SDF を作りたかった 2020年12月24日 佐藤雄一
自己紹介 名前:佐藤 雄一 好物:エレキギター、(初期)仏教、Smalltalk Twitter:@satoyuichi80 趣味:読書、ギター演奏、映画鑑賞 最近好きなTV番組: 「サンドウィッチマン& 芦田愛菜の博士ちゃん」
目的 Unity の Visual Effect Graph で使う SDF データを作るため。下の画像の Teapot
の ように形状を表現するための 3D テクスチャを生成したかった。
Signed Distance Field(SDF)とは 内側で負、境界でゼロ、外側で正となり、形状表面からの距離を示す。これを二次元 や三次元テクスチャとして持ち、形状を表現する。 出所)https://niteeshyadav.com/blog/the-current-state-of-the-text-in-augmented-reality-7507/
が、しかし 手持ちのソフトで SDF を手軽に出力する方法がないようなので、ひとまず Blender で ベクトル場を作って、Unity にインポートすることにした。 SDF とベクトル場の違いは各ボクセルにスカラー値を持つか、ベクトル値を持つかな
ので、どちらかで対応できればもう片方にも適用できるはずと判断した。
Unity で .vf ファイルがインポートできることがわかったので、Blender のアドオンと組 み合わせて以下の順序で生成することにした。 生成順序 .fga をエクスポート (C
で作ったコンバータで ) .fga を .vf に変換 .vf を出力 Unity にインポート Blender でベクトル場を生成
Blender で作ったベクトル場 中心に吸い込み型の力場を作って、その力の方向を各ボクセルに記録しているよう す。
.fga ファイルの構造 Blender のアドオンを使ってベクトル場を作り .fga ファイルをエクスポートする。.fga ファイルはアスキー形式で、以下のような構造になっている。 分割数 X Y
Z BBox 最小値 X 座標 Y 座標 Z 座標 BBox 最大値 X 座標 Y 座標 Z 座標 Vector X 値 Y 値 Z 値 ...
.vf ファイルの構造 .vf ファイルはバイナリ形式で以下のような構造になっている。 • Float(用途:SDF) • Vector(用途:Vector Field, Vector
Gradient Field) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 FourCC(VF_V) X 分割数 Y 分割数 Z 分割数 ベクトル値(float, float, float) ... 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 FourCC(VF_F) X 分割数 Y 分割数 Z 分割数 スカラー値 ...
結果
今後の展望 • Blender で SDF を作るアドオンを開発する • Blender で VGF(Vector
Gradient Field)を作るアドオンを開発する …が、すでにある気がする(調べた限りではないけど
参考資料 • Qiita(https://qiita.com/YuichiSato/items/bc160896b5883f1a125b) • Blender - FGA Vector Field Editor(https://github.com/isathar/Blender_UE4_VectorFieldEditor)
• VF : VectorField file format(https://github.com/peeweek/VectorFieldFile/blob/master/README.md) • fga2vf(https://github.com/satoyuichi/fga2vf)
