Google Compute Engine and Ansible

Google Compute Engine (GCE) enables developers to build cloud infrastructure networks on a truly massive scale. GCE includes a dedicated API we well as utilities to aid in development and administration as part of the Google Cloud SDK. Ansible is the one of the newest in a number of open source orchestration and configuration management tools that helps in automating not-only the management and orchestration of servers or instances as well as complex configuration management of operating system and application software over SSH. Used in combination Ansible and Google Compute Engine allow you to very quickly build highly detailed and large scale networks of computing resources with minimal human intervention. This talk will demo the initial setup of Ansible on Google Compute Engine as well as demonstrate some sample use cases.

Transcript

1. Sharif Salah Google Developer Expert 2014 Google+ profile @sharif_salah about.me/sharif.salah Google Compute Engine and Ansible
2. Image courtesy of Google/Connie Zhou
3. Agenda Cloud Platform and Compute Engine overview Demo of included tools Walkthrough of setting up Ansible on Compute Engine Resources
4. Compute Compute Engine App Engine
5. Storage Cloud Datastore Cloud Storage Cloud SQL
6. Services Cloud Endpoints BigQuery
7. Compute Engine IaaS Compute, Storage & Network Sub-hour billing Hugely scalable Consistent performance Live migration Automatic restart
8. instance zone region project network firewall load balancer disk
9. Storage Differential snapshots Create a new Persistent Disk based on a snapshot Point in time snapshot stored on Google Cloud Storage Google Cloud Storage globally replicaticated Restore from a snapshot from anywhere in the world
10. Networking TCP, UDP, ICMP only Networks are private to a project Public IP addresses can be static or ephemeral Private IP addresses are ephemeral and with DNS Networks support Firewall rules, VPNs, and IP Forwarding
11. Ansible specific considerations SSH as root is disabled, use sudo instead Google supplies custom NTP configuration See building a Compute Engine image for details
12. & custom kernel support
13. Cloud Console Cloud SDK REST APIs
14. Interfaces demo
15. Why Ansible and Compute Engine? Provision and Orchestrate all layers of your project Deploy complete software stacks to Compute Engine Extend your existing Ansible deployment Move loads in and out of the cloud easily
16. localhost (creates ansible) ansible (creates nodes) Development client (runs Google Cloud SDK) Google Compute Engine SSH
17. Prerequisites Create a Google Cloud Platform project Enable billing for the project Enable the APIs for Google Compute Engine Install the Cloud SDK
18. Localhost steps
19. # list the available images $ gcutil --format=names listimages # add a compute engine instance $ gcutil addinstance ansible \ --image=projects/centos-cloud/global/images/<image-name> \ --machine_type=f1-micro \ --service_account_scopes="https://www.googleapis.com/auth/compute" # prepare a certificate as a PEM file $ openssl pkcs12 -in gce-key.p12 -passin pass:notasecret \ -nodes -nocerts | openssl rsa -out gce-key.pem # push the key to our new instance $ gcutil push ansible gce-key.pem </path/to/home/> # connect to our instance over ssh $ gcutil ssh ansible
20. localhost (creates ansible) ansible (creates nodes) Development client (runs Google Cloud SDK) node1 node2 Google Compute Engine SSH
21. # install and enable the Extra Packages for Enterprise Linux (EPEL) $ wget \ https://anorien.csc.warwick.ac.uk/mirrors/epel/6/i386/epel-release-6-8. noarch.rpm $ sudo rpm -ivh epel-release-6-8.noarch.rpm # install dependencies $ sudo yum -y install python-pip git gcc python-devel $ sudo pip install paramiko PyYAML jinja2 httplib2 # clone and install Apache Libcloud $ git clone https://github.com/apache/libcloud $ cd libcloud; sudo python setup.py install; cd ~ # clone and download ansible $ git clone git://github.com/ansible/ansible.git
22. Environment setup
23. # .bash_profile # Get the aliases and functions if [ -f ~/.bashrc ]; then . ~/.bashrc fi # User specific environment and startup programs PATH=$PATH:$HOME/bin:$HOME/ansible/bin export PATH PYTHONPATH=$HOME/ansible/lib:$HOME export PYTHONPATH ANSIBLE_LIBRARY=$HOME/ansible/library export ANSIBLE_LIBRARY MANPATH=$HOME/ansible/docs/man: export MANPATH ANSIBLE_HOSTS=$HOME/ansible-example/home export ANSIBLE_HOSTS ANSIBLE_HOST_KEY_CHECKING=False export ANSIBLE_HOST_KEY_CHECKING eval $(ssh-agent)
24. Configuration
25. # implement the environment configuration $ source ~/.bash_profile # copy the template secrets file for Apache Libcloud $ cp ~/libcloud/demos/secrets.py-dist secrets.py # identify the name of your Google Cloud Platform project $ gcutil getproject --format=names # edit secrets.py GCE_PARAMS = ('somelongstringofcharachters@developer.gserviceaccount.com', ‘/path/to/file/gce-key.pem') .. GCE_KEYWORD_PARAMS = {'project': 'project-name-123'} # run ssh to generate the necessary keys and add the private identity to the agent $ gcutil ssh ansible date $ ssh-add ~/.ssh/google_compute_engine
26. # download some ansible examples $ git clone git://github.com/sharifsalah/ansible-examples.git # test ansible $ ansible -i ~/ansible-examples/hosts all -m ping # run the playbook $ ansible-playbook -i ~/ansible-examples/hosts -v ~/ansible-examples/gce.yml
27. Sample playbook
28. - name: Create new GCE instances hosts: localhost gather_facts: no vars: names: node1,node2 type: f1-micro image: centos-6 zone: europe-west1-b tasks: - name: Create instances local_action: module: gce instance_names: '{{ names }}' machine_type: '{{ type }}' image: '{{ image }}' zone: '{{ zone }}' register: gce
29. - name: Open port 80 to allow Apache hosts: localhost gather_facts: no tasks: - name: Allow HTTP local_action: module: gce_net name: default allowed: tcp:80 fwname: all-http
30. Resources
32. Google Developer Experts directory Book office hours with a GDE Official Google Cloud Platform Community Stack Overflow
33. These slides: http://goo.gl/LFxFCd Thank you! Any questions?
