RoboSpice presentation

RoboSpice is an Android Library that makes it easier to write asynchronous network requests. It is production-ready, open sourced and includes a large range of features.

https://github.com/octo-online/robospice

Transcript

1. 1
   © OCTO 2012
   © OCTO 2012
   Download RoboSpice Demo app


   View Slide

2. 2
   © OCTO 2012
   © OCTO 2012
   Asynchronous Network Requests Made Easy
   Co-authors :
   •  Stéphane Nicolas
   •  Jérôme Van Der Linden
   •  Riccardo Ciovatti
   •  Maxence Walbrou
   •  Matthieu Hausherr


   View Slide

3. 3
   © OCTO 2012
   © OCTO 2012
   Presentation plan :
   u 
   Why AsyncTasks are flawed
   u 
   Why loaders don't fit for networking
   u 
   What RoboSpice has to offer


   View Slide

4. 4
   © OCTO 2012
   © OCTO 2012
   Server Side
   Many Mobile Apps are content driven :
   They basically display content delivered through Web services.
   RoboSpice eases writing those network requests.




   Web
   Services
   Network
   Requests
   Data
   Base


   View Slide

5. 5
   © OCTO 2012
   WHY ASYNCTASK ARE FLAWED


   View Slide

6. 6
   © OCTO 2012
   AsyncTask LifeCycle
   AsyncTasks offer :
   • 
   An asynchronous way to execute code.
   • 
   A clean encapsulated way to group
   asynchronous code and callback code.
   • 
   The ability to execute callback code in the
   UI thread (allow to manipulate widgets).
   onPreExecute
   onPostExecute
   onProgressUpdate
   doInBackground


   View Slide

7. 7
   © OCTO 2012





   private  class  GetAllPersonTask  extends  AsyncTask>  {

    @Override
    protected  List  doInBackground(String...  urls)  {
      //long  running  computation  here
      return  dataSourceOrDomainModel.getListPerson(  progressHandler  );
    }

    @Override
    protected  void  onPostExecute(List  result)  {
      //update  your  UI  here
      listPerson.clear();
            listPerson.addAll(result);
            personListAdapter.notifyDataSetChanged();
    }
   }


   View Slide

8. 8
   © OCTO 2012
   Recipe for a memory leak !
   Async
   Task
   Activity
   New
   Activity
   Async
   Task
   AsyncTasks have one BIG trouble :
   They are poorly tied
   to the activity life cycle !
   u 
   An activity can die during asynchronous
   code execution.
   u 
   Callback will be executed even if activity
   is not showing up anymore and any
   attempt to manipulate widgets will crash
   the app or fail, at best.
   → AsyncTask create memory leaks !
   u 
   It is possible to improve the link between
   AsyncTask and Activities, but you need
   a lot of code and caution to achieve this.
   → Loaders to the rescue
   Process


   View Slide

9. 9
   © OCTO 2012
   WHY LOADERS DON’T FIT NETWORKING


   View Slide

10. 10
    © OCTO 2012
    Activity
    Loader Api
    Loaders :
    • 
    handle activities lifecycles
    • 
    monitor data changes
    update UI
    config changes
    create
    reset
    Loaders to the rescue
    Loader
    Manager
    Loader
    Callbacks
    Loader


    View Slide

11. 11
    © OCTO 2012
    public  class  LoaderTestActivity2  extends  ListActivity
     implements  LoaderManager.LoaderCallbacks>  {

     private  Loader>  personLoader;

     @Override
     public  Loader>  onCreateLoader(int  arg0,  Bundle  arg1)  {
             return  personLoader;
     }

     @Override
     public  void  onLoadFinished(Loader>  personLoader,
                     List  result)  {
             listPerson.clear();
             listPerson.addAll(result);
             personListAdapter.notifyDataSetChanged();
     }

     @Override
     public  void  onLoaderReset(Loader>  loader)  {
             listPerson.clear();
             personListAdapter.notifyDataSetChanged();
     }
    //..  loader  follows,  as  an  inner  class


    View Slide

12. 12
    © OCTO 2012
    Public  class  PersonLoader  extends  AsyncTaskLoader>  {

           public  PersonLoader(Context  context)  {
                   super(context);
           }

           @Override
           public  List  loadInBackground()  {
                   return  dataSourceOrDomainModel.getListPerson(  progressHandler  );
           }
    }
    Loaders have been designed for cursors,
    they don't fit when it comes to networking :
    Asynchronous code is too tied to Activity life cycle.
    • 
    Request's result is lost when you leave the Activity.
    • 
    If you leave the Activity, request dies : users MUST wait for result
    • 
    (they can go to other apps but not to other activities within the app).
    • 
    Exception management is left to the dev without any support.
    • 
    And code is a bit bloated by generics...


    View Slide

13. 13
    © OCTO 2012
    THERE IS A BETTER WAY : RoboSpice


    View Slide

14. 14
    © OCTO 2012
    RoboSpice Api
    RoboSpice uses an Android Service to process network requests.
    RoboSpice is designed for asynchronous networking.
    Activity
    Spice
    Manager
    Spice
    Service
    Request
    Listener
    Request
    notify listeners
    update
    UI
    execute
    process


    View Slide

15. 15
    © OCTO 2012
    RoboSpice Api
    RoboSpice causes no memory leaks, it handles Activities life cycles.
    Activity
    Spice
    Manager
    Spice
    Service
    Request
    Listener
    Request
    process
    execute
    RoboSpice takes caution of objects’ life cycles and cleans up memory.
    config
    changes
    Activity 2
    Spice
    Manager 2
    Request
    Listener 2
    notify listeners
    update
    UI


    View Slide

16. 16
    © OCTO 2012
    RoboSpice's Service can be bound from any Android Context :
    requests and results can be accessed from all of them.
    Application
    Service
    Activity
    Activity Fragment
    Spice
    Manager
    Spice
    Manager
    Spice
    Manager
    Spice
    Manager
    Spice
    Manager
    Spice
    Service


    View Slide

17. 17
    © OCTO 2012
    RoboSpice provides automatic caching of request results.
    RoboSpice’s request processing.
    Spice
    Service
    Request
    Already
    in cache ?
    è Yes ! è No !
    process
    request
    save to
    cache
    notify listeners of
    request’s success
    Request
    Listener
    Request
    Listener
    Request
    Listener
    Request
    Listener Request
    Complete
    notify listeners of
    request’s success


    View Slide

18. 18
    © OCTO 2012
    RoboSpice provides robust asynchronous error handling.
    RoboSpice’s request errors management.
    Spice
    Service
    Request
    Listener
    Request
    Already
    in cache ?
    è Yes ! è No !
    process
    request
    notify listeners of
    request’s failure
    Request
    Listener
    Request
    Listener
    Request
    Listener Request
    Complete
    notify listeners of
    request’s success


    View Slide

19. 19
    © OCTO 2012
    public  class  TweeterSpiceActivity  extends  Activity  {

     private  SpiceManager  spiceManager  =
             new  SpiceManager  (  TweeterSpiceService.class  );

     private  TweetRequestListener  listener  =  new  TweetRequestListener();

     @Override
     protected  void  onStart()  {
                   super.onStart();
                   spiceManager.start(  this  );
     }

     @Override
     protected  void  onStop()  {
                   spiceManager.shouldStop();
                   super.onStop();
     }

     public  void  startDemo()  {
                   spiceManager.execute(new  TweetRequest(),  "tweets",
       DurationInMillis.ONE_MINUTE  *  10,  listener  );
     }


    View Slide

20. 20
    © OCTO 2012






       @Override
           protected  void  onStart()  {
                   super.onStart();
                   spiceManager.start(  this  );
                   spiceManager.addListenerIfPending(  ListTweets.class,
                         "tweets",
                         listener  );
                   spiceManager.getFromCache(  ListTweets.class,
                     "tweets“,

       DurationInMillis.ALWAYS  ,
                     listener  );
           }








    View Slide

21. 21
    © OCTO 2012
    public  class  TweetRequest  extends  RestSpiceRequest<  ListTweets  >  {

           public  TweetRequest()  {
                   super(  ListTweets.class  );
           }

           @Override
           public  ListTweets  loadDataFromNetwork()  throws  Exception  {
                   return  getRestTemplate().getForObject(
                                 "http://search.twitter.com/search.json?q=android&rpp=20",
             ListTweets.class  );
           }
    }


    View Slide

22. 22
    © OCTO 2012

    private  class  TweetRequestListener  implements  RequestListener<  ListTweets  >,
    RequestProgressListener  {

     @Override
     public  void  onRequestFailure(  SpiceException  exception)  {
     Toast.makeText(  TweeterSpiceActivity.this,  "Failed  to  load  Twitter  data.",
                   Toast.LENGTH_SHORT  ).show();
     }

     @Override
     public  void  onRequestSuccess(  ListTweets  listTweets  )  {
       mAdapter.clear();
       for  (  Tweet  tweet  :  listTweets.getResults()  )  {
         mAdapter.add(  tweet.getText()  );
       }
       mAdapter.notifyDataSetChanged();
     }

     @Override
     public  void  onRequestProgressUpdate(  RequestProgress  progress  )  {
       String  status  =  convertProgressToString(  progress  );
       textViewProgress.setText(  status  );
     }
    }


    View Slide

23. 23
    © OCTO 2012
    RoboSpice is an Open Source Library that eases writing asynchronous network
    requests. It executes requests inside an Android Service.
    It provides transparent caching.
    It supports REST out of the box, using Spring Android.
    RoboSpice features
    A FULLY OBJECT ORIENTED API
    POJOs are used to send requests parameters
    POJOs are used to receive request results
    There is no restriction on POJO classes used
    There is no need to implement Serializable or
    Parcelable.
    NO MEMORY LEAK, OPTIMAL RESOURCE USAGE
    Activity / Service life cycles are fully managed
    There is no memory leak at all
    Requests are not lost when sender dies
    Requests results are never lost when sender
    dies
    AUTOMATIC CACHING OF REQUESTS RESULTS
    Caching is fully automatic
    Supports various formats : XML, JSON, ORM
    Lite, Text Strings, Binary data
    EASY TO USE
    Listeners’ methods are invoked on UI Thread
    Intuitive API
    Ease writing integration tests
    Documentated
    Available on Maven Central
    Available on GitHub : http://goo.gl/lw5C7


    View Slide

24. 24
    © OCTO 2012
    Any questions ??
    Or comments !!


    View Slide

25. 25
    © OCTO 2012

    public  class  TweeterSpiceService  extends  SpringAndroidSpiceService  {

           @Override
           public  int  getThreadCount()  {
                   return  3;
           }

           @Override
           public  CacheManager  createCacheManager(  Application  application  )  {
                   CacheManager  cacheManager  =  new  CacheManager();
             //  customize  your  cache  manager  here
       return  cacheManager;
           }

           @Override
           public  RestTemplate  createRestTemplate()  {
                   RestTemplate  restTemplate  =  new  RestTemplate();
                   //  customize  your  rest  template  here
                   restTemplate.setMessageConverters(  listHttpMessageConverters  );
                   return  restTemplate;
           }
    }


    View Slide
