Doing Background Tasks the Right Way

With the large variety of options that Android provides to perform background tasks, developers can get confused on the right way to do background work for their use case. In this talk, I discuss the various ways of doing background work on Android, the challenges various OS versions introduces and the most effective way to perform tasks for various specific use cases.

Transcript

1. Doing Background Tasks the
   Right Way
   Subhrajyoti Sen / @iamsubhrajyoti
   smallcase


   View Slide

2. The Main Thread


   View Slide

3. The Main Thread
   ●
   Default thread that apps start on


   View Slide

4. The Main Thread
   ●
   Default thread that apps start on
   ●
   Known as the UI thread


   View Slide

5. The Main Thread
   ●
   Default thread that apps start on
   ●
   Known as the UI thread
   ●
   Changes to android.view and android.widget need to happen
   to this thread


   View Slide

6. The Main Thread
   ●
   Default thread that apps start on
   ●
   Known as the UI thread
   ●
   Changes to android.view and android.widget need to happen
   to this thread
   ●
   Responsible for dispatching touch events


   View Slide

7. The Main Thread
   ●
   Default thread that apps start on
   ●
   Known as the UI thread
   ●
   Changes to android.view and android.widget need to happen
   to this thread
   ●
   Responsible for dispatching touch events
   ●
   Lifecycle callbacks happen on this thread


   View Slide

8. The Main Thread is Precious


   View Slide

9. The Main Thread is Precious
   ●
   Refreshed at a regular interval


   View Slide

10. The Main Thread is Precious
    ●
    Refreshed at a regular interval
    ●
    Should be never blocked


    View Slide

11. The Main Thread is Precious
    ●
    Refreshed at a regular interval
    ●
    Should be never blocked
    ●
    Any operation longer than a few milliseconds should not take
    place on the Main Thread


    View Slide

12. The Main Thread is Precious
    ●
    Refreshed at a regular interval
    ●
    Should be never blocked
    ●
    Any operation longer than a few milliseconds should not take
    place on the Main Thread
    Or else...


    View Slide

13. View Slide

14. The Solution


    View Slide

15. The Solution
    Do work in the background


    View Slide

16. The Solution
    Do work in the background
    When the user is
    using the app


    View Slide

17. The Solution
    Do work in the background
    When the user is
    using the app
    When the user is not
    using the app


    View Slide

18. Why is background work challenging?


    View Slide

19. A process is not forever
    - Keith Smith


    View Slide

20. The Process Priority Table


    View Slide

21. The Process Priority Table
    1. Native


    View Slide

22. The Process Priority Table
    1. Native
    2. System


    View Slide

23. The Process Priority Table
    1. Native
    2. System
    3. Persistent Apps


    View Slide

24. The Process Priority Table
    1. Native
    2. System
    3. Persistent Apps
    4. Foreground Apps


    View Slide

25. The Process Priority Table
    1. Native
    2. System
    3. Persistent Apps
    4. Foreground Apps
    5. Perceptible Apps


    View Slide

26. The Process Priority Table
    1. Native
    2. System
    3. Persistent Apps
    4. Foreground Apps
    5. Perceptible Apps
    6. Service


    View Slide

27. The Process Priority Table
    1. Native
    2. System
    3. Persistent Apps
    4. Foreground Apps
    5. Perceptible Apps
    6. Service
    7. Home


    View Slide

28. The Process Priority Table
    1. Native
    2. System
    3. Persistent Apps
    4. Foreground Apps
    5. Perceptible Apps
    6. Service
    7. Home
    8. Previous App


    View Slide

29. The Process Priority Table
    1. Native
    2. System
    3. Persistent Apps
    4. Foreground Apps
    5. Perceptible Apps
    6. Service
    7. Home
    8. Previous App
    9. Cached Apps


    View Slide

30. Solutions by Android


    View Slide

31. Solutions by Android
    AsyncTask
    Coroutines
    RxJava
    AlarmManager
    Foreground Service
    Loader
    Thread and Handler
    Intent Service
    WorkManager Job Scheduler


    View Slide

32. So many solutions!!!



    View Slide

33. BUT WHY



    View Slide

34. Changes Introduced in the OS


    View Slide

35. Changes Introduced in the OS
    Android 6.0 introduced Doze
    Source: developer.android.com


    View Slide

36. Changes Introduced in the OS
    ●
    Android 7.0 introduced Doze on the Go


    View Slide

37. Changes Introduced in the OS
    ●
    Android 7.0 introduced Doze on the Go
    ●
    Android 8.0 introduced
    ○
    Background Service Limitations
    ○
    Broadcast Limitations


    View Slide

38. Changes Introduced in the OS
    ●
    Android 7.0 introduced Doze on the Go
    ●
    Android 8.0 introduced
    ○
    Background Service Limitations
    ○
    Broadcast Limitations
    ●
    Android 9.0 introduced App Standy Buckets


    View Slide

39. App Standby Buckets


    View Slide

40. App Standby Buckets
    ●
    Use machine learning to determine how likely each app will be
    used.


    View Slide

41. App Standby Buckets
    ●
    Use machine learning to determine how likely each app will be
    used.
    ●
    Places app in one of 5 priority buckets


    View Slide

42. App Standby Buckets
    ●
    Use machine learning to determine how likely each app will be
    used.
    ●
    Places app in one of 5 priority buckets
    ○
    Active
    ○
    Working Set
    ○
    Frequent
    ○
    Rare
    ○
    Never


    View Slide

43. The “Not Recommended” Solutions


    View Slide

44. AsyncTask


    View Slide

45. AsyncTask
    ●
    Does not auto-cancel when Activity/Fragment is
    destroyed/recreated


    View Slide

46. AsyncTask
    ●
    Does not auto-cancel when Activity/Fragment is
    destroyed/recreated
    ●
    Can lead to memory leaks


    View Slide

47. AsyncTask
    ●
    Does not auto-cancel when Activity/Fragment is
    destroyed/recreated
    ●
    Can lead to memory leaks
    ●
    Not really easy to cancel


    View Slide

48. AsyncTask
    ●
    Does not auto-cancel when Activity/Fragment is
    destroyed/recreated
    ●
    Can lead to memory leaks
    ●
    Not really easy to cancel
    ●
    Can be executed only once


    View Slide

49. AsyncTask
    ●
    Does not auto-cancel when Activity/Fragment is
    destroyed/recreated
    ●
    Can lead to memory leaks
    ●
    Not really easy to cancel
    ●
    Can be executed only once
    ●
    Please do not use it


    View Slide

50. AsyncTask
    ●
    Does not auto-cancel when Activity/Fragment is
    destroyed/recreated
    ●
    Can lead to memory leaks
    ●
    Not really easy to cancel
    ●
    Can be executed only once
    ●
    Please do not use it
    Recommended Read: The Hidden Pitfalls of AsyncTask by Dan Lew


    View Slide

51. Quiz 1:
    What feature of Android Pie did I mention that
    intelligently prioritizes apps?


    View Slide

52. Quiz 2:
    Name any 3 buckets from the App Standy
    Buckets


    View Slide

53. Loaders


    View Slide

54. Loaders
    ●
    Deprecated on Android P (API 28)


    View Slide

55. Loaders
    ●
    Deprecated on Android P (API 28)
    ●
    Confusing API


    View Slide

56. Loaders
    ●
    Deprecated on Android P (API 28)
    ●
    Confusing API
    ●
    Can be unpredictable


    View Slide

57. Loaders
    ●
    Deprecated on Android P (API 28)
    ●
    Confusing API
    ●
    Can be unpredictable
    Recommended way of replacing Loaders is a combination of
    ViewModel and LiveData


    View Slide

58. The “Recommended” Solutions


    View Slide

59. DownloadManager


    View Slide

60. DownloadManager
    ●
    Perform long-running HTTP downloads


    View Slide

61. DownloadManager
    ●
    Perform long-running HTTP downloads
    ●
    Handles HTTP interaction


    View Slide

62. DownloadManager
    ●
    Perform long-running HTTP downloads
    ●
    Handles HTTP interaction
    ●
    Retry on failure


    View Slide

63. DownloadManager
    ●
    Perform long-running HTTP downloads
    ●
    Handles HTTP interaction
    ●
    Retry on failure
    ●
    Continuation after reboot


    View Slide

64. DownloadManager
    ●
    Perform long-running HTTP downloads
    ●
    Handles HTTP interaction
    ●
    Retry on failure
    ●
    Continuation after reboot
    ●
    Handles connectivity changes


    View Slide

65. DownloadManager
    ●
    Perform long-running HTTP downloads
    ●
    Handles HTTP interaction
    ●
    Retry on failure
    ●
    Continuation after reboot
    ●
    Handles connectivity changes
    ●
    Notifies user of progress updates


    View Slide

66. DownloadManager
    ●
    Perform long-running HTTP downloads
    ●
    Handles HTTP interaction
    ●
    Retry on failure
    ●
    Continuation after reboot
    ●
    Handles connectivity changes
    ●
    Notifies user of progress updates
    Use case: download a PDF report


    View Slide

67. Quiz 3:
    Which API level was Loader deprecated in?


    View Slide

68. Quiz 4:
    What should you use to replace Loader?


    View Slide

69. Foreground Services


    View Slide

70. Foreground Services
    ●
    High priority is the process ranking system.


    View Slide

71. Foreground Services
    ●
    High priority is the process ranking system.
    ●
    Non-dismissible notification


    View Slide

72. Foreground Services
    ●
    High priority is the process ranking system.
    ●
    Non-dismissible notification
    ●
    Should be used for immediate, important tasks


    View Slide

73. Foreground Services
    ●
    High priority is the process ranking system.
    ●
    Non-dismissible notification
    ●
    Should be used for immediate, important tasks
    ●
    Should have well defined start and finish


    View Slide

74. Foreground Services
    ●
    High priority is the process ranking system.
    ●
    Non-dismissible notification
    ●
    Should be used for immediate, important tasks
    ●
    Should have well defined start and finish
    Use case: Playing music, high-accuracy location tracking (WhatsApp
    live location sharing)


    View Slide

75. Quiz 5:
    What would be the priority rank of Foreground
    Service in the Process Priority Table?


    View Slide

76. AlarmManager


    View Slide

77. AlarmManager
    ●
    Schedule tasks at a particular time


    View Slide

78. AlarmManager
    ●
    Schedule tasks at a particular time
    ●
    Schedule tasks to execute at intervals


    View Slide

79. AlarmManager
    ●
    Schedule tasks at a particular time
    ●
    Schedule tasks to execute at intervals
    ●
    Available since API 1


    View Slide

80. AlarmManager
    ●
    Schedule tasks at a particular time
    ●
    Schedule tasks to execute at intervals
    ●
    Available since API 1
    Gotchas:


    View Slide

81. AlarmManager
    ●
    Schedule tasks at a particular time
    ●
    Schedule tasks to execute at intervals
    ●
    Available since API 1
    Gotchas:
    ●
    Alarms reset after phone reboot


    View Slide

82. AlarmManager
    ●
    Schedule tasks at a particular time
    ●
    Schedule tasks to execute at intervals
    ●
    Available since API 1
    Gotchas:
    ●
    Alarms reset after phone reboot
    ●
    Alarms reset is system time is changed


    View Slide

83. AlarmManager
    ●
    Schedule tasks at a particular time
    ●
    Schedule tasks to execute at intervals
    ●
    Available since API 1
    Gotchas:
    ●
    Alarms reset after phone reboot
    ●
    Alarms reset is system time is changed
    Use case: WhatsApp chat backup at 2AM


    View Slide

84. Quiz 6:
    Whose blog post did I mention for AsyncTask?


    View Slide

85. JobScheduler


    View Slide

86. JobScheduler
    ●
    Available only on API 23+


    View Slide

87. JobScheduler
    ●
    Available only on API 23+
    ●
    Framework intelligently schedules and batches tasks


    View Slide

88. JobScheduler
    ●
    Available only on API 23+
    ●
    Framework intelligently schedules and batches tasks
    ●
    You can specify conditions for execution


    View Slide

89. JobScheduler
    ●
    Available only on API 23+
    ●
    Framework intelligently schedules and batches it
    ●
    You can specify conditions for execution
    ●
    System holds a wakelock to ensure the device is awake till job
    completion


    View Slide

90. JobScheduler
    ●
    Available only on API 23+
    ●
    Framework intelligently schedules and batches it
    ●
    You can specify conditions for execution
    ●
    System holds a wakelock to ensure the device is awake till job
    completion
    Use case: backup data when WiFi is available


    View Slide

91. WorkManager


    View Slide

92. WorkManager
    ●
    Provides guarantee that job will be executed


    View Slide

93. WorkManager
    ●
    Provides guarantee that job will be executed
    ●
    Backward compatible till API 14


    View Slide

94. WorkManager
    ●
    Provides guarantee that job will be executed
    ●
    Backward compatible till API 14
    ●
    Survives app or phone restart


    View Slide

95. WorkManager
    ●
    Provides guarantee that job will be executed
    ●
    Backward compatible till API 14
    ●
    Survives app or phone restart
    ●
    Allows chaining tasks in different ways


    View Slide

96. WorkManager
    ●
    Provides guarantee that job will be executed
    ●
    Backward compatible till API 14
    ●
    Survives app or phone restart
    ●
    Allows chaining tasks in different ways
    ●
    Should only be used for jobs are not immediate and can be
    executed at a later time


    View Slide

97. WorkManager
    ●
    Provides guarantee that job will be executed
    ●
    Backward compatible till API 14
    ●
    Survives app or phone restart
    ●
    Allows chaining tasks in different ways
    ●
    Should only be used for jobs are not immediate and can be
    executed at a later time
    Use case: sending analytics logs to a server


    View Slide

98. Guidelines


    View Slide

99. Guidelines
    1. Is the work immediate?


    View Slide

100. Guidelines
     1. Is the work immediate?
     2. Does it depend on system conditions?


     View Slide

101. Guidelines
     1. Is the work immediate?
     2. Does it depend on system conditions?
     3. Does it have to happen at a specific time?


     View Slide

102. Quiz 7:
     What is the title of this talk?


     View Slide

103. Thank You...
     @iamsubhrajyoti @SubhrajyotiSen


     View Slide
