  1. best OpenSystems Day Mai 2011 Unterföhring Wolfgang Stief [email protected] Senior

    Systemingenieur best Systeme GmbH GUUG Board Member IBM Storwize V7000 Storage virtualisiert
  2. Was es ist. Wie es aussieht. Was es kann. Was

    es kostet. Agenda 2011-05-11 2 / 25
  3. (Midrange) Storage-System → RAID 0, 1, 5, 6, 10 →

    SAS / Nearline SAS (=SATA) / SSD → 8Gb/s FC oder 1Gb/s iSCSI → erweiterbar Virtualisierung auf Storage-Layer → Thin Provisioning → Flash Copy → Metro / Global Mirror → Easy Tiering → Data Migration / External Virtualization schickes GUI → CLI möglich (Scripting) V7000 – just another storage system? 2011-05-11 3 / 25
  4. Was es ist. Wie es aussieht. Was es kann. Was

    es kostet. Agenda 2011-05-11 4 / 25
  5. V7000 – Erweiterung 2011-05-11 zwei SCSI-Chains, je 5 Enclosures Control

    Enclosure zählt mit max. 9 Expansion Enclosures SAS/SATA Enclosures beliebig mischbar 7 / 25
  6. Was es ist. Wie es aussieht. Was es kann. Was

    es kostet. Agenda 2011-05-11 8 / 25
  7. V7000 Software Architektur SVC v5.1 Software → identisch zw. V7000

    und SVC DS8000 Device Adapter Code → RAID-Code → Easy Tiering GUI von XIV neu in SVC v6.1/V7000 identisch zw. SVC und V7000: → Host Interface → Virtualisierung → Copy Services 2011-05-11 9 / 25
  8. V7000 Software Features Thin Provisioning Volume Mirroring auch über virtualisiertes

    Storage Flash Copy full/increment, multitarget, cascaded, reverse, consistency groups Metro Mirror synchroner Spiegel bis 300km Global Mirror asynchroner Spiegel bis ca. 8.000km Data Migration bzw. Virtualisierung von 3rd Party Storage Easy Tier 2011-05-11 10 / 25
  9. V7000 Easy Tiering – Performance IBM Whitepaper Performance benefits of

    IBM Storwize V7000 with Easy Tier for Oracle 11g workload http://www-03.ibm.com/support/techdocs/atsmastr.nsf/WebIndex/WP101838 V7000 → 32x 300GB 10k SAS (4x8xRAID10) → 6x 300GB E-MLC SSD (3x2xRAID10) → daraus 4 Volumes á 500GB → alles „performance optimized“ → keine Hot Spares Vdbench (5.0.2) http://sourceforge.net/projects/vdbench/ Oracle ORION (11.1.0.7.0) http://www.oracle.com/technetwork/topics/index-089595.html 2011-05-11 19 / 25
  10. V7000 Easy Tiering – Performance vdbench, 100% random read 3720

    IOPS → 5640 IOPS (1.51x) 8.63 ms → 4.85 ms (1.78x) vdbench 70/30 rd/wr 4000 IOPS → 5414 IOPS (1.35x) 8.00 ms → 3.88 ms (2.06x) vdbench 50/50 rd/wr 4342 IOPS → 5000 IOPS (1,15) 7.39 ms→ 3.00 ms (2.46) ORION, 21 outstanding I/O 6109 IOPS → 10.713 IOPS (1.75x) 13.09 ms → 7.47 ms (1.75x) Preis-/Leistung!? 2011-05-11 20 / 25
  11. V7000 Latest News – The Register, 2011-05-10 neue Software v6.2

    → Clustering von zwei Control Enclosures → doppelte Kapazität (480TB) → realtime performance monitoring → Flash Copy mit Remote Mirror Volumes (ähnlich DS8000) 10 Gb/s Ethernet → bis 700% schnelleres iSCSI → Upgrade für bestehende Controller möglich 146GB 15k SAS-Disks Support für VMware vStorage API for Array Integration → „offload“ Storage-Arbeit (Snapshots, Clones) neue externe Storage-Systme: EMC VNX, HDS VSP, HP P9500, Texas Memory RamSan-620 GA im Juni 2011 2011-05-11 21 / 25
  12. Was es ist. Wie es aussieht. Was es kann. Was

    es kostet. Agenda 2011-05-11 22 / 25
  13. V7000 Lizensierung 2011-05-11 License Type Unit Required? Enclosure Grundeinheit und

    Anzahl Expansion Enclosures ja External Virtualization Anzahl physischer Enclosures je externes Storage optional Remote Mirror Anzahl physischer Enclosures optional Flashcopy – included Volume Mirroring – included Thin Provisioning – included Volume Migration – included (45 Tage) Easy Tier – included 23 / 25
  14. IBM Redbook Implementing the IBM Storwize V7000 http://www.redbooks.ibm.com/redpieces/abstracts/sg247938.html?Open IBM Storwize

    V7000 Midrange Disk System http://www-03.ibm.com/systems/storage/disk/storwize_v7000/ weitere Details 2011-05-11 24 / 25
  15. best OpenSystems Day Mai 2011 Unterföhring Wolfgang Stief [email protected] Senior

    Systemingenieur best Systeme GmbH GUUG Board Member Danke für die Aufmerksamkeit. Fragen?
  16. V7000 Easy Tiering – Performance 2011-05-11 Appendix 1 Easy Tier

    IOPS Faktor latency [ms] Faktor vdbench 100% random read on 3.720 → 5.640 1,52 8,63 → 4,85 1,78 vdbench 70/30 read/write on 4.000 → 5.414 1,35 8,00 → 3,88 2.06 vdbench 50/50 read/write on 4.342 → 5.000 1,15 7,39 → 3.00 2,46 ORION 21 outstanding I/O off 6.109 1,75 13,09 1,75 ORION 21 outstanding I/O on 10.713 7,47
  17. V7000 Preisbeispiel (Listpreise) V7000, 22x 600GB SAS, 2x 300GB SSD

    ~ 75.000€ → Controller: 24.300 € → Disks (10k): 31.900 € → SSDs (E-MLC): 37.500 € SAS Enclosure mit 24x 600GB SAS ~ 57.400€ → Enclosure (leer): 5.800 € → Disks (10k): 34.800 € → Software Lizenz: 16.800 € SATA-Enclosure mit 12x 2TB ~ 38.800€ → Enclosure (leer): 5.800 € → Disks (7.2k): 16.200 € → Software Lizenz: 16.800 € External Virtualization Software v6.1 ~ 8.500€ → je externes Shelf 2011-05-11 Appendix 2
