Distributed Tracing and Monitoring with OpenTelemetry

OpenTelemetry is an emerging standard for tracing and the metrics of cloud services. You can use it to gain observability into applications that span multiple clouds and technological stacks.

I explain how to use open source and vendor-agnostic client libraries for OpenTelemetry and export telemetry to common APM systems such as Zipkin and others. Along the way, we discuss core concepts such as tags, metrics, exporters, zPages, and trace context propagation.

Transcript

1. Distributed Tracing and Monitoring
   with OpenTelemetry
   Simon Zeltser
   @simon_zeltser


   View Slide

2. Software Evolution
   @simon_zeltser
   On Prem Cloud
   Virtual Machines Containers
   Monolith Microservices
   Single Language / Stack Polyglot
   Single Cloud Multiple Cloud Providers / Hybrid
   Containers Cloud Functions / Serverless


   View Slide

3. New architectures => new challenges
   Debugging
   Observability
   Standardizing development practices
   Deployment / Packaging
   Configuration Management
   Secrets management
   @simon_zeltser


   View Slide

4. Who Am I
   Software Engineer at
   Cloud Developer Experience -
   Infrastructure and Operations Tools
   Over a decade in distributed systems
   observability
   github.com/simonz130
   @simon_zeltser


   View Slide

5. What is Observability?
   Being able to debug the system and gain insights into the
   system’s behavior
   @simon_zeltser


   View Slide

6. Observability > Monitoring
   @simon_zeltser
   Venn diagram by Cindy Sridharan


   View Slide

7. @simon_zeltser


   View Slide

8. Signals
   Holistic Approach:
   - Distributed Tracing
   - Metrics Collection
   - Continuous system profiling
   - Capturing Logs
   @simon_zeltser


   View Slide

9. Ultimate Recipe for reliable cloud service
   Track System Health
   Capture traces, metrics and
   logs, create alerts on data
   Detect Problems
   Locality, networking,
   scheduling, dependencies
   Fix & Refine
   Optimize performance and
   cost of services
   Observability
   Lifecycle
   @simon_zeltser


   View Slide

10. Observability in Distributed Systems
    Hard and Expensive:
    ● Context propagation between
    components
    ● Multiple environments
    ● External dependencies
    ● Vendor Lock-in
    ● Cost
    @simon_zeltser
    Architecture from Hipstershop Demo App


    View Slide

11. Meet OpenTelemetry!
    @simon_zeltser
    OpenTelemetry is integrated set of APIs and libraries
    to generate, collect and describe telemetry in
    distributed systems
    Problems OpenTelemetry solves:
    - Vendor neutrality for tracing, monitoring and
    logging APIs
    - Context propagation


    View Slide

12. OpenTelemetry is:
    ● Single set of APIs for tracing and metrics collection
    ● Integrations with popular web, RPC and storage frameworks
    ● Standardized Context Propagation
    ● Exporters for sending data to backend of choice
    ● Collector for smart traces & metrics aggregation
    @simon_zeltser


    View Slide

13. Next major version of the OpenTracing and OpenCensus projects
    + =


    View Slide

14. Roadmap
    Announcement: https://medium.com/opentracing/merging-opentracing-and-opencensus-f0fe9c7ca6f0
    Roadmap: https://medium.com/opentracing/a-roadmap-to-convergence-b074e5815289


    View Slide

15. Who is behind OpenTelemetry?
    @simon_zeltser
    Core Contributors


    View Slide

16. Metrics with OpenTelemetry


    View Slide

17. Instrumentation with metrics
    View
    Measurement
    Tag
    Measure
    Aggregation
    View Data
    @simon_zeltser


    View Slide

18. Demo
    Getting Started - Metrics collection with OpenTelemetry
    Demo coDE: https://github.com/simonz130/opencensus-csharp-samples
    @simon_zeltser


    View Slide

19. Tracing with OpenTelemetry
    Demo coDE: https://github.com/simonz130/opencensus-csharp-samples
    @simon_zeltser


    View Slide

20. Tracing with OpenTelemetry - the options
    Agentless Using Agent
    Exporter
    Trace
    Backend
    Container/VM
    Application
    Agent
    Trace
    Backend
    Container/VM
    HTTP IN
    HTTP IN
    Traces
    Application
    Initialize exporter in app code Install the agent alongside the app
    @simon_zeltser


    View Slide

21. Tracing with OpenTelemetry - Terminology
    @simon_zeltser
    Trace - a collection of spans
    Span - a single operation in a trace
    Sampler - decide whether to export a span
    Exporter - sending traces to observability systems


    View Slide

22. Configure Exporter
    // Configure exporter to export traces to Zipkin
    var exporter = new ZipkinTraceExporter(
    new ZipkinTraceExporterOptions()
    {
    Endpoint = new Uri(zipkinUri),
    ServiceName = "tracing-to-zipkin-service",
    },
    Tracing.ExportComponent);
    exporter.Start();
    @simon_zeltser


    View Slide

23. Configure Sampler
    // 100% sample rate, otherwise, few traces will be sampled.
    ITraceConfig traceConfig = Tracing.TraceConfig;
    ITraceParams currentConfig = traceConfig.ActiveTraceParams;
    var newConfig = currentConfig.ToBuilder()
    .SetSampler(Samplers.AlwaysSample)
    .Build();
    traceConfig.UpdateActiveTraceParams(newConfig);
    @simon_zeltser


    View Slide

24. Using the Tracer
    // 3. Tracer is global singleton.
    // You can register it via dependency injection if it exists
    // but if not - you can use it as follows:
    var tracer = Tracing.Tracer;
    @simon_zeltser


    View Slide

25. Create a Span
    // Create a scoped span - only covers “using” block
    using (var scope = tracer.SpanBuilder("Main").StartScopedSpan())
    {
    for (int i = 0; i < 10; i++)
    {
    DoWork(i);
    }
    }
    @simon_zeltser


    View Slide

26. Trace Context Propagation
    Frontend
    AdService Checkout
    Payment
    Service
    EmailService
    {context} {context}
    {context} {context}
    Common scenarios
    ● A/B testing
    TraceId=>{context}
    Frontend
    AdService
    Checkout
    Payment Email
    time
    Trace
    Span


    View Slide

27. Trace Context Propagation in OpenTelemetry
    W3C Standard for Context Propagation
    FORMAT: trace-id "-" parent-id "-" trace-flags
    trace-id = 32HEXDIG ; 16 bytes array identifier. All zeroes forbidden
    parent-id = 16HEXDIG ; 8 bytes array identifier. All zeroes forbidden
    trace-flags = 2HEXDIG ; 8 bit flags. Currently only one bit is used (“recorded”)
    Supported in all OpenCensus client libraries, will be supported in OpenTelemetry
    @simon_zeltser


    View Slide

28. OpenCensus Service
    WHAT?
    ● Agent & Collector for metrics
    and traces
    WHY?
    ● Smart Sampling
    ● Export to one or more
    monitoring/tracing backends
    OC Service Repo
    .NET Core OC Agent Repo
    OpenCensus
    Tracing Library
    OpenCensus
    Monitoring Library
    Jaeger
    Zipkin
    Stackdriver
    Prometheus
    AppInsights
    OpenCensus
    Agent
    OpenCensus
    Collector
    OpenCensus Service
    BE Destinations
    @simon_zeltser


    View Slide

29. Traces & Sampling
    Problem: Traced apps can generate many traces with many
    spans
    ● Higher operational costs
    ● Noise
    @simon_zeltser
    Solution: Smart Sampling
    ● Head-based (sampled at the beginning of the trace)
    ● Tail-based (sampled at the end of the trace)


    View Slide

30. DEMO
    Tail-based sampling
    Demo coDE
    @simon_zeltser


    View Slide

31. Architecture
    @simon_zeltser
    Synthetic Load Generator
    simulates traffic to Hipster Shop Demo App
    Checkout
    Synthetic
    Load
    Generator
    OpenCensus
    Service
    (Collector)
    Jaeger 1
    Jaeger 2
    Cassandra
    Cassandra
    Hipster Shop App
    Browse
    Jaeger 1 - head based sampling
    Jaeger 2 - tail based sampling
    Demo repo


    View Slide

32. Integrations
    OpenCensus and OpenTracing are integrated with a wide variety of frameworks, products and libraries.
    It provides observability for the following:
    ● Redis
    ● Memcached
    ● Google Cloud
    ● Dropwizard
    ● SQL
    ● Caddy
    ● Go kit
    ● GroupCache
    ● MongoDB
    @simon_zeltser


    View Slide

33. Community
    OpenTelemetry Website: https://opentelemetry.io
    Specifications: https://github.com/open-telemetry/opentelemetry-specification
    Meetings: https://github.com/open-telemetry/community
    @simon_zeltser


    View Slide

34. Thank you!
    @simon_zeltser
    CONTACT ME:
    zeltser@google.com
    Slides:
    https://speakerdeck.com/simonz130
    Sample Code: https://github.com/simonz130/opencensus-csharp-samples


    View Slide
