Kubernetes 101

Slides from Google NEXT Extended Singapore event

Transcript

1. Google Container Engine (Kubernetes 101) Google NEXT Extended 2017 Singapore @vincentdesmet
2. @vincentdesmet DevOps - honestbee.sg
3. Applications evolve Reference: http://docker.com Loosely Coupled Services Many Small Servers ~2000 Today Monolithic Big Servers Slow changing Rapidly updated
4. Containers / VMs Infrastructure Container Runtime Interface Bins / Libs Host OS Infrastructure Hypervisor AppA Bins / Libs AppA Guest OS Bins/Libs AppB Guest OS Bins/Libs AppB
5. Docker containers Reference: http://docker.com • Packages up software binaries and dependencies • Isolates software from each other • Container is a standard format • Easily portable across environment • Allows ecosystem to develop around its standard Container
6. Docker Concepts Docker Image The basis of a Docker container Docker Container The standard unit in which the application service resides Docker Engine Creates, ships and runs Docker containers deployable on physical or virtual host locally, in a datacenter or cloud service provider Docker Registry On-premises registry for image storing and collaboration
7. Docker Tools: BUILD, SHIP, RUN
8. KUBERNETES "κυβερνήτης" (kubernetes) is Greek for "pilot" or "helmsman of ship"
9. WHAT IS KUBERNETES? •Container orchestrator •Runs and manages containers •Supports multiple cloud & bare-metal environments •100% Open Source written in Go •Built on decades of experience of running containers at Google •First project hosted by CNCF (Accepted on Mar. 11 2016) Container packaged Dynamically scheduled (Micro) Service oriented
10. PODS & VOLUMES Container Foo Container Bar Namespaces: - Net - IPC - … volumes
11. PODS & VOLUMES volumes
12. LABELS app : my-app role : master track: stable
13. LABELS app : my-app role : master track: stable app : my-app role : worker track: stable app : my-app role : worker track: canary app : my-app role : master track: canary
14. SELECTORS app : my-app app : my-app role : master track: stable app : my-app role : worker track: stable app : my-app role : worker track: canary app : my-app role : master track: canary
15. SELECTORS app : my-app role : worker app : my-app role : master track: stable app : my-app role : worker track: stable app : my-app role : worker track: canary app : my-app role : master track: canary
16. SELECTORS app : my-app track: canary app : my-app role : master track: stable app : my-app role : worker track: stable app : my-app role : worker track: canary app : my-app role : master track: canary
17. CONTROL LOOPS Desired state Actual state pods: - foo - bar pods: - foo
18. CONTROL LOOPS Desired state Actual state pods: - foo - bar pods: - foo create “bar” Create
19. CONTROL LOOPS Desired state Actual state pods: - foo - bar pods: - foo - bar
20. REPLICA SETS + Replica Set: - replicas: 1 - selector: - app: my-app - version: 1.0 - Desired State: - Pod Specification - Replica Count - Label Selector
21. REPLICA SETS + Replica Set: - replicas: 2 - selector: - app: my-app - version: 1.0
22. REPLICA SETS + Replica Set: - replicas: 4 - selector: - app: my-app - version: 1.0
23. SERVICES Service: - nodePort: 30128 - selector: - app: my-app - version: 1.0 - de-couple discovery from application - Define how to access pods - Act as a proxy (Virtual IP - stable for DNS) Think of: - Dynamic Routing Table
24. CANARIES + Replica Set: - replicas: 2 - selector: - app: my-app - version: 1.0 Service: - nodePort: 30128 - selector: - app: my-app + Replica Set: - replicas: 1 - selector: - app: my-app - version: canary Think of: - Partially live the new version
25. DEPLOYMENTS Service: - nodePort: 30128 - selector: - app: my-app + Replica Set: - replicas: 2 - selector: - app: my-app - version: 1.0 + - Manage updates with Deployment resources
26. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + Replica Set: - replicas: 4 - selector: - app: my-app - version: 1.0 + Deployment: - strategy: - rollingUpdate
27. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + + Replica Set: - replicas: 1 - selector: - app: my-app - version: 2.0 Replica Set: - replicas: 4 - selector: - app: my-app - version: 1.0 + Deployment: - strategy: - rollingUpdate
28. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + + Replica Set: - replicas: 1 - selector: - app: my-app - version: 2.0 Replica Set: - replicas: 3 - selector: - app: my-app - version: 1.0 + Deployment: - strategy: - rollingUpdate
29. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + + Replica Set: - replicas: 2 - selector: - app: my-app - version: 2.0 Replica Set: - replicas: 3 - selector: - app: my-app - version: 1.0 + Deployment: - strategy: - rollingUpdate
30. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + + Replica Set: - replicas: 2 - selector: - app: my-app - version: 2.0 Replica Set: - replicas: 2 - selector: - app: my-app - version: 1.0 + Deployment: - strategy: - rollingUpdate
31. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + + Replica Set: - replicas: 3 - selector: - app: my-app - version: 2.0 Replica Set: - replicas: 2 - selector: - app: my-app - version: 1.0 + Deployment: - strategy: - rollingUpdate
32. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + + Replica Set: - replicas: 3 - selector: - app: my-app - version: 2.0 Replica Set: - replicas: 1 - selector: - app: my-app - version: 1.0 + Deployment: - strategy: - rollingUpdate
33. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + Replica Set: - replicas: 4 - selector: - app: my-app - version: 2.0 Replica Set: - replicas: 1 - selector: - app: my-app - version: 1.0 + + Deployment: - strategy: - rollingUpdate
34. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + Replica Set: - replicas: 4 - selector: - app: my-app - Version: 2.0 Replica Set: - replicas: 0 - selector: - app: my-app - version: 1.0 + + Deployment: - strategy: - rollingUpdate
35. UPDATES Service: - nodePort: 30128 - selector: - app: my-app + Replica Set: - replicas: 4 - selector: - app: my-app - Version: 2.0 + Deployment: - strategy: - rollingUpdate
36. CONFIGMAPS Service: - nodePort: 30128 - selector: - app: my-app + + Deployment: - strategy: - rollingUpdate ConfigMap: - sample.yaml: | env: production cache: true max_threads: 8
37. SECRETS Service: - nodePort: 30128 - selector: - app: my-app + + Deployment: - strategy: - rollingUpdate Secret: - sample.yaml: | key: *** db_user: *** db_pw: ***
38. Demo Minikube
39. Getting Started - Free trial cluster - cloud.google.com/container-engine (single node) locally - github.com/kubernetes/minikube - Join www.meetup.com/GCPUGSG/
40. Honestbee We are Hiring DevOps!
41. Thank you!
42. Recap - Multiple resource types - Deployments - Services - ConfigMaps - Secrets - … - Serializable Manifests: Infrastructure as code
43. Overview Concepts: - Containers - Pods - Volumes - Labels & Label Queries - Control Loops & Controllers - Deployment - ReplicaSet - Service
44. Shipping, Deploying & Service Discovery
45. Helm: Package Manager - Collaboration with Google, Bitnami, Deis and others - Deis/Helm -> Kubernetes/Helm - Architecture: - Client: Helm - Server: Tiller - This talk: - Focused on writing charts
46. Helm core values - Aim for the Apt/Yum/Homebrew UX - Ensure collaboration - Reproducible releases - Shareable Packages
47. Chart, Repositories, Releases - Chart: “Package”, “Bundle” - Repository: Package Repository Evolving towards a registry (CoreOS) - Release: Installed Chart (same chart can be installed multiple times)
48. Basic Architecture Client - Server
49. Usage
50. Review using helm - Install charts (creates a release) - helm install - List releases - helm ls - - Bootstrap charts - helm create
51. More features - Upgrade Releases - helm upgrade <release> - Search Charts - helm search - KubeApps.com (Monocular - https://github.com/helm/monocular) - Manage Chart dependencies - requirements.yaml - helm dep up - Helm Plugins - Keybase: helm keybase sign/verify - GitHub: helm github push
52. More info Kubecon talk
