On Deny Capabilities for Safe, Fast Actors

“Deny Capabilities for Safe, Fast Actors (2015)” by Sylvan Clebsch et al. lays out the core novel idea behind the Pony programming language: deny capabilities. Deny capabilities take object capabilities, turn them on their head and then apply them to variable aliases.

In this talk, Sean T. Allen (member of the Pony core team) explains Deny Capabilities and how Pony combines them with an actor-based model – to provide a programming environment that allows for data-race freedom and fearless concurrency.

Transcript

1. On Deny Capabilities
   for Safe, Fast Actors
   1/39


   View Slide

2. Sean T. Allen
   Member of the Pony core team
   @SeanTAllen
   www.seantallen.com
   2/39


   View Slide

3. This is a talk about concurrency.
   3/39


   View Slide

4. This is a talk about going fast.
   4/39


   View Slide

5. This talk is about Pony and Deny Capabilities.
   5/39


   View Slide

6. About the paper
   6/39


   View Slide

7. Actor model
   7/39


   View Slide

8. Actor model basics
   8/39


   View Slide

9. Actor model basics
   Actors communicate with other actors via
   messaging
   8/39


   View Slide

10. Actor model basics
    Actors communicate with other actors via
    messaging
    Actors process messages
    8/39


    View Slide

11. Actor model basics
    Actors communicate with other actors via
    messaging
    Actors process messages
    Actors "protect resources"
    8/39


    View Slide

12. Safe
    9/39


    View Slide

13. Data race freedom
    10/39


    View Slide

14. Data race
    Two memory accesses attempts where both:
    11/39


    View Slide

15. Data race
    Two memory accesses attempts where both:
    Target the same location
    11/39


    View Slide

16. Data race
    Two memory accesses attempts where both:
    Target the same location
    Are performed concurrently by two threads
    11/39


    View Slide

17. Data race
    Two memory accesses attempts where both:
    Target the same location
    Are performed concurrently by two threads
    Are not reads
    11/39


    View Slide

18. Data race
    Two memory accesses attempts where both:
    Target the same location
    Are performed concurrently by two threads
    Are not reads
    Are not synchronization operations
    11/39


    View Slide

19. The actor model can help prevent data races
    12/39


    View Slide

20. The actor model can help prevent data races
    All variables are "protected" by an actor - no
    global variables
    12/39


    View Slide

21. The actor model can help prevent data races
    All variables are "protected" by an actor - no
    global variables
    Actors are processed sequentially 1 message a
    time by a single thread
    12/39


    View Slide

22. The actor model can help prevent data races
    All variables are "protected" by an actor - no
    global variables
    Actors are processed sequentially 1 message a
    time by a single thread
    Actors are "synchronization operations"
    12/39


    View Slide

23. The actor model can help prevent data races
    All variables are "protected" by an actor - no
    global variables
    Actors are processed sequentially 1 message a
    time by a single thread
    But sending data from one actor to another can cause problems...
    12/39


    View Slide

24. Fast
    13/39


    View Slide

25. How to go fast
    14/39


    View Slide

26. How to go fast
    Avoid coordination
    14/39


    View Slide

27. How to go fast
    Avoid coordination
    Avoid contention
    14/39


    View Slide

28. How to go fast
    Avoid coordination
    Avoid contention
    Measure it
    14/39


    View Slide

29. How actors can help with fast
    15/39


    View Slide

30. How actors can help with fast
    make coordination explicit
    15/39


    View Slide

31. How actors can help with fast
    make coordination explicit
    make contention explicit
    15/39


    View Slide

32. How actors can hurt fast
    16/39


    View Slide

33. How actors can hurt fast
    naive implementations can be very slow
    16/39


    View Slide

34. How actors can hurt fast
    naive implementations can be very slow
    message queues are points of contention
    16/39


    View Slide

35. How actors can hurt fast
    naive implementations can be very slow
    message queues are points of contention
    locks are usually faster than a large memory
    copy
    16/39


    View Slide

36. Deny capabilities for safe, fast actors
    17/39


    View Slide

37. Deny capabilities
    doing unsafe fast things safely
    18/39


    View Slide

38. Deny capabilities
    statically con rm you aren't doing something
    unsafe
    19/39


    View Slide

39. Alias control
    20/39


    View Slide

40. What is an alias?
    21/39


    View Slide

41. What is an alias?
    Aliases are "names" for things in memory
    21/39


    View Slide

42. What is an alias?
    Aliases are "names" for things in memory
    Aliases allow you to access a thing at a location
    21/39


    View Slide

43. Aliases in Pony
    22/39


    View Slide

44. Aliases in Pony
    When you assign a value to a variable or a eld.
    22/39


    View Slide

45. Aliases in Pony
    When you assign a value to a variable or a eld.
    When you pass a value as an argument to a
    method.
    22/39


    View Slide

46. Aliases in Pony
    When you assign a value to a variable or a eld.
    When you pass a value as an argument to a
    method.
    When you call a method, an alias of the receiver
    of the call is created. It is accessible as this
    within the method body.
    22/39


    View Slide

47. Count the aliases
    primitive Say
    fun say(msg: String, out: OutStream) =>
    let x = "We say '" + msg + "'"
    out.print(x)
    23/39


    View Slide

48. Count the aliases
    fun say(msg: String, out: OutStream) =>
    primitive Say
    let x = "We say '" + msg + "'"
    out.print(x)
    msg and out are aliases
    23/39


    View Slide

49. Count the aliases
    let x = "We say '" + msg + "'"
    primitive Say
    fun say(msg: String, out: OutStream) =>
    out.print(x)
    x is an alias
    23/39


    View Slide

50. Count the aliases
    out.print(x)
    primitive Say
    fun say(msg: String, out: OutStream) =>
    let x = "We say '" + msg + "'"
    x is aliased when passed to print
    23/39


    View Slide

51. Count the aliases
    primitive Say
    fun say(msg: String, out: OutStream) =>
    let x = "We say '" + msg + "'"
    out.print(x)
    23/39


    View Slide

52. Capabilities
    Annotations on code that can be used to statically
    con rm some property
    24/39


    View Slide

53. actor Main
    new create(env: Env) =>
    let msg: String val = "Hello World!"
    env.out.print(msg)
    25/39


    View Slide

54. let msg: String val = "Hello World!"
    actor Main
    new create(env: Env) =>
    env.out.print(msg)
    val is a capability
    25/39


    View Slide

55. let msg: String val = "Hello World!"
    actor Main
    new create(env: Env) =>
    env.out.print(msg)
    val is part of the type at compile-time
    25/39


    View Slide

56. let msg: String val = "Hello World!"
    actor Main
    new create(env: Env) =>
    env.out.print(msg)
    val says "the alias msg to the String Hello World is immutable"
    25/39


    View Slide

57. What can you deny?
    26/39


    View Slide

58. What can you deny?
    Reading
    26/39


    View Slide

59. What can you deny?
    Reading
    Mutating
    26/39


    View Slide

60. What can you deny?
    Reading
    Mutating
    Aliasing
    26/39


    View Slide

61. What can you deny?
    Reading
    Mutating
    Aliasing
    Sending
    26/39


    View Slide

62. What can you deny?
    Reading
    Mutating
    Aliasing
    Sending
    Sharing
    26/39


    View Slide

63. Some capabilities
    27/39


    View Slide

64. Some capabilities
    ref
    27/39


    View Slide

65. Some capabilities
    ref
    val
    27/39


    View Slide

66. Some capabilities
    ref
    val
    iso
    27/39


    View Slide

67. Some capabilities
    ref
    val
    iso
    tag
    27/39


    View Slide

68. ref
    28/39


    View Slide

69. ref
    allows reading
    28/39


    View Slide

70. ref
    allows reading
    allows mutation
    28/39


    View Slide

71. ref
    allows reading
    allows mutation
    denies sending
    28/39


    View Slide

72. ref
    allows reading
    allows mutation
    denies sending
    allows unlimited aliases
    28/39


    View Slide

73. ref
    allows reading
    allows mutation
    denies sending
    allows unlimited aliases
    denies sharing
    28/39


    View Slide

74. iso
    29/39


    View Slide

75. iso
    allows reading
    29/39


    View Slide

76. iso
    allows reading
    allows mutation
    29/39


    View Slide

77. iso
    allows reading
    allows mutation
    allows sending
    29/39


    View Slide

78. iso
    allows reading
    allows mutation
    allows sending
    denies aliasing
    29/39


    View Slide

79. iso
    allows reading
    allows mutation
    allows sending
    denies aliasing
    denies sharing
    29/39


    View Slide

80. val
    30/39


    View Slide

81. val
    allows reading
    30/39


    View Slide

82. val
    allows reading
    denies mutation
    30/39


    View Slide

83. val
    allows reading
    denies mutation
    allows sending
    30/39


    View Slide

84. val
    allows reading
    denies mutation
    allows sending
    allows unlimited aliases
    30/39


    View Slide

85. val
    allows reading
    denies mutation
    allows sending
    allows unlimited aliases
    allows sharing
    30/39


    View Slide

86. tag
    31/39


    View Slide

87. tag
    denies reading
    31/39


    View Slide

88. tag
    denies reading
    denies mutation
    31/39


    View Slide

89. tag
    denies reading
    denies mutation
    allows aliasing
    31/39


    View Slide

90. tag
    denies reading
    denies mutation
    allows aliasing
    allows sharing
    31/39


    View Slide

91. tag
    denies reading
    denies mutation
    allows aliasing
    allows sharing
    allows sending
    31/39


    View Slide

92. Readable
    32/39


    View Slide

93. Readable
    ref
    32/39


    View Slide

94. Readable
    ref
    iso
    32/39


    View Slide

95. Readable
    ref
    iso
    val
    32/39


    View Slide

96. Readable
    ref
    iso
    val
    Mutable
    32/39


    View Slide

97. Readable
    ref
    iso
    val
    Mutable
    ref
    32/39


    View Slide

98. Readable
    ref
    iso
    val
    Mutable
    ref
    iso
    32/39


    View Slide

99. Readable
    ref
    iso
    val
    Mutable
    ref
    iso
    Aliasable
    32/39


    View Slide

100. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     32/39


     View Slide

101. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     32/39


     View Slide

102. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     32/39


     View Slide

103. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     Sendable
     32/39


     View Slide

104. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     Sendable
     val
     32/39


     View Slide

105. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     Sendable
     val
     tag
     32/39


     View Slide

106. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     Sendable
     val
     tag
     iso
     32/39


     View Slide

107. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     Sendable
     val
     tag
     iso
     Shareable
     32/39


     View Slide

108. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     Sendable
     val
     tag
     iso
     Shareable
     val
     32/39


     View Slide

109. Readable
     ref
     iso
     val
     Mutable
     ref
     iso
     Aliasable
     ref
     val
     tag
     Sendable
     val
     tag
     iso
     Shareable
     val
     tag
     32/39


     View Slide

110. There's no platonic ideal for deny capabilities.
     33/39


     View Slide

111. Code (and errors!)
     34/39


     View Slide

112. actor Main
     new create(env: Env) =>
     let msg: String ref = "Hello World!".clone()
     env.out.print(msg)
     35/39


     View Slide

113. let msg: String ref = "Hello World!".clone()
     actor Main
     new create(env: Env) =>
     env.out.print(msg)
     Hello World String is mutable
     35/39


     View Slide

114. env.out.print(msg)
     actor Main
     new create(env: Env) =>
     let msg: String ref = "Hello World!".clone()
     send msg to actor out
     35/39


     View Slide

115. let msg: String ref = "Hello World!".clone()
     actor Main
     new create(env: Env) =>
     env.out.print(msg)
     ref isn't sendable
     35/39


     View Slide

116. env.out.print(msg)
     actor Main
     new create(env: Env) =>
     let msg: String ref = "Hello World!".clone()
     which will result in an error here
     35/39


     View Slide

117. Error:
     main.pony:4:19: argument not a subtype of parameter
     env.out.print(msg)
     ^
     Info:
     main.pony:4:19: argument type is String ref
     env.out.print(msg)
     ^
     (...):13:12: parameter type is
     (String val | Array[U8 val] val)
     be print(data: ByteSeq)
     ^
     main.pony:3:14: String ref is not a subtype of String val:
     ref is not a subcap of val
     let msg: String ref = "Hello World!".clone()
     ^
     main.pony:3:14: String ref is not a subtype of Array[U8 val] val
     36/39


     View Slide

118. main.pony:4:19: argument not a subtype of paramete
     env.out.print(msg)
     Error:
     ^
     Info:
     main.pony:4:19: argument type is String ref
     env.out.print(msg)
     ^
     (...):13:12: parameter type is
     (String val | Array[U8 val] val)
     be print(data: ByteSeq)
     ^
     main.pony:3:14: String ref is not a subtype of String val:
     ref is not a subcap of val
     let msg: String ref = "Hello World!".clone()
     ^
     msg isn't the correct type
     36/39


     View Slide

119. main.pony:4:19: argument type is String ref
     env.out.print(msg)
     Error:
     main.pony:4:19: argument not a subtype of parameter
     env.out.print(msg)
     ^
     Info:
     ^
     (...):13:12: parameter type is
     (String val | Array[U8 val] val)
     be print(data: ByteSeq)
     ^
     main.pony:3:14: String ref is not a subtype of String val:
     ref is not a subcap of val
     let msg: String ref = "Hello World!".clone()
     ^
     msg is String ref
     36/39


     View Slide

120. (...):13:12: parameter type is
     (String val | Array[U8 val] val)
     be print(data: ByteSeq)
     main.pony:4:19: argument not a subtype of parameter
     env.out.print(msg)
     ^
     Info:
     main.pony:4:19: argument type is String ref
     env.out.print(msg)
     ^
     ^
     main.pony:3:14: String ref is not a subtype of String val:
     ref is not a subcap of val
     let msg: String ref = "Hello World!".clone()
     ^
     main.pony:3:14: String ref is not a subtype of Array[U8 val] val
     l S i f "H ll W ld!" l ()
     print requires String val or Array[U8] val
     36/39


     View Slide

121. The compiler just statically checked our data
     sharing.
     37/39


     View Slide

122. The compiler just statically checked our data
     sharing.
     Let's x it
     37/39


     View Slide

123. actor Main
     new create(env: Env) =>
     let msg: String val = "Hello World!"
     env.out.print(msg)
     38/39


     View Slide

124. let msg: String val = "Hello World!"
     actor Main
     new create(env: Env) =>
     env.out.print(msg)
     Hello World String is immutable
     38/39


     View Slide

125. env.out.print(msg)
     actor Main
     new create(env: Env) =>
     let msg: String val = "Hello World!"
     send msg to actor out
     38/39


     View Slide

126. let msg: String val = "Hello World!"
     actor Main
     new create(env: Env) =>
     env.out.print(msg)
     val is sendable
     38/39


     View Slide

127. env.out.print(msg)
     actor Main
     new create(env: Env) =>
     let msg: String val = "Hello World!"
     no error here
     38/39


     View Slide

128. Learn more
     https:/
     /www.seantallen.com/talks/deny-
     capabilities/
     39/39


     View Slide
