Neos.Fusion.Form and how to extend them

Transcript

1. Real Values.
   Neos.Fusion.Forms and how to extend them
   Neos Conference 2023
   Martin Ficzel
   PaperTiger - Oskar Nebelung PaperTiger - Emil Nebelung


   View Slide

2. Real Values.
   Agenda
   Neos.Fusion.Forms
   and how to extend them
   ● Recap Fusion.Form & Runtime
   ● Demo - Sitegeist.PaperTiger
   ● Extension points used


   View Slide

3. Real Values.
   Neos.Fusion.Form
   recap


   View Slide

4. Real Values.
   FusionForm







   View Slide

5. Real Values.
   Runtime Form - one step
   1. renderer = Neos.Fusion.Form:Runtime.RuntimeForm {
   2.
   3. # the form process for rendering and validation
   4. process = Neos.Fusion.Form:Runtime.SingleStepProcess {
   5.
   6.
   # form content
   7.
   content = afx`...`
   8.
   9.
   # type mapping and validation
   10.
   schema = Neos.Fusion.Form:Runtime.SchemaCollection {
   11.
   firstName = …
   12.
   }
   13. }
   14.
   15. # action after the process is finished
   16. action = Neos.Fusion.Form:Runtime.Actions {
   17.
   email = …
   18. }
   1.
   2.
   4.
   5.
   3.


   View Slide

6. Real Values.
   1. renderer = Neos.Fusion.Form:Runtime.RuntimeForm {
   2.
   3. # the form process for rendering and validation
   4. process = Neos.Fusion.Form:Runtime.MultiStepProcess {
   5.
   6.
   step1 = Neos.Fusion.Form:Runtime.SingleStepProcess
   7.
   step2 = Neos.Fusion.Form:Runtime.SingleStepProcess
   8.
   9. }
   10.
   11. # action after the process is finished
   12. action = Neos.Fusion.Form:Runtime.Actions
   13. }
   Runtime Form - multi step
   1.
   2.


   View Slide

7. Real Values.
   1. renderer = Neos.Fusion.Form:Runtime.RuntimeForm {
   2.
   3. # the form process for rendering and validation
   4. process = Neos.Fusion.Form:Runtime.MultiStepProcess {
   5.
   6.
   step1 = Neos.Fusion.Form:Runtime.SingleStepProcess
   7.
   step2 = Neos.Fusion.Form:Runtime.SingleStepProcess
   8.
   9. }
   10.
   11. # action after the process is finished
   12. action = Neos.Fusion.Form:Runtime.Actions
   13. }
   Runtime Form - multi step
   1.
   2.
   ⚠ could be an anti-pattern ⚠


   View Slide

8. Real Values.
   Runtime Form - multi step
   1. renderer = Neos.Fusion.Form:Runtime.RuntimeForm {
   2.
   3. # the form process for rendering and validation
   4. process = Neos.Fusion.Form:Runtime.SingleStepProcess {
   5.
   6.
   # form content
   7.
   content = Vendor.Site:CustomDialogComponent
   8.
   9.
   # type mapping and validation
   10.
   schema = Neos.Fusion.Form:Runtime.SchemaCollection
   11. }
   12.
   13. # action after the process is finished
   14. action = Neos.Fusion.Form:Runtime.Actions
   15. }
   1.


   View Slide

9. Real Values.
   Extensibility

   Fusion
   ● FieldTypes
   ● FieldContainers
   ○ LabelRenderer
   ○ ErrorRenderer
   PHP
   ● ActionInterface
   ● SchemaInterface
   ○ TypeConverterInterface
   ○ ValidatorInterface
   ● ProcessInterface


   View Slide

10. Real Values.
    Documentation
    ● Neos.Demo - Contact Form
    ● docs.neos.io
    ● github.com/neos/fusion-form
    ● Talk @NeosCon online 2021


    View Slide

11. Real Values.
    Sitegeist.PaperTiger
    Form Builder for NeosCMS


    View Slide

12. Real Values.
    NodeBased Forms - prior art
    ● Node Based Form Packages
    ○ Neos.Fusion.Form.Builder (FusionRenderer)
    ○ ...
    ● Challenges
    ○ Generic Contents, Grids and Custom rendering
    ○ Deeply nested nodes and collections


    View Slide

13. Real Values.
    Photo by Karsten Winegear - Unsplash


    View Slide

14. Real Values.


    View Slide

15. Real Values.


    View Slide

16. Real Values.
    More Building
    Blocks!
    Photo by Garett Mizunaka - Unsplash


    View Slide

17. Real Values.
    Form Builder Nodetype
    1. Sitegeist.PaperTiger:Form:
    2. ui:
    3. label: "Form Builder"
    4. icon: 'icon-list-alt'
    5. superTypes:
    6. Neos.Neos:Content: true
    7. childNodes:
    8. fields:
    9.
    # allow Sitegeist.PaperTiger:Field.Constraint
    10.
    type: Sitegeist.PaperTiger:Field.Collection
    11.
    12. actions:
    13.
    # allow Sitegeist.PaperTiger:Action.Constraint
    14.
    type: Sitegeist.PaperTiger:Action.Collection
    1.
    2.


    View Slide

18. Real Values.
    Form Builder Nodetype
    1. prototype(Sitegeist.PaperTiger:Form) < prototype(Neos.Neos:ContentCompone
    2.
    3. renderer = Neos.Fusion.Form:Runtime.RuntimeForm {
    4.
    5. process = Neos.Fusion.Form:Runtime.SingleStepProcess {
    6.
    7.
    # form content
    8.
    content = Sitegeist.PaperTiger:FieldCollection.Renderer
    9.
    10.
    # type mapping and validation
    11.
    schema = Sitegeist.PaperTiger:FieldCollection.Schema
    12. }
    13.
    14. # action after the process is finished
    15. action = Sitegeist.PaperTiger:ActionCollection.Definition
    16. }
    1.
    2.
    3.


    View Slide

19. Real Values.
    1. Generic content in forms
    1. #
    2. # Allow text and image contents inside the form
    3. #
    4. 'Neos.Demo:Content.Text':
    5. superTypes:
    6. 'Sitegeist.PaperTiger:Field.Constraint': true


    View Slide

20. Real Values.
    2. E-Mail Field
    ● NodeType based on Sitegeist.PaperTiger:Field
    ● NodeType:Name - Fusion prototype
    ● NodeType:Name.Schema - Fusion prototype


    View Slide

21. Real Values.
    2. E-Mail Field
    ● NodeType based on Sitegeist.PaperTiger:Field
    ● NodeType:Name.Renderer - Fusion prototype
    ● NodeType:Name.Schema - Fusion prototype
    1. prototype(Sitegeist.PaperTiger:Field.Email) < prototype(Neos.Neos:Cont
    2. …
    3.
    4. renderer = afx`
    5. 6.
    field.name={q(node).property(identifier)}
    7.
    label={q(node).property('label')}
    8. >
    9.
    10.
    attributes.type="email"
    11.
    attributes.required={q(node).property('isRequired')}
    12.
    />
    13.
    14. `
    15. }


    View Slide

22. Real Values.
    2. E-Mail Field
    ● NodeType based on Sitegeist.PaperTiger:Field
    ● NodeType:Name.Renderer - Fusion prototype
    ● NodeType:Name.Schema - Fusion prototype
    1. prototype(Sitegeist.PaperTiger:Field.Email.Schema) < prototype(Neos.Fu
    2. isRequired = ${q(node).property('isRequired')}
    3.
    4. renderer = ${Form.Schema.string().validator('Neos.Flow:EmailAddress
    5. renderer.@process.required = ${props.isRequired ? value.required :
    6. }


    View Slide

23. Real Values.
    2. E-Mail Field
    ● NodeType based on Sitegeist.PaperTiger:Field
    ● NodeType:Name.Renderer - Fusion prototype
    ● NodeType:Name.Schema - Fusion prototype
    1. prototype(Sitegeist.PaperTiger:Field.Email.Schema) < prototype(Neos.Fu
    2. isRequired = ${q(node).property('isRequired')}
    3.
    4. renderer = ${Form.Schema.string().validator('Neos.Flow:EmailAddress
    5. renderer.@process.required = ${props.isRequired ? value.required :
    6. }
    ⚠ fe-validation != be-validation ⚠


    View Slide

24. Real Values.
    3. Message Action
    ● Class implementing ActionInterface
    ● NodeType based on Sitegeist.PaperTiger:Action
    ● NodeType:Name.Preview - Fusion prototype
    ● NodeType:Name.Definition - Fusion prototype


    View Slide

25. Real Values.
    3. Message Action
    ● NodeType based on Sitegeist.PaperTiger:Action
    ● NodeType:Name.Preview - Fusion prototype
    ● NodeType:Name.Definition - Fusion prototype
    1. prototype(Sitegeist.PaperTiger:Action.Message.Preview) < prototype(
    2. message = ${q(node).property('message')}
    3.
    4. renderer = afx`
    5. {props.message}
    6. `
    7. }


    View Slide

26. Real Values.
    ● NodeType based on Sitegeist.PaperTiger:Action
    ● NodeType:Name.Preview - Fusion prototype
    ● NodeType:Name.Definition - Fusion prototype
    3. Message Action
    1. prototype(Sitegeist.PaperTiger:Action.Message.Definition) < prototy
    2. message = ${q(node).property('message')}
    3. message.@process.data = Sitegeist.PaperTiger:Action.DataTemplate
    4.
    5. renderer = Sitegeist.PaperTiger:Action {
    6. type = 'Neos.Fusion.Form.Runtime:Message'
    7. options {
    8.
    message = ${props.message}
    9. }
    10. }
    11. }


    View Slide

27. Real Values.
    even more
    ● Captcha Field
    ○ Sitegeist.FusionForm.FriendlyCaptcha
    ○ FriendlyCaptcha - Fieldtype
    ○ FriendlyCaptchaValidator
    ● Upload Field
    ○ Sitegeist.FusionForm.Upload
    ○ Cache & Multiple support
    ○ Fieldtype / TypeConverter / Validator
    ● E-Mail Action
    ○ Sitegeist.Neos.SymfonyMailer
    ○ SendMailAction


    View Slide

28. Real Values.
    Sitegeist.PaperTiger
    ● Current version 0.30 …
    ● Opinionated and hard to replace
    ● No multisteps forms / No dependencies between fields
    sitegeist/Sitegeist.PaperTiger
    sitegeist/Sitegeist.FusionForm.FriendlyCaptcha
    sitegeist/Sitegeist.FusionForm.Upload
    sitegeist/Sitegeist.Neos.SymfonyMailer


    View Slide

29. Real Values.
    Thank you!
    Slack: @kopfaufholz
    Fediverse: @martin@neos.social
    PaperTiger - Oskar Nebelung
    PaperTiger - Emil Nebelung


    View Slide
