The Vision for the Future of Network Virtualization with VMware NSX (Q2 2016)

This presentation outlines the vision for the future of network virtualization with VMware NSX (updated as of Q2 2016).

Transcript

1. © 2014 VMware Inc. All rights reserved. The Vision for the Future of Network Virtualization with VMware NSX Scott Lowe Engineering Architect NSBU, VMware, Inc.
2. Agenda •  Who is this guy? •  Network virtualization with VMware NSX: the story so far •  Where do we go from here? •  Questions and answers
3. Who is this guy? •  Husband, father, Jeeper, geek •  Engineering Architect in VMware’s Network & Security Business Unit (NSBU) •  Author (7 books so far, 8th book in the works) •  Blogger (11 years at http://blog.scottlowe.org) •  Speaker (VMworld, Interop, OpenStack meetups, VMUG events worldwide) •  Podcaster (The Full Stack Journey podcast) •  Jack of all trades, master of none 3
4. Network virtualization with VMware NSX The story so far
5. NSX customer and business momentum Organizations have spent over US$1M on NSX 100+ NSX Customers 1400+ production deployments (adding 50-90 per quarter) 340+
6. Networking is a software industry
7. Virtual Machines Physical Network Infrastructure Internet Network virtualization with VMware NSX today Virtual machines Physical network infrastructure Internet Virtual infrastructure Application demands •  Many different applications •  Different compliance and security needs •  Frequent change Hardware complexity •  Multiple vendors •  Different architectures •  Multiple locations NSX network virtualization •  Speed and automation •  Agility •  Security and policy
8. Major NSX use cases Intra-Datacenter Micro-Segmentation DMZ Anywhere Secure User Environments Security IT Automating IT Developer Clouds Multi-tenant Infrastructure Agility Disaster Recovery Metro Pooling Hybrid Cloud Networking Application Continuity
9. Where do we go from here?
10. Physical networks and bare- metal workloads
11. Overlay-to-VLAN gateway functionality •  Overlays allow NSX to decouple logical networks from the physical network •  The overlay-to-VLAN gateway allows communication between logical and physical networks Physical Network, VLAN-backed segments VM NSX Logical Network, VXLAN/STT/Geneve tunnels VXLAN ßà VLAN gateway Physical Workload
12. Overlay-to-VLAN gateway form factors VXLAN/STT/ Geneve VLAN x86-based bridge Physical Workloads VXLAN VLAN Physical Workloads Leverages x86 server Highest density and throughput with partner HW HW VTEP
13. Distributed network services
14. Why distributed network services? 14 Scale out of network services Apply services at the vNIC for very granular control Unprecedented visibility
15. NSX vSwitch Tech preview: Distributed load balancing 15 Web Tier App Servers Database Load Balancer Load Balancer Physical View Logical View NSX vSwitch
16. Containers
17. Container networking today 17 Internal App Internal App Website Website Website Website Internet Database Port 80 Internal network
18. Tech preview: Containers with VMware NSX 18 Website Website Website Website Internet Internal network Physical network infrastructure Internal App Internal App Database Data center HONEY POT VULNERABILITY SCANNER Micro- segmentation Alert Connection to data center NSX provides segmentation, visibility, and integration
19. Micro- segmentation Alert Connection to data center Benefits of NSX and containers 19 Micro- segmentation Alert Connection to data center •  Micro-segmentation to establish clear boundaries •  Stop compromises at container or application level •  Central visibility into connectivity across the data center •  Per-flow tracking •  Alerts for suspicious behavior •  Virtual taps at a per- container level •  Integration with the rest of your IT infrastructure •  Monitoring, incident response, forensics •  Access to databases, backup, system updates
20. Public clouds
21. Power of cloud: workload mobility
22. Lock-in through services Storage service Load balancing service Firewall service Storage service Load balancing service Firewall service Storage service Load balancing service Firewall service
23. Cloud: just new silos? Storage service Load balancing service Firewall service Storage service Load balancing service Firewall service Storage service Load balancing service Firewall service
24. NSX Tech preview: VMware NSX on public clouds Storage service Load balancing service Firewall service Storage service Load balancing service Firewall service Storage service Load balancing service Firewall service
25. NSX tomorrow: virtual networking for all platforms Physical network Hyper-V Virtual infrastructure
26. NSX tomorrow: virtual networking for all platforms 26 Speed Provision connectivity for any endpoint across different domains. Agility Automate provisioning via templates and rich APIs. Security Consistent security posture and visibility across all types of endpoints. On-premises data centers Third-generation apps Public clouds Virtual desktops Mobile devices Hyper-V
27. Some additional resources •  Watch Bruce Davie’s VMworld US 2015 session NET4989, “The Future of Network Virtualization with VMware NSX” •  Watch Guido Appenzeller’s VMworld US 2015 spotlight session, “The Next Horizon for Cloud Networking” (video recording available on YouTube at http://www.youtube.com/watch?v=RBJ-KoAM-OQ) •  Tons more VMware NSX content available from VMworld—VMUG Advantage members have access to all this content! •  Learn more about VMware NSX using the VMware Hands-On Labs at http://hol.vmware.com 27
28. Speaking of VMworld… •  Bring your spouse/partner/family/friend with you to VMworld in Las Vegas •  Activities planned throughout the entire conference •  Win prizes, make friends, and have fun •  Will also be available in Barcelona for VMworld EMEA •  http://spousetivities.com/ 28
29. Questions & Answers
30. Thank You! Scott Lowe slowe@vmware.com Twitter: @scott_lowe Blog: http://blog.scottlowe.org GitHub: https://github.com/lowescott Life: Colossians 3:17
