DroidKaigi 2018付録2 ConstraintLayout の 機能の実現 株式会社ノハナ 瀬戸優之 @seto_hi
略解 ConstraintLayoutの 機能の内部実装 https://qiita.com/hiroyuki-seto/items/7b8781b336efba14872e のもう少し深い話
Guideline
Guideline • 実態はView • constraint-layout側はほぼ空実装 ◦ 描画されないようにだけ実装されている ◦ ConstraintLayoutがmeasureをskipする •
solver側はLinearSystemにSolverVariableを追加している ◦ Vertical or Horizontal or Percent で条件分け
Group
の前に
ConstraintHelper
ConstraintHelper • 実態はView • 参照されているViewのidの一覧を持つ • updatePreMeasure、updatePostMeasure • updatePreLayout、updatePostLayout •
measureされない ◦ if文ですべてskipされている
Group
Group • View、ConstraintHelper • updatePreLayout ◦ 対象Viewのvisibilityとelevationを変更 • updatePostLayout ◦
自身の幅と高さを0 ▪ VisibilityがGONEでないため レイアウトされる可能性がある その際に幅と高さを持たないため
Barrier
Barrier • View、ConstraintHelper • Typeを持つだけ ◦ 対象ViewのどこにBarrierを張るか
Barrier • LinearSystemへの追加 ◦ 条件 ▪ LeftとTopの場合はGreaterThan ▪ RightとBottomの場合はLowerThan ◦
strength ▪ match_constraintなWidgetがある場合LOW(1) ▪ match_constraintなWidgetがない場合BARRIER(7)
Placeholder
Placeholder • solver側に対応するクラスがない • updatePostMeasure ◦ contentのvisibilityをVISIBLE →自身のサイズに子Viewのサイズを代入 →contentのvisibilityをGONE ▪
ConstraintWidgetはvisibilityがGONEだとsizeが0 • updatePreLayout ◦ contentにisInPlaceholderフラグを立てる ◦ 自身とcontentのvisibilityをVISIBLE
Placeholderレイアウト • ConstraintLayout#onLayoutにif文 ◦ isInPlaceholderのViewはレイアウトをskip ◦ Placeholderのレイアウト時に 代わりにcontentのViewをレイアウト ◦ 恐らくレイアウトの順番を守るため
▪ 描画の上下関係が崩れないように
Chain
Chain • staticメソッドが2つ ◦ beta3からクラス化、beta2まではOptimizer内にあった • 300行くらいあって複雑!
Chain • ConstraintWidgetContainer#addChildrenToSolverで LinearSystemに数値を追加する最後に Chain.applyChainConstraints(3引数)を呼ぶ • Chain.applyChainConstraints(3引数)では chainそれぞれにChain.applyChainConstraints(5引数)を呼 ぶ
Chain.applyChainConstraints(5引数) 1. chainの要素でwhile文 ◦ LinearSystemに追加 2. chainの端の制約をLinearSystemに追加 3. ConstraintLayoutがwrap_content ◦
chainの端が親をはみ出さない制約を LinearSystemに追加 4. match_constraintなwidget ◦ MATCH_CONSTRAINT_SPREADか MATCH_CONSTRAINT_RAITOの場合は等分にする
Chain.applyChainConstraints(5引数) 5. packed, spread, spreadInsideの処理 • packed or 要素Chainの1個 ◦
先頭の項目を中央揃え(bias考慮)で配置 ◦ packedは1.の時に各要素が隣接するように配置 • spread ◦ Chainの要素を中央寄せで配置 • spreadInside ◦ Chainの端以外の要素を中央寄せで配置 ◦ Chainの端の要素をmarginの位置に配置
