide

49. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 49/50
    Resources
    “Variant Visitation V2” - Michael Park
    https://mpark.github.io/programming/2019/01/22/variant-visitation-v2/
    “When performance guarantees hurts
    performance – std::visit” - Björn Fahller
    https://playfulprogramming.blogspot.com/2018/12/when-performance-guarantees-hu
    rts.html
    “CPPInsights.io” - Andreas Fertig
    https://cppinsights.io


    View Slide

50. Variant Visitation Variations – StockholmCpp 23 © Björn Fahller @bjorn_fahller 50/50
    Björn Fahller
    Variant Visitation Variations
    bjorn@fahller.se
    @bjorn_fahller
    @rollbear


    View Slide
